Dukane ImagePro 6765WU User manual

NEC Display Solutions of America, Inc.
PA653U/PA803U/PA853W/PA903X Installation Guide
Desktop and Ceiling Mount Rev 1.0
www.necdisplay.com PA653U/PA803U/PA853W/PA903X Page 1 of 14
Contents
Product Description, Lens Specs, Screen/Aspect Ratio
Notes and Formulas Pg 1
Distance Charts and Formulas Pg 2-4
Ceiling Mount/Desktop Installation Pg 5
Lens Shift Adjustable Range Pg 6
Cabinet Dimensions Pg 7
Cabinet Dimensions Pg 8
Lens Dimensions (Optional) Pg 9-12
Ceiling Mount Dimensions and Input Panel Pg 13
Control Codes Pg 14
Product Description
Type
: 3 panel LCD projector,
Dimensions: 19.8”(W) x 6.6”(H) x 14.4”(D)
0.8 p-Si TFT w/MLA Weight: 18.5 lbs
Resolution: 1920 x 1200 (16:10) Brightness: 6500 Lumens
1920 x 1200 (16:10)
8000 Lumens
1280 x 800 (16:10) 8500 Lumens
1024 x 768 (4:3)
9000 Lumens
Fan Noise
: 39 dB / 33dB @ 1 meter
Power Consumption: 460W (max) BTU’s: 1571 BTU/hour
Network Ready, integrated wired and wireless adapter
Manual: Lens Shift, Horizontal & Vertical /Zoom/ Focus
Lens Specifications
NP11FL: Throw Ratio: ~ 0.8:1 Focal Length: 13.2mm NP30ZL: Throw Ratio: 0.79 – 1.04:1 Focal Length: 13.2 – 17.2mm
Screen Sizes: 40”-150
” F/#:2.3 Screen Sizes: 4
0” - 500” F/#:1.9 -2.
1
NP12ZL: Throw Ratio: 1.16 - 1.52:1 Focal Length: 19.4 – 25.3mm NP40ZL: Throw Ratio: 0.79 – 1.04:1 Focal Length: 13.2 – 17.2mm
Screen Sizes: 30” - 500” F/#:2.2 – 2.69 _________ Screen Sizes: 50” - 500”
F/#:2.0 -2.43
NP13ZL: Throw Ratio: 1.46 – 2.95:1 Focal Length: 24.4 – 48.6mm NP41ZL: Throw Ratio: 1.30 – 3.02:1 Focal Length: 21.8 – 49.8mm
Screen Sizes: 40” - 500” F/#:1.7 – 2.37 _________ Screen Sizes: 50” - 500”
F/#:1.7 – 2.0
NP14ZL: Throw Ratio: 2.90 -4.68:1 Focal Length: 48.5 - 77.6mm NP42ZL: Throw Ratio: 2.99 – 5.98:1 Focal Length: 13.2 – 17.2mm
Screen Sizes: 60” - 500” F/#:2.2 -2.64 _________ Screen Sizes: 50” - 500”
F/#:2.2 -2.3
Sc
reen/Aspect Ratio
4:3, 16:9 and 16:10 screens are fully supported with proper aspect ratio control for both type sources using NEC developed
scaling technology. Menu selections have settings for each screen type and aspect ratio control for each source type.
Notes
 For screen sizes not indicated on the projection tables, use the formulas below.
If the figures on the tables do not match the results of formulas, use the figures in the table..
 Distances are in inches, for millimeters multiply by 25.4.
 Distances may vary 5%.
Note: The Dukane models described in this document are manufactured by
NEC and use the same rmware, software programs, control code, and acces-
sory parts. The equivalent Dukane to NEC models are 6765WU (NP-PA653U),
6780WU (NP-PA803U), 6785W (NP-PA853W), and 6790 (NP-PA903X).
www.dukaneav.com 430-6765WU-6780WU-6785W-6790-Installation-Guide-00 Page 1 of 14
6765WU/6780WU/6785W/6790 Installation Guide
Desktop and Ceiling Mount Rev 1.0
Dukane AV Division
6765WU
6780WU
6785W
6790

NEC Display Solutions of America, Inc.
PA653U/PA803U/PA853W/PA903X Installation Guide
Desktop and Ceiling Mount Rev 1.0
www.necdisplay.com PA653U/PA803U/PA853W/PA903X Page 2 of 14
Formulas: 4:3 Aspect Ratio (6790—XGA)
The Projection Formulas use the image width for calculation. Image width is the same for all aspect ratios, only vertical image size
varies. For proper projector placement, determine the image width for a desired screen size. Use the Screen Formulas below to
calculate all screen dimensions. Plug in the image width for “W” in the Projection Formulas.
Refer to the diagrams and charts for popular screen sizes on page 2 and 3:
Projection Formulas: Definitions: 4:3 Screen Formulas:
NP11FL: C = 0.827W – 1.374 W = Image Width W = H x 4/3
NP12ZL: C(Wide) = 1.214W – 1.794 ------ C(Tele) = 1.578W – 1.794 H = Image Height (size) H = W x 3/4
NP13ZL: C(Wide) = 1.525W – 1.974 ------ C(Tele) = 3.043W – 1.972 C = Throw distance Diagonal = W x 5/4
NP14ZL: C(Wide) = 3.034W – 4.844 ------ C(Tele) = 4.855W – 4.844
NP30ZL: C(Wide) = 0.827W – 1.587 ------ C(Tele) = 1.078W – 1.587
NP40ZL: C(Wide) = 0.824W – 1.535 ------ C(Tele) = 1.156W – 1.632
NP41ZL: C(Wide) = 1.354W – 1.771 ------ C(Tele) = 3.096W – 1.542
NP42ZL: C(Wide) = 2.993W + 5.143 ------ C(Tele) = 6.006W +4.320
Note: Tilting the front of the projector up or down by more than 45° from level could reduce lamp life by up to 20%.
Distance Chart for popular 4:3 screens
Rear Lens
NP11FL
Diagonal
Width(W)
Height (H) 0.8:1
inches inches inches inches
40 32 24 25.09 24.9 - 32.9 37.1 - 48.7 46.8 - 95.4 92.2 - 150.5 24.8 - 35.4 41.6 - 97.5 100.9 - 196.5
60 48 36 38.32 38.1 - 50.2 56.5 - 74.0 71.2 - 144.1 140.8 - 228.2 38.0 - 53.9 63.2 - 147.1 148.8 - 292.6
67 54 40 42.95 42.7 - 56.2 63.3 - 82.8 79.8 - 161.1 157.8 - 255.4 42.6 - 60.3 70.8 - 164.4 165.6 - 326.2
72 58 43 46.26 46.0 - 60.5 68.1 - 89.1 85.9 - 173.3 169.9 - 274.8 45.9 - 65.0 76.2 - 176.8 177.6 - 350.3
84 67 50 54.20 54.0 - 70.9 79.8 - 104.2 100.5 - 202.5 199.0 - 321.4 53.8 - 76.1 89.2 - 206.5 206.3 - 407.9
90 72 54 58.17 58.0 - 76.0 85.6 - 111.8 107.8 - 217.1 213.6 - 344.7 57.8 - 81.6 95.7 - 221.4 220.7 - 436.8
100 80 60 64.79 64.6 - 84.7 95.3 - 124.4 120.0 - 241.5 237.9 - 383.6 64.4 - 90.8 106.5 - 246.1 244.6 - 484.8
120 96 72 78.02 77.8 - 101.9 114.8 - 149.7 144.4 - 290.2 286.4 - 461.2 77.6 - 109.3 128.2 - 295.7 292.5 - 580.9
150 120 90 NA 97.7 - 127.8 143.9 - 187.6 181.0 - 363.2 359.2 - 577.8 97.3 - 137.1 160.7 - 370.0 364.3 - 725.0
180 144 108 NA 117.5 - 153.6 173.0 - 225.4 217.6 - 436.2 432.1 - 694.3 117.1 - 164.8 193.2 - 444.3 436.2 - 869.2
210 168 126 NA 137.3 - 179.5 202.2 - 263.3 254.2 - 509.3 504.9 - 810.8 136.9 - 192.6 225.7 - 518.6 508.0 - 1013.3
240 192 144 NA 157.2 - 205.4 231.3 - 301.2 290.8 - 582.3 577.7 - 927.3 156.7 - 220.3 258.2 - 592.9 579.9 - 1157.5
270 216 162 NA 177.0 - 231.3 260.4 - 339.1 327.4 - 655.3 650.5 - 1043.8 176.4 - 248.1 290.7 - 667.2 651.7 - 1301.6
300 240 180 NA 196.9 - 257.1 289.6 - 376.9 364.0 - 728.3 723.3 - 1160.4 196.2 - 275.8 323.2 - 741.5 723.5 - 1445.8
400 320 240 NA 263.1 - 343.4 386.7 - 503.2 486.0 - 971.8 966.0 - 1548.8 262.1 - 368.3 431.5 - 989.2 963.0 - 1926.2
500 400 300 NA 329.2 - 429.6 483.8 - 629.4 608.0 - 1215.2 1208.8 - 1937.2 328.1 - 460.8 539.8 - 1236.9 1202.5 - 2406.7
Screen Size (4:3)
2.97 -4.79:1
NP30ZL
NP12ZL
NP13ZL
NP14ZL
1.50 - 3.02:1
Zoom Lenses
NP40ZL
0.80 - 1.14:1
inches
inches
inches
0.79 - 1.04:1
1.19 - 1.56:1
inches
inches
NP41ZL
1.33 - 3.08:1
inches
NP42ZL
3.06 - 6.06:1
inches
Dukane AV Division
6765WU/6780WU/6785W/6790 Installation Guide
Desktop and Ceiling Mount Rev 1.0
Dukane AV Division
www.dukaneav.com 430-6765WU-6780WU-6785W-6790-Installation-Guide-00 Page 2 of 14

NEC Display Solutions of America, Inc.
PA653U/PA803U/PA853W/PA903X Installation Guide
Desktop and Ceiling Mount Rev 1.0
www.necdisplay.com PA653U/PA803U/PA853W/PA903X Page 3 of 14
Formulas: 16:10 Aspect Ratio (6785W—WXGA)
The Projection Formulas use the image width for calculation. Image width is the same for all aspect ratios, only vertical image size
varies. For proper projector placement, determine the image width for a desired screen size. Use the Screen Formulas below to
calculate all screen dimensions. Plug in the image width for “W” in the Projection Formulas.
Refer to the diagrams and charts for popular screen sizes on page 2 and 3:
Projection Formulas: Definitions: 16:10 Screen Formulas:
NP11FL: C = 0.812W – 1.346
W = Image Width W = H x 16/10
NP12ZL: C(Wide) = 1.193W – 1.795 ------ C(Tele) = 1.551W – 1.795 H = Image Height (size) H = W x 10/16
NP13ZL: C(Wide) = 1.495W – 1.972 ------ C(Tele) = 2.985W – 1.972 C = Throw distance Screen Diagonal = W x 18.868/16
NP14ZL: C(Wide) = 2.976W – 4.843 ------ C(Tele) = 4.763W – 4.843
NP30ZL: C(Wide) = 0.808W – 1.587 ------ C(Tele) = 1.054W – 1.587
NP40ZL: C(Wide) = 0.810W – 1.535 ------ C(Tele) = 1.136W – 1.632
NP41ZL: C(Wide) = 1.330W – 1.761 ------ C(Tele) = 3.045W – 1.539
NP42ZL: C(Wide) = 2.941W+ 5.143 ------ C(Tele) = 5.901W + 4.320
Distance Chart for popular 16:10 Screens (WXGA)
Rear Lens
NP11FL
Diagonal
Width(W)
Height (H) 0.8:1
inches inches inches inches
40 34 21 26.3 25.9 - 34.3 38.8 - 50.9 48.9 - 99.5 96.3 - 157.1 26.0 - 37.0 43.5 - 102.0 105.1 - 205.0
60 51 32 40.1 39.7 - 52.2 59.0 - 77.3 74.3 - 150.3 146.9 - 238.1 39.8 - 56.3 66.1 - 153.8 155.1 - 305.3
67 57 36 44.9 44.5 - 58.5 66.2 - 86.6 83.2 - 168.2 164.8 - 266.6 44.6 - 63.1 74.0 - 172.0 172.8 - 340.7
72 61 38 48.2 47.8 - 62.8 71.0 - 92.8 89.2 - 180.1 176.7 - 285.7 47.9 - 67.7 79.4 - 184.2 184.5 - 364.3
84 71 45 56.3 55.8 - 73.3 82.9 - 108.3 104.2 - 210.0 206.5 - 333.3 56.0 - 79.0 92.7 - 214.7 214.0 - 423.3
90 76 48 60.4 59.9 - 78.6 88.9 - 116.1 111.6 - 224.9 221.3 - 357.1 60.0 - 84.7 99.3 - 229.9 228.7 - 452.8
100 85 53 67.7 67.1 - 88.1 99.6 - 130.0 125.1 - 251.8 248.1 - 400.0 67.3 - 94.9 111.3 - 257.3 255.1 - 505.9
120 102 64 81.5 80.9 - 106.0 119.9 - 156.4 150.5 - 302.5 298.7 - 481.0 81.1 - 114.2 133.9 - 309.1 305.1 - 606.2
150 127 79 NA 101.1 - 132.3 149.7 - 195.2 187.9 - 377.1 373.1 - 600.1 101.3 - 142.6 167.1 - 385.2 378.7 - 753.7
180 153 95 NA 122.1 - 159.7 180.7 - 235.5 226.8 - 454.7 450.5 - 723.9 122.4 - 172.2 201.7 - 464.3 455.1 - 907.2
210 178 111 NA 142.3 - 186.1 210.6 - 274.3 264.1 - 529.4 524.9 - 843.0 142.6 - 200.6 235.0 - 540.5 528.6 - 1054.7
240 204 127 NA 163.3 - 213.5 241.6 - 314.6 303.0 - 607.0 602.3 - 966.8 163.7 - 230.1 269.6 - 619.6 605.1 - 1208.1
270 229 143 NA 183.5 - 239.8 271.4 - 353.4 340.4 - 681.6 676.7 - 1085.9 184.0 - 258.5 302.8 - 695.8 678.6 - 1355.6
300 254 159 NA 203.7 - 266.2 301.2 - 392.2 377.8 - 756.2 751.1 - 1205.0 204.2 - 286.9 336.1 - 771.9 752.2 - 1503.2
400 339 212 NA 272.4 - 355.8 402.6 - 524.0 504.8 - 1009.9 1004.0 - 1609.8 273.1 - 383.5 449.1 - 1030.7 1002.1 - 2004.8
500 424 265 NA 341.1 - 445.4 504.0 - 655.8 631.9 1263.7 1257.0 - 2014.7 341.9 - 480.0 562.2 - 1289.5 1252.1 - 2506.3
NP41ZL
NP42ZL
1.31 - 3.03:1
3.00 - 5.95:1
inches
inches
inches
inches
inches
0.79 - 1.04:1
1.19 - 1.56:1
inches
inches
Screen Size (16:10)
2.97 -4.79:1
NP30ZL
NP12ZL
NP13ZL
NP14ZL
1.50 - 3.02:1
Zoom Lenses
NP40ZL
0.79 - 1.12:1
6765WU/6780WU/6785W/6790 Installation Guide
Desktop and Ceiling Mount Rev 1.0
Dukane AV Division
www.dukaneav.com 430-6765WU-6780WU-6785W-6790-Installation-Guide-00 Page 3 of 14

NEC Display Solutions of America, Inc.
PA653U/PA803U/PA853W/PA903X Installation Guide
Desktop and Ceiling Mount Rev 1.0
www.necdisplay.com PA653U/PA803U/PA853W/PA903X Page 4 of 14
Formulas: 16:10 Aspect Ratio (6765WU/6780WU—WUXGA)
The Projection Formulas use the image width for calculation. Image width is the same for all aspect ratios, only vertical image size
varies. For proper projector placement, determine the image width for a desired screen size. Use the Screen Formulas below to
calculate all screen dimensions. Plug in the image width for “W” in the Projection Formulas.
Refer to the diagrams and charts for popular screen sizes on page 2 and 3:
Projection Formulas: Definitions: 16:10 Screen Formulas
NP11FL: C = 0.807W
– 1.354 W = Image Width W = H x 16/10
NP12ZL: C(Wide) = 1.185W – 1.794 ------ C(Tele) = 1.541W – 1.794 H = Image Height (size) H = W x 10/16
NP13ZL: C(Wide) = 1.488W – 1.974 ------ C(Tele) = 2.970W – 1.972 C = Throw distance Screen Diagonal = W x 18.868/16
NP14ZL: C(Wide) = 2.961W – 4.844 ------ C(Tele) = 4.737W – 4.844
NP30ZL: C(Wide) = 0.808W – 1.537 ------ C(Tele) = 1.054W – 1.537
NP40ZL: C(Wide) = 0.807W – 1.535 ------ C(Tele) = 1.131W – 1.632
NP41ZL: C(Wide) = 1.323W – 1.763 ------ C(Tele) = 3.034W – 1.539
NP42ZL: C(Wide) = 2.929W + 5.143 ------ C(Tele) = 5.878W +4.320
Distance Chart for popular 16:10 Screens (WUXGA)
Note: For screen sizes not indicated in projection tables, refer to formulas above respective charts.
Rear Lens
NP11FL
Diagonal
Width(W)
Height (H) 0.8:1
inches inches inches inches
40 34 21 26.08 25.9 - 34.3 38.5 - 50.6 48.6 - 99.0 95.8 - 156.2 25.9 - 36.8 43.2 - 101.6 104.7 - 204.2
60 51 32 39.80 39.7 - 52.2 58.6 - 76.8 73.9 - 149.5 146.2 - 236.7 39.6 - 56.0 65.7 - 153.2 154.5 - 304.1
67 57 36 44.65 44.5 - 58.5 65.8 - 86.0 82.8 - 167.3 163.9 - 265.2 44.5 - 62.8 73.6 - 171.4 172.1 - 339.4
72 61 38 47.87 47.8 - 62.8 70.5 - 92.2 88.8 - 179.2 175.8 - 284.1 47.7 - 67.4 78.9 - 183.5 183.8 - 362.9
84 71 45 55.94 55.8 - 73.3 82.3 - 107.6 103.7 - 208.9 205.4 - 331.5 55.8 - 78.7 92.2 - 213.9 213.1 - 421.7
90 76 48 59.98 59.9 - 78.6 88.3 - 115.3 111.1 - 223.7 220.2 - 355.2 59.8 - 84.3 98.8 - 229.0 227.7 - 451.0
100 85 53 67.24 67.1 - 88.1 98.9 - 129.2 124.5 - 250.5 246.8 - 397.8 67.1 - 94.5 110.7 - 256.4 254.1 - 504.0
120 102 64 80.96 80.9 - 106.0 119.1 - 155.4 149.8 - 301.0 297.2 - 478.3 80.8 - 113.7 133.2 - 307.9 303.9 - 603.9
150 127 79 NA 101.1 - 132.3 148.7 - 193.9 187.0 - 375.2 371.2 - 596.8 101.0 - 142.0 166.3 - 383.8 377.1 - 750.8
180 153 95 NA 122.1 - 159.7 179.5 - 234.0 225.7 - 452.4 448.2 - 719.9 121.9 - 171.4 200.7 - 462.7 453.3 - 903.7
210 178 111 NA 142.3 - 186.1 209.1 - 272.5 262.9 - 526.7 522.2 - 838.3 142.1 - 199.7 233.7 - 538.5 526.5 - 1050.6
240 204 127 NA 163.3 - 213.5 239.9 - 312.6 301.6 - 603.9 599.2 - 961.5 163.1 - 229.1 268.1 - 617.4 602.7 - 1203.4
270 229 143 NA 183.5 - 239.8 269.6 - 351.1 338.8 - 678.2 673.2 - 1079.9 183.3 - 257.4 301.2 - 693.2 675.9 - 1350.4
300 254 159 NA 203.7 - 266.2 299.2 - 389.6 376.0 - 752.4 747.3 - 1198.4 203.4 - 285.6 334.3 - 769.1 749.1 - 1497.3
400 339 212 NA 272.4 - 355.8 399.9 - 520.6 502.5 - 1004.9 998.9 - 1601.0 272.0 - 381.8 446.7 - 1027.0 998.1 - 1997.0
500 424 265 NA 341.1 - 445.4 500.6 - 651.6 628.9 1257.3 1250.6 - 2003.6 340.6 - 477.9 559.2 - 1284.9 1247.0 - 2496.6
NP41ZL
NP42ZL
1.30 - 3.02:1
2.88 - 5.72:1
inches
inches
inches
inches
inches
0.79 - 1.04:1
1.19 - 1.56:1
inches
inches
Screen Size (16:10)
2.97 -4.79:1
NP30ZL
NP12ZL
NP13ZL
NP14ZL
1.50 - 3.02:1
Zoom Lenses
NP40ZL
0.79 - 1.11:1
6765WU/6780WU/6785W/6790 Installation Guide
Desktop and Ceiling Mount Rev 1.0
Dukane AV Division
www.dukaneav.com 430-6765WU-6780WU-6785W-6790-Installation-Guide-00 Page 4 of 14

NEC Display Solutions of America, Inc.
PA653U/PA803U/PA853W/PA903X Installation Guide
Desktop and Ceiling Mount Rev 1.0
www.necdisplay.com PA653U/PA803U/PA853W/PA903X Page 5 of 14
Ceiling Mount Installation
Desktop Installation
Note: Lens Shift Feature is not available to NP11FL. This lens should only be used for “zero degree”/”no-offset” applications. See
below
Screen Cent er
Screen T op
Shift Rang e
C
Screen Cent er
Shift Rang e
Screen Bot t om
C
ONLY FOR NP12ZL, NP13ZL, NP14ZL, NP30ZL, NP40ZL, NP41ZL and NP42ZL LENSES
Screen Cent er
C
3. 54
FOR USE WITH NP11FL ONL Y
6765WU/6780WU/6785W/6790 Installation Guide
Desktop and Ceiling Mount Rev 1.0
Dukane AV Division
www.dukaneav.com 430-6765WU-6780WU-6785W-6790-Installation-Guide-00 Page 5 of 14

NEC Display Solutions of America, Inc.
PA653U/PA803U/PA853W/PA903X Installation Guide
Desktop and Ceiling Mount Rev 1.0
www.necdisplay.com PA653U/PA803U/PA853W/PA903X Page 6 of 14
Lens Shift Adjustable Range
Lens Shift Range for Desktop and Ceiling Mount
Application
The diagram below shows the location of the image
position in the lens. The lens can be shifted within
the shaded area as shown using the normal
projection position as a starting point.
Note: Lens shift feature is not available with
NP11FL (rear lens). NP11FL should be used only
for “zero degree” / “no-offset” applications.
Maximum Possible Range for NP12ZL, NP13ZL,
NP14ZL, NP30ZL, NP40ZL, NP41ZL, NP42ZL:
Towards ceiling/floor: 0.5H (0.6H for 6785W)
Away from ceiling/floor: 0.1H
Right: 0.3W
Left: 0.3W
(W: width of projected image, H: height of projected
image)
Note: Horizontal lens shift range for the 6765WU
and 6780WU is 0.15W at a 200” projected image
with NP41ZL
0.3W 0.3WW
0.6H
0.5HH0.1H
0.3W
0.3W W
0.6H
0.5H H0.1H
CEILING FRONT
DES KTOP FRONT
VERTI CAL
VERTI CAL
HORIZONTAL
6765WU/6780WU/6785W/6790 Installation Guide
Desktop and Ceiling Mount Rev 1.0
Dukane AV Division
www.dukaneav.com 430-6765WU-6780WU-6785W-6790-Installation-Guide-00 Page 6 of 14

NEC Display Solutions of America, Inc.
PA653U/PA803U/PA853W/PA903X Installation Guide
Desktop and Ceiling Mount Rev 1.0
www.necdisplay.com PA653U/PA803U/PA853W/PA903X Page 7 of 14
Cabinet Dimensions
The following diagrams show the cabinet dimensions for the 6765WU/6780WU/6785W/6790.
Dimensions are in inches. For millimeters multiply by 25.4.
Note: Dimensions below shown with the NP41ZL lens
16.18
0.9
19. 65
6.61
6.45
3.54
9.899.89
2.30 15. 25
AC Inlet
Exhaust
Exhaust
Lamp Intake Filter
18.44
NP41ZL
2.55
6765WU/6780WU/6785W/6790 Installation Guide
Desktop and Ceiling Mount Rev 1.0
Dukane AV Division
www.dukaneav.com 430-6765WU-6780WU-6785W-6790-Installation-Guide-00 Page 7 of 14

NEC Display Solutions of America, Inc.
PA653U/PA803U/PA853W/PA903X Installation Guide
Desktop and Ceiling Mount Rev 1.0
www.necdisplay.com PA653U/PA803U/PA853W/PA903X Page 8 of 14
Cabinet Dimensions
2.66 7.88
9.85
6-M4(Max.M4 x 8)
4.91
FOR CEILING MOUNT
6765WU/6780WU/6785W/6790 Installation Guide
Desktop and Ceiling Mount Rev 1.0
Dukane AV Division
www.dukaneav.com 430-6765WU-6780WU-6785W-6790-Installation-Guide-00 Page 8 of 14

NEC Display Solutions of America, Inc.
PA653U/PA803U/PA853W/PA903X Installation Guide
Desktop and Ceiling Mount Rev 1.0
www.necdisplay.com PA653U/PA803U/PA853W/PA903X Page 9 of 14
Optional Lens Dimensions (NP11FL and NP12ZL)
2.78
2.25
NP11FL
NP12ZL
6765WU/6780WU/6785W/6790 Installation Guide
Desktop and Ceiling Mount Rev 1.0
Dukane AV Division
www.dukaneav.com 430-6765WU-6780WU-6785W-6790-Installation-Guide-00 Page 9 of 14

NEC Display Solutions of America, Inc.
PA653U/PA803U/PA853W/PA903X Installation Guide
Desktop and Ceiling Mount Rev 1.0
www.necdisplay.com PA653U/PA803U/PA853W/PA903X Page 10 of 14
Optional Lens Dimensions (NP13ZL and NP14ZL)
NP13ZL
NP14ZL
3.05
1.4
164
www.dukaneav.com 430-6765WU-6780WU-6785W-6790-Installation-Guide-00 Page 10 of 14
6765WU/6780WU/6785W/6790 Installation Guide
Desktop and Ceiling Mount Rev 1.0
Dukane AV Division

NEC Display Solutions of America, Inc.
PA653U/PA803U/PA853W/PA903X Installation Guide
Desktop and Ceiling Mount Rev 1.0
www.necdisplay.com PA653U/PA803U/PA853W/PA903X Page 11 of 14
Optional Lens Dimensions (NP30ZL and NP40ZL)
NP30ZL
NP40ZL
4.57
4.08
www.dukaneav.com 430-6765WU-6780WU-6785W-6790-Installation-Guide-00 Page 11 of 14
6765WU/6780WU/6785W/6790 Installation Guide
Desktop and Ceiling Mount Rev 1.0
Dukane AV Division

NEC Display Solutions of America, Inc.
PA653U/PA803U/PA853W/PA903X Installation Guide
Desktop and Ceiling Mount Rev 1.0
www.necdisplay.com PA653U/PA803U/PA853W/PA903X Page 12 of 14
Optional Lens Dimensions (NP42ZL)
NP42ZL
6.89
www.dukaneav.com 430-6765WU-6780WU-6785W-6790-Installation-Guide-00 Page 12 of 14
6765WU/6780WU/6785W/6790 Installation Guide
Desktop and Ceiling Mount Rev 1.0
Dukane AV Division

NEC Display Solutions of America, Inc.
PA653U/PA803U/PA853W/PA903X Installation Guide
Desktop and Ceiling Mount Rev 1.0
www.necdisplay.com PA653U/PA803U/PA853W/PA903X Page 13 of 14
Optional Ceiling Mount Dimensions (Part #: NP600
CM)
The following diagrams show ceiling mount dimensions for the NP600CM.
Dimensions are in inches. For millimeters multiply by 25.4.
Input Panel
1.31 1.28 9.88
1.601.22 7.88
3.77
6.31 6.16 5.35 5.35
www.dukaneav.com 430-6765WU-6780WU-6785W-6790-Installation-Guide-00 Page 13 of 14
6765WU/6780WU/6785W/6790 Installation Guide
Desktop and Ceiling Mount Rev 1.0
Dukane AV Division
or use the universal mount PRG-UNV.

NEC Display Solutions of America, Inc.
PA653U/PA803U/PA853W/PA903X Installation Guide
Desktop and Ceiling Mount Rev 1.0
www.necdisplay.com PA653U/PA803U/PA853W/PA903X Page 14 of 14
PC Control Codes
Function Code Data
POWER ON 02H 00H 00H 00H 00H 02H
POWER OFF 02H 01H 00H 00H 00H 03H
INPUT SELECT HDMI1 02H 03H 00H 00H 02H 01H A1H A9H
INPUT SELECT HDMI2 02H 03H 00H 00H 02H 01H A2H AAH
INPUT SELECT DisplayPort 02H 03H 00H 00H 02H 01H A6H AEH
INPUT SELECT Computer 02H 03H 00H 00H 02H 01H 01H 09H
INPUT SELECT HDBaseT 02H 03H 00H 00H 02H 01H BFH C7H
PICTURE MUTE ON 02H 10H 00H 00H 00H 12H
PICTURE MUTE OFF 02H 11H 00H 00H 00H 13H
SOUND MUTE ON 02H 12H 00H 00H 00H 14H
SOUND MUTE OFF 02H 13H 00H 00H 00H 15H
ON SCREEN MUTE ON 02H 14H 00H 00H 00H 16H
ON SCREEN MUTE OFF 02H 15H 00H 00H 00H 17H
ASPECT RATIO (4:3 Screen)
4:3 03H 10H 00H 00H 05H 18H 00H 00H 00H 00H 30H
LETTERBOX 03H 10H 00H 00H 05H 18H 00H 00H 01H 00H 31H
WIDESCREEN 03H 10H 00H 00H 05H 18H 00H 00H 02H 00H 32H
ZOOM 03H 10H 00H 00H 05H 18H 00H 00H 03H 00H 33H
ASPECT RATIO (RGB)
4:3 WINDOW 03H 10H 00H 00H 05H 18H 00H 00H 00H 00H 30H
16:9 03H 10H 00H 00H 05H 18H 00H 00H 02H 00H 32H
5:4 03H 10H 00H 00H 05H 18H 00H 00H 0BH 00H 3BH
16:10 03H 10H 00H 00H 05H 18H 00H 00H 0CH 00H 3CH
15:9 03H 10H 00H 00H 05H 18H 00H 00H 0DH 00H 3DH
AUTO ADJUST 02H 0FH 00H 00H 02H 05H 00H 18H
Cable Connection
Communication Protocol:
Baud Rate: 38400 bps (for cable lengths longer than 20’, it is recommended changing to 9600 bps in setup menu)
Data Length: 8 bits
Parity: No Parity
Stop Bit: One bit
X on/off: None
Communications: Full duplex
PC Control Connector (D-Sub 9P)
NOTE 1 : Pins 1, 4, 6, and 9 are used inside the projector.
NOTE 2:For long cable runs it is recommended to set communication speed within the projector to 9600 bps.
NOTE 3: Jumper “Request to Send” and “Clear to Send” together on both ends of the cable to simplify cable connection.
12345
67 8 9
To GND of PC
To RxD of PC
To TxD of PC
To CTS of PC
To RTS of PC
www.dukaneav.com 430-6765WU-6780WU-6785W-6790-Installation-Guide-00 Page 14 of 14
6765WU/6780WU/6785W/6790 Installation Guide
Desktop and Ceiling Mount Rev 1.0
Dukane AV Division
