Dunkirk L-GZ326PST-2 User manual

Congratulations on your purchase of our SUNJOY Dunkirk Grill Gazebo. Our clear, easy to follow,
step-by-step instructions will guide you through the assembly process from start to finish.
WARNING:
Read and follow all Warnings & Assembly Instructions before attempting to assemble.
Keep all children and pets away from assembly area. Children and pets should be supervised
when they are in the area of construction.
Keep assembly area at least 6 feet from any obstruction such as a fence, garage, house,
overhanging branches, laundry line, or electrical wires.
Some parts may contain sharp edges. When assembling and using this product, basic safety
precautions should always be followed to reduce the risk of personal injury and damage to the
product.
Assemble on level ground.
Check all bolts for tightness before use, and periodically check and tighten bolts as necessary.
This unit is heavy. Do not assemble this item alone.
Dunkirk Grill Gazebo
Item#: L-GZ326PST-2


Top Screen A 2
Tilt Beam (1) B1 2
Tilt Beam (2) B2 2
Baffler B3 4
Upper Connection Pole C1 2
Lower Connection Pole C2 2
Top Connection Pole D1 1
Top Hook D2 2
Cover Supporting Bar E 4
Big cover (1) F1 2
Big cover (2) F2 2
Big cover (3) F3 2
Small cover (1) G1 2
Small cover (2) G2 2
Small cover (3) G3 2
Cover panel H 1
Post (1) I1 1
Post (2) I2 1
Post (3) I3 1
Post (4) I4 1
Screen J 2
Parts List
2

Item Identification
For ease of identification, all parts are labeled to correspond to the step number in which the part is
used. The gazebo is designed to be constructed in 3 main steps.
Slate table top K 2
Corner slice L 8
Shelf 1 L1 2
Shelf 2 L2 2
Screen foot M 2
Hanger bar N 1
Grid O 1
Big basket P 1
Small basket Q 1
Tissue basket R 1
Stick S 1
Cup T 3
Small hook U 8
Cover Panel Presser V 32
AA M6X15 Screw
TBZ00106015SS 28 PCS
BB M6 Washer
TBZ10406SS 32 PCS
CC M6X30 Screw
TBZ00306030SS 4 PCS
Z M6 Wrench 1 PC
Hardware Pack 1
3

Fig.1: Insert Tilt beam B1 to Top screen Aˈand tighten them with Baffler B3 by using Screw AA and Washer
BB. Same way for Tilt beam B2. Then tighten Upper Connection Pole C1 to it by Screw AA and Washer BB
(Side with mark “UP” up).
Fig.2: Tighten one end of Lower Connection Pole C2 to Tilt beam B1, the other end of C2 to B2, with Screw
AA and Washer BB.
Fig.3: Attach Top hook D2 to Top Connection Pole D1.
Fig.4: Tighten Top Connection Pole D1 with Top screen A by using Screw AA and Washer BB.
Fig.5: Tighten Cover Supporting Bar E to Tilt beam B1 and B2 with Screw CC and Washer BB.
UP
4

BB M6 Washer
TBZ10406SS 36 PCS
CC M6X30 Screw
TBZ00306030SS 4 PCS
DD M6X15 Screw
TBZ00306015SS 30 PCS
EE M6X40 Screw
TBZ00306040SS 2 PCS
Hardware Pack 2
Fig.6: Insert the lower end of Big cover F2 to Cover supporting bar E, and tighten the upper end of F2 to
Upper Connection Pole C1 with Screw DD and Washer BB. Insert the lower end of Big cover F1 and F3 to
E, and tighten the upper and side of F1, F3 with Screw DD and Washer BB.
Fig.7: Tighten E to Top screen A with Screw CC and Washer BB.
5

Fig.8: Insert Small cover G2 to Cover
supporting bar E, and then insert
Small cover G1, G3 to E. Tighten the
side with Screw DD and Washer BB.
Fig.9: Tighten Cover panel H to Top Connection Pole D1 with Screw EE and Washer BB.
AA M6X15 Screw
TBZ00106015SS 16 PCS
BB M6 Washer
TBZ10406SS 48 PCS
JJ M6X45 Screw
TBZ00306045SS 16 PCS
FF M6X35 Screw SS finish
TBZ00106035SS 4 PCS
HH M6 Washer SS finish
TBZ10406SS 4 PCS
DD M6X15 Screw
TBZ00306015SS 16 PCS
II 6*180 Stake 8 PCS
Hardware Pack 3
Fig.10
˖
Fix Cover Panel Presser V to Cover F1ˈF2, F3, G1, G2 and G3.
6

Fig.11: Tighten Screen foot M to Screen J with Screw AA and Washer BB.
Fig.12: Tighten one Screen J to Post I1, I2 with Screw JJ and Washer BB. Another Screen J to Post I3,
I4.
7

Fig.19: Put Shelf L2 on the bottom of screen, and L1 on the middle.
Fig.16: Fix Grid O to Post I1, I2 with Screw FF and Washer HH.
Fig.17: Fix Hanger bar N to Post I3, I4 with Screw AA and Washer BB.
Fig.18: Secure the gazebo on the ground by Stake II..
Fig.13: Put the top frame on the posts, and tighten it from bottom to top with Screw JJ and Washer BB.
Connect posts with Tilt Beam B1, B2 by using Screw AA and Washer BB.
Fig.14: Connect Slate table top K with Post I1, I2 by Corner slice L with Screw DD and Washer BB. Same
way for another slate table top to I3, I4. (Note: Round shape hole of Corner slice should attach Post, while
long shape hole should attach Table top).
Fig.15: Fix Corner slice L, Table top K and Screen J with Screw DD and Washer BB.
