IB-CD855(CDX82C-60C8)-WM-E-011604
OPERATING INSTRUCTIONS
PLEASE READ CAREFULLY BEFORE USE
MODEL CD-855
60 SECOND ESP PLUS
TM
ELECTRONIC SHOCK PROTECTION
PROGRAMMABLE COMPACT DISC PLAYER
WITH REMOTE CONTROL
PLAYS MUSIC COMPACT DISCS
INCLUDES WIRED REMOTE CONTROL
BASS BOOST SYSTEM
6 DIGIT LCD VISUAL DISPLAY
TRACK REPEAT & DISC REPEAT
60 SECOND ESP PLUS
TM
(ELECTRONIC SKIP PROTECTION) SYSTEM
DELUXE STEREO HEADPHONES INCLUDED
USES 2 SIZE AA BATTERIES (NOT INCLUDED)
LINE OUT JACK - CONNECTS TO YOUR STEREO SYSTEM
IB-CD855(CDX82C-60C8)-WM-E-011604.p65 2/7/04, 7:28 PM1

Great user manuals database on UserManuals.info
IB-CD855(CDX82C-60C8)-WM-E-011604
INTRODUCTION
Your new DURABRAND Model CD-855 portable compact disc player, uses the latest
technology to give you crisp clean sound from all your compact discs.
Please read these operating instructions completely to take advantage of all the features
of this set.
ACCESSORIES INCLUDED
WIRED REMOTE CONTROL
STEREO HEADPHONES
1
Plug into the PHONES jack
IB-CD855(CDX82C-60C8)-WM-E-011604.p65 2/7/04, 7:28 PM2

Great user manuals database on UserManuals.info
IB-CD855(CDX82C-60C8)-WM-E-011604
LOCATION OF CONTROLS
1. LCD DISPLAY
2. CD DOOR OPEN BUTTON
3. REPEAT BUTTON
4. PROG. BUTTON (for programmed play)
5. RANDOM BUTTON
6. LINE OUT JACK (for home stereo connection)
7. VOLUME CONTROL
8. CD DOOR
9. PHONES JACK (headphones jack, also for
REMOTE CONTROL connection)
10. FORWARD SKIP + BUTTON
11. BACKWARD SKIP - BUTTON
12. STOP AND POWER OFF BUTTON
13. PLAY/PAUSE & POWER ON BUTTON
14. BASS BOOST SWITCH
15. BATTERY DOOR
16. AC ADAPTOR JACK (AC ADAPTOR not included)
2
17. PLAY/PAUSE & POWER ON
18. STOP/OFF
19. SKIP/SEARCH BACKWARD
20. SKIP/SEARCH FORWARD
21. VOLUME CONTROL
22. BELT CLIP (at back)
23. HEADPHONES JACK
The following controls are for the
Wired Remote Control
18
20
19
16
17
21
22
15
4
5
7
8
10
9
11
1
3
213 12
14
6
23
IB-CD855(CDX82C-60C8)-WM-E-011604.p65 2/7/04, 7:28 PM3

Great user manuals database on UserManuals.info
IB-CD855(CDX82C-60C8)-WM-E-011604
POWER SOURCES
3
ALKALINE BATTERY LIFE
Bear in mind that battery life expectancy is based upon volume and bass listening
levels.
Maximum battery power consumption happens at maximum settings. Typical life for 2
size AA alkaline batteries is above 8 hours of continuous CD play.
NOTE: You may use rechargeable batteries on this set. However, because
rechargeable batteries generally have lower voltage (1.2 volts instead of
1.5 volts). Your playing time will be much less than normal fresh alkaline
batteries.
Power this CD player by inserting 2 size AA fresh alkaline batteries.
TIPS ON BATTERY USE
Reversing polarities will damage the batteries and possibly your set. Be sure to
follow polarity ( + and - ) as indicated.
Do not mix different types together (Alkaline, Carbon-Zinc, Nickel-Cadmium etc.),
or old batteries with new ones.
When not in use for an extended period of time, or while internal batteries will not
be used, remove them to prevent possible acid leakage or corrosion resulting in
damage to your player.
When the batteries have become discharged, they must be disposed of in a safe
manner that complies with all applicable laws.
Installation of batteries should only be done by an adult (for safety).
1. USING WITH BATTERIES
Insert 2 size AA alkaline batteries according to
the + and - markings on the bottom of the set.
2. AC ADAPTOR (OPTIONAL)
While the CD is playing, if the alkaline batteries are weak or discharged, this symbol
  shows or flashes in the display, then the power automatically turns off. If this
occurs, replace both alkaline batteries (also if the display does not show anything, the
batteries are dead).
WHEN SHOWS IN THE DISPLAY
You can also power this CD player by connecting an optional AC adaptor. Before you
buy an optional AC Adaptor, please note, the only AC ADAPTOR suitable for this player
is DC 4.5V 600mA (or greater), with plus center polarity . Others may damage
your player. Please check voltage and current (mA) before buying an AC ADAPTOR.
NOTE: Player will not work, and batteries will be
drained, if batteries are not inserted as
shown on the bottom of the set.
IB-CD855(CDX82C-60C8)-WM-E-011604.p65 2/7/04, 7:28 PM4

Great user manuals database on UserManuals.info
IB-CD855(CDX82C-60C8)-WM-E-011604
4
CONNECTING TO HOME STEREO SYSTEMS
The LINE OUT jack is made to accept a stereo mini plug (3.5mm). Simply connect the
cables mini plug to the LINE OUT jack on your player, and the other appropriate end
usually RCA JACKS to the CD/AUX INPUTS of your home stereo.
OPTIONAL CABLE (3.5mm)
TO RCA JACKS
YOUR CD PLAYER
TO AUX IN JACKS TO LINE OUT JACK
YOUR STEREO
SYSTEM
IB-CD855(CDX82C-60C8)-WM-E-011604.p65 2/7/04, 7:29 PM5

Great user manuals database on UserManuals.info
IB-CD855(CDX82C-60C8)-WM-E-011604
WIRED REMOTE CONTROL
You can control the CD PLAYER with the provided remote control (including the functions
of PLAY/PAUSE AND POWER ON, STOP/OFF, SKIP/SEARCH and VOLUME CONTROL).
1. PLAY/PAUSE & POWER ON
2. STOP/OFF
3. SKIP/SEARCH BACKWARD
4. SKIP/SEARCH FORWARD
5. VOLUME CONTROL
6. BELT CLIP (at back)
7. HEADPHONES JACK
PLAYING CDS WITH THE WIRED REMOTE CONTROL
The PHONES jack is made to play this player with the included WIRED REMOTE
CONTROL. Simply insert the WIRED REMOTE CONTROLs plug to the PHONES jack
on right side of this player, and plug the STEREO HEADPHONES plug into the jack on the
top of the WIRED REMOTE CONTROL.
TO PHONES JACK
(ONLY)
PLUG HEADPHONES INTO
PHONES JACK
5
3
5
7
4
1
2
6
CD PLAYER STEREO
HEADPHONES
REMOTE CONTROL
IB-CD855(CDX82C-60C8)-WM-E-011604.p65 2/9/04, 6:02 PM6

Great user manuals database on UserManuals.info
IB-CD855(CDX82C-60C8)-WM-E-011604
CD PLAYING
4Adjust the Volume.
1Load the Disc.
2Connect the Headphones.
3Press the PLAY/PAUSE button.
Label side up
Push to open
To PHONES jack
NOTE: The ESP PLUSTM function will turn on automatically when the PLAY/PAUSE
button is pressed.
6
Stereo Headphones
PLAY/PAUSE
button
VOLUME CONTROL
TOTAL TRACKS TOTAL PLAYING
TIME OF THE CD
TRACK NUMBER
CURRENTLY
PLAYING
ELAPSED PLAYING
TIME OF THE
CURRENT TRACK
Push
here
Disc
12345
12345
12345
12345
IB-CD855(CDX82C-60C8)-WM-E-011604.p65 2/7/04, 7:29 PM7

Great user manuals database on UserManuals.info
IB-CD855(CDX82C-60C8)-WM-E-011604
OTHER OPERATIONS
Operation Press Display window shows
To pause play
To release pause and resume
play
To stop
To skip to the next track(s)
To skip to the previous track(s)
SKIP + button once (or repeatedly).
SKIP - button once (or repeatedly).
To go ahead at high speed
(search)
Keep SKIP + button depressed and release when
the desired music section of the disc is found.
To go back at high speed
(search).
Keep SKIP - button depressed and release when the
desired music section of the disc is found.
BASS BOOST switch
This switch enhances the low frequency
(bass) sounds at low listening levels.
Switch the BASS BOOST switch ON or
OFF to suit your taste.
PLAY/PAUSE
button
PLAY/PAUSE
button
STOP button
To turn off the power STOP button once and wait 30 seconds, or press
STOP button twice.
BASS BOOST switch
TRACK NUMBER
CURRENTLY PLAYING
PLAYING TIME
FLASHES
TRACK NUMBER
CURRENTLY PLAYING
PLAYING TIME
ADVANCES
7
TOTAL TRACKS TOTAL PLAYING TIME
IB-CD855(CDX82C-60C8)-WM-E-011604.p65 2/7/04, 7:29 PM8

Great user manuals database on UserManuals.info
IB-CD855(CDX82C-60C8)-WM-E-011604
Single Track Repeat
Plays one song over and over till you press STOP.
During play, select the song you want to repeat with
either of the SKIP + or SKIP - button, then press the
REPEAT button once, the symbol
REPEAT ONE will appear
in the display.
The song currently playing will repeat over and over,
until you press STOP.
All Tracks Repeat
Repeats all songs in order, till you press STOP.
During play, press the REPEAT button twice, the symbol
REPEAT ALL will show in the display.
All songs will keep playing in sequence 1, 2, 3, etc., and
when finished, will start all over again until you press the
STOP.
REPEAT AND INTRO PLAY
You may have repeat and intro play using the REPEAT button. Press the REPEAT button
several times, and the display will show the followings in turn:
Intro Play
This plays the first 10 seconds of songs in sequential
order.
1. During play, press the REPEAT button three times,
the word INTRO will flash in the display.
2. Press the PLAY button, the word INTRO will stop
flashing and the first 10 seconds of each song on the
CD will play in sequential order.
3. When you find a song you like, press the PLAY button
again, the symbol INTRO will disappear from the
display, normal play will be resumed, that song (and
the following songs) will play NORMALLY.
This plays the songs on the disc in a random order.
1. During play, press RANDOM button the word
RND will
flash in the display.
2. Press the PLAY button, this will play all of the songs
in random order selected by the CD player. The word
RND will stop flashing.
3. Press the SKIP + button to skip to the next random
song.
8
REPEAT ONE --> REPEAT ALL --> INTRO --> NORMAL PLAY
RANDOM PLAY
IB-CD855(CDX82C-60C8)-WM-E-011604.p65 2/9/04, 6:02 PM9

Great user manuals database on UserManuals.info
IB-CD855(CDX82C-60C8)-WM-E-011604
The tracks (songs) on the disc can be programmed (arranged in advance) to play in
any order you prefer (up to 20 tracks can be programmed).
Programming Example:
Program Number 12 3 4 5 6 7 8
Track Number (song number) 35 8 1 2 4 1 1
etc.
etc.
PROGRAMMED PLAY
During programming, the word PROG flashes in the display. To program songs to play
in your preferred order, follow steps below:
1.Press the PROG. button.
The word PROG and   will flash in the
display.
2.Press the SKIP + or SKIP - button to
select track number 3 (example).
PROG
and track number 03 will flash in the
display.
3.Press the PROG. button to confirm.
Track 3 is now programmed.
Program number 2 will now show in the
display, ready for your next selection of
track.
4.Repeat steps 2 and 3 to program other
tracks till you finish (up to 20
selections).
NOTE:
- The player will stop automatically after
all programmed tracks have been
played.
- To quit programmed play, press the
STOP button once. Then you may press
the PLAY button to re-start normal play.
5.After programming is finished, press the
PLAY button to begin programmed play.
The word PROG changes to be steadily
on in the display, and music begins to
play in the order you programmed.
Track number
Program number
Your programmed memory will be
lost:
When the alkaline batteries are
exhausted or removed, or the optional
AC ADAPTOR is disconnected.
When the power is shut off.
9
