Dunlop MC401 User manual

92503004776revD
MC401 BOOST/ LINE DRIVER

MC401 BOOST/LINE DRIVER
DIRECTIONS
• Run a cable from your guitar to
the Boost/Line Driver’s Input jack
and run another cable from the
Boost/Linedriver’s Output jack to
your amplier.
• Start with the Boost knob at
0dB. Rotate the knob clockwise
to increase boost level, up to
+20dB.
DUNLOP MANUFACTURING, INC.
P.O. BOX 846 BENICIA, CA 94510 U.S.A.
TEL: [phone] FAX: [phone]
CONTROLS
BOOST knob controls overall
boost (inactive in bypass mode)
AC adapter input
Footswitch toggles effect
on/bypass (ice blue LED
indicates on)
DESCRIPTION
• Boost function with knob
adjustment from 0 to +20dB
of clean uncolored boost
• True bypass
SPECIFICATIONS
Input Impedance 1 kΩ
Output Impedance 150 Ω
Nominal Input -22 dBV
Output Level -22 dBV
Boost Gain Range 20 dB
Noise Floor* >95 dB
Bypass True Hardwire
Current Draw 1.5 mA
Power Supply 9 volts DC
*A-weighted, Vref=1Vrms
POWER
The MXR/CAE Boost/Line Driver
is powered by one 9 volt battery
(remove bottom plate to install),
a 9 volt AC Adapter such as the
Dunlop ECB003/ECB003EU or
a powersupply such as the DC
Brick™.
