Dukane 8937 User manual

High performance LCD projector
captures attention in classrooms or
conference rooms with dynamic images
and 4,000 ANSI lumens.
Key Features
■XGA 1024 x 768 resolution
■4,000 ANSI lumens white/color output
■16 watt audio output
■3000:1 contrast ratio
■HDMI 1 input
■5,000 hours hybrid lter*
■5,000 hours lamp life (Standard mode)
and 6,000 hours lamp life (Eco mode)**
■Power saving standby mode less
than .5W
8937
From the classroom to the conference room, Dukane’s 8937 LCD projector
combines superior image clarity, high quality value, and long-life reliability.
Bright, vivid colors with razor-sharp text and bold graphics will truly enhance
any lesson or meeting and make it more memorable. Further engage the
audience by annotating over images with the optional TB-1 tablet and pen.
For greater installation convenience, the 8937 has a cloning function which
enables you to copy setting data from one projector to others of the same
model via USB memory. Plus, Dukane’s Intelligent Eco Mode with ImageCare
combines optimal picture performance with maximum energy savings for
a lower total cost of ownership. For added peace of mind, Dukane’s 8937
is also backed by a generous warranty and our world-class service and
support programs.
8937 LCD Projector
DUKANE CORP
Audio Visual Products
2900 Dukane Drive, St. Charles, Illinois 60174
Toll-free: 888-245-1966 •Fax: [phone]
E-mail: [email protected]
www.dukane.com/av

STANDARD FEATURES
UNIQUE FEATURES
Display via USB
Simply plug and play using the USB port instead of the
15-pin D-sub VGA cable.
Network Control, Maintenance and Security
Embedded networking gives you the ability to manage and
control multiple projectors over your LAN. Features include
scheduling of events, centralized reporting, image transfer and
e-mail alerts for reactive and routine maintenance.
PC-Less Presentation
By using a USB memory stick or other stor-
age device, you can use the projector without
a computer. Menus are easy to see with a
thumbnail display. Additionally there is also a
slideshow function.
PIN Lock / MyScreen / MyText
PIN lock protection can limit projector users. MyScreen PIN
lock keeps captured images on the startup screen. Users can
set any name logo to MyScreen, clearly identifying ownership.
MyText provides the ability to write text on the startup screen
such as model name, serial number or location.
PJMessenger
PJMessenger function allows you to send and display text
messages and audio alerts on your networked projectors. It
is an easy and efficient way to send announcements out to
multiple units.
Present Content via LAN
Dukane’s suite of networking software allows you to easily
send content directly from your PC to the projector via your
LAN connection.
Serial Number and Media Access Control Label
A label is affixed to side of projector to more easily access
and read the model name, serial number and MAC address
while mounted in ceiling use. This is a convenience for
installers, end users and auditors for instant accessibility.
Serial #
Wireless Presentation Ready
You can use a wireless network by connecting the projector
to a computer using the optional USB wireless adapter part
number USBWL11N. The adapter supports IEEE802.11b/g
and the latest 11n.
Drawing Function with Optional Tablet (TB-1)
The optional Dukane wireless tablet and pen allows you to
engage your audience by annotating over images shown on
the projector.
Cloning Function
Copy setting data from one projector to others of the same
model via USB memory. Cloning can save almost all PJ
settings such as gamma and keystone via USB memory.
settings
settings
Intelligent Eco and Saver Modes
Automatically changes the brightness of the lamp according to
the brightness level of the screen. Also, automatically changes
the brightness of the lamp if there is no change in the screen
image. Using ImageCare technology, these features give
optimal picture performance with maximum energy savings.
Input Source Naming
Users can name input sources in simple language instead of
factory default name.
Microphone Input
A microphone can be used via the jack located on the
input panel. Allows for more dynamic presentations even in
standby mode.
ImageCare Technology
ImageCare is a lamp power control function that combines
optimal picture performance with maximum energy savings
by decreasing energy usage, improving contrast ratio and
lengthening lamp life. The result is a lower total cost of
ownership and decreased maintenance cost.
8937 LCD Projector
* Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings
and usage. Hours of average filter life specified are not guaranteed and do not constitute part of the product warranty.
** Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user
settings and usage. Hours of average lamp life specified are not guaranteed and do not constitute part of the product or
lamp warranty. Lamp brightness decreases over time.
DUKANE CORP
Audio Visual Products
2900 Dukane Drive, St. Charles, Illinois 60174
Toll-free: 888-245-1966 •Fax: [phone]
E-mail: [email protected]
www.dukane.com/av

Long-life reliability with a lower
total cost of ownership.
From classrooms to conference rooms, Dukane’s
8937 can make a big impact on your audience.
With 4,000 ANSI lumens brightness and XGA
1024 x 768 resolution, the 8937 is designed to make
any message more memorable with colorful images,
crisp text, and powerfully clear audio. Incorporating
Dukane’s leading-edge technology, the 8937
features high contrast ratio, long lamp life, cloning
function enabling you to copy settings data from one
projector to others of the same model, and is wireless
presentation ready. Plus, embedded networking
gives you the ability to manage and control multiple
projectors over your LAN (scheduling of events,
centralized reporting, image transfer, and e-mail
alerts). Even with the the array of advanced features,
Dukane’s 8937 is designed for user-friendly operation
and installation convenience.
Input/Outputs
8937
Left Profile
Right Profile
Top View
1
1314 12 9101115
17
16
2 3 54
6
7
8
1. USB Type A x 2
2. USB Type B
3. HDMI
4. Computer in 1
5. Computer in 2
6. Audio In 3
7. Audio in 1
8. Audio in 2
9. Composite Video
10. S-Video
11. Audio Out
12. Monitor Out
13. Microphone Input
14. Control (RS-232C)
15. Kensington Lock
16. Security Bar
17. LAN
Front View
8937 LCD Projector
DUKANE CORP
Audio Visual Products
2900 Dukane Drive, St. Charles, Illinois 60174
Toll-free: 888-245-1966 •Fax: [phone]
E-mail: [email protected]
www.dukane.com/av
5 Year Warranty
Closed Captioning
3LCD Technology

Accessories and Lenses
Supplied
Accessories
Remote control, power cord, computer
cable, network and wireless software,
user’s manuals, safety manual
Optional
Accessories
USBWL11N USB wireless adapter,
TB-1 wireless USB tablet
Optional Lenses NA
Replacement Parts
Lamp 456-8755N
Remote Control HL02881
Filter MU06481
Specifications
Display
Projection Technology 3LCD, 3 chip technology
Resolution XGA - 1024 x 768
White Light Output 4,000 ANSI lumens
Color Light Output 4,000 ANSI lumens
Colors 16.7 million colors
Aspect Ratio Native 4:3 and 16:9 / 16:10 compatible
Contrast Ratio 3000 : 1 (using active IRIS)
Throw Ratio
(distance : width)
1.5 - 1.8 : 1
Lens & Operation
Lens x1.2 with manual zoom
Lamp Wattage 215W
Expected Lamp Life* Approximately 5,000 hours (standard mode)
6,000 hours (Eco mode)
Expected Filter Life** Approximately 5,000 hours
Speaker Output 16W (8W x 2)
Acoustic Noise Level 36 dB (29 dB in Eco mode)
Keystone +/- 30º vertical only
Compatibility
Computer VGA, XGA, WXGA, WXGA+, SVGA, SXGA+,
UXGA (compressed), MAC 16"
H-Sync 31.5 kHz - 106 kHz
V-Sync 56 Hz - 120 Hz
Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video 480i, 480p, 576i, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 720p, 1080i, 1080p,
computer signal TMDS clock 27 MHz - 150 MHz
Connectors
Digital Input HDMI x 1 (HDCP compliant)
Computer Input 1 15-pin mini D-sub x 1
Computer Input 2 15-pin mini D-sub x 1
Computer Monitor Output 15-pin mini D-sub x 1
Video Input
S-Video Mini DIN 4-pin x 1
Composite Video RCA jack x 1
Component Video 15-pin mini D-sub x 2 (shared w/analog computer 1/2)
Audio Input 3.5 mm stereo mini jack x 2, RCA jack (L/R) x 1,
MIC-in 3.5 mm mini jack x 1
Audio Output RCA jack (L/R) x 1
Network LAN Wired RJ-45 port / 100-base-T
Network LAN Wireless IEEE802.11 b/g/n - optional wireless adapter required
USB Type A x 2 (PC-less presentation and wireless adapter)
Type B x 1 (USB display or mouse control)
Control Terminals 9-pin D-sub x 1 (RS-232 control)
Ratings & Warranty
Power Supply AC90-132V / AC198-264V, 50/60Hz
Power Consumption 310W
Operating Temperature 40ºF - 95ºF (5ºC - 35ºC)
Dimensions (W x D x H) 12.5" x 11.3" x 3.9" / Shipping 18.0" x 15.0" x 8.0"
Weight 8.15 lbs. / Shipping 14.0 lbs.
Approvals UL 60950-1 / cUL FCC Part 15 subpart B class B
Warranty Five (5) year limited warranty plus Dukane’s 1 year Peace of
Mind Loaner Program
UPC 00000060519400264
Projection Throw Chart (In inches)
Screen Size 4:3 Throw Distance
Diagonal Width Min Max
30 24 32 38
60 48 68 81
80 64 91 109
100 80 115 137
150 120 175 208
200 160 234 278
300 240 354 420
Throw Ratio: 1.5 - 1.8 : 1 (distance : width)
8937
8937 LCD Projector
DUKANE CORP
Audio Visual Products
2900 Dukane Drive, St. Charles, Illinois 60174
Toll-free: 888-245-1966 •Fax: [phone]
E-mail: [email protected]
www.dukane.com/av
HI0080-06/12
Specifications subjext to change without notice.
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
** Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
filter life specified are not guaranteed and do not constitute part of the product warranty.
