Durabrand PDV-702 User manual

IB-PDV702-WM-E-010807
PORTABLE DVD PLAYER
MODELPDV-702
Plays DVDs, Audio CDs, CD-R/RW,MP3CDs andPictureCDs
Includes Rechargeable Battery for Portable Use Anywhere
Includes AC Adaptor
Includes Car Adaptor for Travel
Connects to Your Larger Screen Home TV (cable included)
PLEASE READ CAREFULLYBEFORE USE
INSTRUCTION MANUAL
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM1

IB-PDV702-WM-E-010807
SAFETY INSTRUCTIONS
TOPREVENTFIREOR SHOCK HAZARD, DO NOTUSETHEPLUG WITH AN EXTENSIONCORD,
RECEPTACLE OR OTHEROUTLETUNLESS THE BLADES CAN BEFULLYINSERTED TOPREVENT
BLADEEXPOSURE.TO REDUCETHE RISKOFFIREOR ELECTRICSHOCK,DONOTEXPOSE
THIS APPLIANCE TORAIN OR MOISTURE. TO PREVENTELECTRICALSHOCK, MATCH WIDE
BLADE PLUG TOWIDE SLOT,FULLYINSERT.
WARNING
The lightning flash with
arrowhead symbol,within an
equilateraltriangle, is intended
to alertthe user to thepresence
of uninsulated dangerous
voltage”within the product’s
enclosure that may be of
sufficient magnitude to
constitute arisk of electric
shockto persons.
CAUTION
RISK OFELECTRICSHOCK
DO NOT OPEN
WARNING:TOREDUCETHE
RISKOF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR
BACK). NO USER
SERVICEABLEPARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
Theexclamationpoint within
an equilateral triangle is
intended toalert the userto
thepresence of important
operatingandmaintenance
(servicing)instructionsin the
literatureaccompanyingthe
appliance.
IMPORTANT SAFETYINSTRUCTIONS
S3152A
13.Unplug thisapparatus duringlightning storms orwhen unusedforlong periods oftime.
14.Referallservicingtoqualified service personnel.Servicing is requiredwhentheapparatushas
beendamagedinanyway,such aspower-supply cord or plug is damaged, liquid has been spilled
orobjectshavefallen into theapparatus,theapparatushasbeenexposedtorain ormoisture,
does notoperate normally or has been dropped.
15.This appliance shall notbe exposedto dripping or splashing water and that no object filledwith
liquid such asvases shall be placed on the apparatus.
Rating plateandcaution markingare markedonthe bottomenclosureoftheapparatus.
1.Readtheseinstructions.
2.Keeptheseinstructions.
3.Heedall warnings.
4.Followall instructions.
5.Donotusethis apparatus nearwater.
6.Clean only withdrycloth.
7.Do not blockanyventilationopenings, install in accordancewith the manufacturer’sinstructions.
8.Do not install near any heatsourcessuch asradiators, heatregisters, stoves,or otherapparatus
(including amplifiers)thatproduceheat.
9.Do not defeat the safetypurposeofthepolarized orgrounding-typeplug. Apolarized plug has
two blades with one wider than the other.Agrounding type plug has two blades and athird
grounding prong. The wide bladeorthethird prongareprovidedforyour safety.Iftheprovided
plugdoes not fit into youroutlet,consultan electrician for replacement of the obsolete outlet.
10.Protect the power cord frombeing walked on or pinched particularly atplugs, convenience
receptacles,andthepointwheretheyexitfromtheapparatus.
11.Only use attachments/accessories specified by the manufacturer.
12.Useonly with the cart,stand, tripod, bracket, or tablespecified bythemanufacturer,
orsold with the apparatus.When acartisused, use caution when moving the
cart/apparatus combination to avoidinjury from tip-over.
1
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM2

IB-PDV702-WM-E-010807
NOTE
Thisproductincorporatescopyrightprotectiontechnologythatisprotectedbymethodclaims
ofU.S.patentnumbers4,631,603; 4,819,098; 4,907,093;5,315,448;and6,516,132and
other intellectualproperty rights ownedby Macrovision Corporation and other rights owners.
Use of this copyrightprotectiontechnology must be authorized by Macrovision Corporation,
andisintendedforhome and otherlimitedviewingusesonly,unless otherwiseauthorized by
Macrovision Corporation.Reverseengineeringordisassemblyisprohibited.
CAUTION
Use of controls or adjustments or
performanceof proceduresother than
those specified herein may result in
hazardousradiation exposure. Do not
opencoversanddo not repair yourself.
Refer servicing to qualified personnel.
ThisDVDVIDEO player isclassifiedas
CLASS 1LASER PRODUCTasstated
on the bottomof the set.
INCLUDEDACCESSORIES
Thefollowing items areincluded withyour
DVDplayer:
-Rechargeable battery
-AC adaptor
-Caradaptor
-Audio cable
-Video cable
-User’sGuide
-ProductRegistration Card
FCC NOTE
This devicecomplieswith Part15 of the FCC Rules.Operation is subject tothefollowing two
conditions:(1)Thisdevicemaynotcause harmful interference, and (2) Thisdevice mustaccept
anyinterferencereceived,includinginterferencethatmaycauseundesirableoperation.
WARNING:
Changes or modifications to this unit not expressly approved by the party responsible for
compliancecould void the user’sauthorityto operate the equipment.
NOTE:
This equipmenthasbeentestedandfound tocomplywiththelimitsforaClassBdigital device,
pursuant toPart 15of the FCC rules. Theselimits are designedto provide reasonable protection
againstharmful interferencein aresidentialinstallation. Thisequipmentgenerates,uses and
can radiate radiofrequency energy and,if not installed andused in accordance with the
instructions, may cause harmful interference to radio communications. However,there is no
guaranteethatinterferencewillnotoccur inaparticularinstallation.Ifthis equipment does
cause harmful interference to radioor television reception,which can bedeterminedby turning
theequipment off and on, the useris encouraged totrytocorrecttheinterferencebyoneor
moreofthefollowingmeasures.
-Reorient or relocate the receiving antenna.
-Increasetheseparationbetweenthe equipmentandreceiver.
-Connectthis equipment intoan outlet onacircuit differentfromthat towhich the receiveris
connected.
-Consult thedealeror an experienced radio/TVtechnicianforhelp.
Do not apply oil orpetroleum products orsolvents toanypart ofthis set.
SAFETY INSTRUCTIONS
2
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM3

IB-PDV702-WM-E-010807
TABLE OF CONTENTS
GettingStarted:
Safety Instructions ---------------------------------------------------------------------------------------- 1
Controls Overview ---------------------------------------------------------------------------------------- 4
Power Supply ---------------------------------------------------------------------------------------------- 6
Notes on Discs -------------------------------------------------------------------------------------------- 8
Basic Operation:
1.PlayingaDisc -------------------------------------------------------------------------------------- 9
2.UsingtheSearchFunction--------------------------------------------------------------------- 10
3.SelectingAudio Mode -------------------------------------------------------------------------- 10
4.ChangingSubtitleLanguage----------------------------------------------------------------- 10
5.Displaying DiscInformation ------------------------------------------------------------------- 11
6.RepeatPlay------------------------------------------------------------------------------------------ 12
7.Slow-Motion Play--------------------------------------------------------------------------------- 12
8.ZoomPlay------------------------------------------------------------------------------------------13
9.Search for Preferred Play ---------------------------------------------------------------------13
10.MP3Disc Operation ----------------------------------------------------------------------------- 14
11.JPEG orPictureDiscOperation--------------------------------------------------------------14
Initial Setting:
SystemSetup(TVSystem,LCDMode,TVType&Default)
Settingthe TV System----------------------------------------------------------------------------- 18
SettingtheLCDMode -------------------------------------------------------------------------- 18
SelectingtheTVType---------------------------------------------------------------------------19
Default-Resettingthe Functions toFactoryDefaults----------------------------------19
LanguageSetup(OSD,Audio,Subtitle&Menu)---------------------------------------------20
VideoSetup------------------------------------------------------------------------------------------------20
SpeakerSetup--------------------------------------------------------------------------------------------- 20
Precautions ---------------------------------------------------------------------------------------------- 21
Trouble Shooting -----------------------------------------------------------------------------------------22
Glossary ----------------------------------------------------------------------------------------------------- 25
Specifications ------------------------------------------------------------------------------------------- 26
Connection
SystemConnections------------------------------------------------------------------------------------- 15
WatchingaDVDonYourTV-----------------------------------------------------------------------17
3
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM4

IB-PDV702-WM-E-010807
Front View
1.TFT LCD SCREEN –Providesahigh resolution picture.
2.SCREEN COLOR BUTTONS –Adjust the color of the LCD screen to your taste.
3.SCREEN BRIGHTNESS BUTTONS –Adjust the brightness of the LCD screen.
4.SPEAKERS –Provide stereo sound.
5.DISC DOOR –Open the door bypressing the open button and set the disc inside it.
6. OPEN BUTTON –Press to open the disc door.
7.TITLE BUTTON –Press to displaythe title menu (onlyif it ispresent on the disc).
8. MENU BUTTON –Press to displaythe disc’smenu(onlyif your disc hasamenu).
9. AUDIO BUTTON –Press to select the audio channel (or director’scut channel).
10.POWER ON INDICATOR –Will light up when the set ison.
11.SUBTITLE BUTTON –Press to select or change the subtitles (if available on your disc).
12.SCREEN OFF BUTTON –When you fold down the LCD screen, the LCD panel will push
thisbutton and turn off the LCD screen butkeepsthe set working for viewing DVDs on
your TV.This isuseful when the AUDIO andVIDEO cablesare connected to your TV.
13.REPEAT/DISPLAYBUTTON –Press for the repeat function.Press and hold to view the
disc information and times.
14. SETUP /SEARCH BUTTON –Press to displaythe DVD player’ssetup menu. Press and
hold to displaythe searchmenu, then press the direction buttonsto select the desired
disc starting time, track, or title for playback.
15.OK BUTTON –Press to confirm aselection.
16. DIRECTION BUTTONS –Used to select optionsand DVD menus and CD/MP3 tracks.
UP &DOWN direction buttons (& )arealsotheFORWARD andBACKWARDbuttons
forforwardandbackward search.
LEFT &RIGHT direction buttons (& )arealsothePREVIOUS andNEXT buttons for
skippingtothepreviousornexttitle,chapterortrack.
CONTROLS OVERVIEW
4
1
2
3
44
5
6
78910
12
13
14
15
16
17
18
11
19
20
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM5

IB-PDV702-WM-E-010807
RightSideView
12345
1.PHONESJACK –Insertyourheadphones (notincluded)toenjoy the sound withoutdisturbing
others.
2.AUDIOOUT JACK –ConnectstheDVD player to yourTVorhometheater usingthe supplied
AUDIOcableforaudioout.
3.VIDEO OUT JACK –Connects the DVD player to your TVusing the supplied VIDEO cable
for video out.
4. POWER ON/OFF SWITCH –Slide to switchthe DVD player ON or OFF.
5. DC IN JACK –For connecting to the suppliedAC adaptor or car adaptor.
Rechargeable Battery
1.RECHARGEABLE BATTERY –For DC power supply.
2.BATTERYTAB –Push to removethe battery.
3.BATTERYLED INDICATOR –Will flash when batteryischarging and remain steadilyon
when batteryisfully charged.
CONTROLS OVERVIEW
5
231
17.ZOOM /SLOW BUTTON –Press to zoom (enlarge or reduce) the playing picture in DVD
mode or hold more than 1secondto view slow motion playback.
18. PLAY/PAUSE BUTTON –Press to start or pauseplay..
19.STOP BUTTON –Stops playback, press twice for full stop.
20.VOLUME BUTTONS –Press to adjust the volume (left is –or less, right is+or more).
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM6

IB-PDV702-WM-E-010807
POWER SUPPLY
You can power this portable DVD player byconnecting the AC adaptor,the car adaptor or the
rechargeable battery(all included).
A. Using the AC adaptor
Thisplayer issupplied with an AC adaptor
for powering the unit and charging the
battery.
Insert the AC adaptor plug to the DC IN jack
on the portable DVD player and connect the
adaptor to awall outlet.
B. Using the car adaptor (12V)
Insertthe caradaptor plugtothe DC IN jackontheportableDVD playerandconnect thecar
adaptor to thevehicle’s12V accessory/ cigarettelighter socket,the caradaptor indicatorwill light
up.
CAUTION:
1.The included car adaptor isfor usewith this unit only.Do not useit with other equipment.
2. Use this unit onlywith the included car adaptor,using with other car adaptorscould damage
the unit and the unit may not work.
3.Do not operate this unit or view video movies while driving avehicle.
4. If some linesappear on the screen during the startup of the vehicle, pleaseturn the unit off
and turn it on again after the vehicle isrunning.
5.Placethe unit in aproper position for viewing.
6.When the inside of the cigarette lighter socketisdirtywith ashesor dust, the plug section
may become hotornotworkdue topoorcontact.Besuretocleanthecigarettelighter
socket beforeuse.
7.Disconnectthecaradaptor fromboththeunitandthe cigarettelightersocket whenthe
batteryisfully charged and the unit isnot in use.
Thisplayer issupplied with a12V car adaptor for powering the unit and recharging the battery
while in avehicle that hasa12V power system.
6
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM7

IB-PDV702-WM-E-010807
Workingconditionsandprecautionsfor therechargeablebattery
New batteriesshould be fully chargedbefore initial use(about 5hours).
Batteryshould be changed byan adult for safety.
Batteryshould onlybe used and chargedwhen temperatures are between 32 -100OF.
Never put the batteryin fire or water.
Do not exposethe batteryto high temperaturesor store in hot, sunnyplaces.
Do not short the batteryterminals.
Do not open the battery.
When the batteryisweak, the Low Powericon ” will appear on the LCD screen and
then the power automaticallyturns off. If this occurs,pleaseusethe AC adaptor to
recharge the batteryor playthe set on AC power.
NOTE: When inserting the batterywhile the set is AC powered or car powered, there will be a
delayof several secondsbefore the LED lights up. This isbecausethe batterycharging
circuit needsto reset and detect the batterystatus.
2.The batteryLED indicator will flash when thebatteryischarging and remain steadilyon
when the batteryisfully charged.
3.Chargingtime isabout 5hours.Afully chargedbatterydeliversabout 2.5hoursofviewing time.
4. Tocharge the batteryusing the supplied caradaptor,follow point Bon the previouspage.
C. Using the rechargeable battery
The rechargeablebatterypackis suitableforportableusewhichallows you to enjoy the
unique functions of this unit outdoors.
Remembertochargethebatteryfullybeforeinitialuse (about5hours).
AttachingtheBattery
(referto thediagramontheright)
1.Make suretheplayerisoff and the AC adaptororcar
adaptorisdisconnected.
DetachingtheBattery
(referto thediagramontheright)
1.Make sure the player isoff and the AC adaptor
or car adaptor isdisconnected.
2.Push the tab on the batterydown.
3.Slide and lift the batteryout.
Tocharge the battery
1.Insert the AC adaptor’splug into the DC INjack on the DVD player and connect the AC
adaptorto awall outlet. After5seconds, the batteryLED indicator will turn on and start to
flash.
2.Placethe DVD playeron asoftandsmooth surface
with thebottom oftheunitfacingup.
3.Withone hand onthe DVD player toprevent it from
moving, takethebattery and align the plastic tabs on the
battery with slots on the player,and slide itforward to
lock, The batterywill click intoplace.
slot
S
L
I
D
E
3
2
tab
7
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM8

IB-PDV702-WM-E-010807
NOTES ON DISCS
Discs thatcan be played
DISC TYPE &LOGO MARK RECORDED CONTENT
DVDVideo
(Region 1)
DVD-R /DVD-RW
Video +Audio
JPEGdisc Video only (Photos)
or Audio /Video
“.JPG”or “JPEG”
Video +Audio
CD-Rdisc
CD-RWdisc
Music CD Audio only
Audio only
or Audio /Video
Audio only
or Audio /Video
MP3 disc MP-3 Audio only
Discsthat cannot beplayed
CD-Is,CD-ROMs(includingcomputersoftware discsand gamediscs),datapartofCD-Extras,
DVD-ROMs,DVD Audio discs, DIVX, MPEG 4DVD discs, HD layer on SACDs or discs recorded
inanother formatsuchasSECAM, andregionsother thanyourregion. Thisset willalsonotplay
damaged, scratchedordirtydiscs.
NOTE: Ahand symbol ”may appear on the screen whenpressing some buttons. A ”
meansthat theoperationis not permittedbytheDVDplayer forthediscinthat mode or
atthat time. Sometimes,the setneedstobeinstop mode orothermodes for thatbutton
to work.
8
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM9

IB-PDV702-WM-E-010807
2SlidetheDVD player’sPOWER switch totheONposition,the DVDlogo (start-uppicture)will
appearonthescreen.
1Lift the LCD screen.
3Press the OPEN button on theDVD player to open the disc
door.Place adiscgently onthe tray withthelabelside up,make
surethediscisseated onthespindlebypressing downin the
center,then closethe door.The DVD player startsto read the
disc’stableofcontents (thismay take afew seconds).
5Press the VOLUME +or VOLUME –button to adjust the volume level.
6Press the BRIGHTNESS and COLOR buttonstoadjust the brightness and the color of
the LCD screen if needed.
NOTE 1: Load the discwith thelabel sidefacingup,when
playing adouble-sided disc, load it with the desired
playing side face down.
NOTE 2: NO DISC”willshow in thedisplay if the discis upside
downor the discisbadlyscratched or dirty,it will not
play.Pleaseclean it or change the disc before use.
Also you can buy adiscpolishertotrytorepairthe
scratched disc.
8Topausethe playback, press the PLAY/PAUSE button. Toresume playback, press the
PLAY/PAUSE button again.
NOTE 1: During play,pressing the STOPbutton oncewill show PRE STOP ”in the
display,if you press the STOPbutton the second time, the displaywill show
STOP ”,and now your system isin the full STOP mode.
NOTE 2: Leaving the set in the stop mode for alonger time will drain the batterythe same
asduring normal play,remember to shut offthe power after use.
9Toskip to anothertrack/chapter,presstheNEXT orPREVIOUS button repeatedly
duringplayback.
4Some discs will startplayingautomatically,andothers willdisplaythedisc contents menu on
thescreen.Ifthemenu isshown,usethe ( , , & )directionbuttonsto highlightyour
selectionand press the OK buttontoconfirm,otherwiseyoumaypress play.
10 Toaccess the disc menu or title menu duringDVD play,press the MENU or TITLE button.
11 Remember to shut offthe player byslidingthe POWER switchto the OFF position when
the movie finishes playing.
NOTE: This player hasascreen saver which will displayabouncing DVD logo if no video is
played for awhile.
7Tostop playback, press the STOPbutton.
1. PLAYING ADISC
9
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM10

IB-PDV702-WM-E-010807
2.USINGTHESEARCH FUNCTION
During play,you can searchquicklythrough achapter or track.
NOTE: In anyfast forward or fast backward mode,press the PLAY/PAUSE button to return to
normal playmode immediately.
Search through achapter oratrack
1During play,press the FORWARD button to searchforward atafaster speed, the fast
search speed changesasfollows:
FORWARD X2 FORWARD X4 FORWARD X8 FORWARD X20
PLAY
2During play,press the BACKWARD button to searchbackwardsat afaster speed, the
search speed changesasfollows:
BACKWARD X2 BACKWARD X4 BACKWARD X8 BACKWARD
X20 PLAYY
3.SELECTINGAUDIOMODE
IfaDVDdisc contains aMulti-Audiosoundtrackfeature,youcanselectthedesiredaudio
languageby pressingtheAUDIO buttonrepeatedlyduringplay,playbackstatuswill bedisplayed
onthescreen. The AUDIO buttoncan also select director’scuts dialogueand otherdisc
dialogue.
Note 2:This DVDplayerdoes not support DTSdecoding.For discs withDTSdecoding,
please press the AUDIO button to select another audio output mode, such as
AC-3 or until youhear thesound.
Note 1: Ifyoupress theAUDIO buttonforseveraltimes, butthedesiredlanguageisnot
selected, it means asecond language isnot available on the disc.
NOTE: This operation works onlywith DVD discs on which multiplesubtitle languages are
recorded. Some DVDs haveno subtitles, some may have5or more. If no subtitlesare
recorded on your DVD, pressing this button will not change the subtitles.
Toremovethe subtitlesdisplay,pressthe SUBTITLE button again until :[OFF] ”shows.
4.CHANGINGSUBTITLE LANGUAGE (DVDONLY)
You can select adesired subtitle quicklyand easilywith the SUBTITLE button.
10
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM11

IB-PDV702-WM-E-010807
5.DISPLAYINGDISC INFORMATION
If you want to know disc information during play,press and hold the REPEAT/DISPLAYbutton.
Everytime you press and hold the REPEAT/DISPLAYbutton, thedisc information will appear
on the top of the screen asshown below:
ForDVD Play
DVDTT 1/2CH 6/12C-00:06:41
DVDTT 1/2CH 6/12 T00:18:05
DVDTT1/2CH 6/12 T-01:05:40
DVD TT 1/2 CH 6/12 00:02:35
o)) 1/3ENG 5.1CH 2/3ENG OFF
OFF
The informationaboutthe title/chapternumber
andchapterelapsed timeis shown.
TheinformationabouttheAUDIO,SUBTITLE
andANGLE is shown.
Theinformationaboutthe chapterremaining
timeisshown.
Theinformationaboutthe titleelapsedtime is
shown.
The informationaboutthe title remainingtime
is shown.
Theinformationdisplay goesoff.
ForCDPlay
CD TRK 2/12 00:01:03
CDTRK 2/12 C-00:02:42
CDTRK2/12 T00:10:49
CDTRK2/12 T-00:40:35
OFF
The information aboutthe currenttrack
elapsed timeis shown.
The information aboutthe currenttrack
remainingtimeis shown.
Theinformationaboutthetotal trackelapsed
timeisshown.
Theinformationaboutthe totaltrackremaining
timeisshown.
Theinformationdisplay goesoff.
MP3 TRK 2/124 00:03:03
MP3 TRK 2/124 C-00:01:36
OFF
ForMP3 Play
The information aboutthe currenttrack
elapsed timeis shown.
The information aboutthe currenttrack
remainingtimeis shown.
Theinformationdisplay goesoff.
NOTE 2: Dependingonthe disc, the aboveinformation maynotappear on yourscreenoryou
may not beable tochangethe display.
NOTE 1: TT”standsfortitle, CH”stands for chapter,and TRK”standsfortrack.
11
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM12

IB-PDV702-WM-E-010807
For CD
REP: [REP1] REP: [REPALL] REP: [OFF] REPEATA- REPEATA-B
A-BCANCEL
For MP3
REP: [REP1] REP: [REPDIR] REP: [REPALL] REP: [OFF] REPEATA-
REPEATA-B A-BCANCEL
NOTE: When you select ATO B”repeat play:
1. Press the REPEAT/DISPLAYbutton until REPEATA- ”appearsat the beginning of the
segment (point A)you want to playrepeatedly.
2.PressREPEAT/DISPLAYbuttonagainattheend of thesegment (point B), REPEATA-B”will
appear on the display.
3.The DVD player will automaticallyplaythe selected segmentsAto Bover and over till
you press REPEAT/DISPLAYbutton again.
6. REPEATPLAY
The REPEATfunction allows you to repeatthe currenttrack, chapter,title, achosen section(A-B),
orallofthe disc.
Each time you press the REPEAT/DISPLAYbutton repeatedly,the repeat mode changesas
follows:
A-BCANCEL”SHOWSAND
NORMALPLAYRESUMES
REP:[CHAPTER]REP:[TITLE] REP: [REPALL] REP: [OFF]
REPEATA-REPEATA-B
A-B CANCEL
WILLREPEATTHIS
CHAPTER OVERAND OVER
WILLREPEATTHIS
TITLE OVERAND OVER
WILLREPEATTHIS
DISC OVERANDOVER
ForDVD
REPEATATOBSEGMENTOVERAND OVER.
7. SLOW-MOTION PLAY
Adisccan alsobeplayed in slow-motionby pressingthe ZOOM/SLOW button.
1Eachtimeyoupressandhold the ZOOM/SLOWbutton duringplay,the playbackspeed will
change asfollows:
SF 1/2 SF 1/3 SF 1/4 SF 1/5 SF 1/6 SF 1/7 PLAYY
2Press the PLAY/PAUSE button to resume normal play from any slow-motion mode.
(JUST FOR DVD)
NOTE 1: Sound will be silent during slow motion play.
NOTE 2: SF stands for SLOW FORWARD.
NORMALPLAY
12
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM13

IB-PDV702-WM-E-010807
9. SEARCH FOR PREFERREDPLAY
Toselectascenewith thetitle,the chapter,
thetrack number or the timeduring play use
theSETUP/SEARCHbutton.
1Pressandhold theSETUP/SEARCH
buttonduring play,thescreenwillshow
asontheright:
2Movetheleft andright directionbuttons
(& )toselectthetitle, the chapter,,
the track, or the time, then press the up
and down direction buttons( & ) to
enterthenumber,thenpresstheOK
button to confirm.
3The player will jump to play the section
youselected and the menu display
disappears from the screen.
ForCD
input thesecond you
want to jump to
inputtheminuteyou
want to jump to
CDTRK02/12 00:03:111
trackyou want
tojump to
chapter youwant
tojump to
titleyouwant
tojump to
For DVD
for searching by title, chapter &time
DVD TT 01/02CH002/013 00:02:03
timeyouwant
tojump to
For MP3
MP3TRK 0016/154 00:01:21
trackyou want
tojump to
NOTE: The searchfunction may not work
during the opening screensof many DVDs,
such asthe FBI warnings etc.
8. ZOOM PLAY (FOR DVD)
1Press the ZOOM/SLOW button repeatedlyto enlarge or reduceapicture. The displaywill
show asfollows:
ZOOM 2 ZOOM3 ZOOM4 ZOOM1/2 ZOOM1/3 ZOOM1/4 ZOOM:OFF
2Pressandhold the directionbuttons( , , & )to movethe enlargedpicture up,down,left
orright.
3Toreturn to normal playfrom the ZOOM mode, press ZOOM/SLOW button repeatedlytill
theicon shows ZOOM:OFF”.
NOTE 1: Some discs may not respond to the zoom feature and during some zoom functions
the picture edgesmay seem fuzzy,this isnormal.
NOTE 2: When reducing to smaller sizes, the black area around the picture will enlarge, this
is normal.
The ZOOM/SLOW button allowsyou to do aminimal zoom into apicture aswell asshift the
zoom point.
13
input thesecond you
want to jump to
inputtheminuteyou
want to jump to
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM14

IB-PDV702-WM-E-010807
11.JPEGORPICTUREDISCOPERATION
Toreturn to normal view,press ZOOM/SLOW button till ZOOM: OFF”shows on the screen.
Tomove the enlarged picturein anydirection, press and hold anyof the ( / / / )
direction buttons.
5Press the NEXT button to see the next image in your folder..
1Load aJPEGdisc or pictureCDdisc into the player,amenu willshow on thescreen.
2Goto themenu of directory which you want toview byusing the direction buttons, press
the OK button to start the JPEG play.
3During the picture show,press and hold the ( / / / ) direction buttonsto rotate,
invert, or mirror the picture left or right.
4Press the ZOOM/SLOW button repeatedlyto enlarge or reduceapicture. The displaywill
show asfollows:
ZOOM 2 ZOOM3 ZOOM4 ZOOM1/2 ZOOM1/3 ZOOM1/4 ZOOM:OFF
6Eachpicture in the currentdirectory willbedisplayedconsecutively inaslideshow
presentation.
10.MP3DISC OPERATION
1Load yourrecordedMP3discinto theplayer,amenu will show on thescreen.
This allowsyou to playyour MP3 audio recordeddisc you made on this set. This set will not
playWMAformat songs. When recording your MP3 disc on your computer,pleaserecord the
songs in MP3 format.
[MP3]01-------MP3
02.02
03.03
04.04
05.05
06.06
07.07
08.08
09.09
10.10
01.01
01.MP3
You can playyour JPEG or picture disc on this set.
2Select the desired folder by pressing the UP or DOWN button.
3Press the OK button to open the folder.
4Select the desired track bypressing the UP or DOWN button.
5Press the OK button to start playback.
6You may use the PREVIOUS or NEXT button to skip to the previous or next track.
7Press and hold the BACKWARD or FORWARD button on the player for fast backward
or fast forward play.
8Press STOP button to stop playing.
14
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM15

IB-PDV702-WM-E-010807
SYSTEMCONNECTIONS
Always ensure when connecting cables, the DVD player,TV and anyother electrical equipment
are turned off and not plugged into the AC outlet.
Ensure that you observethe color codingwhen connecting audio and video cables.
Usingthe attachedAUDIO andVIDEOcables
Insert the 3.5mm plug of the AUDIO cable into the AUDIO OUT jack on the DVD player and
insert the RED and WHITE plugsto yourTV’sAUDIO IN jacks for audio output.
Insert the 3.5mm plug of the VIDEO cable into the VIDEO OUT jack on your DVD player and
insert the YELLOW plug to your TV’sVIDEO IN jack for video output.
1. Connecting the DVD playerto your TV
ThisDVD player can alsobe used to view movieson your larger screen TV.When viewing on
your TV,you may fold the screen down to shut offthe TFTLCD display.
ForTV Connection
Pleasefollowthe
cable plug colors.
15
YOUR TV
AUDIO IN
VIDEOIN
LR
YELLOW
WHITE
RED
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM16

IB-PDV702-WM-E-010807
Connectingtoadigitalhometheatersystem
Refer to your home theater system’smanual before connection.
For Video, insert the 3.5mm plugof the video cable into the VIDEO OUT jack on your DVD
player and the yellow plug into your TV’sVIDEO jack.
For Audio, insert the 3.5mm plugof the audio cable into the AUDIO OUT jack on the DVD
player and insert the RED and WHITE plugstoyour home theater system’sAUDIO IN jacks.
SYSTEMCONNECTIONS ForTV Connection
2. Connecting to your headphones (headphones are not included)
Turn down the volume of the DVD player and connect the headphones(optional, not included)
to the DVD player’sPHONES jack, when headphonesare connected, the speakersof your
DVD player will automaticallyturn off. Adjustthe volume to your taste (but not too loud).
YOUR HOME
THEATER SYSTEM
OR AMPLIFIER
16
YOURTV
AUDIOIN
VIDEOIN
LR
YELLOW
WHITERED
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM17

IB-PDV702-WM-E-010807
1Make sure all of the equipment is plugged back into the AC outlet.
2Lift the LCD screen.
3SlidetheDVD player’sPOWER switch totheONposition,the DVDlogo (start-uppicture)will
appearonthescreen.
4Turn on yourTVand set it to DVDmode (pleaseseebox below),theDVD logowill appear on
yourTV’sscreen.
5Press the OPEN button on the DVD player to open the disc door.Place adiscgently onthe
traywiththe label sideup, makesurethedisc isseatedonthespindlebypressingdown in
thecenter,close thedoor.The DVD playerstarts toreadthedisc’stableofcontents (this
maytake afew seconds).
6Some discs willstartplayingautomatically,andothers willdisplay thedisc contents menu on
thescreen.Ifthemenuis presented,usethe ( , , & )directionbuttonsto highlightyour
selectionandpressOKbutton to confirm.
7Press the VOLUME +or VOLUME –button onthe DVD player and on your TV’sremote
to adjust the volume level.
8Fold down the LCD screen cover,the DVD playerwill continue to work, but the screen will
be dark.
9Tostop playback, press the STOPbutton.
10 Topausethe playback, press the PLAY/PAUSE button on the DVD player.Toresume
playback, press the PLAY/PAUSE button again.
NOTE 1: During play,press the STOPbutton once, the display will show PRE STOP ”.
Ifyoupressthe STOPbuttonthe secondtime,thedisplaywill show STOP ”,
and now your system isin the full STOP mode.
NOTE 2: Leaving the set in the stop mode for alonger time will drain the batterythe same
asduring normal play,remember to shut offthe power after use.
11 Toskip to anothertrack/chapter,presstheNEXT orPREVIOUS button repeatedly
duringplayback.
12 Toaccess the disc menu or title menu duringDVD play,press the MENU or TITLE button
on the DVD player.
13 If you want to useother DVD playfunctions, pleasesee pages10-14.
14 Remember to shut off the player byslidingthe POWER switchto the OFF position when
the movie finishes playing.
HowtoFindyourTV’sVideoInput Channel
Make sure you havemade all the connections(see page 15), you may need to change
your TV’svideo input mode to see the DVD player’smenu and movies, alsodouble check
that both TV and player are plugged into the AC outlet.
1.Set your TV to the correct video input. Forexample, if you connect this player to the
VIDEO 1input on your TV,switchyour TV to video 1.
2.Switchyour TV to the correct video input channel. The video input channel varieswith
differentTVbrands andmodels, many TVremotecontrols have aTV/VIDEObutton
whichcan be usedtochangetodifferent videoinputsand back to TV fornormal
broadcast viewing, on some older TVs, youmay need to press channel 3or 4on your
TV’sremote. Onceyouselected the correct channel, your TV will show the opening
DVD screen. For more details,pleasesee your TV’smanual.
After allthe connectionshavebeendone,pleasefollow stepsbelow to watchaDVD on yourTV.
WATCHINGADVDONYOURTV
17
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM18

IB-PDV702-WM-E-010807
INITIALSETTING
1Press the SETUP/SEARCH button, aSETUP menu
will appear on the TV screen.
4When thesetuphas beendone,presstheSETUP/
SEARCHbutton to exit the SETUP mode.
SYSTEM SETUP (TVSYSTEM,LCDMODE,TVTYPE&DEFAULT)
SettingtheTVSYSTEM (only when youareusingyour TVtowatchthepicture).
-NTSC
AUSAvideostandard.IfyourTVis NTSCsystem,
selectthismode.
-AUTO
Iftheconnected TV ismulti-system, selectthis
mode.The outputformatwillbein accordance
with the video signal of the disc.
When usingtheDVDplayer forthefirst time,youmay needtosetsome ofthesettingsand
adjustmentsaccordingtoyourTVandfavoritepreferences.
Youcanget to the SETUPmenu byfollowingthe belowsteps.
SYSTEMSETUP
TVSYSTEM
LCD MODE
TVTYPE
DEFAULT
EXITSETUP
This allowsyou to set the aspect ratio of the LCD
screen.
SettingtheLCDMODE
3Press the OKbutton to confirm your selection.
2Usethe / / / direction buttons tohighlight
your selection.
SYSTEMSETUP
TVSYSTEMNTSC
AUTO
LCD MODE
TVTYPE
DEFAULT
EXITSETUP
SYSTEMSETUP
TVSYSTEM
4:3
16:9
LCD MODE
TVTYPE
DEFAULT
EXITSETUP
4:3
16:9
For TVor PortableUse
18
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM19

IB-PDV702-WM-E-010807
INITIALSETTING
Select theaspect ratio of the movietomatchthe
LCD screen and your TV set. There are three types
of screen sizesyou may select.
Selecting the TVTYPE
16X9Widescreen(16:9) -Choosethissetting if yourDVDPlayer is
connectedtoaWIDESCREENTV.If youchoosethis settingandyou
don’thaveawidescreen TV,theimageson the screen may appear
distorteddue to verticalcompression(facesmayseem longandthin).
Ifyouplaya discrecordedin4 X 3formatonawidescreenTV, theleft
andrightsideof thescreenwillappearblack. PressSETUP/SEARCH
buttontochange to4:3 ratio or matchthetype ofTVyou have.
16X9 Widescreen
4X3 Standard
4X3Letterbox
4X3Letterbox (4:3 LB LETTER BOX) -Choose this setting if you
want toseemoviesintheiroriginal aspectratio(width-to-height
ratio). You’ll see the entire frame of the movie, but it will take up a
smaller portion of the screen vertically.The movie will appear with
black barsat thetopand bottomofthescreen, butyouwillseeevery-
thing to the left &right of thecenter asin amovie theater.
4X3Standard (4:3 PS PAN and SCAN) -Choose this setting if
you want to see movie fill the entire screen of your TV.This might
mean that partsofthepicture(the left andright edges) won’tbe
seen.
Most discs produced in aWIDESCREEN format can’t be cropped in
this fashion.
NOTE: If your DISC isnot encoded to allow you to
change the aspect ratio,theTV display
cannot be changed.
SYSTEMSETUP
TVSYSTEM
LCD MODE
TVTYPE
DEFAULT
EXITSETUP
4:3LB
16:9
4:3PS
Default-Resettingthe functions to factorydefaults
Incaseyoucannotreturn theset to its normal
operation; youcanresetthemajoroptions on
this set.
NOTE:
Ifyouset DEFAULT”,all items in thesetupmenu
will be reset todefault setting.
SYSTEMSETUP
TVSYSTEM
RESTORE
LCD MODE
TVTYPE
DEFAULT
EXITSETUP
NOTE: For16:9 Widescreen TV TYPE, you need toadjustboth
theLCD modeand theTVTYPE to 16:9(seepage 18 forSetting
the LCDMODE).
19
IB-PDV702-WM-E-010807.pmd1/30/2007, 7:12 PM20
