DVIGear DVI-3130a User manual

DVI-D Fiber Optic Cable
User Guide
DVI to HDTV Converter
DVI-3130a
HDTV to DVI Converter
DVI-3310a

Table of Contents
Section Page
1.0 Introduction.......................................1
2.0 Specifications.....................................3
3.0 Checking Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . 4
4.0 Connecting the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5.0 OperatingTheUnit.................................4
6.0 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
7.0 Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
8.0 RegulatoryCompliance.............................5

-1-
1.0 INTRODUCTION
Thank you for purchasing this Format Converter from DVIGear. The model
DVI-3130a converts HDTV component analog inputs (YPbPr) to digital DVI
format signals enabling display on digital HDTV monitors, or as an input to
DVI distribution devices. The model DVI-3310a converts a digital DVI signal
(non-HDCP) to HDTV component analog format (YPbPr) allowing the viewing
or switching of a DVI input signal on an analog system. Our professional
video conversion products have been serving the industry for several years.
DVIGear offers a full line of high quality Video Scalers, Scan Converters,
Analog-Digital Converters and DVI/HDMI Converters, as well as Signal
Switchers and Distribution Amplifiers.
1.1 Liability Statement
Every effort has been made to ensure that this product is free of errors. DVIGear
cannot be held liable for the use of this hardware or any direct or indirect
consequential damages arising from its use. It is the responsibility of the user
of the hardware to check that it is suitable for his/her requirements and that
it is installed correctly. All rights reserved. No parts of this manual may be
reproduced or transmitted by any form or means electronic or mechanical,
including photocopying, recording or by any information storage or retrieval
system without the written consent of the publisher.
DVIGear reserves the right to revise any of its hardware and software following
its policy to modify and/or improve its products where necessary or desirable.
This statement does not affect the legal rights of the user in any way.
All third party trademarks and copyrights are recognised. The DVIGear logo is
a registered trademark of DVIGear, Inc. All other trademarks are the property of
their respective holders.
1.2 Features
The DVI-3130a DVI to HDTV Converter and DVI-3310a HDTV to DVI Converter
offering several unique features:
•Improved Video picture quality via DVI interface
•Format may be digital RGB or analog YPbPr
•Plug and Play for easy installation and use
•Supports Single-Link DVI data rates up to 1.65 GBit/sec.
•Supports pixel clock rates up to 165 MHz

-2-
1.3 Getting the Best Results
There are many factors affecting the quality of results when converting video
signals. Some basic precautions will ensure the best possible performance from
this product.
Output Display Device – The quality of the output signal will depend largely upon
the type and quality of display device used. For instance, some video projectors
just look better than others.
Distance between the Video Converter and the Display Device – This plays a
major role in the final result. Long distances are possible, but special measures
should be taken in order to avoid cable losses. These include using high quality
(coax-type) VGA cables and premium DVI Cables such as DVIGear’s Super High
Resolution™ cables. In some applications the use of digital repeaters or extenders
may also be necessary.
Output Connection Cables – Low quality cables are susceptible to interference.
They degrade signal quality due to poor impedance matching and cause
elevated noise levels. Therefore, cables should be of the best quality. Coax-type
computer cables are recommended because of their superior internal shielding
characteristics.
Interference from Nearby Electrical Devices – These can have an adverse effect
on signal quality. For example, an older computer monitor often emits very high
electromagnetic fields that can interfere with the performance of video equipment in
its proximity.

-3-
2.0 SPECIFICATIONS
Video Input/Output
YPbPr Analog Component
3x RCA Female connectors
Y: 1V p-p@75Ω
Pb/Pr: 0.7V p-p@75Ω
DVI Digital RGB
1x 29-pin DVI-I Female connector
8-bit RGB 4:4:4, or 12-bit Component 4:2:2
DVI Rev 1.0 compliant
Bandwidth / Bit Rates
Maximum Pixel Clock Frequency up to 165 MHz
Data Rate (Single-Link DVI) up to 1.65 GBit/sec.
Supported Resolutions
Interlaced (50, 60Hz) 480i, 576i, 1080i
Progressive (50, 60Hz) 480p, 576p, 720p, 1080p
Special (24, 30Hz) 1080p@24, 1080p@25, 1080p@30
Scaling Engine none
Mechanical
Size (H x W x D) 1.2” x 3.0” x 4.1” (30 x 76 x 105 mm)
Weight (Net) 11.0 lbs. (2.2 kg)
Environmental
Operating Temperature 0°to +48°C (+32°to +120°F)
Operating Humidity 10% to 85% Non-condensing
Storage Temperature -10°to +70°C (+14°to +158°F)
Storage Humidity 10% to 85% Non-condensing
Power Requirements
External AC Power Adaptor Input: 100-240 VAC @50-60Hz
Output: +5 VDC / 2A
Regulatory Approvals
Converter Unit FCC, CE
Power Adaptor UL, CE, CSA

-4-
3.0 CHECKING PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make certain
the following items are contained in the shipping carton:
• DVI-3130a DVI to HDTV Converter, or DVI-3310a HDTV to DVI Converter
• 1x External AC Power Adapter
• 1x User Guide
Note: Please retain the original packing material should the need ever arise to return the unit.
If you find any items are missing, contact your reseller or DVIGear immediately. Please have the
Model Number, Serial Number and Invoice Number available for reference when you call.
4.0 CONNECTING THE HARDWARE
DVI INTPUT 5VDC
C
+
-
Pr Pb Y
OUTPUT
Converter DVI to HDTV
DVI-3130a
DVI OUTPUT 5VDC
C
+
-
Pr Pb Y
INPUT
Converter HDTV to DVI
DVI-3310a
DVI-3130a DVI to HDTV Converter DVI-3310a HDTV to DVI Converter
To begin, connect the External AC Power Adapter to the unit’s DC Power Input
Jack input. Then connect the appropriate cables from the source device to the
unit’s input panel. Finally, connect the output cables from the unit’s output panel to
the destination device. Once the cables have been connected, apply power to the
source and destination devices, then plug the converter’s power adapter into an AC
power source. The converter will function as soon as it has power and you should
immediately see an image on the output device.
5.0 OPERATING THE UNIT
Neither the DVI-3310a nor the DVI-3130a has any controls that require adjustment.
Simply connect the cables and power as explained in Section 4 above and the
device will convert whatever signal is present on its input to the complementary
signal on its output. For example, if you provide a digital 1080i resolution signal
to the input of the DVI-3310a, an analog 1080i signal will appear on its output.
The DVI-3130a would perform the same conversion in reverse, changing a 1080i
resolution analog signal into a 1080i Digital signal.
Note: DVI signals that are HDCP encrypted will NOT be converted by these devices due to
licensing and legal issues. This does not constitute a failure of the units.

-5-
6.0 TROUBLESHOOTING
Other than problems with power or cabling, there is little in the way of
troubleshooting required for either of the products. If neither the cabling nor the
power is at fault and you still have faulty operation, make certain that both the
source and destination devices are working properly.
After trying the above suggestions should the problem still persist, contact your
dealer for additional suggestions. Should the dealer’s technical personnel be
unable to assist you, please contact DVIGear via telephone at [phone]
(United States and Canada); international callers may dial [phone], or use
e-mail at [e-mail]
7.0 LIMITED WARRANTY
LIMITED WARRANTY – With the exceptions noted in the next paragraph,
DVIGear, Inc. warrants the original purchaser that the equipment it
manufactures or sells will be free from defects in materials and workmanship for
a period of three years from the date of purchase. Should this product, in
DVIGear’s opinion, prove defective within this warranty period, DVIGear, at its
option, will repair or replace this product without charge. Any defective parts
replaced become the property of DVIGear. This warranty does not apply to
those products which have been damaged due to accident, unauthorized
alterations, improper repair, modifications, inadequate maintenance and care, or
use in any manner for which the product was not originally intended.
If repairs are necessary under this warranty policy, the original purchaser must
obtain a Return Authorization Number from DVIGear and return the product
freight prepaid to a location designated by DVIGear. After repairs are complete,
the product will be returned, freight prepaid.
LIMITATIONS – All products sold are “as is” and the above Limited Warranty is
in lieu of all other warranties for this product, expressed or implied, and is
strictly limited to three years from the date of purchase. DVIGear assumes no
liability to distributors, resellers or end-users or any third parties for any loss of
use, revenue or profit.
DVIGear makes no other representation of warranty as to fitness for the purpose
or merchantability or otherwise in respect of any of the products sold. The liability
of DVIGear with respect to any defective products will be limited to the repair
or replacement of such products. In no event shall DVIGear be responsible or
liable for any damage arising from the use of such defective products whether
such damages be direct, indirect, consequential or otherwise, and whether such
damages are incurred by the reseller, end-user or any third party.
8.0 REGULATORY COMPLIANCE
This product has been tested for compliance with: FCC Class B and CE. The
External AC Power Adapter supplied with this product has been tested for
compliance with: UL, CSA and CE. This product is RoHS compliant.

Your Digital Connectivity Experts
400 Meadowmont Village Circle
Suite 425
Chapel Hill, NC 27517
Toll Free 888.463.9927
Phone [phone]
Fax [phone]
www.dvigear.com
www.dvigear.com
Toll Free 888.463.9927 DVIGear, Inc.
Phone [phone] Triad Court, Suite 8
Fax [phone] Marietta, Georgia 30062-2258
DVI-3130a-UG-01 / Mar.2007
