ADEMCO VISTA-20P Series Operating instructions

9,67$3366HULHV
9,67$36HULHV
3URJUDPPLQJ*XLGH
ON OFF
1
OFF
4
MAX
7
INSTANT
READY
2
AWAY
5
TEST
8
CODE
0
3
STAY
6
BYPASS
9
CHIME
#
ARMED
READY
1
OFF
4
MAX
7
INSTANT
READY
2
AWAY
5
TEST
8
CODE
0
3
STAY
6
BYPASS
9
CHIME
#
ARMED
READY
®
K5305-1PRV1 4/02
www.PDF-Zoo.com

– 2–
TO ENTER PROGRAMMING MODE:
Local programming requires the use of an alpha keypad connected to the keypad terminals on the control.
A. POWER UP, then depress [✱] and [#] both at once, within 50 seconds of powering up (if ✱98 was used to exit program
mode, this method must be used to reenter program mode).
OR
B. Initially, key: Installer Code (4 + 1 + 1 + 2) plus 8 + 0 + 0.
DATA FIELD PROGRAMMING PROCEDURES
Task Procedure
Go to a Data Field Press [∗] + [Field Number], followed by the required entry.
Entering Data When the desired field number appears, simply make the required entry. When the last entry for a
field is entered, the keypad beeps three times and automatically displays the next data field in
sequence.
If the number of digits that you need to enter in a data field is less than the maximum digits available
(for example, the phone number fields *41, *42), enter the desired data, then press [∗] to end the
entry. The next data field number is displayed.
Review a Data Field Press [#] + [Field Number].
Data will be displayed for that field number. No changes will be accepted in this mode.
Deleting an Entry Press [∗] + [Field Number] + [∗]. (Applies only to fields ∗40–*46, *94, and pager programming fields)
INTERACTIVE MODE PROGRAMMING (∗56, ∗57, ∗58, ∗79, ∗80, ∗81, ∗82, ∗187)
Press [✱]+[Interactive Mode No.] (for example, ✱56). The alpha display keypad will display the first of a series of prompts
requesting entries.
Interactive Mode Used to Program
✱56 Zone Programming Zone characteristics, report codes, alpha descriptors, and serial numbers for 5800 RF
transmitters.
✱57 Function Key Programming Unlabeled keypad keys (known as ABCD keys) for special functions
✱58 Zone Programming Same options as *56 mode, but with fewer prompts. Intended for those familiar with
(Expert mode) this type of programming, otherwise *56 mode is recommended.
✱79 Output Device Mapping Assign module addresses and map individual relays/powerline carrier devices
✱80 Output Programming 4229 or 4204 Relay modules, Powerline Carrier devices, or on-board triggers
✱81 Zone List Programming Zone Lists for relay/powerline carrier activation, chime zones, pager zones, etc.
✱82 Alpha Programming Zone alpha descriptors
INITIALIZE DOWNLOAD and RESET DEFAULTS
✱96 Initializes download ID and subscriber account number.
✱97 Sets all data fields to original factory default values.
TO EXIT PROGRAMMING MODE:
✱98 Exits programming mode and
prevents
re-entry by: Installer Code + 8+ 0+ 0. If ✱98 is used to exit programming
mode, system must be powered down, and method A above used to enter the programming mode.
See field *88 for other *98 Program mode lockout options.
✱99 Exits programming mode and
allows
re-entry by: Installer Code + 8+ 0 + 0or method 1 above.
Special Messages
OC = OPEN CIRCUIT (no communication between Keypad and Control).
EE or ENTRY ERROR = ERROR (invalid field number entered; re-enter valid field number).
After powering up, AC, dI (disabled) or Busy Standby and NOT READY will be displayed after approximately 4 seconds.
This will revert to a “Ready”message in approximately 1 minute, which allows PIRS, etc. to stabilize. You can bypass this
delay by pressing [#] + [0].
If E4 or E8 appears, more zones than the expansion units can handle have been programmed. Correct the programming
and then completely de-power and re-power the control to clear this indication and remove the disable indication.
www.PDF-Zoo.com

– 3–
352*5$00,1*)250
Programmable values apply to all controls, except field *189, which applies to the VISTA-20PS only.
Entry of a number other than one specified will give unpredictable results. Values shown in brackets are factory defaults.
Entries shown in dashed boxes indicate partition entries for VISTA-20P only (not applicable for VISTA-15P).
Field Function Data Entries Programmable Values
SYSTEM SETUP (✱20–✱29)
✱20 INSTALLER CODE | | | [4112] 4 digits, 0–9
✱21 QUICK ARM ENABLE [0,0]
Part. 1 Part.2
0 = no; 1 = yes
✱22 RF JAM OPTION [0] 0 = no RF Jam detection; 1 = send RF Jam report
UL: must be 1 if wireless devices are used
✱23 QUICK (FORCED) BYPASS [0,0]
Part. 1 Part. 2
0 = no quick bypass UL: must be “0”
1 = allow quick bypass (code + [6] + [#] )
✱24 RF HOUSE ID CODE | | |
Part. 1 Part. 2 Common
00 = disable all wireless keypad usage
01–31 = using 5827, 5827BD or 5804BD keypad
[00,00,00]
✱26 CHIME BY ZONE [0] 0 = no; 1 = yes (select zones to chime on zone list 3,
using *81 Menu mode)
✱27 POWERLINE CARRIER DEVICE (X–10)
HOUSE CODE [0] 0 = A; 1 = B, 2 = C, 3 = D, 4 = E, 5 = F, 6 = G,
7 = H, 8 = I, 9 = J, #10 = K, #11 = L, #12 = M, #13 = N,
#14 = O, #15 = P UL: not for fire or UL installations
✱28 ACCESS CODE FOR
PHONE MODULE | [00]
(Partition 1 only)
00 = disable; 1st digit: enter 1–9; 2nd digit: enter # + 11
for "✱", or # + 12 for "#".
UL: must be “00”for UL Commercial Burg. installations
✱29 LONG RANGE RADIO OUTPUT [0] 0 = disable; 1 = enable
ZONE SOUNDS AND TIMING (✱31 – ✱39)
✱31 SINGLE ALARM SOUNDING per ZONE [0] 0 = no UL: must be “0”; 1 = yes
✱32 FIRE ALARMSOUNDER TIMEOUT [0] 0 = sounder stops at timeout;
1 = no sounder timeout UL: must be “1” for fire install.
✱33 ALARM SOUNDER (BELL) TIMEOUT [1] 0 = none; 1 = 4 min; 2 = 8 min; 3 =12 min; 4 = 16 min;
UL: For residential fire alarm installation, must be set for a
minimum of 4 min (option 1); for UL Commercial Burglary
installations, must be minimum 16 min (option 4)
✱34 EXIT DELAY | | [60,60]
Part. 1 Part. 2
00 - 96 = 0 - 96 secs; 97 = 120 secs
SIA Installations: minimum exit delay is 45 seconds
UL: see inst. instr. for requirements.
Common zones use same delay as partition 1.
✱35 ENTRY DELAY #1 (zone type 01) | | [30,30]
Part. 1 Part. 2
Common zones use same
delay as partition 1.
00 - 96 = 0 - 96 seconds
97 = 120 seconds SIA Installations:
98 = 180 seconds minimum entry delay is
99 = 240 seconds 30 seconds
For UL Residential Burglary Alarm installations, must be set
for a maximum of 30 seconds; entry delay plus dial delay
should not exceed 1 min. For UL Commercial Burglar Alarm,
total entry delay may not exceed 45 seconds.
✱36 ENTRY DELAY #2 (zone type 02) | | [30,30]
Part. 1 Part. 2
See *35 Entry Delay 1 above for entries.
∗37 AUDIBLE EXIT WARNING [1] 0 = no; 1 = yes
SIA Installations: must be enabled (enter 1)
✱38 CONFIRMATION OF ARMING DING [0,0]
Part. 1 Part. 2
0 = no; 1 = yes (wired keypads and RF)
2 = yes, RF only
UL: must be “1” for UL Commercial Burglar Alarm inst.
✱39 POWER UP IN PREVIOUS STATE [1] 0 = no; 1 = yes UL: must be “1”
DIALER PROGRAMMING (✱40 – ✱42)
Do not fill unused spaces. Enter 0–9; #+11 for '✱'; #+12 for '#'; #+13 for a 2-second pause. If fewer than the maximum digits entered, exit the
field by pressing [✶]. The next data field number is displayed.
✱40 PABX ACCESS CODE | | | | | Enter up to 6 digits. To clear entries, press ✱40✱. If call waiting
used, enter “∗(#+11) 70”plus “# + 13”(pause).
✱41 PRIMARY PHONE No. | | | | | | | | | | | | | | | | | | |
✱42 SECOND PHONE No. | | | | | | | | | | | | | | | | | | |
Enter up to 20 digits. To clear entries, press ✱41✱or ✱42✱respectively.
www.PDF-Zoo.com

– 4–
NOTE: Entry of a number other than one specified will give unpredictable results.
For fields *43- *46: Enter 0–9; #+11 for B; #+12 for C; #+13 for D; #+14 for E; #+15 for F. Enter [✱]as the fourth digit if a 3-digit account number (for 3+1 dialer
reporting format) is used. Enter 0 as the first digit of a 4-digit account number for Nos. 0000-0999. Exit field by pressing ✱if only 3 digits are used. E.g., For Acct.
B234, enter: #+11| 2 | 3 | 4
✱43 PARTITION 1 PRIMARY ACCT. No. | | | / | | | | | Enter 4 or 10 digits, depending on selection in *48 Report
Format. See box above. To clear entries, press *43*. [FFFF]
✱44 PART. 1 SECONDARY ACCT. No. | | | / | | | | | Enter 4 or 10 digits, depending on selection in *48 Report
Format. See box above. To clear entries, press *44*. [FFFF]
✱45 PARTITION 2 PRIMARY ACCT. No. | | | / | | | | | Enter 4 or 10 digits, depending on selection in *48 Report
Format. See box above. To clear entries, press *45*. [FFFF]
✱46 PARTITION 2 SECONDARY ACCT.
No.
| | | / | | | | | Enter 4 or 10 digits, depending on selection in *48 Report
Format. See box above. To clear entries, press *46*. [FFFF]
✱47 PHONE SYSTEM SELECT [1] If Cent. Sta.
IS NOT
on a WATS line:
0=Pulse Dial; 1=Tone Dial;
if Cent. Sta.
IS
on a WATS line:
2 = Pulse Dial ; 3 = Tone Dial
✱48 REPORT FORMAT [77]
primary secondary
0 = 3+1, 4+1 ADEMCO L/S STANDARD
1 = 3+1, 4+1 RADIONICS STANDARD
2 = 4+2 ADEMCO L/S STANDARD
3 = 4+2 RADIONICS STANDARD
5 = 10-digit ADEMCO CONTACT ID®REPORTING
6 = 4+2 ADEMCO EXPRESS
7 = 4-digit ADEMCO CONTACT ID®REPORTING
8 = 3+1, 4+1 ADEMCO L/S EXPANDED
9 = 3+1, 4+1 RADIONICS EXPANDED
✱49 SPLIT/DUAL REPORTING [0] 0 = Standard/backup reporting only (all to primary)
Primary Phone No. 2nd Phone No.
1 = Alarms, Restore, Cancel Others
2 = All except Open/Close, Test Open/Close, Test
3 = Alarms, Restore, Cancel All
4 = All except Open/Close, Test All
5 = All All
✱50 BURGLARY DIALER DELAY [2] 0 = no delay UL: must be “0”
1 = 15 seconds SIA Installations: delay
2 = 30 seconds must be minimum of
3 = 45 seconds 30 seconds
✱53 SESCOA/RADIONICS SELECT [0] 0 = Radionics (0-9, B-F)
1 = SESCOA (0-9 only reporting)
Select “0” for all other formats.
✱54 DYNAMIC SIGNALING DELAY [0] Select delay from 0 to 225 secs, in 15-sec increments.
0 = no delay (both signals sent), 1 = 15 secs,
2 = 30 secs, etc.
UL: Grade AA must be “0;”Grade A must be “15”max
✱55 DYNAMIC SIGNALING PRIORITY [0] 0 = Primary Dialer first; 1 = Long Range Radio first.
For UL Commercial Burglary installations that use a
DACT and LRR, this field must be “0”.
✱56, *57, *58 MENU MODES These are Menu Mode commands, not data fields, for Zone Programming, Function
Key Programming, and Expert Mode Zone Programming respectively. See page 2 and
their respective sections in the Installation and Setup Guide for procedures.
TO PROGRAM SYSTEM STATUS, & RESTORE REPORT CODES (✱59 – ✱76, & ✱89):
For 3+1 or 4+1 Standard Format: Enter a code in the
first
box: 1–9, #+10 for 0, #+11 for B, #+12 for C, #+13 for D, #+14 for E, #+15 for F.
A 0 (
not
#+10) in the
first
box will disable a report. A 0 (
not
#+10) in the
second
box will result in automatic advance to the next field.
For Expanded or 4+2 Format: Enter codes in
both
boxes (1st and 2nd digits) for 1–9, 0, or B–F, as described above.
A 0 (
not
#+10) in the
second
box will eliminate the expanded message for that report. A 0 (
not
#+10) in
both
boxes will disable the report.
For Ademco Contact ID®Reporting: Enter any digit (other than 0) in the
first
box, to enable zone to report (entries in the
second
boxes are ignored).
A 0 (
not
#+10) in the
first
box disables the report. UL: see installation instructions for requirements
SYSTEM STATUS REPORT CODES (✱59–✱68)
✱59 EXIT ERROR REPORT CODE [0] See box above.
✱60 TROUBLE REPORT CODE | [00] See box above.
✱61 BYPASS REPORT CODE | [00] See box above.
✱62 AC LOSS REPORT CODE | [00] See box above.
✱63 LOW BAT REPORT CODE | [00] See box above.
✱64 TEST REPORT CODE | [00] See box above. Use Scheduling mode to set periodic test reports,
or use the following key commands:
Each mode sets schedule 32 (VISTA-20P) or installer code +[#] + [0] + 0 = test report sent every 24 hours
schedule 08 (VISTA-15P) to the stated installer code +[#] + [0] + 1 = test report sent once per week
repeat option; first test report sent 12 hours after command. installer code +[#] + [0] + 2 = test report sent every 28 days
www.PDF-Zoo.com

– 5–
✱65 OPEN REPORT CODE [0,0,0] See box above.
Part. 1 Part. 2 Common
✱66 ARM AWAY/STAY RPT CODE [0,0,0,0,0,0] See box above.
Away Stay Away Stay Away Stay
Part. 1 Part. 2 Common
✱67 RF XMTR LOW BAT REPORT CODE | [00] See box on previous page.
UL: must be enabled if wireless devices are used
✱68 CANCEL REPORT CODE | [00] See box on previous page.
RESTORE REPORT CODES (✱70 – ✱76)
✱70 ALARM RESTORE RPT CODE [0] See box on previous page.
✱71 TROUBLE RESTORE RPT CODE | [00] See box on previous page.
✱72 BYPASS RESTORE RPT CODE | [00] See box on previous page.
✱73 AC RESTORE RPT CODE | [00] See box on previous page.
✱74 LOW BAT RESTORE RPT CODE | [00] See box on previous page.
✱75 RF XMTR LO BAT RST RPT CODE | [00] See box on previous page.
UL: must be enabled if wireless devices are used
✱76 TEST RESTORE RPT CODE | [00] See box on previous page.
OUTPUT AND SYSTEM SETUP (✱77 – ✱93)
✱77 DAYLIGHT SAVINGS TIME
START\END MONTH | [4][10] 0 = Disabled
1-12 = January-September (1 = Jan, 2 = Feb, etc)
#+10 = October; #+11 = November; #+12 = December
✱78 DAYLIGHT SAVINGS TIME
START\END WEEKEND | [1][5] 0 = disabled, 1 = first, 2 = second, 3 = third
4 = fourth, 5 = last, 6 = next to last, 7 = third to last
∗79, *80, *81, *82 MENU MODES These are Menu Mode commands, not data fields, for Output Device Mapping, Output
Programming, Zone List Programming, and Alpha Programming respectively. See
page 2 and their respective sections in the Installation and Setup Guide for procedures.
✱84 AUTO STAY ARM [3] 0 = no, 1 = partition 1 only
2 = partition 2 only, 3 = both partitions
✱85 CROSS ZONE TIMER
This option not for use in UL installations.
[0]
(assign cross zones on
zone list 4, using *81 Menu
mode)
0 = 15 seconds 6 = 2-1/2 min #+12 = 8 min
1 = 30 seconds 7 = 3 min #+13 = 10 min
2 = 45 seconds 8 = 4 min #+14 = 12 min
3 = 60 seconds 9 = 5 min #+15 = 15 min
4 = 90 seconds #+10 = 6 min
5 = 2 minutes #+11 = 7 min
✱86 CANCEL VERIFY [1] 0 = no, 1 = yes
✱87 MISC. FAULT DELAY TIME
(used with Configurable Zone Types “digit 6”) [0] 0 = 15 seconds 6 = 2-1/2 min #+12 = 8 min
1 = 30 seconds 7 = 3 min #+13 = 10 min
2 = 45 seconds 8 = 4 min #+14 = 12 min
3 = 60 seconds 9 = 5 min #+15 = 15 min
4 = 90 seconds #+10 = 6 min
5 = 2 minutes #+11 = 7 min
UL: may only be used on non-burglar alarm/ non-fire alarm
zones when used in fire and/or UL burglar alarm installation
✱88 PROGRAM MODE LOCKOUT
OPTIONS [0] 0 = standard *98 installer code lockout (reentry only by
[∗] + [#] within 50 seconds after power up)
1 = lockout [∗] + [#] reentry after *98 exit (reenter via
installer code only)
2 = not used
3 = lockout all local programming after *98 exit (reentry
via downloader only)
✱89 EVENT LOG FULL REPORT CODE | [00] See box on previous page for report code entries.
✱90 EVENT LOG ENABLES [3]
NOTE
:
System messages are
logged when any non-zero
selection is made.
0 = None; 1 = Alarm/Alarm Restore
2 = Trouble/Trouble Restore;
4 = Bypass/Bypass Restore;
8 = Open/Close.
Example:
To select “Alarm/Alarm
Restore”, and “Open/Close”, enter 9 (1 + 8); To select
all, enter #15.
✱91 OPTION SELECTION [8] 0 = None
4 = AAV UL: do not use AAV
8 = Exit Delay Restart/Reset UL: must be disabled
SIA Installations: Exit Delay should be enabled.
Multiple choice example: for AAV (4) + Exit Delay
restart (8) enter # + 12.
www.PDF-Zoo.com

– 6–
✱92 PHONE LINE MONITOR ENABLE
UL: see Inst. Instructions for requirements
[0,0]
12
NOTE: Output Device must
either be programmed to be
STOPPED in field ✱80 or
STOPPED by Code + # + 8 +
output number.
Entry 1:: 0 = disabled, 1-15 = 1 min - 15 min
(#+10 = 10 min; #+11 = 11 min; #+12 = 12 min;
#+13 = 13 min; #+14 = 14 min; #+15 = 15 min)
Entry 2:
0 = Keypad display when line is faulted
1 = Keypad display plus keypad trouble sound
2 = Same as “1”, plus programmed output device
STARTS. If either partition is armed, external
sounder activates also.
✱93 No. OF REPORTS IN ARMED PERIOD
PER ZONE (Swinger Suppression) [1] 0 = Unlimited Reports; 1 = 1 report; 2 = 2 reports
UL: must be “0”
DOWNLOAD INFORMATION (✱94, ✱95)
✱94 DOWNLOAD PHONE No. | | | | | | | | | | | | | | | | | | |
Enter up to 20 digits, 0–9; #+11 for '✱'; #+12 for '#'; #+13 for a 2-second pause. Do not fill unused
spaces. If fewer than 20 digits, exit field by pressing ✱. To clear entries from field, press ✱94✱.
UL: downloading may be performed only if a technician is at the site.
✱95 RING COUNT FOR DOWNLOADING [15]
NOTE: Do not enter “0” if using
4285/4286 Phone Module.
0 = Disable Station Initiated Download;
1–14 = number of rings (1–9, # +10 =10, # +11 =11,
# +12 =12, # +13 =13, # +14 =14);
15 = answering machine defeat (# +15 =15).
∗96, ∗97 INITIALIZE/RESET DEFAULTS These are commands, not data fields. See page 2.
∗98, *99 EXIT COMMANDS These are commands, not data fields. See page 2.
PAGER OPTIONS (✱160- ✱172)
✱160 PAGER 1 PHONE No. | | | | | | | | | | | | | | | | | | |
Enter up to 20 digits. 0–9; #+11 = '✱'; #+12 = '#'; #+13 = 2-second pause.
✱161 PAGER 1 CHARACTERS | | | | | | | | | | | | | | |
Enter the optional prefix characters, up to 16 digits.
0–9; #+11 = '✱'; #+12 = '#'; #+13 = 2-second pause.
✱162 PAGER 1 REPORTING OPTIONS
Part. 1 Part. 2 common
[0,0,0]
For each partition, select from the following options:
0 = no reports sent
1 = Open/closes all users
4 = All alarms and troubles
5 = All alarms / troubles, and open/closes for all users
12 = Alarms / troubles for zones entered in zone list 9
13 = Alarms / troubles for zones entered in zone list 9,
and open/closes for all users
✱163 PAGER 2 PHONE No. | | | | | | | | | | | | | | | | | | |
Enter up to 20 digits. 0–9; #+11 = '✱'; #+12 = '#'; #+13 = 2-second pause.
✱164 PAGER 2 CHARACTERS | | | | | | | | | | | | | | |
Enter the optional prefix characters, up to 16 digits.
0–9; #+11 = '✱'; #+12 = '#'; #+13 = 2-second pause.
✱165 PAGER 2 REPORTING OPTIONS [0,0,0]
Part. 1 Part. 2 common
See field *162 for reporting options. Select for each
partition (use zone list 10 if using options 12 or 13).
✱166 PAGER 3 PHONE No. | | | | | | | | | | | | | | | | | | |
Enter up to 20 digits. 0–9; #+11 = '✱'; #+12 = '#'; #+13 = 2-second pause.
✱167 PAGER 3 CHARACTERS | | | | | | | | | | | | | | |
Enter the optional prefix characters, up to 16 digits.
0–9; #+11 = '✱'; #+12 = '#'; #+13 = 2-second pause.
✱168 PAGER 3 REPORTING OPTIONS 0,0,0]
Part. 1 Part. 2 common
See field *162 for reporting options. Select for each
partition (use zone list 11 if using options 12 or 13).
✱169 PAGER 4 PHONE No. | | | | | | | | | | | | | | | | | | |
Enter up to 20 digits. 0–9; #+11 = '✱'; #+12 = '#'; #+13 = 2-second pause.
✱170 PAGER 4 CHARACTERS | | | | | | | | | | | | | | |
Enter the optional prefix characters, up to 16 digits.
0–9; #+11 = '✱'; #+12 = '#'; #+13 = 2-second pause.
✱171 PAGER 4 REPORTING OPTIONS [0,0,0]
Part. 1 Part. 2 common
See field *162 for reporting options. Select for each
partition (use zone list 12 if using options 12 or 13).
✱172 PAGER DELAY OPTION FOR ALARMS [3] 0 = none, 1 = 1 minute, 2 = 2 minutes, 3 = 3 minutes
This delay is for ALL pagers in the system.
NOTE: The delay does not reset for new alarms
occurring while an existing pager delay is in progress.
www.PDF-Zoo.com

– 7–
MISCELLANEOUS SYSTEM FIELDS (*174-*181)
✱174 CLEAN ME REPORTING OPTIONS
(for ESL smoke detectors) [0] 0 = disable; 1 = Clean Me signal reports;
Note:
If Clean Me is enabled, you must enter “3” in
field ✱56 programming for zone 1 response time.
✱177 DEVICE DURATION 1, 2
(used in *80 Menu mode-Device Actions 5/6) [0] [0]
1 2
0 = 15 seconds 6 = 2-1/2 min #+11 = 7 min
1 = 30 seconds 7 = 3 min #+12 = 8 min
2 = 45 seconds 8 = 4 min #+13 = 10 min
3 = 60 seconds 9 = 5 min #+14 = 12 min
4 = 90 seconds #+10 = 6 min #+15 = 15 min
5 = 2 minutes
✱181 50/60 HERTZ AC OPERATION [0] 0 = 60 Hz; 1 = 50 Hz
CONFIGURABLE ZONE TYPE OPTIONS (*182-*185)
✱182 CONFIGURABLE ZONE TYPE 90
12345678910
Enter the appropriate value for each entry, 1-10, based on the charts provided on the
next page. Each entry is the sum of the values of its selected options
(0-9, #+10=10, #+11=11, #+12=12, #+13=13, #+14=14, #+15=15).
UL: Do not configure zones as a fire alarm or UL burglar alarm zone.
✱183 ZONE TYPE 90 REPORT CODES
IMPORTANT: Use existing Contact ID®
codes, if appropriate, or define unique codes
in CID code range 750-789. See important
note in installation instructions.
90 ALARM ID: XXX
TROUBLE ID: XXX
Enter the desired 3-digit Contact ID®report codes for
alarms and troubles occurring on zones assigned to
this zone type. Enter the codes sequentially (all 6
digits). When entering digits, [#] moves cursor back, [∗]
moves forward. Press [∗] when done to continue.
✱184 CONFIGURABLE ZONE TYPE 91
12345678910
Enter the appropriate value for each entry, 1-10, based on the charts provided on the
next page. Each entry is the sum of the values of its selected options
(0-9, #+10=10, #+11=11, #+12=12, #+13=13, #+14=14, #+15=15).
UL: Do not configure zones as a fire alarm or UL burglar alarm zone.
✱185 ZONE TYPE 91 REPORT CODES
IMPORTANT: Use existing Contact ID®
codes, if appropriate, or define unique codes
in CID code range 750-789. See important
note in installation instructions.
91 ALARM ID: XXX
TROUBLE ID: XXX
Enter the desired 3-digit Contact ID®report codes for
alarms and troubles occurring on zones assigned to
this zone type. Enter the codes sequentially (all 6
digits). When entering digits, [#] moves cursor back, [∗]
moves forward. Press [∗] when done to continue.
SYMPHONY (AUI) ENABLE
✱189 Symphony (AUI) ENABLE
(VISTA-20PS Only) [0] [0]
AUI 1 AUI 2
Enter each AUI’s home partition.
0 = disabled
1 = partition 1; 2 = partition 2; 3 = partition 3 (common)
NOTE: A minimum of one standard keypad must also be
installed when AUI is used.
KEYPAD OPTIONS *190-*196 (NOTE: Options for keypad address 16 are set by the factory and cannot be changed.)
NOTE: Each keypad must be assigned a unique address. Keypads programmed with the same address will give
unpredictable results.
✱190 KEYPAD 2 DEVICE ADDRESS 17 [0] [0]
Partition/ Sound
Enable†
†VISTA-20P: enter partition
VISTA-15P: 1 = enable
0 = disable
Partition: 0 = keypad disabled; 1-3 = part. no. (3 = com)
Sound: 0 = no suppression
1 = suppress arm/disarm and E/E beeps
2 = Suppress chime beeps only
3 = suppress arm/disarm, E/E, and chime
beeps
Part./Enable†Sound
✱191 KEYPAD 3 DEVICE ADDRESS 18 [0] [0] See field ∗190 for entries.
✱192 KEYPAD 4 DEVICE ADDRESS 19 [0] [0] See field ∗190 for entries.
✱193 KEYPAD 5 DEVICE ADDRESS 20 [0] [0] See field ∗190 for entries.
✱194 KEYPAD 6 DEVICE ADDRESS 21 [0] [0] See field ∗190 for entries.
✱195 KEYPAD 7 DEVICE ADDRESS 22 [0] [0] See field ∗190 for entries.
✱196 KEYPAD 8 DEVICE ADDRESS 23 [0] [0] See field ∗190 for entries.
✱197 EXIT TIME DISPLAY INTERVAL [0] 0 = no display; 1-5 = seconds between display refresh
✱198 DISPLAY PARTITION NUMBER
(for Alpha Display Keypads)
[0] 0 = no; 1 = yes (partition no. appears on Alpha Display)
✱199 ECP FAIL DISPLAY [0] 0 = 3-digit display (“1” + device address)
1 = 2-digit fixed-display as “91”
www.PDF-Zoo.com

– 8–
Configurable Zone Types Worksheets
Configurable zone types 90 and 91 can be programmed via downloader software or from a keypad using data
fields*182-*185. Configurable zone types 92 and 93 (VISTA-20P only) can only be programmed using the
downloader software.
Programming Configurable Zone Type options involves making 10 entries in data field *182 for zone type 90 and
field *184 for zone type 91, where each entry represents the sum of the values of the various options shown in the
tables below. Use fields *183 and *185 to program Contact ID report codes for these zone types.
ENTRY 1 (See note 5 for RF zones) ENTRY 2 (See note 5 for RF zones)
Response when system disarmed and zone is:
Intact EOL
RF zone normal
Open
RF zone N/A
Shorted
RF zn off-normal
Auto
Restore Vent Zone
0 = normal
1 = alarm
2 = trouble
3 = fault
0 = normal
4 = alarm
8 = trouble
12 = fault
0 = normal
1 = alarm
2 = trouble
3 = fault
0 = no
4 = yes 0 = no 8 = yes
Entry 1 = EOL + Open Entry 2 = Short + auto restore + vent zone
ENTRY 3 (See note 5 for RF zones) ENTRY 4 (See note 5 for RF zones)
Response when armed STAY and zone is:
Intact EOL
RF zone normal
Open
RF zone N/A
Shorted
RF zn off-normal
Byp. when
disarmed Byp. when armed
0 = normal
1 = alarm
2 = trouble
3 = fault
0 = normal
4 = alarm
8 = trouble
12 = fault
0 = normal
1 = alarm
2 = trouble
3 = fault
0 = no
4 = yes 0 = no 8 = yes
Entry 3 = EOL + Open Entry 4 = Short + byp. disarmed + byp. armed
ENTRY 5 (See note 5 for RF zones) ENTRY 6 (See note 5 for RF zones)
Response when armed AWAY and zone is:
Intact EOL
RF zone normal
Open
RF zone N/A
Shorted
RF zn off-normal
Dial Delay
(see field *50) Fault Delay (see field *87)
0 = normal
1 = alarm
2 = trouble
3 = fault
0 = normal
4 = alarm
8 = trouble
12 = fault
0 = normal
1 = alarm
2 = trouble
3 = fault
0 = no
4 = use delay 0 = no 8 = use delay
see note 1
Entry 5 = EOL + Open Entry 6 = Short + dial delay + fault delay
ENTRY 7 ENTRY 8
Display Faults Power Reset/
Verification Use Entry Delay 1/2 Use Exit Delay Respond as Interior Type
0 = show alarms
when armed
& disarmed
1 = don’t show
alarms when
armed (show
alarms, trbles,
faults when
disarmed)
3 = never show
any alarms,
trbles, faults
0 = no
4 = power reset
after fault
(by code + OFF)
12 = verification
(see zone
type 16)
0 = no
1 = delay 1
2 = delay 2
0 = no
4 = use exit
delay
0 = no
8 = yes
see note 2
Entry 7 = fault display + power
reset/verification Entry 8 = entry delay 1/entry delay 2 + exit delay + interior zone type
ENTRY 9 ENTRY 10
Alarm Sounds Use Bell
Timeout Respond as Fire Zone Trouble Sounds Chime when Chime Mode On
0 = none
1 = steady
keypad
2 = steady bell
and keypad
3 = pulsing bell
and keypad
0 = no
4 = yes
see fields *32,
*33
0 = no
8 = yes
see zone type
09; see note 4
0 = none
1 = periodic
beep
2 = trouble
beeps
0 = no
4 = yes
Entry 9 = alarm sounds + bell timeout + fire zone Entry 10 = trouble sounds + chime
Entries for Fields *182 and *184
Entry Zone Type 90 Zone Type 91
(field *182) (field *184)
1
2
3
4
5
6
7
8
9
10
To calculate the value for each entry:
Simply add the values of the selected options
in each of the entry’s columns (one option per
column). For example, to program Entry 2 for
“alarm response to short,” “auto restore on,”
but not a “vent zone,”enter 5 (“1” for alarm
short + “4” for auto restore yes + “0” for vent
zone no).
OPEN SHORTEDINTACT
EOL
ZONE-003-V0
Zone Conditions Represented
in Entries 1-6
NOTES:
1. Do not use the “fault delay”option with a
configurable zone type if it is set for an
entry or exit delay, otherwise
unpredictable results may occur.
2. To create an interior type zone, select
“respond as interior zone type”(entry 8,
interior type = yes), and set zone
response to “fault”in entries 3-4 to ensure
fault displays; do not set as “normal,”
“alarm,”or “trouble.”
3. Do not set fire zones to respond as a
“fault”(entries 1-6), otherwise faults will
not display unless the [∗] key is pressed.
4. 4219/4229 modules must use EOLRs or
unpredictable results may occur.
5. RF Zones: The “open”option in entries 1,
3, and 5 is not applicable for RF zones.
Use the “intact EOL”option for normal RF
zone conditions and “shorted”for off-
normal RF zone conditions.
6. Zone-Doubling/Double-Balanced: A short
on either zone of a zone-doubled pair or
on a double-balanced zone causes a
tamper condition.
www.PDF-Zoo.com

– 9–
*56 ZONE PROGRAMMING WORKSHEET (VISTA-15P supports up to 32 zones: 1-6, 9-34) [default shown in brackets]
Zone Zn Type Part. Report Hardwire
Type Rsp. Time Location
1[09] [1] [EOL] [1]
2[01] [1] [EOL] [1]
3[03] [1] [EOL] [1]
4[03] [1] [EOL] [1]
5[03] [1] [EOL] [1]
6[03] [1] [EOL] [1]
7[03] [1] [EOL] [1]
8[03] [1] [EOL] [1]
Zone Zn Type Part. Report Input Type Loop Serial No. Location
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49 [1] [BR]
50 [1] [BR]
51 [1] [BR]
52 [1] [BR]
53 [1] [BR]
54 [1] [BR]
55 [1] [BR]
56 [1] [BR]
57 [1] [BR]
58 [1] [BR]
59 [1] [BR]
60 [1] [BR]
61 [1] [BR]
62 [1] [BR]
63 [1] [BR]
64 [1] [BR]
95 [00] N/A N/A N/A keypad [1] / [∗]
96 [00] N/A N/A N/A keypad [3] / [#]
99 [06] N/A N/A N/A keypad [∗] / [#]
NOTES:
Zone Type: see chart on
page 12;
Report Code: enabled if
any digit entered as 1st
digit;
Hardwire Type (zns 1-8):
0 = EOL
1 = NC
2 = NO
Input Type:
2 = AW (zones 9-48)
3 = RF (zones 9-48)
4 = UR (zones 9-48)
5 = BR (zones 49-64)
NOTE: Zones 9-16 not
available if zone
doubling enabled.
Response Time:
0 = 10msec
1 = 350msec
2 = 700msec
3 = 1.2 sec
Reserved Zones
91 = addressable device
report enable/disable
default zone type =
[05].
92 = Duress report
enable/disable
www.PDF-Zoo.com

– 10 –
*57 FUNCTION KEY PROGRAMMING
Option Function A B C D Comments
01 Paging
02 Time Display
03 Arm AWAY
04 Arm STAY
05 Arm NIGHT-STAY
06 Step Arming
07 Device Activation Device:
08 Comm. Test
09 Macro Key 1
10 Macro Key 2
11 Macro Key 3
12 Macro Key 4
00 Emergency Keys: zone 95 zone 99 zone 96 paging
Personal Emergency n/a
Silent Alarm n/a
Audible Alarm n/a
Fire n/a
Emergency Keys: A = paired keys [1] / [∗] (zone 95); B = paired keys [∗] / [#] (zone 99); C = paired keys [3] / [#] (zone 96)
OUTPUT RELAYS/POWERLINE CARRIER DEVICES WORKSHEET FOR ∗79, ∗80 and ∗81.
Applicable only if Relays and/or Powerline Carrier Devices are to be used.
∗79 RELAY/POWERLINE CARRIER DEVICE MAPPING (Must program before using *80)
OUTPUT TYPE OUTPUT TYPE (09-16 apply to VISTA-20P only)
Relay X10 Relay X10
Output
No. Module Addr. Pos
(1-4) Unit
No. Description Output No. Module Addr. Pos
(1-4) Unit
No. Description
01 09
02 10
03 11
04 12
05 13
06 14
07 15
08 16
17 On-Board Trigger 1 norm output =
18 On-Board Trigger 2 norm output =
✱81 ZONE LISTS FOR OUTPUT DEVICES
Fill in the required data on the worksheet below and follow the procedure in the installation manual as you enter the
data during the displays and prompts that appear in sequence.
NOTE: Record desired zone numbers below, noting that a list may include
any
or
all
of system's zone numbers.
List No. Used For…Contains These Zones…
01 General Purpose (GP)
02 General Purpose
03 Chime-by-Zone or GP
04 Cross Zones
05 Night-Stay Zones or GP
06 General Purpose
07 General Purpose
08 General Purpose
09 Zones activating pager 1
10 Zones activating pager 2
11 Zones activating pager 3
12 Zones activating pager 4
www.PDF-Zoo.com

– 11 –
✱80 OUTPUT DEFINITIONS
Fill in the required data on the worksheet below and follow the programming procedure in the installation manual as you
enter the data during the displays and prompts that appear in sequence.
Notes:
1. For Relays, 4229 and 4204 devices are programmed in *79, *80, and *81 modes.
2. For Powerline Carrier devices (plcd), field ✱27 must be programmed with a House Code.
3. Tampers of expansion units cannot be used to operate devices.
Activation Type and Detail Event (for zone list/activated by)Output
Function
Number
(V20P=1-48)
(V15P=1-24)
Activated by
0=delete
1=zn list
2=zn type
3=zn no.
Zone List
(ZL)
1-8 = list
Zone Type
(ZT)
(see table
below)
Zone No.
(ZN)
00=none
01-64
Partition
Number
(P)
(if using ZT trig)
0 = any
1 = partition 1
2 = partition 2
3 = common
By Zone List
0 = restore
1 = alarm
2 = fault
3 = trouble
By Zone No.
0 = restore
1 = alrm/flt/trbl
Action
0 = off
1 = close 2 secs
2 = stay closed
3 = pulse
4 = toggle
5 = duration 1††
6 = duration 2††
Output
Number
V20P=1-18
V15P=1-8,
17, 18
Device
Type
R = relay
T = trigger
X = X10
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
ZONE TYPE/SYSTEM OPERATION –Choices for Zone Types are:
00 = Not Used 05 = Trouble Day/Alarm Night 10 = Interior w/Delay 24 = Silent Burglary
01 = Entry/Exit#1 06 = 24 Hr Silent 12 = Monitor Zone 77 = Keyswitch
02 = Entry/Exit#2 07 = 24 Hr Audible 14 = Carbon Monoxide 81 = AAV Monitor Zone
03 = Perimeter 08 = 24 Hr Aux 16 = Fire w/Verification 90-91 = Configurable
04 = Interior Follower 09 = Fire 23 = No Alarm Response
Choices for System Operation are:
20 = Arming–Stay 38 = Chime 52 = Kissoff
21 = Arming–Away 39 = Any Fire Alarm 54 = Fire Zone Reset
22 = Disarming (Code + OFF) 40 = Bypassing 58 = Duress
31 = End of Exit Time 41 = **AC Power Failure 60 = AAV Trigger
32 = Start of Entry Time 42 = **System Battery Low 66 = Function key†
33 = Any Burglary Alarm 43 = Communication Failure 67 = Bell Failure
36 = **At Bell Timeout*** 68 = TELCO Line Fault
78 = Keyswitch red LED†††
79 = Keyswitch green LED†††
Note: In normal operation mode:
Code + # + 7 + NN Key Entry starts Device
Code + # + 8 + NN Key Entry stops Device
** Use 0 (any) for Partition No. (P) entry.
*** Or at Disarming, whichever occurs earlier.
†Use *57 Menu mode to assign the function key.
†† Duration is set in program field *177.
††† Device action not used for these choices.
www.PDF-Zoo.com

– 12 –
Zone Type Definitions
Type 00
Zone Not Used
Use this zone type if the zone is not used.
Type 01
Entry/Exit Burglary #1
•Assign to zones that are used for primary entry and exit.
•Provides entry delay if the control is armed in the Away or Stay modes.
•No entry delay is provided when the panel is armed in the Instant mode.
•Entry delay #1 is programmable for each partition.
•Exit delay begins whenever the control is armed, regardless of the arming mode selected, and is
independently programmable.
Type 02
Entry/Exit Burglary #2
•Assign to zones that are used for entry and exit and require more time than the primary entry/exit point.
•Provides a secondary entry delay, in same manner as entry delay #1.
•Entry delay #2 is programmable for each partition.
•Exit delay is same as described for Type 01.
Type 03
Perimeter Burglary
•Assign to all sensors or contacts on exterior doors and windows.
•Provides an instant alarm if the zone is faulted when the panel is armed in the Away, Stay, Instant, or
Maximum modes.
Type 04
Interior Follower
•Assign to a zone covering an area such as a foyer, lobby, or hallway through which one must pass upon
entry (to and from the keypad).
•Provides a delayed alarm (using the programmed entry/exit time) if the entry/exit zone is faulted first.
Otherwise this zone type gives an instant alarm.
•Active when the panel is armed in the Away mode.
•Bypassed automatically when the panel is armed in the Stay or Instant modes.
Type 05
Trouble by Day/
Alarm by Night
•Assign to a zone that contains a foil-protected door or window (such as in a store), or to a zone covering a
sensitive area such as a stock room, drug supply room, etc.
•Can also be used on a sensor or contact in an area where immediate notification of an entry is desired.
•Provides an instant alarm if faulted when armed in the Away, Stay, Instant or Maximum (night) modes.
•During the disarmed state (day), the system will provide a latched trouble sounding from the keypad (and a
central station report, if desired).
Type 06
24-hour Silent Alarm
•Usually assigned to a zone containing an emergency button.
•Sends a report to the central station but provides no keypad display or sounding.
Type 07
24-hour Audible Alarm
•Assign to a zone that has an emergency button.
•Sends a report to the central station, and provides an alarm sound at the keypad, and an audible external
alarm.
Type 08
24-hour
Auxiliary Alarm
•Assign to a zone containing an emergency button, or to a zone containing monitoring devices such as wate
r
or temperature sensors.
•Sends a report to the central station and provides an alarm sound at the keypad. (No bell output is
provided.)
Type 09
Fire
•Provides a fire alarm on short circuit and a trouble condition on open circuit. A fire alarm produces a
pulsing bell output.
•This zone type is always active and cannot be bypassed.
Note: Hardwired zone 1 should be used with 2-wire smoke detectors; zones 2-8 can be used with 4-wire
smoke detectors; any wireless zone can be used as a fire zone.
Type 10
Interior w/Delay
•Provides entry delay (using the programmed entry time), if tripped when the panel is armed in the Away
mode.
•Entry Delay begins whenever sensors in this zone are violated, regardless of whether or not an entry/exit
delay zone was tripped first.
•Bypassed when the panel is armed in the Stay or Instant modes.
Type 12
Monitor Zone
•Works as a dynamic monitor of a zone fault/trouble. In the case of a short/open, the message, "ALARM-
24 Hr. Non-Burg. -#XXX " (where XXX is the zone number) will be sent to the Central Station. The
system keypad will display a “check”message indicating the appropriate zone (but keypad beeping does
not occur). Upon restoral of the zone, the message, "RESTORE-24 Hr. Non-Burg. -#XXX " will be sent to
the Central Station.
•The “check”message will automatically disappear from the keypad dynamically when the zone restores; a
user code + off sequence is not needed to reset the zone.
•Faults of this zone type are independent of the system, and can exist at the time of arming without
interference.
•Since this is a “trouble”zone type, do not use this zone type with relays set to activate upon “alarm.”
Type 14
Carbon Monoxide
•Assigned to any zone with a carbon monoxide detector.
•The bell output will pulse when this zone type is alarmed.
•Always active and cannot be bypassed.
Type 16
Fire w/Verification
•Provides a fire alarm when zone is shorted, but only after alarm verified.
•System verifies alarm by resetting zones for 12 seconds after short is detected. A subsequent short circuit
within 90 seconds triggers fire alarm.
•Provides a trouble response when zone is open.
Type 20
Arm-Stay
•Arms the system in Stay mode when the zone is activated.
•Pushbutton units send the user number to the central station when arming or disarming.
•User code for button must be assigned.
www.PDF-Zoo.com

– 13 –
Type 21
Arm-Away
•Arms the system in Away mode when the zone is activated.
•Pushbutton units send the user number to the central station when arming or disarming.
•User code for button must be assigned.
Type 22
Disarm
•Disarms the system when the zone is activated.
•User code for button must be assigned.
Type 23*
No Alarm Response
•Can be used on a zone when an output relay action is desired, but with no accompanying alarm (e.g.,
lobby door access).
Type 24
Silent Burglary
•Usually assigned to all sensors or contacts on exterior doors and windows where bells and/or sirens are
NOT desired.
•Provides an instant alarm, with NO audible indication at any keypad or external sounder, if the zone is
faulted when the system is armed in the Away, Stay, Instant, or Maximum modes.
•A report is sent to the central station.
Type 77
Keyswitch
•Assign to zone wired to a keyswitch.
Type 81
AAV Monitor Zone
•Assign to zone connected to AAV module.
•Monitors 2-way voice sessions as follows:
- When the zone is faulted, all alarm sounding and dialer reporting stops, except for fire alarms,
which immediately terminate the voice session and cause a fire report to be sent.
- When the zone is restored (session ended), sounding resumes (if bell timeout has not expired)
and reports that were stopped are sent.
Types 90-93
Installer Defined
•These zone types can be programmed for various custom responses. See data fields *182-*185.
•Types 92 and 93 can only be programmed via the downloader.
UL: Zone types 90-93 may not be used as fire or burglar zones in fire or UL burglar alarm installations.
*The system can still be armed when these zone types are in a faulted condition.
Schedules (installer code + [#] + [6] [4];
master code can only access schedules 01-16 for VISTA-20P, 01-04 for VISTA-15P, and
events 00-07 for both controls; VISTA-15P supports up to 8 schedules, VISTA-20P supports up to 32 schedules
)
No. Event Device No. Group No. Partition Start Time/ Stop Time/ Repeat Random
(see list below) for “01”events: for “02”events: for “04-06”events: Days Days (yes/no) (yes/no)
enter 01-18 enter 1-8 enter 1, 2, or 3
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
Events: Master/Installer Installer Only
00 = clear event 04 = forced STAY arm 10 = display custom words 8-10
01 = device on/off 05 = forced AWAY arm 11 = periodic test report
02 = user access 06 = auto disarm
03 = latch key report 07 = display “reminder”
www.PDF-Zoo.com

– 14 –
ALPHA VOCABULARY LIST (For Entering Zone Descriptors)
000
(Word Space)
–A –
•001 AIR
•002 ALARM ∗
004 ALLEY
005 AMBUSH
•006 AREA
•007 APARTMENT
•009 ATTIC ∗
010 AUDIO
–B –
•012 BABY ∗
•013 BACK ∗
•014 BAR
•016 BASEMENT ∗
•017 BATHROOM ∗
•018 BED
•019 BEDROOM ∗
020 BELL
•021 BLOWER
•022 BOILER
023 BOTTOM
025 BREAK
•026 BUILDING
–C –
028 CABINET
•029 CALL
030 CAMERA
031 CAR
033 CASH
034 CCTV
035 CEILING
036 CELLAR
•037 CENTRAL
038 CIRCUIT
•040 CLOSED ∗
•046 COMPUTER
047 CONTACT
–D –
•048 DAUGHTERS
049 DELAYED
•050 DEN ∗
051 DESK
•052 DETECTOR ∗
•053 DINING ∗
054 DISCRIMINATOR
055 DISPLAY
•057 DOOR ∗
•059 DOWN
•060 DOWNSTAIRS
061 DRAWER
•062 DRIVEWAY
•064 DUCT
–E –
•065 EAST
066 ELECTRIC
067 EMERGENCY ∗
068 ENTRY
•069 EQUIPMENT
•071 EXIT ∗
072 EXTERIOR
–F –
•073 FACTORY
075 FAMILY
•076 FATHERS
•077 FENCE
•079 FIRE ∗
•080 FLOOR ∗
081 FLOW
082 FOIL
•083 FOYER
084 FREEZER
•085 FRONT ∗
–G –
•089 GARAGE ∗
•090 GAS
091 GATE
•092 GLASS
093 GUEST
094 GUN
– H –
•095 HALL ∗
•096 HEAT
098 HOLDUP
099 HOUSE
100 INFRARED
•101 INSIDE ∗
102 INTERIOR
103 INTRUSION
–J –
104 JEWELRY
–K –
•105 KITCHEN ∗
–L –
•106 LAUNDRY ∗
•107 LEFT
108 LEVEL
•109 LIBRARY ∗
•110 LIGHT
111 LINE
•113 LIVING ∗
•114 LOADING
115 LOCK
116 LOOP
117 LOW
•118 LOWER
–M –
•119 MACHINE
121 MAIDS
122 MAIN ∗
•123 MASTER ∗
•125 MEDICAL ∗
126 MEDICINE
128 MONEY
129 MONITOR
•130 MOTHERS
•131 MOTION ∗
132 MOTOR
–N –
•134 NORTH
135 NURSERY
–O –
•136 OFFICE ∗
•138 OPEN ∗
139 OPENING
•140 OUTSIDE
142 OVERHEAD
–P –
143 PAINTING
•144 PANIC ∗
145 PASSIVE
•146 PATIO ∗
147 PERIMETER
•148 PHONE
150 POINT
151 POLICE ∗
152 POOL ∗
•153 POWER
–R –
155 RADIO
•156 REAR
157 RECREATION
159 REFRIGERATION
160 RF
•161 RIGHT
•162 ROOM ∗
163 ROOF
–S –
164 SAFE
165 SCREEN
166 SENSOR
•167 SERVICE
•168 SHED ∗
169 SHOCK
•170 SHOP ∗
171 SHORT
•173 SIDE ∗
174 SKYLIGHT
175 SLIDING ∗
•176 SMOKE ∗
•178 SONS
•179 SOUTH
180 SPRINKLER
•182 STATION
184 STORE
•185 STORAGE ∗
186 STORY
190 SUPERVISED ∗
191 SUPERVISION
192 SWIMMING
193 SWITCH
–T –
194 TAMPER
196 TELCO
197 TELEPHONE
•199 TEMPERATURE
200 THERMOSTAT
•201 TOOL
202 TRANSMITTER
–U –
•205 UP
•206 UPPER
•207 UPSTAIRS ∗
•208 UTILITY ∗
–V –
209 VALVE
210 VAULT
212 VOLTAGE
–W –
213 WALL
214 WAREHOUSE
•216 WEST
•217 WINDOW ∗
•219 WING
220 WIRELESS
–X –
222 XMITTER
–Y –
223 YARD
–Z –
224 ZONE (No.)
•225 ZONE ∗
•226 0
•227 1
•228 1ST ∗
•229 2
•230 2ND ∗
•231 3
•232 3RD ∗
•233 4
•234 4TH
•235 5
•236 5TH
•237 6
•238 6TH
•239 7
•240 7TH
•241 8
•242 8TH
•243 9
•244 9TH
245 Custom Word #1
246 Custom Word #2
247 Custom Word #3
248 Custom Word #4
249 Custom Word #5
250 Custom Word #6
251 Custom Word #7
252 Custom Word #8
253 Custom Word #9
254 Custom Word #10
Note: Bulleted (•) words in boldface type are those that are also available for use by the 4285/4286 Phone Module. If
using a Phone module, and words other than these are selected for Alpha descriptors, the module will not provide
annunciation of those words.
Italicized
words followed by an asterisk indicate those words supported by the 6160V/6150V Voice Keypads
CHARACTER (ASCII) CHART (For Adding Custom Words)
32 (space)
33 !
34 "
35 #
36 $
37 %
38 &
39 '
40 (
41 )
42 *
43 +
44 ,
45 –
46 .
47 /
48 0
49 1
50 2
51 3
52 4
53 5
54 6
55 7
56 8
57 9
58 :
59 ;
60 <
61 =
62 >
63 ?
64 @
65 A
66 B
67 C
68 D
69 E
70 F
71 G
72 H
73 I
74 J
75 K
76 L
77 M
78 N
79 O
80 P
81 Q
82 R
83 S
84 T
85 U
86 V
87 W
88 X
89 Y
90 Z
www.PDF-Zoo.com

– 15 –
5800 Series Transmitter Input Loop Identification
All of the transmitters illustrated below have one or more unique factory assigned input (loop) ID codes.
Each of the
inputs requires its own programming zone
(e.g., a 5804's four inputs require four programming zones).
WIRELESS INPUT TYPES
"RF" (Supervised RF) Type send periodic check-in
si
g
nals, as well as fault, restore and low battery si
g
nals.
The transmitter must remain within the receiver's range.
“UR" (Unsupervised RF) Type send all the signals that
the "RF" Type does, but the control does not supervise
the check-in si
g
nals. The transmitter may, therefore, be
carried off-premises.
"BR" (Unsupervised Button RF) Type only send fault
si
g
nals. They do not send restore or check-in si
g
nals.
They will indicate a low battery condition when tested or
activated normally. They can be carried off-premises.
Note: For information on any transmitter not shown
above, refer to the instructions accompanyin
g
that
transmitter for details regarding loop numbers, etc.
UL NOTE: The following transmitters are not intended for
use in UL installations: 5802MN, 5802MN2, 5804, 5804BD,
5814, 5816TEMP, 5819, 5819WHS & BRS, and 5850.
The 5827BD and 5800TM can be used in UL Listed
Residential Burglar installations.
5801
ENROLL AS "UR" OR "RF"
LOOP
1
5802MN
ENROLL AS "UR" OR "RF"
YOU MUST
ENROLL THIS
BUTTON
LOOP 3
LOOP 1
LOOP 2
LOOP 4
LOOP
1
5808
ENROLL AS "RF"
5804
ENROLL
AS "BR"
5817
ENROLL AS "RF"
LOOP
1
(PRIMARY)
2
(AUX. CENTER)
3
(AUX. RIGHT)
LOOP
1
(MOTION)
5890
ENROLL AS "RF"
5816
ENROLL AS "RF"
LOOP
2
(REED)
LOOP 1
(TERMINALS)
5827
SET HOUSE CODE 5827BD
SET HOUSE CODE
5816MN
ENROLL AS "RF"
LOOP
2
(REED)
LOOP 1
(TERMINALS)
5819
ENROLL AS "RF"
LOOP
2
(REED) LOOP 1
(TERMINALS)
ALTERNATE
POSITION
FOR LOOP2
LOOP 3
(TERMINALS) 5819S (WHS & BRS)
ENROLL AS "RF"
LOOP
2
(REED)
LOOP 1
(INTERNAL
SHOCK
SENSOR)
LOOP 3
(TERMINALS)
5850 (GBD)
ENROLL AS "RF"
(Green)
(Red)
(Yellow)
5804BD
ENROLL AS "BR"
•
•
•
••
••
•
•
••
•
•
•
••
•
•
•
LOOP 3
LOOP 1
LOOP 2
LOOP 4
SET
HOUSE
CODE
YOU MUST
ENROLL THIS
BUTTON
LOOP 3
LOOP 1
LOOP 2
LOOP 4
YOU MUST
ENROLL THIS
BUTTON
LOOP
1
5809
ENROLL AS "RF"
LOOP 2
(REED)
Wireless Key Predefined Default Templates
For 5804 Loop Function Zone Type For 5804BD Loop Function Zone Type
TEMPLATE 1 1 No Response 23 TEMPLATE 4 1 No Response 23
2 Disarm 22 2 No Response 23
3 Arm Away 21 3 Arm Away 21
4 No Response 23 4 Disarm 22
TEMPLATE 2 1 No Response 23 TEMPLATE 5 1 No Response 23
2 Disarm 22 2 Arm Stay 20
3 Arm Away 21 3 Arm Away 21
4 Arm Stay 20 4 Disarm 22
TEMPLATE 3 1 24-hour audible 7 TEMPLATE 6 1 24-hour audible 7
2 Disarm 22 2 Arm Stay 20
3 Arm Away 21 3 Arm Away 21
4 Arm Stay 20 4 Disarm 22
Table of Device Addresses
This Device Uses Address Reports as†† Enabled By…
RF Receiver 00 100 *56 zone programming: input device type entry
Long Range Radio 03 103 automatic if output to long range radio field *29 enabled
4286 Voice Module 04 104 automatic if phone module access code field *28 enabled
Zone Expanders (4219/4229):
module 1 (for zones 09 - 16)
module 2 (for zones 17 - 24)
module 3 (for zones 25 - 32)
module 4 zones 33 - 40
module 5 zones 41 - 48
07
08
09**
10**
11**
107
108
109
110
111
*56 zone programming: input device type entry, then:
automatic if zone no. 9-16 entered as AW type or relay assigned
automatic if zone no. 17-24 entered as AW type or relay assigned
automatic if zone no. 25-32 entered as AW type or relay assigned
automatic if zone no. 33-40 entered as AW type or relay assigned
automatic if zone no. 41-48 entered as AW type or relay assigned
Relay Modules (4204):
module 1
module 2
module 3
module 4
12
13
14**
15**
112
113
114
115
*79 output device programming: device address prompt:
entered at device address prompt
entered at device address prompt
entered at device address prompt
entered at device address prompt
Keypads:
keypad 1
keypad 2
keypad 3
keypad 4
keypad 5
keypad 6
keypad 7
keypad 8
16
17
18
19
20
21
22
23
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
data field programming as listed below:
always enabled, all sounds enabled.
data field *190
data field *191
data field *192
data field *193
data field *194
data field *195
data field *196
5800TM Module 28 n/a automatic
** These module addresses apply to VISTA-20P only.
†† Addressable devices are identified by “1” plus the device address when reporting. Enter report code for zone 91 to enable addressable device
reporting (default = reports enabled). See field *199 for addressable device (ECP) 3-digit/2-digit identification keypad display options.
www.PDF-Zoo.com

V20P_V15P-SOC-V0
CLASS 2 PLUG-IN TRANSFORMER
16.5VAC, 25VA
(e.g. ADEMCO No. 1321).
(USE No. 1321CN IN CANADA)
TO 110VAC
UNSWITCHED
OUTLET (24HR)

+
THIS EQUIPMENT SHOULD BE INSTALLED IN ACCORDANCE WITH THE NATIONAL FIRE PROTECTION ASSOCIATION'S
STANDARD 72, CHAPTER 2 (NATIONAL FIRE PROTECTION ASSOCIATION,
BATTERY-MARCH PARK, QUINCY,MA
02269). PRINTED INFORMATION DESCRIBING PROPER INSTALLATION,
OPERATION,TESTING, MAINTENANCE, EVACUATION PLANNING AND REPAIR SERVICE IS TO BE PROVIDED WITH THIS
EQUIPMENT.
24-HR BATTERY STANDBY REQUIRED FOR FIRE INSTALLATIONS. USE 12V, 17.2AH BATTERY FOR 600mA AUX POWER. SEE INSTRUCTIONS.
BATTERY CAPACITY FOR EMERGENCY BURGLARY STANDBY USE AT LEAST 4 HRS
USE UL LISTED LIMITED ENERGY CABLE FOR ALL CONNECTIONS
USE 4300 / 1321X10 TRANSFORMER INTERFACE IN PLACE OF 1321 OR 1321CN WHEN POWER LINE CARRIER DEVICES ARE BEING USED. (SEE INSTRUCTIONS FOR CONNECTIONS)
FOR COMPLETE
INFORMATION, SEE
INSTRUCTIONS K5305-1V1
ALARM OUTPUT
10.5–13.8VDC, 2A MAX.
(600mA MAX. FOR UL
USAGE, INCLUDING
AUX POWER) STEADY
FOR BURGLARY/PANIC,
TEMPORAL PULSE
SOUNDING FOR FIRE.
CAN USE ADEMCO No. 702
SIREN, OR 12V BELL).
SEE INSTRUCTIONS.
CHARGING VOLTAGE 13.8VDC. MAXIMUM CHARGING CURRENT 650mA.
BATTERY
12V, 4AH

+

+
BLACK
RED
SEALED LEAD-ACID TYPE. BATTERY NORMALLY NEED NOT BE REPLACED FOR AT LEAST 3 YRS.
TO DETERMINE TOTAL STANDBY LOAD ON BATTERY, ADD 100mA TO TOTAL OF AUX. POWER OUTPUT AND REMOTE KEYPAD CURRENTS.
FLYING LEADS FOR BATTERY CONNECTION
CONNECTION OF THE FIRE ALARM SIGNAL TO A FIRE ALARM HEADQUARTERS OR A CENTRAL STATION
SHALL BE PERMITTED ONLY WITH THE PERMISSION OF THE LOCAL AUTHORITY HAVING JURISDICTION. THE BURGLAR ALARM SIGNAL SHALL NOT BE CONNECTED TO A POLICE EMERGENCY NUMBER.
OPTIONAL
FOR UP TO 40 ADDITIONAL ZONES
( FROM EITHER OR BOTH GROUPS)
ADEMCO 5881* Type
RF RECEIVER
WIRELESS ZONES
*5882 IN CANADA
ADEMCO No. 4219
WIRED EXPANSION MODULE
(8 ADD'L EOLR WIRED ZONES)
-OR-
ADEMCO No. 4229
WIRED EXPANSION/RELAY MODULE
(8 ADD'L EOLR WIRED ZONES PLUS 2
OUTPUT RELAYS)
-OR-
ADEMCO No. 4204 RELAY MODULE
(4 OUTPUT RELAYS)
BLK RED GRN YEL
12378
11 12 17
20 21 22 23 24 25
EARTH
GROUND
SEE
INSTRUCTIONS
FOR PROPER
GROUNDING
TELEPHONE WIRING
(VIA RJ31X* JACK AND DIRECT
CONNECT CORD)
*CA38A IN CANADA
DOC LOAD NO.: 3
BLACK: KEYPAD GROUND (- ) RETURN
RED: KEYPAD PWR ( + )
GREEN: DATA IN FROM KEYPAD
YELLOW: KEYPAD DATA OUT
▲
▲
REMOTE
KEYPADS
AND OTHER
ADDRESSABLE
DEVICES
(e.g. 5800TM,
4285/4286, LRR,
4219, 4229,
4204, 5881)
WARNING:
TO PREVENT RISK OF SHOCK,
DISCONNECT TELEPHONE LINE AT TELCO JACK BEFORE SERVICING THIS UNIT.
BLK
RED
GRN
YEL
TO TERM 4 TO TERM 5 TO TERM 6 TO TERM 7
BLK RED GRN YEL
AND/OR
RING
(GRAY)
TIP
(GREEN)
RING
(RED)
INCOMING
PHONE LINE
HANDSET
ZONE 1
ZONE 2
HI
LO
HI
LO
ZONE 3
ZONE 4
HI
LO
HI
LO
ZONE 5
ZONE 6
HI
LO
HI
LO
ZONE 7
ZONE 8
HI
LO
HI
LO
•
MAXIMUM LOOP RESISTANCE: (EACH ZONE) 300 OHMS (PLUS EOLR)
•
•
RESPONSE, ZONES 1-8: 10, 350, OR 700 MSEC (PROGRAMMABLE)
8-PIN CONNECTOR
USED FOR 4300/1321X10
TRANSFORMER
CONNECTIONS AND FOR
ON-BOARD TRIGGERS
SEE INSTRUCTIONS.
78 (USE SA4120XM-1
CABLE)
TIP
(BROWN)
}
}
THIS DEVICE COMPLIES WITH PART 15 OF FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
COMPLIES WITH FCC RULES, PART 68.
FCC REGISTRATION NO. 5GBUSA-44003-AL-E RINGER EQUIVALENCE: 0.1B.
WEEKLY TESTING IS REQUIRED TO ENSURE PROPER OPERATION OF THIS SYSTEM. IN ADDITION,THIS SYSTEM MUST BE CHECKED BY A QUALIFIED TECHNICIAN AT LEAST ONCE EVERYTHREE (3) YEARS.
CAN BE USED FOR 2-WIRE SMOKE DETECTORS
RED JUMPER CUT FOR BELL SUPERVISION. ALSO, CONNECT 2000 OHM RESISTOR DIRECTLY ACROSS SOUNDER.
FOR CONNECTION OF OPTIONAL 4285 OR 4286 VIP MODULES TO PHONE TERMINALS, SEE INSTRUCTIONS.
ASSEMBLED IN MEXICO
5881L: UP TO 8 5881M: UP TO 16 5881H: UP TO 64
NOTE: KEYPAD (S) CURRENT (IN BOTH PARTITIONS) AND ALL OTHER DEVICES DRAWING POWER FROM TERMS 4 & 5 MUST BE INCLUDED IN AUX CURRENT DRAIN CALCULATIONS.
AUX. POWER
OUTPUT
10.5-13.8VDC
600mA MAX.
(500mA MAX.
FOR UL
INSTALLATIONS)
ALL OUTPUTS
ARE POWER
LIMITED.
+
}
2000
OHMS
EOLR
2000
OHMS
EOLR
2000
OHMS
EOLR
2000
OHMS
EOLR
2000
OHMS
EOLR
2000
OHMS
EOLR
2000
OHMS
EOLR
2000
OHMS
EOLR
SYNC
COM
DATA
TO TRANS.
GND
+12 AUX
18 19
16
15
14
13
10
9
6
4
1234 5 6
OUTPUT 18
(TRIG. 2)
OUTPUT 17
(TRIG. 1)
ALL DEVICES AND ACCESSORIES
USED IN A CANADIAN INSTALLATION
MUST BE LISTED FOR USE IN CANADA
BATTERY FUSE FOR REPLACEMENT, USE SAME VALUE (e.g. ADEMCO No. 90-12)
3A
4-WIRE SMOKE DETECTOR CONNECTIONS
SET RECEIVER’S DIP SWITCH FOR DEVICE ADDRESS OF “0”. SEE INSTRUCTIONS.
SET UNIT’S DIP SWITCH FOR DEVICE ADDRESSES 7 - 15 SEE INSTRUCTIONS.
MAXIMUM NUMBER OF 2-WIRE SMOKE DETECTORS ON ZONE 1 IS 16; DETECTORS MUST HAVE COMPATIBILITY IDENTIFIER AS "A".
ZONE PAIRS 2 / 10 3 / 11 4 / 12 5 / 13 6 / 14 7 / 15 8 / 16
VISTA-20P/PS SERIES, VISTA-15P SERIES
SUMMARY OF CONNECTIONS
1312 14
10 11
6.2k
ZONE 10
3k
ZONE 2
2k
2k
2k
ZONE 3
2k
2k
2k
ZONE 4
TAMPER
CONTACTS
TAMPER
CONTACTS
VISTA-20P/PS ONLY
TYPICAL WIRING FOR
ZONE DOUBLING
(VISTA-20P/PS ONLY)
TYPICAL WIRING FOR
DOUBLE BALANCED ZONE
(VISTA-20P/PS ONLY)
REMOTE KEYPADS CAN USE 6150 OR 6160 KEYPADS. LOCAL PROGRAMMING MUST BE DONE WITH A 6139/6160, BUT NEED NOT REMAIN IN THE SYSTEM (SET TO ADDRESS 16).
POWER SHUTDOWN NOTE: SYSTEM SHUTS DOWN SENSOR DETECTION PROCESSING IF CONTROL'S VOLTAGE DROPS
BELOW 9.6V.
+
+
2000 OHMS EOLR
HEAT
DETECTOR
RED
EOL POWER SUPERVISION RELAY MODULE A77-716B. USE N.O. CONTACT, WHICH CLOSES WHEN POWER IS APPLIED.
VIOLET
AUX PWR
OUTPUT
TERMINALS
5
4
_
_
+
BLK
_
TO ZONE TERM. ( )
TO ZONE TERM. ( )
RELAY
CONTACT OPENS MOMENTARILY UPON FIRE ALARM RESET
PROGRAM
RELAY
AS ZONE
TYPE 54
(FIRE ZONE
RESET)
_
+
4-WIRE SMOKE
OR COMBUSTION
DETECTOR
N.C. N.O.
TO OUTPUT 17
PROGRAM OUTPUT 17
FOR "OUT NORM
LOW" = YES IN 79 MENU
MODE AND AS ZONE
TYPE 54 IN
80 MENU MODE
OR
5
BLK
A DIVISION OF PITTWAY CORPORATION
165 Eileen Way, Syosset, NY 11791
Copyright © 2001 Pittway Corporation
¬.359l
K5305-1PRV1 4/02
www.PDF-Zoo.com
