Dunelm Carson Extra Wide TV Unit User manual

Carson Extra Wide TV Unit
INSTRUCTIONS
www.dunelm.com

www.dunelm.com
Thank you
Dear Customer
Thank you for purchasing your new piece of furniture from Dunelm. We put a lot of effort in the
design and construction of our products to ensure they set the standard for quality, durability and
ease of assembly.
If for any reason you feel we haven’t lived up to the high standards we set ourselves, please don’t
hesitate in contacting us on 03451 656565 where our team will be very keen to understand what
has gone wrong and, more importantly, put it right.
The next step...
There is no need to feel daunted by the number of
parts and fittings in front of you, we have compiled
this straight forward, step-by-step guide to make sure
that assembling your furniture is as easy as 1, 2, 3.
Before you begin, we advise that you check that you
have everything you need to get started.
Top tip
Find a space to spread everything out across the
floor before you begin assembling the item. Lay
each panel down on a clean and level area, ideally
in the room of intended use, ensuring there is
enough room to manoeuvre around the item. It
is recommended that two people assemble this
product together. The full list of furniture parts,
fixtures and fittings, as well as the tools you will need
for assembly can be found on page 2 and 3 of this
manual.
Top tip
Identify all of the fittings, make sure that you have
them all prepared and familiarise yourself with each
component, to make things easier when you are
putting it all together.
Safety and care advice
IMPORTANT - The first step you need to take is to
ensure your safety! Please take the time to read and
understand these instructions before assembling
your furniture.
Please keep these instructions for future reference.
Keep children and animals away from the assembly
area. This furniture contains small parts that could
cause choking if swallowed.
Keep all plastic wrapping materials away from babies
and children to avoid danger of suffocation.
Ensure that all packaging is disposed of carefully
and responsibly.
From time to time check that there are no loose
fittings on the unit, re-tighten when necessary.
Two people may be required for the assembly of
this product.
Once items are part or fully assembled they are not
returnable unless faulty.
This item is not for outdoor use – unless stated
otherwise.
Some items will be supplied with a wall fixing strap,
which we recommend is used to secure the item
to the wall, to prevent a child from accidentally
pulling furniture over.Furniture can be dangerous if
incorrectly installed. Assembly should be carried out
by a competent person. No liability will be accepted
for damage or injury caused by incorrectly installed
or assembled furniture.

Component parts supplied
Ref Dimensions
1
Visual Qty
2
3
4
5
6
40.3x27.5cm 1
1
1
1
1
1
41.8x27.5cm
40.3x27.5cm
148x42cm
46.6x26.9cm
46.6x26.9cm
71
145.3x28.2cm
148x42cm
81
91
Ref Dimensions
10
Visual Qty
11
12
13
14
13.5x4cm
47.1x35.8cm
33x9.5cm
14.5x4.5cm 4
1
2
2
2
33x9.5cm
15 2
41.7x9.5cm
16 2
42.5x32.2cm
17 2
46.6x13.3cm
41.8x27.5cm

www.dunelm.com
Parts and fittings
Fixtures and fittings supplied(not to scale)
Re Dimensions Qty
A
12
N/A
B
12
N/A
H
2
N/A
I
1
N/A
J
4
N/A
K
4
N/A
L
4
N/A
2
Visual
Fixtures and fittings
supplied(actual size)
8X30mm
6X30mm
3.5X14mm
10mm 20 4030 50 60 70 9080 100 110 130120
Re Qty
Dimensions
C
D
E
8
16
28
5X40mm
F12
6X25mm
G1
6X16mm
V2
A2 4X14mm 4
Re Dimensions Qty
M
4
N/A
N
1
N/A
O
1
N/A
P
1
N/A
Q
8
N/A
R
S
10
N/A
N/A
4
T
N/A
1
U
N/A
4
W
N/A
Visual
2
X
N/A
4
Y
N/A
1
Z
N/A
2
A1
N/A

www.dunelm.com
Exploded view
17
15
13
14
12
1
2
16
×2
10
10
10
11
10
8
12
5
3
9
4
6
7

www.dunelm.com
Step 1:
Step 2:
E x 12 CL x 2 CR x 2
A1
=
CL
+++
CR DL DR
E x 4 X x 2
Need to assemble drawer runner in the correct pilot hole as the diagram indicates.
E
CL
E
EE
E
E
CR
E
E
12
=+
XX1 X2
X1
X1
E
E
X2
13
X
X

www.dunelm.com
Step 3:
Step 4:
CORRECT WRONG
WHEN FITTING CAMS
ENSURE STARTING POSITION IS CORRECT
BEFORE YOU INSERT CONNECTING CAM-PILLAR
TURN CLOCKWISE UNTIL SECURE
A x 8
Shoulder
NO GAP
CAM-LOCK
Tighten until shoulder is flush
with panel.Do not overtighten
or undertighten(see example below)
Panel Panel
B x 8 D x 8
5
5
2
1
4
3
A
A
A
B
B
B
D
D
D
D

www.dunelm.com
Step 5:
Step 6:
S x 2 T x 4
6
Slant the door to let pivot into the guide groove.
7
5
2
1
6
3
T
T
T
T
S
S
S
T
T
T
4x
7

www.dunelm.com
Step 7:
Step 8:
5
2
1
4
3
5
7
7
6
6
2
1
3
4

www.dunelm.com
Step 9:
Step 10:
5
7
6
3
1
U x 1I x 2 V x 2 W x 4
I
I
UW
W
W
V
D
D
D
D
D x 8
2
2
8
1
4
3

www.dunelm.com
Step 11:
Step 12:
F x 8
F
F
F
11
G
I
O
G x 1 I x 1 J x 4 O x 1 Y x 4
9
2
3
4
1
J
J
J
Y
Y
x 4
10
10
10

www.dunelm.com
Step 13:
Step 14:
R x 10
11
10
10
10
N
K
L
MA2
P
XX
YY
R
R
R
2
2
8
9
10
10
A2 x 4
K x 4 M x 4 N x 1L x 4 P x 1

www.dunelm.com
Step 15:
Step 16:
Q x 8
3
Q
Q
Q
Q
12
12
6
7

www.dunelm.com
Step 17:
Step 18:
CORRECT WRONG
WHEN FITTING CAMS
ENSURE STARTING POSITION IS CORRECT
BEFORE YOU INSERT CONNECTING CAM-PILLAR
TURN CLOCKWISE UNTIL SECURE
A x 4 B x 4 C x 4 H x 2
F x 4
C x 4
× 2
C
C
F
F
× 2
A
A
H
C
C
B
B
15 15
13 13
13
14
14
14 16
17
17

www.dunelm.com
Step 20:
Step 21:
E x 12 DL x 2 DR x 2
× 2
E
E
E
E
DR
DL
14
17
17
17

www.dunelm.com
Step 22:
Z
1.Use stickers (Z) on all visible holes.
Z x 1
2x

www.dunelm.com
Assembly instructions
455
1480
420
80
313
417
138 98
470 470

www.dunelm.com
Wood care advice
Wood care advice
Wood is a natural product and each piece is
individual.
As a natural product, wood is affected by
temperature and humidity. We recommend that
you avoid placing the furniture directly in front of
heat sources such as radiators or fires as this can
cause cracking or warping over time.
The colour will mellow over time and new items
can vary in shade from items that you have already
purchased.
Strong direct sunlight can affect the colour
dramatically, so try to avoid this as much as
possible, we also recommend that any ornaments,
coasters and items placed on the product are
periodically moved around to allow the colour to
mellow evenly.
Always use matts and coasters to protect the
surface when placing items on the furniture. This
will help to protect the finish from heat, liquids or
items that might scratch your furniture.
If items are to be placed on the surface of your
furniture and have rubber feet, it is advisable to
use mats to prevent marking.
Always lift your furniture into place, avoid
dragging it across the floor as this can cause
damage to joints.
When placing furniture on a wooden or laminate
floor, please ensure that the plastic or felt
protectors are securely fitted and in place.
Only clean using a damp cloth and mild detergent,
do not use bleach or abrasive cleaners.
From time to time check that there are no loose
screws on this unit.
Remove any spills immediately to avoid staining.
Dust regularly with a soft lint free cloth or duster.
The use of abrasive polish or silicon based polishes is
not advised as these can affect the polished finish and
joints over time.
Uneven floors could give the impression that doors
of wall units and wardrobes are out of alignment.
Be aware of this and compensate if necessary by
adjusting the hinges or packing a corner to level the
item. Please refer to the instructions, included with
your furniture, and adjust accordingly.
If your furniture becomes stained, scratched, chipped
or suffers other damage, we recommend professional
help is sought to restore it. Please contact our
customer services line for recommended agents.
Always follow fitting instructions carefully and retain
them for future use.
