Duratool D03291 User manual

Hand Held Hot Air SMD Rework Tool
Model: D03291

IMPORTANT SAFETY INFORMATION
WHAT’S INCLUDED
OPERATION
• Hot air rework tool
• 3 off spare nozzles
• Stand
• Instruction manual.
• When using electrical appliances basic safety precautions should always be
followed.
• Check that the voltage indicated on the rating plate corresponds with that of the
local network before connecting the appliance to the mains power supply.
• Do not operate the appliance with a damaged plug or cord, after a malfunction or
after being dropped or damaged in any way.
• If the supply cord is damaged, it must be replaced by a qualied engineer in order
to avoid injury or a hazard.
• There are no user-serviceable parts in this product. Refer servicing to qualied
personnel.
• The nozzle and accessories of this tool become extremely hot during use. Let
these parts cool down before touching or changing accessories.
• Do not expose to rain or moisture.
• Do not leave the appliance unattended when it is switched on.
• Do not direct the hot airow towards yourself or others.
• Do not use in the presence of an explosive atmosphere.
• A re may result if the appliance is not used with care, therefore be careful when
using the appliance in places where there are combustible materials. Be aware
that heat may be conducted to combustible materials that are out of sight.
• This appliance is not intended for use by persons (including children) who are not
mentally able, physically capable, experienced or do not understand the product.
They should be given supervision and instruction in the use of the appliance by a
person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Do not apply heat to the same place for a long time.
• Ensure there is sufcient space and ventilation around the appliance to allow the
escape of heat and/or fumes.
• Never place the product or part of it in water, or operate if your hands are wet.
• Always observe the safety instructions and applicable regulations.
• Always place the tool on it’s stand when not in use.
• Disconnect from the supply when not in use.
• Use only one hand to hold the tool.
Prior to operation :
• Attach the required nozzle for the task.
• Connect the mains plug to a socket.
• Turn on the power switch, set the air ow rate and temperature.
• Put the nozzle on the pins of the IC, so that the hot air can melt the solder tin on
the IC pin, then use tweezers to remove the IC.

CONTROLS AND LCD DISPLAY
Note: The rework tool is tted with an overheat safety cut-out which will cut the power
until the heat level has dropped to a safe level.
Display in C or F Scale Temperature display
Fan speed display
Temperature scale
indication
Mode selection button Adjustment buttons
• The central three digit display shows the temperature. oC is default.
• To adjust the temperature press the + or - buttons. During this procedure the
‘Setting’ icon will display. Once adjustment is complete this will extinguish.
• To display the temperature in C or F press the oC/F button. The scale indicator will
display the chosen setting.
• To adjust the fan speed press ‘*’ button. The fan symbol will display.
• Press + or - to adjust the fan speed. The speed display will show the speed setting
incrementally.
• Press ‘*’ button again to exit the fan speed adjustment mode.
ACCESSORY FITTING
• Removing or tting nozzles should only be done when the hot air tool is switched
off and at room temperature.
• The nozzles are a rm slip on t onto the output tube with additional locking screw.
• Do not over tighten the screw.
CLEANING
• Cleaning should only be done when the heat gun is switched off and at room
temperature.
• The hot air tool may be cleaned with a damp cloth and a small amount of liquid
detergent if necessary.
• Do not use any chemicals, abrasives or solvents that could damage the casing.

SPECIFICATION
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF
ELECTRICAL & ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical
& Electronic Equipment (WEEE). Any WEEE marked products must not be mixed with
general household waste, but kept separate for the treatment, recovery and recycling of
the materials used. Contact your local authority for details of recycling schemes in your
area. Made in China. PR2 9PP
Man Rev 1.0
Voltage 220-240V~50Hz
Power 300W
Air temperature 200-500oC / 392-932oF
Air Flow 22l/min (Max)
