Duratech TS-1640 User manual

Soldering Station
User Manual
TS-1640

FEATURES:
Soldering station designed for lead free soldering
Compact light durable design
LED display
Temperature range from 160℃ to 480℃
ast start up from room temperature to 350℃ in 30 seconds
Including N9-1 tip
OPERATION
efore operation:
Place the soldering iron in the holder.
Then connect the plug to the receptacle on the station and turn clockwise to tighten
the plug nut.
Connect the control unit to the power socket and switch on the power.
Then a self-test is carried out in which all display elements are switched on briefly.
The electronic system then switches on automatically to the set temperature and
displays this value.
DISPLAY & TEMPERATURE SETTINGS:
Press the button “+” or “-”to adjust the
temperature. Use a short press, to change the
set-point by ±1℃. Hold the button “+” or “-” down
to change the set-point quickly to reach your
target temperature.
“*” is the transfer button between ℃/ ℉ The
default unit is ℃, press the “*” button to make
change between ℃ and ℉. - Do not use this
system near the flammable items. - Advise other
people in the work area that the unit can reach a
very high temperature and should be considered
potentially dangerous. - Turn off the power switch while taking breaks and when
finishing using. - Before replacing parts or storing the system, turn off the power and
let it cool down to the room temperature.
2

CAUTION
The manufacturer assumes no liability for uses other than those described in the
operating instructions or for unauthorized alterations.
The operating instructions and cautions should be read carefully and kept in an
easily visible location in the vicinity of the control system. Non-observance of the
cautions will result in accidents, injury or risks to health.
Avoid touching grounded parts with your body, e.g. pipes, heating radiators and
so on. The grip of antistatic designed soldering tool is conductive.
Do not use the soldering tool in a moist or wet environment. The soldering iron
should be placed on the holder after finished using.
The power cord only can be inserted in approved power sockets or adapters.
The temperature of the soldering tip will reach as high as around 400℃（752℉)
when the power switch is on. Since mishandling may lead to burn and fire, be
sure to comply with the following precautions: - Do not touch metallic parts near
the soldering tip/ nozzle.
This appliance is not intended for use by young children and infirm persons
unless they have been adequately supervised by a responsible person to ensure
that they can use the appliance safely.
Young children should be supervised to ensure that they do not play with the
appliance.
A fire may result if the appliance is not used with care, therefore: - be careful
when using the appliance in places where there is combustible material; - do not
apply to the same place for a long time; - place the appliance on its stand after
use; - allow it to cool down before storage; - do not leave the appliance
unattended when it is switched on. - unused soldering tools should be stored in a
dry location which is out of the reach of children. Switch off all unused soldering
tool.
MAINTENANCE
Do not use this tool for any applications other than soldering or desoldering.
Do not tap the iron against the work bench or otherwise subject the iron to
severe shocks.
Do not file the soldering tip to remove oxide, please use tip cleaner or the
cleaning sponge provided. (tin the tip before storing away).
Please turn off the power before connecting or disconnecting the soldering iron.
Discontinue any further use if control station or soldering iron or cabling are
damaged or worn.
3

SPECIFICATIONS
Rated Power Input: 60w
Rated Voltage Range: AC 220-240V 50Hz.
Soldering Station Temperature: 50-480℃
Display: LED Segment Displays
DISTRI UTED Y:
TechBrands by Electus Distribution Pty. Ltd.
320 Victoria Rd, Rydalmere NSW 2116 Australia
Ph: 1300 738 555
Int’l: [phone]
ax: 1300 738 500
www.techbrands.com
Made in China
