Duratech DFC-039 User manual

1
Manual
DFC-039
DFC-049
FLOW Cartridge Filter

2

3
Removing The Cartridges
Clean Seal Ring And Seal Surface
Starting The Pump
PACKAGING CONTENTS
MAINTAINING YOUR FILTER
FILTER RE-ASSEMBLY INSTRUCTIONS
STARTING THE PUMP AND FILTER SYSTEM
INSTALLATION
SAFETY INSTRUCTIONS
FILTERING
LOW WATER FLOW
SHORT FILTER CYCLES
POOL WATER WON’T CLEAR UP
LEAKING OF THE CLAMP
REMOVING THE MANUAL AIR RELIEF VALVE
RE-INSTALLATION OF THE MANUAL AIR RELIEF VALVE
FILTER SPECIFICATIONS
Cleaning The Cartridges
Body And Clamp Re-assembly
OPERATION
REMOVING THE MANUAL AIR RELIEF VALVE
WINTERIZING FILTER
PROBLEM SOLVING LIST
Filter Disassembly Instructions
Re-installing Cartridges
Before Starting The Pump
GENERAL INFORMATION
6.2.2
6.3.2
5.2.2
2.
6.2
6.3
5.2
5.1
4.
6.1
9.1
9.2
9.3
9.4
7.1
7.2
1.
6.2.3
6.3.3
6.
7.
8.
9.
6.2.1
6.3.1
5.2.1
5.
16
16
13
6
15
16
12
12
8
14
20
20
20
21
19
19
5
16
17
14
19
20
20
15
16
12
11
TABLE OF CONTENTS
SPARE PARTS LIST3. 7

4

5
1. FILTER SPECIFICATIONS
MODEL NO.
MAXIMUM WORKING PRESSURE FOR ALL MODELS = 3,45 BAR (50 PSI)
ATTENTION INSTALLER: THIS MANUAL CONTAINS IMPORTANT INFORMATION
OF THE OPERATION AND SAFE USE OF THE EQUIPMENT.
THIS MANUAL IS INTENDED FOR THE END USER OF THIS PRODUCT.
NET. WEIGHTEFFECTIVE FILTRATION RATE
M² FT²
DESIGN FLOWRATE
M³/H GMP KG
DFI - 039 39,5
48,8
425
525
24
32
150
150
13
15
DFI - 049
APPROVED FOR FRESH OR SALT WATER
MODEL NO.
MAXIMUM WORKING PRESSURE FOR ALL MODELS = 3,45 BAR (50 PSI)
ATTENTION INSTALLER: THIS MANUAL CONTAINS IMPORTANT INFORMATION
OF THE OPERATION AND SAFE USE OF THE EQUIPMENT.
THIS MANUAL IS INTENDED FOR THE END USER OF THIS PRODUCT.
NET. WEIGHTEFFECTIVE FILTRATION RATE
M² FT²
DESIGN FLOWRATE
M³/H GMP KG
DFI - 039 39,5
48,8
425
525
24
32
150
150
13
15
DFI - 049
APPROVED FOR FRESH OR SALT WATER
SUGGESTED POOL CHEMISTRY LEVELS
pH 7,2 to 7,8
Calcium Hardness 200 to 400 ppm
Chlorine (Stabilized) 1,0 to 3,0 ppm
Total Alkalinity 80 to 120 ppm
Combined Chlorine 0,2 ppm Maximum
Chlorine Stabilizer (Cyanuric Acid) 60 to 80 ppm

6
2. PACKAGING CONTENTS
Item No. Qty.Part Description
Pressure Gauge
Manual Air Relief Valve
O-Ring
Upper Filter Body for DFC-039
Upper Filter Body for DFC-049
Clamp System including:
Clamp, Clamp Nut and Bolt, Hang Tag,
Metal Reinforced Seal and Labels
1 1
1
1
1
1
1
Air Relief Filter 1
Top Manifold 1
Cartridge Element for DFC-039 4
Cartridge Element for DFC-049 4
O-Ring 1
Adaptor 1
Outlet Pipe for DFC-039 1
Outlet Pipe for DFC-049 1
Inlet Elbow 1
Outlet Elbow 1
Bottom Seal Plate 1
Lower Filter Body 1
1
½” Drain Plug with O-Ring 1
O-Ring 2
Bulkhead Fitting 2
Union Connection Kit (63mm) 2
2
3a
4
3b
5
7
6
8a
9
8b
10
11b
11a
12
14
13
15
17
18
19
16
Figure 1

7
3. SPARE PARTS LIST
Item No. Part DescriptionPart No.
Pressure Gauge
Manual Air Relief Valve
O-Ring
1
Cartridge Element for DFC-039
Cartridge Element for DFC-049
1
½” Drain Plug with O-Ring
O-Ring
Bulkhead Fitting
Union Connection Kit (63mm)
2
5
Clamp Nut and Bolt4
8a
8b
17
18
19
16
SP_DFC-003
SP_DFC-004
SP_DFC-005
SP_DFC-006
SP_DFC-001
SP_DFC-002
SP_DFC-007
SP_DFC-008

8
4. SAFETY INSTRUCTIONS
READ, UNDERSTAND AND FOLLOW ALL SAFETY AND OPERATION INSTRUCTIONS!
FAILURE TO FOLLOW SAFETY AND OPERATION INSTRUCTIONS CAN RESULT IN
SEVERE PERSONAL INJURY OR DEATH.
____CAUTION To reduce risk of injury, do not permit children to use or climb
on this product. Closely supervise children at all times. The ANSI/NSPI-4
and EN16582 Standard (above-ground and on-ground pools) advises that
components such as the ltration system, pumps, and heaters be positioned
to prevent their being used as a means of access to the pool by young
children.
____WARNING COMPONENT SEPARATION HAZARD
Pool and spa water circulation systems operate under hazardous pressure
during start up, normal operation, and possibly after pump shut off. Pressure
in system can cause explosive component separation of the upper lter
body if safety and operation instructions are not followed. Severe personal
injury or death can result.
____This product should be installed and serviced only by a qualied
____pool professional.
____This is the safety-alert symbol. When you see this symbol on your equipment
or in this manual, look for one of the following signal words and be alert to the
potential for personal injury or death.
____WARNING Warns about hazards that could cause serious personal injury or,
death, and or major property damage and if ignored presents a potential hazard.
____CAUTION Warns about hazards that will or can cause minor or moderate
personal injury and/or property damage and if ignored presents a potential
hazard. It can also make consumers aware of actions that are unpredictable
and unsafe.
The NOTICE label indicates special instructions that are important but not related
to hazards.

9
TO AVOID COMPONENT SEPARATION
-
-
-
-
-
-
-
-
-
-
-
-
____WARNING EXCESS PRESSURE HAZARD
Pressure testing of the pump and lter system in excess of the 3,45 Bar (50 PSI)
can cause explosive separation of the components. Component separation
can result in severe personal injury or death.
Follow all safety and operation instructions.
Do not operate the water circulation system if a system component is
assembled improperly, damaged, missing, or not a genuine component.
Before performing maintenance on the water circulation system, verify
all system and pump controls are in OFF position and the lter manual air
relief valve is in the OPEN position.
Use ONLY genuine components: Please use original components,
otherwise may fail in use and cause explosive separation.
Never rely on hand tightening the clamp nut to the clamp bolt.
Using a ¾” socket on a torque wrench, torque clamp nut and clamp bolt
to 17Nm (150 inch-lbs).
Before starting the circulation pump, insure the Manual Air Relief Valve
Body is properly installed onto the Upper Filter Body.
Before starting the system pump, verify that all system valves are set in a
position to allow water from the lter to return back to the pool.
Before starting the system pump, the manual air relief valve must be in the
OPEN position. Do this to remove air from the system.
When starting the circulation pump, do not stand over or near the lter.
If water leakage appears in the area of the lter tank clamp, immediately
turn off all system circulation pumps and electrical power.
Do not return to the lter until all water ow has stopped. Reassemble the
clamp system per the instructions in this manual to stop the leak.
See chapter: 9.4 LEAKING OF THE CLAMP
Return to lter to close manual air relief valve only when a steady stream
of water (Not air or air and water mix) is discharged from the manual air
relief valve.
Do not change the lter control valve position while system pump is
running.

10
____WARNING ELECTROCUTION HAZARD
-
-
-
-
High Voltage electricity is present in the pool and spa equipment. High
voltage electricity can cause shock and electrocution. Shock and
electrocution can result in severe personal injury or death.
All electrical wiring MUST be in conformance with applicable local codes
and regulations.
Before performing any service or maintenance on electrical equipment
turn off all electrical power.
Verify water discharge from the lter manual air relief valve is directed
away from electrical devices. Do not locate any electrical controls over
or near lter.
--------------------------------------------------------------------------------------------------
SAVE THESE INSTRUCTIONS

11
MODEL NO. DISTANCE: A
REQUIRED CLEARANCE
CM INCH CM INCH CM INCH
DISTANCE: B (SIDE) DISTANCE: C (ABOVE)
DFI - 039 94
112,5
37
44,3
46
46
18
18
48
56
16
22
DFI - 049
5. GENERAL INFORMATION
The ‘Cartridge Filter’ combines superior water ltration with ease of operation and
totally corrosion-resistant construction. With ltration ratings to 34,000 liters
(9000 gallons ) per hour, they are designed for continuous or intermittent operation,
for installation above or below the pool water line, for fresh or salt water swimming
pools or spa’s.
The lters utilize multiple reusable, reinforced polyester and anti-bacterial lter
cartridge elements to provide a high degree of water clarity and long lter cycles
with minimum care.
Outlet
Inlet
Manual Air Relief Valve
Figure 2

12
____This product should be installed and serviced only by a qualied pool professional.
____WARNING
Filter installation:
1.
2.
3.
4.
5.
6.
7.
8.
9.
____WARNING
1.
2.
3.
4.
5.1 INSTALLATION
The lter system should be installed on a level concrete slab or other rigid base.
Select a well drained and vented area, one that does not ood when it rains.
Position the lter so that the piping connections, and winter drain are convenient
and accesible for operation, service, maintenance and winterizing.
Position the Filter Body in such way that all operation and safety labels are visible.
Position the Filter so that the lter will drain by gravity.
If practical, place the pump and lter in the shade to shield it from continuous,
direct heat from the sun.
Connect the pool suction plumbing between the skimmer, pool suction outlet
(from the pool) and the pump.
Connect the pump discharge (pump OUTLET) to the lter INLET.
Connect the lter OUTLET to the pool return plumbing lines.
Do not locate pump controls over or near the lter.
Verify water discharge from the Manual Air Relief Valve (MAR) is directed away
from electrical devices.
Use ONLY Original components; Non-Original Clamp components may fail in
use and cause explosive component separation. Verify that Upper and Lower
Filter Bodies are properly secured with the Filter Body Clamp. Never rely on hand
tightening the Clamp Nut to the Clamp Bolt. Using a ¾” socket on a torque wrench,
torque Clamp Nut to Clamp Bolt to 17Nm (150 inch-lbs). (See Fig 5)
Verify that the Filter Manual Air Relief Body is in the LOCK position, and no lter
components are missing, damaged or not genuine DuraTech components.
(See Fig 4)
Close lter drain. NOTE: Filter Plug requires an O-Ring seal. (See Fig 3)
Open all system valves to allow water from the pool to the ltration system and
from the lter to return to the pool.
Place the Manual Air Relief Valve in OPEN position. (See Fig 4)
5.2.1 Before Starting The Pump
5.2 STARTING THE PUMP AND FILTER SYSTEM

13
MANUAL AIR RELIEF VALVE
MANUAL AIR RELIEF VALVE
Clamp Bolt
Clamp Body
Clamp Nut
To Open
O-Ring Manifold
Drain Plug
with O-Ring
Lower Body
Sealsurface
1.
2.
When starting system pump, do not stand over or near lter. If water leakage
appears at lter tank clamp, immediately turn off all system circulation pumps and
all electrical power. Do not return to the lter until all water leakage has stopped.
Reassemble the Clamp System per the instructions on page 17 in this manual to
stop leak.
See chapter: 6.3.3 Body and Clamp Re-Assembly
When a steady stream of water (Not air or air and water mix) is discharged from
the Manual Air Relief Valve, then close the Manual Air Relief Valve.
5.2.2 Starting The Pump
Figure 3
Figure 4
Figure 5

14
Time to clean the
Filter Cartdridges,
when the pressure
reaches the Red Arrow.
0,49 - 0,69 Bar
(7 - 10 PSI)
Clean Pressure.
Place a Green
Arrow here.
0 Bar
6. OPERATION
____WARNING
Filtration starts as soon as ow is steady through the lter. As the lter removes dirt
from the pool water, the accumulated dirt causes a resistance to ow. As a result, the
gauge pressure will rise and the ow will decrease.
When the pressure rises between 0,49 - 0,69 bar (7 and 10 psi) above the starting
pressure, or when the ow decreases below the desired rate, clean or replace the
lter cartridge elements. Once your lter is running and there is a pressure reading,
line up the green arrow with the current reading. (See Fig 6)
When the pressure rises to or above the red or second arrow, it is time to clean or
replace your lter cartridge elements.
By recording the initial starting pressure (with clean lter elements) a determination
can be made when the Filter Cartridge Elements should be replaced rather than
cleaned. After the Filter Elements have been cleaned and reinstalled if the starting
pressure is higher than 0,41 bar (6 PSI) above the starting pressure with the new Filter
Cartridge Elements, the Filter Cartridge Elements should be replaced the next time
the gauge arrow reaches the red arrow.
6.1 FILTERING
Figure 6

15
MANUAL AIR RELIEF VALVE
To Open
MANUAL AIR RELIEF VALVE
To Open
To Close
Clamp Bolt
Clamp Body
Clamp Nut
6.2 MAINTAINING YOUR FILTER
____This product should be installed and serviced only by a qualied pool professional.
____WARNING
6.2.1 Filter Disassembly Instructions
1.
2.
3.
4.
5.
6.
7.
Turn off all system circulation pumps and all electric power on the equipment pad.
Set all system valves in a position to prevent water ow to the lter.
The Manual Air Relief Valve must be placed in the OPEN position. (See Fig 8)
Remove Filter Drain Plug and drain water from the cartridge lter to a level below
the height of the Lower Filter Body. (See Fig 3)
Using 3/4” wrenches or hex sockets, loosen and remove the Clamp Nut and the
Clamp Bolt. (See Fig 7)
Holding both ends of the Filter Clamp carefully spread the clamp ends. Remove
the clamp by lifting over the Upper Filter Body. Do not drop the clamp during
removal, because the clamp could be damaged. Do not strike the clamp with
metal tools as they can damage the clamp.
Lift off the Upper Filter Body. Do not use the Pressure Gauge to lift the Upper Filter
Body.
Figure 7 Figure 8

16
1.
2.
3.
Remove the top Manifold, which is exposed when the upper Filter Body is removed.
(See Fig 3)
Remove the Filter Cartridge Elements by using slight rocking motion and lifting up.
Clean Filter Cartridge Elements.
The Cartridge Filter Element can be cleaned by washing inside and outside with
a garden hose. After hosing cartridge, for best results, carefully brush the pleated
surface to remove ne particles. Do not pressure wash as it can damage the lter
element.
You may nd some debris on the cartridge pleats, which may not have been removed
with hosing.
6.2.2 Removing The Cartridges
6.2.3 Cleaning The Cartridges
6.3 FILTER RE-ASSEMBLY INSTRUCTIONS
____This product should be installed and serviced only by a qualied pool professional.
____WARNING
6.3.1 Re-Installing Cartridges
1.
2.
3.
4.
Flush and drain any dirt or debris from the bottom of the Lower Filter Body.
(See Fig 9)
Flush any dirt or debris from the Upper Filter Body and from around the Manual
Air Relief Area.
Carefully replace the cartridges over the hubs on the bottom seal plate.
Place top manifold securely on top of cartridges, aligning the return pipe with the
port in the manifold.
1.
2.
3.
4.
6.3.2 Clean Sealing Ring and Seal Surface
Remove lter tank O-Ring.
With a clean cloth, wipe the Lower Filter Body seal surface and clean seal of all dirt
and debris. (See Fig 3) Do not use a solvent.
With a clean cloth wipe the Upper Filter Body seal surface.
Reposition the O-Ring in the Lower Filter Body.

17
MANUAL AIR RELIEF VALVE
Align the
Labels
Align the
Labels
Drain Plug
Lower Filter
Body
Clamp Bolt
Clamp Body
Clamp Nut
Figure 9
Figure 10
Figure 11

18
1.
2.
____Never hit or strike the Clamp Body with a metal hammer or any other metal tool!
Reposition the Upper Filter Body on the Lower Filter Body and press down the Upper
Filter Body against the sealing. Verify that there is an even gap between the Lower
and Upper Filter Body. If the gap is not even, then reposition the Upper Filter Body
again.
Make sure all Operation and Safety Labels are clearly visible.
Assembly the Clamp Body around the Filter Body. (See Fig 10)
1. Insert the Clamp Bolt through the Clamp ends.
2. Thread the Clamp Nut onto the Clamp Bolt.
3. Tighten the Clamp Bolt and Nut up to 17Nm (150 inch-lbs).
6.3.3 Body and Clamp Re-Assembly
Thread the Clamp Bolt 10 times and gently tap the Clamp Body with a
RUBBER hammer, around the circumference of the Filter Body.
Thread the Clamp Nut about 10 times and gently tap the Clamp Body with
a RUBBER hammer, around the circumference of the Filter Body.
Use a torque wrench to apply the nal torque on the Clamp Nut and Bolt.
(17Nm /150 inch-lbs)
-
-
-
--------------------------------------------------------------------------------------------------
Follow again the instructions for “Starting the Pump and Filter System”.

19
7.1 REMOVING THE MANUAL AIR RELIEF VALVE
____This product should be installed and serviced only by a qualied pool professional.
____WARNING
7. THE MANUAL AIR RELIEF VALVE
7.2 RE-INSTALLATION OF THE MANUAL AIR RELIEF VALVE
1.
2.
3.
4.
5.
6.
Check the O-Ring seals, replace as needed.
With a clean cloth, wipe the Upper Filter Body and O-Ring groove.
Remove all dirt and debris.
Align the notch in the MAR Flange with notch on top of the Upper Filter Body.
Press the MAR straight down into the Upper Filter Body.
Turn the MAR clockwise until the indicator is aligned with the “LOCK” position on
the Upper Filter Body.
Verify the MAR discharge points away from all electrical connections.
Turn off all system circulation pumps and all electric power on the equipment pad.
Set all system valves in a position to prevent water from owing to the lter.
The Manual Air Relief Valve must be placed in the OPEN position. (See Fig 11)
Wait until all water leakage has stopped.
The Manual Air Relief Valve can be removed by screwing the whole parts counter
clockwise.
Your Filter comes with a Manual Air Relief Valve (MAR) preinstalled rom the factory.
For Qualied pool professionals only: If MAR valve needs to be serviced, follow these
instructions carefully.
1.
2.
3.
4.
5.

20
9. PROBLEM SOLVING LIST
9.1 LOW WATER FLOW
9.2 SHORT FILTER CYCLES
9.3 POOL WATER WON’T CLEAR UP
1.
2.
3.
1.
2.
1.
2.
3.
Check the skimmer and the Pump Strainer Baskets for debris.
Check for restrictions in the intake and discharge lines.
Check for air leaks in the intake line. (Indicated by bubbles returning to the pool)
Check for algae in the pool and super-chlorinate the pool water as required.
Be sure chlorine and pH levels are in the proper range (adjust as required).
Check the Chlorine, pH and Total Alkalinity levels and adjust as required.
Be sure the ow rate through the lter is sufcient.
Operate the lter for longer periods.
____This product should be installed and serviced only by a qualied pool professional.
____WARNING
____In areas where subfreezing temperatures can be expected, the lter should be
____drained to protect the lter from damage.
1.
2.
3.
4.
5.
The lter should be disassembled and the Filter Cartridges Elements cleaned or
replaced.
Follow directions under FILTER DISASSEMBLY INSTRUCTIONS
Then follow REMOVING CARTRIDGES per instructions
Reassemble per FILTER RE-ASSEMBLY INSTRUCTIONS.
Be sure to leave the Drain Plug unattached during the winter season to avoid
cracking the Filter Body.
8. WINTERIZING FILTER
