Dukane 8105B User manual

Fully featured ultra short throw
LCD projector with network capabilities
and a low operating cost all in a
portable design.
Key Features
■XGA 1024 x 768 resolution
■2,200 ANSI lumens white/color output
■4000:1 contrast ratio
■HDMI 1 input
■4,000 hours hybrid lter*
■3,000 hours lamp life (Standard mode)
and 5,000 hours lamp life (Eco mode)**
■ImageCare technology
■Wireless compatible
8105B
Dukane’s 8105B ultra short throw LCD projector combines an array of
advanced features in a compact, portable design perfectly suited for
classrooms of any size. Small in size, but big on performance, the 8105B
provides vibrant image quality, cost-effective operation, and long-lasting
reliability. The 8105B incorporates a cloning function which enables you to
copy setting data from one projector to others of the same model via USB
memory. Plus, Dukane’s Intelligent Eco Mode with ImageCare combines
optimal picture performance with energy savings for a lower total cost of
ownership. For added peace of mind, Dukane’s 8105B is also backed by a
generous warranty and our world-class service and support programs.
8105B LCD Projector
DUKANE CORP
Audio Visual Products
2900 Dukane Drive, St. Charles, Illinois 60174
Toll-free: 888-245-1966 •Fax: 630-584-5156
E-mail: [email protected]
www.dukane.com/av
UNIQUE FEATURES
STANDARD FEATURES
Display via USB
Simply plug and play using the USB port instead of the
15-pin D-sub VGA cable.
Drawing Function with Optional Tablet (TB-1)
The optional Dukane wireless tablet and pen allows you to
engage your audience by annotating over images shown on
the projector.
Tabletop Presentation
Make any tabletop a projection screen using the optional
tabletop stand. Ideal for a small group environment or in a
room with limited space.
Microphone Input
A microphone can be used via the jack located on the
input panel. Allows for more dynamic presentations even in
standby mode.
Input Source Naming
Users can name input sources in simple language instead of
factory default name.
Network Control, Maintenance and Security
Embedded networking gives you the ability to manage and
control multiple projectors over your LAN. Features include
scheduling of events, centralized reporting, image transfer and
e-mail alerts for reactive and routine maintenance.
PIN Lock / MyScreen / MyText
PIN lock protection can limit projector users. MyScreen PIN
lock keeps captured images on the startup screen. Users can
set any name logo to MyScreen, clearly identifying ownership.
MyText provides the ability to write text on the startup screen
such as model name, serial number or location.
PJMessenger
PJMessenger function allows you to send and display text
messages and audio alerts on your networked projectors. It
is an easy and efficient way to send announcements out to
multiple units.
PC-Less Presentation
By using a USB memory stick or other storage device, you
can use the projector without a computer. Menus are easy
to see with a thumbnail display. Additionally there is also a
slideshow function.
Present Content via LAN
Dukane’s suite of networking software allows you to easily
send content directly from your PC to the projector via your
LAN connection.
Template Function
Line templates in the projector menu can help when writing
on a whiteboard. There are four types of line templates to
choose from.
Wireless Presentation Ready
You can use a wireless network by connecting the projector
to a computer using the optional USB wireless adapter part
number USBWL11N. The adapter supports IEEE802.11b/g
and the latest 11n.
Cloning Function
Copy setting data from one projector to others of the same
model via USB memory. Cloning can save almost all PJ
settings such as gamma and keystone via USB memory.
settings
settings
Intelligent Eco and Saver Modes
Automatically changes the brightness of the lamp according to
the brightness level of the screen. Also, automatically changes
the brightness of the lamp if there is no change in the screen
image. Using ImageCare technology, these features give
optimal picture performance with maximum energy savings.
ImageCare Technology
ImageCare is a lamp power control function that combines
optimal picture performance with maximum energy savings
by decreasing energy usage, improving contrast ratio and
lengthening lamp life. The result is a lower total cost of
ownership and decreased maintenance cost.
Serial Number and Media Access Control Label
A label is affixed to the front of the projector to more easily
access and read the model name and serial number while
mounted in ceiling use. This is a convenience for installers,
end user and auditors for instant accessibility.
8105B LCD Projector
* Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings
and usage. Hours of average filter life specified are not guaranteed and do not constitute part of the product warranty.
** Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user
settings and usage. Hours of average lamp life specified are not guaranteed and do not constitute part of the product or
lamp warranty. Lamp brightness decreases over time.
DUKANE CORP
Audio Visual Products
2900 Dukane Drive, St. Charles, Illinois 60174
Toll-free: 888-245-1966 •Fax: 630-584-5156
E-mail: [email protected]
www.dukane.com/av
Enhance the educational experience
with Dukane’s 8105B.
The 8105B ultra short throw LCD projector from
Dukane is specifically designed to enhance the
educational experience
—
for students and teachers.
Leading edge projector technology helps stimulate
the imagination of students of all ages and makes
lessons become more interesting, compelling and
memorable. Vivid colors. Bold graphics. Crisp text.
The 8105B does it all in classrooms of all sizes. With
2,200 ANSI lumens brightness and XGA 1024 x 768
resolution, the 8105B provides the perfect solution.
It also features a high contrast ratio, long lamp life,
cloning function enabling you to copy settings data
from one projector to others of the same model,
and is wireless presentation ready. Plus, embedded
networking gives you the ability to manage and
control multiple projectors over your LAN (scheduling
of events, centralized reporting, image transfer, and
email alerts). Best of all, the high performance 8105B
is exceptionally reliable and offers a lower cost of
ownership.
Input/Outputs
8105B
Right Side Profile
Rear View
Top View
41 32
141516 13 89101112
5 76
1. LAN
2. USB Type A x 2
3. S-Video
4. USB Type B
5. HDMI
6. Computer in 2
7. Computer in 1
8. Monitor Out
9. Microphone Input
10. Audio in 1
11. Audio in 2
12. Control (RS-232C)
13. Audio in 3
14. Audio Out
15. Composite Video
16. AC In
Front 3/4 View
8105B LCD Projector
DUKANE CORP
Audio Visual Products
2900 Dukane Drive, St. Charles, Illinois 60174
Toll-free: 888-245-1966 •Fax: 630-584-5156
E-mail: [email protected]
www.dukane.com/av
5 Year Warranty
Closed Captioning
3LCD Technology
Accessories and Lenses
Supplied
Accessories
Remote control, power cord,
computer cable, user's manual,
network manual
Optional
Accessories
AW250NWALLARM, A3WALLARM, TB-1
wireless tablet, TT-251 tabletop stand,
USBWL11N - USB wireless adapter
Optional Lenses
Replacement Parts
Lamp 456-8105B
Remote Control HL02772
Filter UX37191
Specifications
Display
Projection Technology 3LCD, 3 chip technology
Resolution XGA - 1024 x 768
White Light Output 2,200 ANSI lumens
Color Light Output 2,200 ANSI lumens
Colors 16.7 million colors
Aspect Ratio Native 4:3 / 16:9 and 16:10 compatible
Contrast Ratio 4000 : 1 (using active IRIS)
Throw Ratio
(distance : width)
0.1 : 1 from edge of projector to screen
0.3 : 1 from mirror to screen
Lens & Operation
Lens F = 4.1 mm
Lamp Wattage 215W
Expected Lamp Life* Approximately 3,000 hours (standard mode)
5,000 hours (Eco mode)
Expected Filter Life** Approximately 4,000 hours
Speaker Output 10W x 1
Acoustic Noise Level 34 dB (28 dB in Eco mode)
Keystone H and V: +/- 5º
Compatibility
Computer SVGA, SXGA, SXGA+, UXGA (compressed), VGA, WSXGA+,
WXGA, WXGA+, XGA, MAC 16"
H-Sync 31.5 kHz - 106 kHz
V-Sync 56 Hz - 120 Hz
Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video 480i, 480p, 576i, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 720p, 1080i, 1080p,
computer signal TMDS clock 27 MHz - 150 MHz
Connectors
Digital Input HDMI x 1 (HDCP compliant)
Computer Input 1 15-pin mini D-sub x 1
Computer Input 2 15-pin mini D-sub x 1
Computer Monitor Output 15-pin mini D-sub x 1
Video Input
S-Video Mini DIN 4-pin x 1
Composite Video RCA jack x 1
Component Video 15-pin mini D-sub x 2, (shared with analog computer 1/2)
Audio Input 3.5 mm stereo mini jack x 2, RCA jack (L/R) x 1,
MIC-in 3.5 mm mini jack x 1
Audio Output RCA jack (L/R) x 1
Network LAN Wired RJ-45 port / 100-base-T
Network LAN Wireless IEEE802.11 b/g/n - optional wireless adapter required
USB Type A x 2 (PC-less, wireless adapter, TB-1)
Type B x 1 (USB display or mouse control)
Control Terminals 9-pin mini D-sub x 1 (RS-232 control)
Ratings & Warranty
Power Supply AC90-132V / AC198-264V, 50/60Hz
Power Consumption 320W
Operating Temperature 32ºF - 104ºF (0ºC - 40ºC)
Dimensions (W x D x H) 13.6" x 11.9" x 3.7" / Shipping 19" x 17" x 9"
Weight 8.6 lbs. / Shipping 19 lbs.
Approvals UL 60950-1 / cUL FCC Part 15 subpart B Class B
Warranty Five (5) year limited warranty plus Dukane’s 1 year Peace of
Mind Loaner Program
UPC 00000060519400268
Projection Throw Chart (In inches)
Screen Size 4:3 Throw Distance
Diagonal Distance from
leading edge of
projector to screen
Distance from
mirror to screen
60 3.8 15.9
70 6.3 18.4
80 8.9 20.9
90 11.4 23.4
100 13.9 26.0
Throw Ratio: (distance : width)
0.1 : 1 from edge of projector
0.3 : 1 from mirror
8105B
8105B LCD Projector
DUKANE CORP
Audio Visual Products
2900 Dukane Drive, St. Charles, Illinois 60174
Toll-free: 888-245-1966 •Fax: 630-584-5156
E-mail: [email protected]
www.dukane.com/av
HI0081-06/12
Specifications subjext to change without notice.
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
** Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
filter life specified are not guaranteed and do not constitute part of the product warranty.

Other Dukane Projector manuals

Dukane ImagePro 8755H User manual

Dukane

Dukane ImagePro 8755H User manual

Dukane ImagePro 8764 User manual

Dukane

Dukane ImagePro 8764 User manual

Dukane 8063C User manual

Dukane

Dukane 8063C User manual

Dukane ImagePro 8762 Technical document

Dukane

Dukane ImagePro 8762 Technical document

Dukane ImagePro 8767A Technical document

Dukane

Dukane ImagePro 8767A Technical document

Dukane 8950W User manual

Dukane

Dukane 8950W User manual

Dukane ImagePro 7300 User manual

Dukane

Dukane ImagePro 7300 User manual

Dukane ImagePro 8756A User manual

Dukane

Dukane ImagePro 8756A User manual

Dukane ImagePro 8043 User manual

Dukane

Dukane ImagePro 8043 User manual

Dukane 28A622A User manual

Dukane

Dukane 28A622A User manual

Dukane ImagePro 8755A User manual

Dukane

Dukane ImagePro 8755A User manual

Dukane ImagePro 9135 User manual

Dukane

Dukane ImagePro 9135 User manual

Dukane 8930C User manual

Dukane

Dukane 8930C User manual

Dukane 28A8945 User manual

Dukane

Dukane 28A8945 User manual

Dukane ImagePro 8774 User manual

Dukane

Dukane ImagePro 8774 User manual

Dukane 28A8247 User manual

Dukane

Dukane 28A8247 User manual

Dukane 8120WI User manual

Dukane

Dukane 8120WI User manual

Dukane 8527 User manual

Dukane

Dukane 8527 User manual

Dukane ImagePro 8063 User manual

Dukane

Dukane ImagePro 8063 User manual

Dukane ImagePro 6765WU User manual

Dukane

Dukane ImagePro 6765WU User manual

Dukane ImagePro 8950P User manual

Dukane

Dukane ImagePro 8950P User manual

Dukane ImagePro 8935 User manual

Dukane

Dukane ImagePro 8935 User manual

Dukane 8926H-RJ User manual

Dukane

Dukane 8926H-RJ User manual

Dukane 6235W User manual

Dukane

Dukane 6235W User manual

Popular Projector manuals by other brands

Hitachi CP-X8170 specification

Hitachi

Hitachi CP-X8170 specification

PJLink CP-WX3011N user manual

PJLink

PJLink CP-WX3011N user manual

Hitachi CP-X4020 operating guide

Hitachi

Hitachi CP-X4020 operating guide

Eiki EK-610U Service manual

Eiki

Eiki EK-610U Service manual

Sony VPLFH36/B Specification sheet

Sony

Sony VPLFH36/B Specification sheet

Optoma EP719 Service manual

Optoma

Optoma EP719 Service manual

Conrad Rayo i5 Mini Important information

Conrad

Conrad Rayo i5 Mini Important information

Philips NeoPix Easy quick start guide

Philips

Philips NeoPix Easy quick start guide

Hitachi SM0541 Service manual

Hitachi

Hitachi SM0541 Service manual

BenQ MX763 user manual

BenQ

BenQ MX763 user manual

Braun NOVAMAT E 130 Instruction book

Braun

Braun NOVAMAT E 130 Instruction book

Hilti SL 6-A22 Original operating instructions

Hilti

Hilti SL 6-A22 Original operating instructions

Hitachi CP-WU13K user manual

Hitachi

Hitachi CP-WU13K user manual

LG BS274 user manual

LG

LG BS274 user manual

Javes HDX-520 user manual

Javes

Javes HDX-520 user manual

Eiki LC-SM1 owner's manual

Eiki

Eiki LC-SM1 owner's manual

Barco R5975039 owner's manual

Barco

Barco R5975039 owner's manual

HP xp8010 series installation guide

HP

HP xp8010 series installation guide

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
