Duemmegi Contatto ModKB User manual

Contatto
ModKB
ModKB: Module for PIN code access control
ModKB module has been specially developed for the con-
nection to third-party numerical keypads using WIEGA D
standard protocol.
ModKB module interfaces, through MCP XT controller, to
the well tested Contatto world, thus integrating it with an
easy to use PI code based access control system. The
main features are the following:
•2 generic Contatto inputs
•1 relay output for electrical door lock control
•2 LED outputs for OK and OK codes
•WIEGA D 32 or 26 protocol (SITE code and PI )
•programmable pulse duration on door lock relay
•“SITE code” management for keypad identification
•PI code management
•up to 30 different PI codes can be defined and stored
•for each PI it is possible to define the days of the
week during which the access is granted
•for each PI it is possible to define up to 2 time slots
during which the access is granted (provided that the
access occurs during one of the allowed days)
•the module takes 1 input address reporting on the bus
the entered PI code, the status of the generic inputs
and other information for diagnostic
•the module takes 1 optional output address allowing to
separately lock each one of the 30 PI codes and to
drive the relay
ModKB module features a 12-way removable terminal
block for the connection to the keypad (not provided), to the
generic inputs and to the LEDs reporting the granted or
denied access information. The normally opened contact of
the internal relay of ModKB is available on a separated 2-
way removable terminal block, allowing the connection to
the electrical door lock or similar devices.
An additional 5-way removable terminal block allows the
connection to the Contatto bus.
ModKB module housing is a reduced-height 3 modules box
for DI rail mounting.
Operation
ModKB module allows the access control through the en-
tering by the user, on a keypad, of one of the 30 codes pre-
viously stored in the module.
ModKB is compatible with keypads having serial WIE-
GA D protocol; the data transmitted by the keypad is
made by the SITE code (identifying the keypad) and the
PI code. The SITE code is a 16-bit number for WIEGA D
32 and it is a 8-bit number for WIEGA D 26; in both cases
the PI code is a 16-bit number.
The SITE code must be set in the keypad during the setting
up of the plant using the procedure defined by the manu-
facturer of the keypad.
Since the PI code is a 16-bit number, then it will be in the
range 00001 e 65535.
The module can be set to recognize up to 30 different PI
codes, for instance each one related to different categories
of personnel; if the entered code corresponds to one of the
stored 30 ones, ModKB will check if the access has been
required in a allowed day and in an allowed time slot. The
time slots that can be set for each PI code are two and,
once set, they are valid for each allowed day of the week.
All evaluations for deciding if the entered PI code is valid
will be fully executed by ModKB module; the control of the
electrical door lock (or similar devices) will be also automat-
ically performed by the module itself.
In this way, the Contatto MCP XT controller does not need
any specific programming, thus drastically reducing the
times needed for the development and the setting up of the
access control system. In this way, therefore, the operation
of the access control system is guaranteed also in case of
temporary failure of the bus.
It is however possible to set ModKB module in order to it
does not take autonomous decisions, thus leaving the
management of the access to MCP XT controller or to the
supervisor of the system; in this case ModKB module will
be limited to transmit on the bus the entered OI code.
Address programming
ModKB module takes one 4-channel / 16-bit input address ;
as option, one 1-channel / 16-bit output address can be ac-
tivated in order to executed some commands as will be de-
scribed in the following.
The input and output addresses are equal each one to the
other, so only a base address is needed; this one must be
assigned by FXPRO programmer.
Digital inputs
ModKB module features 2 Contatto generic digital inputs,
which can be therefore used for the connection to potential-
free contacts supplied by the module itself.
These two inputs can be separately configured both for O
and C logic during the setting up.
DUEMMEGI s.r.l. - Via Longhena, 4 - 20139 MILA O
Tel. [phone] - Fax [phone] – www.duemmegi.it
Rel.: 1.1 July 2012 Page 1 of 6
HOME AND BUILDIN AUTOMATION

Contatto
ModKB
Installation
The wiring diagram in Figure 1 shows the connection to be
executed between ModKB module and the bus, the
keypad, the electrical door lock, the input contacts and the
optional LEDs. For details about the connection of the third
party keypad refer to the manufacturer technical sheet.
ModKB module features a green LED near to the bus ter-
minal lock, lighted when the module is properly supplied.
The contacts connected to the inputs in Figure 1 are O
type only to give an example, being possible to configure
each input according to the desired O/ C logic (see in the
following pages of this manual).
The following table gives some hints about the section of
the wires to be used for the connections and the suggested
maximum length.
Connection Suggested wire
Bus 4 x 2.5 mmq not shielded
Inputs 0.5 mmq, MAX 25mt
LEDs 0.22 mmq, MAX 25mt
Door lock 0.5 mmq
Keypad 5 x 0.5mmq, MAX 15mt
Method for the access control
The access control is based on the entering of a PI code
through the keypad.
The check of the entered PI code, executed by ModKB
module, is performed according to the rules described in
the following.
The PI codes to be enabled (up to 30) can be freely
defined during the setting up and transferred to the memory
of ModKB through the Contatto bus.
The first 8 or 16 bits (depending WIEGA D 26 or 32 re-
spectively has been chosen) transmitted by the keypad cor-
responds to the SITE code set on the keypad itself; this
code uniquely identifies the keypad connected to a given
ModKB module. The next transmitted 16 bits corresponds
to the entered PI code, thus making a number in the
range 00001 to 65535.
ModKB module features a non-volatile memory containing
30 blocks of information, each one related to a different
PI code that must be granted; the same SITE code set in
the keypad must be stored in the ModKB memory too.
DUEMMEGI s.r.l. - Via Longhena, 4 - 20139 MILA O
Tel. [phone] - Fax [phone] – www.duemmegi.it
Rel.: 1.1 July 2012 Page 2 of 6
Figure 1: Connection diagram
+24V
BUS
0V
L1
L2
Ve
DOOR
LOCK
21 22 23 24 25 26 27 28 29 30 31 32
ON
Contatto
DUEMMEGI
MILA O-ITALY
ADDRESS
+24V
0V L1
L2
P
13 14 16 1715
Access controller
Power supply 24V= ±25% / 40mA
MODKB
1 2
KB
I1 I2 C O1 O2 C12V LD D1 D0 C
1 2 3
4 5 6
7 8 9
* 0 #
HOME AND BUILDIN AUTOMATION
Relationship
terminals ↔ keypad:
21 ↔ 12V for keypad
22 ↔ keypad LED control
23 ↔ do not connect
24 ↔ Wiegand data '1'
25 ↔ Wiegand data '0'
26 ↔ common
O1 = code OK
O2 = code NOK

Contatto
ModKB
When the ModKB receives a message from the keyboard,
it verifies that the SITE code is correct, then verifies that
the entered PI code is one of those stored; if everything
matches, before allowing access, ModKB module also
evaluates the following parameters related to that PI :
•the day of the week when the access is allowed
•the two time slots when the access is allowed
If all the listed conditions have satisfied, then the ModKB
module generates a pulse on the relay in order to activate
the electrical door lock or other similar device.
Moreover, whether those conditions have been satisfied or
not, ModKB will send on the bus some information related
to the recognized PI as described below.
Information from and to ModKB module
ModKB module takes, inside the Contatto system, one in-
put and one (optional) output address with the same value.
The output address, if it is not needed, can be disabled dur-
ing the setting up.
Input section
The input address provides four 16-bit channels, used as
described in the following.
Input channel 1: digital inputs
Point Description
1Generic input 1 status (1=activated)
2Generic input 2 status (1=activated)
3-
4-
5-
6-
7-
8-
9Wrong SITE code
10 Wrong PI code
11 Access denied for not allowed day of the week
12 Access denied for not allowed time slot
13 -
14 -
15 -
16 -
The points 1 and 2 report the status of the two generic in-
puts of ModKB module. The logic of the contacts connec-
ted to these inputs depends on the C/ O configuration
which has been chosen, during the setting up, for each one
of them. If the input has been configured as C, then the
status on the bus will be 1 when the contact is opened; if
the input has been instead configured as O, the the status
will be 1 when the contact is closed.
The points 9÷12 will be activated when ModKB module
denies the access for one of the reasons described above.
The information related to these points remains for the time
set in the configuration panel of ModKB (Code Perman-
ence, 5 seconds typical value).
Input channel 2: entered code
This channel shows the last PI code typed on the keypad;
this code remains in this channel for the set time (Code
Permanence) then it returns to zero.
Input channel 3 and 4: valid PIN codes
These channels report 30 mutually exclusive points, each
one corresponding to the occurred recognition of one of the
30 PI code set in ModKB. The point related to the last val-
id entered code remains active for the set time (Code Per-
manence), then it returns to zero.
Point CH3 CH4
1PI 1 OK PI 17 OK
2PI 2 OK PI 18 OK
3PI 3 OK PI 19 OK
4PI 4 OK PI 20 OK
5PI 5 OK PI 21 OK
6PI 6 OK PI 22 OK
7PI 7 OK PI 23 OK
8PI 8 OK PI 24 OK
9PI 9 OK PI 25 OK
10 PI 10 OK PI 26 OK
11 PI 11 OK PI 27 OK
12 PI 12 OK PI 28 OK
13 PI 13 OK PI 29 OK
14 PI 14 OK PI 30 OK
15 PI 15 OK -
16 PI 16 OK -
Output section
On the output address, if it has been enabled during the
ModKB setting up, four 16-bit channels are available; the
following tables shows the arrangement:
Point CH1 CH2 CH3 CH4
1Relay pulse - PI 1 lock PI 17 lock
2- - PI 2 lock PI 18 lock
3- - PI 3 lock PI 19 lock
4- - PI 4 lock PI 20 lock
5- - PI 5 lock PI 21 lock
6- - PI 6 lock PI 22 lock
7- - PI 7 lock PI 23 lock
8- - PI 8 lock PI 24 lock
9- - PI 9 lock PI 25 lock
10 - - PI 10 lock PI 26 lock
11 - - PI 11 lock PI 27 lock
12 - - PI 12 lock PI 28 lock
13 - - PI 13 lock PI 29 lock
14 - - PI 14 lock PI 30 lock
15 - - PI 15 lock ALL lock
16 - - PI 16 lock -
Activating the point 1 of CH1, ModKB module generates a
pulse on the internal relay, whose duration can be fixed
during the setting up; only one pulse will be generated even
if the output point 1 remains in active status or less.
DUEMMEGI s.r.l. - Via Longhena, 4 - 20139 MILA O
Tel. [phone] - Fax [phone] – www.duemmegi.it
Rel.: 1.1 July 2012 Page 3 of 6
HOME AND BUILDIN AUTOMATION

Contatto
ModKB
The channel 2 is not used. Channel 3 and 4 report 30 digit-
al points which, when activated, deny the access to the re-
lated PI code. The point 15 of CH4, when activated,
denies the access to any PI codes.
Configuration of ModKB module
This paragraph describes the configuration of ModKB mod-
ule, allowing to adapt its operation according to the re-
quests of the specific application, and to enter the PI
codes s that must allow the access.
For the configuration of ModKB module, MCP IDE program
for MCP XT has to be used. The configuration of the mod-
ule is performed through the Contatto bus.
Note: ModKB module can work only if the MCP XT controller has
been installed the configuration and the programming of MCP XT
requires the software package MCP IDE.
All ModKB modules installed in the plant must be declared
in the MCP XT configuration, specifying the addresses as
in the following example (where the output address has
been supposed enabled):
MODKB = ( I100, O100 )
MODKB = ( I101, O101 )
MODKB = ( I102, O102 )
… … … …
After having transferred a program to MCP XT containing
at least the addresses of installed ModKB modules, the
second step is the setting of the operating parameters.
From the menu of MCP IDE select Programming, Modules
Configuration and then ModKB.
The window shown in Figure 2 will appear, where:
Module Address: this is the address of ModKB module to
be configured.
Enable Output Address: this option enables the output
address, thus allowing the execution of commands to the
ModKB as described in the paragraph “Output section”.
Pulse Length (msec): it is the duration of the pulse gener-
ated on the internal relay of ModKB for driving the electrical
door lock or similar devices. This duration can be defined at
100msec steps; the maximum allowed value is 25500, that
means 25.5 seconds.
Code Permanence: it is the time, in seconds, during which
the information remain in the input section; the maximum
allowed value is 255 seconds.
SITE code: it is the code set in the keypad and it is a num-
ber in the range 0 to 255 for WIEGA D 26 keypad, or 0 to
65535 for WIEGA D 32 keypad (for the procedure to set
this code refer to the documentation of the keypad).
N.C. Inputs: allows to choose the logic for each on e of the
two available inputs. If an input has been configured as C,
then the status on the bus will be 1 when the contact is
opened; if the input has been instead configured as O,
the the status will be 1 when the contact is closed.
The table in the bottom side of the configuration window
shown in Figure 2 allows to define the PI codes and other
related parameters.
DUEMMEGI s.r.l. - Via Longhena, 4 - 20139 MILA O
Tel. [phone] - Fax [phone] – www.duemmegi.it
Rel.: 1.1 July 2012 Page 4 of 6
HOME AND BUILDIN AUTOMATION
Figure 2: ModKB configuration panel

Contatto
ModKB
The first column report a progressive number (1 to 30) re-
lated to each one of the possible PI code; the other
columns have the following menaning:
PIN: it is the PI code that, entered by the keypad, must
grant the access. This code must be a number in the range
1 to 65535 (the code 0 means “not used”).
Valid Days: these are the days of the week during which
the access is allowed. Double clicking with the mouse in
the cell, the panel shown at this
right side will appear, where the
allowed days can be selected
(Monday to Sunday). The two
buttons under the days of the
week allow to select and deselect all the related days. The
button OK confirms the executed selection.
From.....To: in this two columns, the time slot during which
the access is allowed has to be chosen.
Double clicking with the mouse in these cells,
the panel shown at this right side will appear,
allowing to choose the time with 15 minutes
resolution. Enter the desired time in the cell on
the bottom left side, then select the minutes
clicking on one of the 4 points. The button on
the bottom side allows to confirm the executed selection.
The columns related to the times are 4 because 2 time
slots are allowed for each PI .
To enable the access over all 24 hours, enter the character
– both in the column From and in the column To for at least
one of the two time slots, like in the following example:
To disable one of the two time slots, enter equal values for
the start time and for the end time (typically 00:00); In the
following example the access is allowed from 10:00 to
14:00:
ote that, in the following example, the access is allowed
over all 24h:
Time slots across the midnight are also allowed as in the
following example, where the access is allowed from 22:00
of Saturday to 3:00 of Sunday:
The buttons in ModKB configuration window have the fol-
lowing meaning:
Read: read the current settings from ModKB module
and show them in the window
Program: transfer the settings shown in the window to
ModKB module
ID & Ver.: report the firmware version of connected
ModKB module
From File and To File: respectively to open a file con-
taining the settings of a ModKB module and to save in
a file the settings shown in the window (the file has .KB
extension)
Clear: clear the table
Close: close the ModKB configuration window
Technical characteristics
Power supply ModKB 24V ± 25% SELV
Power supply for the keypad 12V 50mA MAX provided
by ModKB
Total current consumption
(ModKB only)
50mA TYP at 24V
Serial protocol for keypad WIEGA D 26 and WIEGA D
32 with automatic detection
Digital Inputs 2, for potential free contacts
Current for each digital I 4mA (with closed contact) TYP
Threshold voltage on dig. I 8V TYP
umber of LED outputs 2 (code OK and OK)
Current for each LED output 3.5mA internally limited
umber of relay outputs 1
MAX rating for O contact 5A, 0÷250V~ resistive load
1A, 0÷250V~ inductive load
3A, 0÷30V resistive load
Minimum load on O contact
of the relay
1.2W (100mA at 12V )
Operating temperature -10 ÷ +50 °C
Storage temperature -30 ÷ +85 °C
Protection degree (both Mod-
KB and TPR/T)
IP20
Outline dimensions
DUEMMEGI s.r.l. - Via Longhena, 4 - 20139 MILA O
Tel. [phone] - Fax [phone] – www.duemmegi.it
Rel.: 1.1 July 2012 Page 5 of 6
HOME AND BUILDIN AUTOMATION
90mm
33mm
53.5mm 42mm
21 22 23 24 25 26 27 28 29 30 31 32
ON
Contatto
DUEMMEGI
MILA O-ITALY
ADDRESS
+24V
0V L1 L2
P
13 14 16 1715
Access controller
Power supply 24V= ±25% / 40mA
MODKB
1 2
KB
I1 I2 C O1 O2 C12V LD D1 D0 C

Contatto
ModKB
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other
European countries with separate collection sys-
tems). This marking on the product, accessories or
literature indicates that the product should not be
disposed of with other household waste at the end
of their working life. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, please separ-
ate these items from other types of waste and recycle them re-
sponsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they pur-
chased this product, or their local government office, for details of
where and how they can take these items for environmentally safe
recycling. This product and its electronic accessories should not be
mixed with other commercial wastes for disposal.
Installation and use restrictions
Standards and regulations
The design and the setting up of electrical systems must be per-
formed according to the relevant standards, guidelines, specifica-
tions and regulations of the relevant country. The installation,
configuration and programming of the devices must be carried out
by trained personnel.
The installation and the wiring of the bus line and the related
devices must be performed according to the recommendations of
the manufacturers (reported on the specific data sheet of the
product) and according to the applicable standards.
All the relevant safety regulations, e.g. accident prevention regula-
tions, law on technical work equipment, must also be observed.
Safety instructions
Protect the unit against moisture, dirt and any kind of damage dur-
ing transport, storage and operation. Do not operate the unit out-
side the specified technical data.
ever open the housing. If not otherwise specified, install in closed
housing (e.g. distribution cabinet). Earth the unit at the terminals
provided, if existing, for this purpose. Do not obstruct cooling of the
units. Keep out of the reach of children.
Setting up
The physical address assignment and the setting of parameters (if
any) must be performed by the specific softwares provided togeth-
er the device or by the specific programmer. For the first installa-
tion of the device proceed according to the following guidelines:
•Check that any voltage supplying the plant has been removed
•Assign the address to module (if any)
•Install and wire the device according to the schematic dia-
grams on the specific data sheet of the product
•Only then switch on the 230Vac supplying the bus power sup-
ply and the other related circuits
Applied standards
This device complies with the essential requirements of the follow-
ing directives:
2004/108/CE (EMC)
2006/95/CE (Low Voltage)
2002/95/CE (RoHS)
Note
Technical characteristics and this data sheet are subject to change
without notice.
DUEMMEGI s.r.l. - Via Longhena, 4 - 20139 MILA O
Tel. [phone] - Fax [phone] – www.duemmegi.it
Rel.: 1.1 July 2012 Page 6 of 6
HOME AND BUILDIN AUTOMATION
