Dunlop MXR Dyna Comp Installation manual

Operation
Manual
92503020553REVA

SPECIFICATIONS
Input Impedance 470 kΩ
Output Impedance 10 kΩ
Max Input Level -5 dBV
Noise Floor* >- 87 dBV
Current Draw 2.2 mA
Bypass True Hardwire
Power Supply 9 volts DC
*A-weighted, all controls at mid position
DESCRIPTION
The Script Dyna Comp Compressor
combines old school compression
tone with upgrades for modern gigging
convenience. Spec’d from our own
1976 Dyna Comp Compressor, this
pedal features the rare CA3080 “metal
can” integrated circuit (IC), which yields
quieter operation, greater transparency,
and increased dynamic range. An effect
status LED and AC power jack upgrade
this compressor for easy use on stage.
POWER
The Script Dyna Comp Compressor
is powered by one 9-volt battery
(remove bottom plate to install), a
9-volt AC adapter such as the Dunlop
ECB003, or the DC Brick™and Iso-Brick™
power supplies.
CONTROLS
• OUTPUT knob controls overall
effect volume
• SENSITIVITY knob sets compression ratio
• FOOTSWITCH toggles effect on/bypass
(red LED indicates on)
DIRECTIONS
• Run a cable from your guitar to the
CSP102SL’s INPUT jack and run
another cable from the CSP102SL’s
OUTPUT jack to your amplifier.
• Start with both controls at 12 o’clock.
• Turn the effect on by depressing
the footswitch.
• Rotate OUTPUT knob clockwise to
increase overall volume of effect or
counterclockwise to decrease it.
• Rotate SENSITIVITY knob clockwise
to increase sensitivity (more compression)
or counterclockwise to decrease it
(less compression).
CSP102SL SCRIPT DYNA COMP®COMPRESSOR
