HOW TO USE THIS MANUAL
Dustbane Products Limited
This manual contains the following sections:
-HOW TO USE THIS MANUAL
-SAFETY
-OPERATIONS
-MAINTENANCE
-PARTS LIST
The HOW TO USE THIS MANUAL section
will tell you how to find important information
for ordering correct repair parts.
Parts may be ordered from authorized dealers.
When placing an order for parts, the machine
model and machine serial number are important.
Refer to the MACHINE DATA box which is
filled out during the installation of your machine.
The MACHINE DATA box is located on the
inside of the front cover of this manual.
The model and serial number of your machine is
on the bottom back-end of the machine.
The SAFETY section contains important
information regarding hazard or unsafe practices
of the machine. Levels of hazards is identified
that could result in product or personal injury, or
severe injury resulting in death.
The OPERATIONS section is to familiarize the
operator with the operation and function of the
machine.
The MAINTENANCE section contains
preventive maintenance to keep the machine and
its components in good working condition. They
are listed in this general order:
-Belt/Brush Motor
-Vac Motor and Filters
-Vac Motor Carbon Brushes
-Brush Motor
-Carbon Brush
-Daily Maintenance
-Regular/Periodic Maintenance
The PARTS LIST section contains assembled
parts illustrations and corresponding parts list.
The parts lists include a number of columns of
information:
-REF –column refers to the
reference
number on the parts illustration.
-PART NO. –column lists the part
number for the part.
-QTY–column lists the quantity of
the
part used in that area of the
machine.
-DESCRIPTION –column is a
brief
description of the part.
-SERIAL NO. FROM–column
indicates the first machine the part
number is applicable to. When the
machine design has changed, this
column will indicate serial number
of applicable machine. The main
illustration shows the most current
design of the machine. The boxed
illustrations show older designs. If
column has an asterisk (*), call
manufacturer for serial number.
-NOTES–column for information
not noted by the other columns.
NOTE: If a service or option kit is installed on
your machine, be sure to keep the KIT
INSTRUCTIONS which came with the kit. It
contains replacement parts numbers needed for
ordering future parts.
MODEL _____________________________________
DATE OF PURCHASE ________________________
SERIAL NUMBER ____________________________
SALES REPRESENTATIVE # ___________________
DEALER NAME ______________________________
OPERATIONS GUIDE NUMBER __________________
PUBLISHED ________________________________
1-1
