Dustcontrol DC 1800 Autostart User manual

1
Mobile Instructions
This Document is intended to be a condensed version of the
DC 1800 manual, for field use.

2
Disclaimer
Dustcontrol reserves the right to change speci cations
without notice and is under no obligation to alter previously
delivered products. Dustcontrol is not responsible for errors
or omissions in this catalogue.

3
Content
Table of Contents
Safety Considerations ............................................................. 4
Technical Data ........................................................................ 8
Operation ................................................................................ 9
Service ................................................................................... 10
Accessories............................................................................ 12
Warranty ............................................................................... 13
Trouble Shooting .................................................................. 14
Spare Parts ............................................................................ 15

4
Safety Considerations
Read all instructions before attempting to operate this
machine and save these instructions. Warning! When using
electric machines, basic safety precautions should always be
followed to reduce the risk of re, electric shock and
personal injury, including the following:
1. Important!
Neither hot particles nor ignition sources are allowed to be
sucked into the unit. The machine should not be used for
explosives, unstable or pyrophoric particles or dust.
– WARNING Operators shall be adequately instructed on the
use of these machines.
– WARNING This machine is for dry use only.
– CAUTION This machine is for indoor use only.
– CAUTION This machine shall be stored indoors only.
2. Work area environment
Don´t expose the machine for rain. Don´t use it in damp or
wet locations or in presence of flammable liquids or gases.

5
3. Overload
Never let the machine operate fully throttled. Always follow
the regulations pertinent to the material you are working
with i.e. asbestos. Don´t use the machine for purposes that it
isn´t intended for.
4. Body injuries
Never let the suction come in contact with parts of the body.
The strong suction effect can hurt the blood-vessels in the
skin. Don´t repair the electric components yourself. The
machine should be serviced by quali ed personnel only.
Faults may cause injury. See also below under warnings.
5. Don´t abuse cord
Never pull the machine by the cord. Keep the cord from heat
and sharp edges. Check the electric cable regularly for
damage.
6. Important measure
With cleaning and maintenance on the machine, the power
cable should be dis-connected from the supply. The machine
must not be washed or cleaned with water.

6
7. Maintain the machine with care
Keep the machine clean and check that the hose is
undamaged and that all gaskets are tight. Follow
instructions. Keep handles dry and free from oil and grease.
8. Checking for damage
Before further use of the machine it should be carefully
checked that the machine is undamaged. If there are any
damaged parts these should be repaired by a Dustcontrol
authorized service center. If the supply cord is damaged, it
must be replaced by the manufacturer, its service agent or
similarly quali ed persons in order to avoid a hazard.
9. Warning
Use only accessories and replaceable parts which are
available in the Dustcontrol catalogue.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.

7
Children should
be supervised to ensure that they
do not
play with the appliance.
This machine is intended for commercial use only, for
example in hotels, schools, hospitals, factories, shops, offices
and rental businesses.

8
Technical Data
DC 1800
HxWxL (mm/in) 740x380x380 / 29x15x15
Weight (kg/lb) 10/22
Hose Length (m) 5
Collecting Container (l) 20
Max, Flow (m
³
/h /cfm) 190/114
Neg. Pressure (kPa/inwg) 21/84
Power Consumption (W) 1200
Fine Filter Area (m
²
/ft
²
) 1.5/16.2
Degree of Separation
(EN 60335-2-69, Class M)
99.9%
H13 HEPA Filter Area (m
²
/ft
²
) 0.85/9.2
HEPA Degree of Separation
(EN 1822-1)(EN 60335-69, Class
H)
HEPA H13
99.995%
*Sound Level <68 dB(A)
* Sound level at 1.6 m height and 1 m distance according to DIN
45635 Section 1 (4/84) in free space and at maximum airflow.

9
Operation
Connect machine to suitable power source. If extension cord
is to be used only waterproof is acceptable.
The DC 1800 is equipped with a filter indication lamp alerting
you when the filter requires cleaning or changing. Generally
the filter should be cleaned once to twice daily. DC Canada
recommends cleaning it before the machine is shut down.
Machine must be running to preform filter cleaning. To
preform filter cleaning first loosen end cuff off tool. Block the
end cuff by pressing it onto the cylindrical protrusion on the
outlet channel. Push the side flap open and release it quickly
to pulse the filter. Repeat this 3-6 times. Below is a pictorial
showing the correct procedure.

10
The DC 1800 can be used with or without a plastic colle
ction
bag. The plastic bag of the DC 1800 should be changed only
after filter cleaning. Changing the bag is as simple and only
involves un-latching the three container latches, removing
and replacing the bag then re-latching the container on.
When installing a bag with the assembly make sure it seats
around the container edge. This ensures a proper seal and
that the bag will not be sucked into the cyclone body.
Service
During cleaning disconnect unit from power. The fine filter
should be changed at least once per year. HEPA filter is
recommended to be changed every 300 running hours. Use
proper protection to ensure ones self as well as surrounding
persons are shielded from Dust during filter change. Check
the power cord regularly for damage.
Filter change (pictorial of steps below)
Remove motor head and locate the top side of the filter. Lift
the filter out of the housing. Place in new filter with the
same orientation as the old one. If dustless changes are
required place a plastic bag over the top of the machine

11
before removing the filter.
Check gasket during filter change
to ensure good seal is made, if a poor seal is present dust will
travel downstream and cause damage to the motor.
Fine Filter
HEPA Filter

12
Motor Service
For vacuum motor the typical average life of the original
brushes is 600 - 700 hours. They can then be exchanged or
complete motor/fan replaced. For 2nd brush set life is 400
hours and for 3rd brush set 300 hours. After that the
commutator is worn out and the motor needs to be
replaced.
Accessories
Description Part No.
Plastic sack, standard 42027
Fine Filter, cellulose
(standard)
42029
Fine Filter, polyester 42028
HEPA Microfilter 42027
Machine inlet cuff 2108
Hose (5 m length) 2012
Turnable end cuff 2114
Ø
38 mm chrome wand 7257
Ø
38 mm Alu Floor tool 7235
*Note other accessories are available for use with this
machine. This list includes all accessories supplied standard
with the DC 1800 excluding the 42028 filter.

13
Warranty
The warranty period for this machine is two years and covers
manufacturer’s faults. The warranty is valid under the
condition that the machine is used under normal conditions
on the task for which it was designed and is maintained
properly.
Normal wear is not covered by this warranty. Service
performed by other than Dustcontrol or its authorized agent
voids automatically the warranty. No other warranty express
or implied is applicable.

14
Trouble Shooting
Below is a list of common problems of the machine. If your problem is
not found below contact your local Dustcontrol dealer.
Problem
Fault
Solution
Motor will not start.
Machine not
connected.
Make sure of
connection
The motor stops
directly after starting.
Incorrect fuse.
Change to correct
circuit.
Fan runs
but no
suction.
Hose not connected.
Hose is plugged. No
plastic sack on cyclone.
Connect the hose. Find
and remove block.
Mount the correct
sack.
Fan runs but poor
suction.
Hole in the hose.
Plugged filter. Hose too
long or too small. Hose
is kinked. Machine top
mounted incorrectly.
Dust is packed in the
cyclone.
Change or repair hose.
Clean or change filter.
Change the hose.
Check and free kink.
Adjust motor
mounting. Take off top
and clean cyclone.
Machine blows dust.
Filter is perforated or
has come loose.
Check the filters and
change if necessary.
Abnormal sound from
machine.
Order service.

15
Spare Parts
Below is a simplified parts breakdown of the DC 1800. On the
preceding page is a table outlining the parts. Contact your local
Dustcontrol dealer or full manual for further spare parts.

16
Art No.
Description
40097
Switch
40453
Filter Cleaning Flap
40524
Guiding Flange
42012
Bottom Cone assembly
4847
Bottom Flap only
4867
Bottom Cone only
42027
HEPA Filter
42029
Fine Filter Cellulose (Standard)
42028
Fine Filter Polyester (optional)
42275
Outlet Channel
42366
Wheelset
42366
Fastener
426700
Handle
42702
Plastic Bag
42814
Clip for fastener
42820
Chassis
4850
Cone Gasket
48
5100
Solid Top Cover
485101
Cover with hole
485703
Motor Housing
4871
Motor Assembly
4873
Front Wheel (castor)
487802
Power Cord
940452
-
70
Inlet Module
