Dwyer Instruments SPPM Series Installation and operating instructions

Series S M Smart rogrammable anel Meters
Specifications - Installation and Operating Instructions
Bulletin C-S M
DWYER INSTRUMENTS, INC. hone: 219/879-8000 www.dwyer-inst.com
.O. BOX 373 • MICHIGAN CITY, INDIANA 46360, U.S.A. Fax: [phone] e-mail: [email protected]
The Series S M Smart rogrammable anel Meter is a configurable, full color
display that can be used in a variety of applications. Utilizing a USB connection,
the panel meter can be configured with downloadable software, using any
computer running Windows®based software. Available with a 2.4˝, 2.8˝ or 3.5˝
screen which features remarkable graphics that can easily be customized to read
and/or graph pressure, temperature, humidity, gas concentration, or many other
parameters. Up to two transmitters or transducers can feed the panel meter’s user
scalable inputs. The Series SPPM includes a gasket and mounting clip for quick
installation into a panel.
S ECIFICATIONS
Inputs: 0 to 40 VDC, scalable (factory
set from 0 to 10 V).
Accuracy: 0.1%.
Resolution: 0.3 to 9.8 mV (depending
on input range).
ower Supply: 4-30 VDC.
Current Consumption: 190 mA max.
Display: 2.4˝, 2.8˝ or 3.5˝ TFT full
color screen.
Display Resolution: 320 x 240 pixels.
Sampling Rate: 3 samples/second.
Operating Temperature: 32 to 104°F
(0 to 40°C).
Mounting: Panel mount.
Connection: Screw terminals, pin
connection, or USB.
Software Requirements: Compatible
with Windows®XP, Windows®2000,
Windows®7 and Windows Vista®.
Weight: SPPM-24: 3.2 oz (90.7 g);
SPPM-28: 4 oz (113.4 g); SPPM-35:
5.1 oz (144.6 g).
Approvals: CE, oHS.
1-11/16
[42.55]
23/32
[18.29]
9/32
[7.11]
1-29/32
[48.26]
15/16
[23.62]
1/2
[12.45]
1/16
[1.52]
21/32
[16.51]
3[76.45]
2-3/8
[60.44]
SMART PROGRAMMABLE PANEL METER
(COUNTRY OF ORIGIN)
DATE CODE
Windows® and Windows Vista® are registered trademarks of Microsoft Corporation
3-17/32
[89.51]
3-1/2
[89.10]
1/4
[6.71]
19/32
[15.19]
2-1/8
[53.81]
19/32
[15.20]
5/16
[7.70] 3-5/16
[84.10]
9/16
[14.00]
3/16
[5.07]
2-1/4
[56.80]
1-11/16
[43.22]
29/32
[23.40]
3/8 [9.80]
3/4
[19.06] 1-3/8
[35.12]
5/32 [3.90]
11/16
[17.80]
1/16
[1.90]
2-9/32
[57.60]
SM-24
S M-28
Figure 1
3-25/32
[96.00]
3-1/2 [88.85]
3-3/32
[78.50]
29/32
[23.30]
27/32
[21.26]
31/32
[24.81] 2-5/32
[55.01]
23/32
[17.95]
3/32
[2.70]
5/8
[16.16]
S M-35
Mounting
1. Punch out a rectangular hole in the panel or enclosure.
SPPM-24 Panel Cut-out: 2.91 x 1.81˝ (74 x 46 mm).
SPPM-28 Panel Cut-out: 3.43 x 2.15˝ (87 x 54.5 mm).
SPPM-35 Panel Cut-out: 3.62 x 2.91˝ (92 x 74 mm).
2. Place the gasket around the bezel of the display.
3. Slide the display through the front hole in the panel or enclosure.
4. Attach the mounting clip from the rear as shown in Figure 1.

Wiring
Series SPPM features two voltage inputs that can be programmed independently.
With the downloadable software, the user can scale the two voltages to create eight
different voltage ranges. The software is programmed to use the smallest range
possible because the smallest voltage range offers the highest resolution. The eight
possible voltage ranges and their corresponding resolutions can be found in the Table
1.
Table 1
Figure 2
IN2 Analog voltage input 2 (maximum of 40 VDC);
IN1 Analog voltage input 1 (maximum of 40 VDC);
0 V 0V power supply input;
V+ Positive power supply input (4 to 30 VDC).
Current Consumption
The current consumption of the panel meter is voltage dependent.
Graph 1
USB Connection
A USB cable is required for customization of the Series SPPM. When connected to a
PC’s USB port, the display is powered by the PC.
in Connection
The DIL IDC socket is an alternative to using the screw terminals. This connection can
also be utilized for data busses and alarm outputs. See Figure 3 for the pin layout.
Figure 3
Downloading Software
Customization software is available at www.dwyer-inst.com. To download, follow
these instructions:
1. To begin downloading, click “ un” when prompted.
2. When a security warning appears, click “ un” a second time.
3. As soon as the InstallShield Wizard screen appears, follow the on-screen
instructions.
4. If a Windows®logo testing error appears, click “Continue Anyway” .
5. When installation is complete, click “Finish” to quit the installer. The software can
now be used by clicking on the new icon on the desktop.
Launch the software before plugging in the smart panel meter.
DAC1
SPI-SLCK
SPI-MISO
I²C-SCL
ALM1
0V
IN1
0V
SPI-MOSI
SPI-CS2
I²C-SDA
ALM2
V+
IN2
Voltage Range (V)
0 to 1.25
0 to 2.5
0 to 4
0 to 5
0 to 8
0 to 10
0 to 20
0 to 40
Resolution (mV)
0.3
0.6
1.0
1.2
2.0
2.4
4.9
9.8
NOTICE
For safety reasons, the meter should be isolated from both the
supply and signal voltages before connecting the USB.
CAUTION

Set Up Menus
When setting up new configurations, the following items can be adjusted, scaled, or
changed:
Meter Style
Input Voltage Range
Color and Appearance
Splash Screen
A configuration can be saved or immediately uploaded to a smart panel meter.
MAINTENANCE
Upon final installation of Series SPPM, no routine maintenance is required. The
display is not protected against moisture or dust and should only be cleaned with a
dry, soft, and lint free cloth. Series SPPM is not field serviceable and should be
returned if repair is needed (field repair should not be attempted and may void
warranty). Be sure to include a brief description of the problem plus any relevant
application notes. Contact customer service to receive a return goods authorization
number before shipping.

DWYER INSTRUMENTS, INC. hone: 219/879-8000 www.dwyer-inst.com
.O. BOX 373 • MICHIGAN CITY, INDIANA 46360, U.S.A. Fax: [phone] e-mail: [email protected]
©Copyright 2012 Dwyer Instruments, Inc. Printed in U.S.A. 6/12 F # 6-443849-00 ev. 3
