Specifications - Installation and Operating Instructions
Series DM-1000 DigiMag®Digital Differential Pressure Gage
The Series DM-1000 DigiMag®Digital Differential Pressure Gage is the ideal
digital instrument to take the place of analog mechanical pressure gages. The
DigiMag®Digital Gages are more versatile than analog gages with their ability to be
field-programmed to display many commonly used engineering units as well as
percent of full scale. The Series DM-1000 can be programmed in 8 commonly
used engineering units plus percent of full scale. This capability allows quick units
selection on site, eliminating the need to calculate various unit conversions. The
DigiMag®Digital Differential Pressure Gages have an added feature for filter
applications where a set point can be input where the display will blink when the
filter is dirty, alerting the user that a maintenance action needs to occur.
Programming the Series DM-1000 is easy using the menu key to access 4
simplified menus which provide access to: Security level; engineering units; filter
set point; view peak and valley process readings; digital damping for smoothing
erratic process applications; display update to conserve battery life; zero and span
field calibration.
The Series DM-1000 DigiMag®Digital Differential Pressure Gage possesses a full
scale accuracy of 1% on ranges down to 2˝ w.c. and 2% accuracy down to the very
low ranges of 1” to 0.25" w.c. Models are also available with bi-directional ranges.
DigiMag®Digital Differential Pressure Gages offer power versatility by working with
9-24 VDC line power or simply 9V battery power. f using line power and
connecting the 9V battery, the battery will act as a back-up if line power is lost or
interrupted.
SPECIFICATIO S
Service: Air and non-combustible, compatible gases.
Wetted Materials: Consult factory.
Housing Materials: Glass filled plastic.
Accuracy: ±1% F.S. including linearity, hysteresis and repeatability; ±2% F.S. for
ranges 1˝ w.c. and below.
Temperature Limits: 0 to 140°F (-18 to 60°C).
Compensated Temperature Limits: 32 to 122°F (0 to 50°C).
Long Term Stability: ±1% F.S. per year.
Thermal Effect: ±0.05% F.S./°F typ.; ±0.10% F.S./°F for ranges 1˝ w.c. and
below.
Display: 4-digit LCD (Digits: 0.60˝H x 0.33˝W).
Display Update: Selectable for 1 second to 10 minutes or update only from
button push.
Pressure Limits: Normal and bi-directional ranges 5˝ w.c. and lower = 2 psi
(13.7 kPa); Normal and bi-directional ranges 10˝ w.c. and higher = 11 psi (75
kPa).
Selectable Engineering Units: in w.c., psi, kPa, Pa, mm w.c., mBar, in Hg, mm
Hg, FS (0-100%).
Power Requirements: 9V battery or external power supply 9-24 VDC. Battery
included but not connected.
Type of Battery: 9V alkaline battery (Duracell®PC 1604 or equivalent).
Battery Service Life: Battery life depending on the Display Update setting: 150
hours (typical) if Display Update = 1 second; 9 month (typical) if Display Update =
10 minutes; 1.5 years (typical) if Display Update is disabled. Battery may last up
to four times longer when using lithium-based battery ULTRAL FE U9VL-J.
Current Consumption: 5 mA maximum.
Electrical Connections: Removable terminal block for 16 to 26 AWG.
Electrical Entry: Cable gland for 0.114 to 0.250˝ (2.9 to 6.4 mm) diameter cable.
Process Connections: 3/16˝ .D. tubing (5 mm .D.), maximum O.D. 3/8˝ tubing.
Enclosure Rating: NEMA 4X ( P66).
Weight: 1.18 lb (535 g).
Size: 5˝ (127 mm) O.D. front face.
Agency Approvals: CE, EN 61326-1 [ mmunity Test Requirement for ndustrial
Environments] with the following SPEC:
EC 61000-3-2
EC 61000-3-3
EC61000-4-2
EC61000-4-3
EC61000-4-4
EC61000-4-5
EC61000-4-6
EC61000-4-11
Duracell®is a registered trademark of The Gillette Company.
4-31/64
[113.89]
3X1/8
[3.30]
1-59/64
[48.89]
17/64
[6.91]
Ø5
[127.00]
PRESSURE
CONNECTIONS
21/64 [8.59] LONG
3-5/64
[78.27]
1
[25.44]
3-15/32
[88.12]
Ø13/64
[5.18]
Ø25/64
[10.03]
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

ISTALLATIO
Mounting
A vertical position required. That is the position in which all standard models are
calibrated at the factory. Provide a 4-9/16˝ diameter opening in panel. nsert gage
and secure in place with provided screws and adapters.
ncluded Accessories:
Mounting lugs –3
6-20 x 2-1/2 screws –3
4-20 x 3/8 screws – 3 (mounting hole depth is 3/8˝ [9.53])
Cable gland –1
Pressure Connections
Two integral tubing connections are provided on the back of the gage. They are
sized to fit 3/16˝ (4.8 mm) .D. x 5/16˝ (7.9 mm) O.D. flexible PVC tubing. To
measure single positive pressure, connect tubing to the + port and vent the – port
to atmosphere. To measure single negative pressure (vacuum), connect tubing to
the – port and vent the + port to atmosphere. To measure differential pressure,
connect higher pressure to the + port and lower pressure to the – port. Be sure the
pressure rating of the tubing exceeds that of the operating ranges.
Electrical Connections
A 9V battery or an external power supply 9-24 VDC can be used to power the unit.
f both battery and external power supply are connected, the battery will work as
back up power.
Battery Installation
The unit is shipped with a separate 9V alkaline battery. Remove the unit’s top back
cover, do not remove bottom cover. Connect the 9V battery to the battery holder as
shown in Figure 1. Replace top back cover and tighten screws to 2 ±.25 in. lbs.
External Power Supply Installation
Remove the unit’s back cover then connect the external power supply to the
terminal block as shown in Figure 1.
OPERATI G I STRUCTIO S
Key Functions
Home Position
Function
Allows access to the
menus
Displays pressure
readings instantly
(rAtE KEY MODE only)
Displays full scale
range of unit
Main Menu
Function
Return to home
position
Sequences through
menus
Sequences through
menus
Enter into SUB
MENU
Sub Menu
Function
Return to previous
menu
ncrements a value
Decrements a value
Changes a value or
setting. Press
ENTER and display
will blink. Adjust with
UP or DOWN
arrows. Press
ENTER to store.
Display will stop
blinking.
Ø5/8 [15.88]
THRU HOLE FOR
ONDUIT CONNECTION
OUTSIDE DIAMETER
OF A-286 FLANGE
1-1/4 [31.75] (3) FLANGE MOUNTING
HOLE LOCATIONS
Ø
B
FIGURE 1
Menu
Up Arrow
Down Arrow
Enter
POWER MUST BE OFF WHILE WIRI G CO ECTIO S
ARE BEI G MADE. DO OT EXCEED SPECIFIED SUPPLY
VOLTAGE RATI GS. PERMA E T DAMAGE OT COVERED BY WARRA TY
WILL RESULT.
CAUTIO
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Menu Map
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

MAI ME U PROGRAMMI G I STRUCTIO S
(Upper Right Display Reads ME U)
Security Menu: SECr-ME U
Lock out access to all menus or lock out access to all menus except Auto-Zero
function (Auto-ZERO).
Operation Menu: OPEr-ME U
Select the measurement type – pressure, velocity or flow and corresponding
engineering units (Velocity and flow are not available for Model DM-1100).
Display Menu: diS-ME U
Monitor and adjust display related settings: Filter type, filter point, dampening,
display update, peak and valley.
Advanced Menu: AdU-ME U
Perform auto-zero or full-scale calibration.
SECURITY ME U: SECR-ME U
With the gage reading pressure (home position), press and hold the ME U key
until the Security MENU is displayed. Press the Ekey to show the security SUB
MENU SECr–0001. When the security SUB MENU is selected, the present
security level is displayed in the upper right hand display. To change the security
level, adjust the number displayed to the number shown in the following table for
the desired security level.
The password values shown in the table cannot be altered, so retain a copy of
these pages for future reference.
OPERATIO ME U: OPER-ME U
With the gage reading a numerical value (home position), press and hold the
ME U key until the Security MENU is displayed. Press the qkey to show the
OPEr-ME U. Press the Ekey to show the Operation SUB MENUS.
The Operation SUB MENUS for Series DM-1100 is PrES–I WC (Pressure–Unit)
PRESSURE SUB ME U: PRES – I WC
PrES – I WC: Pressure – inches of water column
With the LCD reading PrES – I WC, press the Ekey; the display will blink. Press
the qkey to change the pressure unit then press the Ekey to save the desired
unit.
For pressure measurement, the following units are available:
I WC – nches of water column MBAR – Millibar
PSI – Pounds per square inch I HG – nches of mercury
KPA – Kilopascals MMHG – Millimeters of mercury
PA – Pascals FS – % of full scale
MMWC – Millimeters of water column
Security Level
Displayed
1
2
3
Access
All menus access
All menus locked except
the auto-zero function
All menus locked
Password Value
to Enter
10
90
111
TABLE 1 PRESSURE RA GE VS. AVAILABLE U ITS
OTE: OFL (over flow) or UFL (under flow) will appear when the low and high
range levels have been exceeded by 10% F.S.
in w.c.
0.250
0.500
1.000
2.000
5.000
10.00
15.00
25.00
50.00
100.0
psi
–
–
–
–
0.181
0.361
0.543
0.903
1.806
3.613
kPa
0.062
0.124
0.249
0.498
1.245
2.491
3.738
6.227
12.45
24.91
Pa
62.20
124.5
249.1
498.2
1245
2491
3738
6227
–
–
mbar
0.622
1.245
2.492
4.982
12.45
24.91
37.38
62.27
124.5
249.1
mm w.c.
6.35
12.70
25.40
50.80
127.0
254.0
381.0
635.0
1270
2540
in Hg
–
–
–
–
0.368
0.736
1.104
1.839
3.678
7.355
mm Hg
0.467
0.934
1.868
3.736
9.34
18.68
28.02
46.71
93.42
186.8
% of
FS
100.0
100.0
100.0
100.0
100.0
100.0
100.0
100.0
100.0
100.0
Resolution
(in w.c.)
0.001
0.001
0.001
0.001
0.002
0.010
0.010
0.010
0.020
0.100
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

DISPLAY ME U: diS – ME U
With the gage reading a numerical value (home position), press and hold the
ME U key until the Security MENU is displayed. Press the qkey until the LCD
shows diS – ME U. Press the Ekey to show the Display SUB MENUS.
FILTER TYPE SETTI G
With the LCD reading FILt – OFF, press the Ekey; the display will blink. Press the
qkey to change the filter type then press the Ekey to save the desired filter type.
FILt – OFF: Filter type = OFF. The filter function is disabled.
FILt – HIGH: Filter type = H GH. The display blinks when pressure is greater than
the filter point.
FILt – LOW: Filter type - LOW. The display blinks when pressure is less than the
filter point.
FILTER POI T SETTI G
With the LCD reading 0.00 – SPPT, press the Ekey; the display will blink. Press
the qkey to change the filter point then press the Ekey to save the desired filter
point.
0.00 – SPPT: Filter point = 0.00. The filter point may be set to anywhere within the
range of the instrument.
DAMPI G SETTI G
With the LCD reading 1 – DAMP, press the Ekey; the display will blink. Press the
qkey to change the damping level then press the Ekey to save the desired
damping level.
1 – DAMP: Damping level = 1. The damping level can be adjusted from 1 to 15.
Damping stabilizes the display from instabilities due to things such as vibration and
excessive pressure fluctuations. The damping function adjusts the amount of
readings that are averaged for each display update.
DISPLAY UPDATE SETTI G
With the LCD reading rAtE – ORM, press the Ekey; the display will blink. Press
the qkey to change the display update rate then press the Ekey to save the
desired display update rate.
rAtE – ORM: Display update = Normal (1 second).
The gage reads the process pressure and updates the LCD every second.
rAtE – 10: Display update = 10 minutes.
The gage reads the process pressure and updates the LCD every 10 minutes.
rAtE – KEY (On-Touch mode): Display update is disabled.
The gage reads the process pressure and updates the LCD whenever the p key
is pressed. f the pkey is released, the LCD will hold and display the last pressure
reading.
OTES:
1. Depending on the Display Update setting, the battery life is shown below:
-150 hours (typical) if Display Update is set for “Normal” 1 second update. rAtE-
NORM
-9 months (typical) if Display Update is set for 10 minutes. rAtE-10
-1.5 years (typical) if Display Update is disabled. rAtE-KEY
2. f the Display Update is set for 10 minutes or disabled (On-Touch mode), the
process pressure value can be read instantly by pressing and holding the pkey
on the front panel. Also the LCD will automatically show “ALAr” if the filter point has
been exceeded.
PEAK A D VALLEY SETTI G
100.0 – PEAK: Peak value = 100.0
The peak feature stores the highest pressure reading the instrument has measured
since the last reset or power up. At power up PEAK is reset to the present pressure
reading. To manually reset the PEAK value, press the Ekey while in the PEAK
SUB MENU.
0.0 – VALY: Valley value = 0.0
The valley feature stores the lowest pressure reading the instrument has measured
since the last reset or power up. At power up VALY is reset to the present pressure
reading. To manually reset the VALY value, press the Ekey while in the VALY SUB
MENU.
ADVA CED ME U: AdU – ME U
With the gage reading pressure (home position), press and hold the ME U key
until the Security MENU is displayed. Press the qkey until the display shows the
AdU – ME U. Press the Ekey to show the advanced function SUB MENUS.
Auto ZERO: auto-zero
OTE: For accurate calibration, DO OT apply any pressure when
performing this function.
With the display reading Auto ZERO, release pressure to Zero then press the E
key; the display will blink. Press the Ekey again to complete the auto-zero.
CAL – SPA : full-scale calibration
With the display reading CAL – FS, apply full-scale pressure then press the Ekey;
the display will blink. Press the Ekey again to save the full-scale calibration or
press the ME U key to cancel the calibration.
MAI TE A CE
This model is not field-serviceable and should be returned if repair is needed (field
repair should not be attempted and may void warranty). Be sure to include a brief
description of the problem plus any relevant application notes. Contact customer
service to receive a return goods authorization number before shipping.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

DWYER I STRUME TS, I C. Phone: [phone] www.dwyer-inst.com
P.O. BOX 373 • MICHIGA CITY, I DIA A 46360, U.S.A. Fax: [phone] e-mail: [email protected]
©Copyright 2013 Dwyer nstruments, nc Printed in U.S.A. 1/14 FR# 19-443779-00 Rev.4
3-5/64
[78.27]
STANDARD MOUNTING HOLE
DIMENSION FOR DIGIMAG GAUGE
Ø4-9/16 [115.89]
1
[25.44]
2X30°
2xØ13/32 [10.32]
THRU HOLES FOR
PRESSURE PORTS
1-51/64 [45.72]
3-15/32 [88.12]
(3) SURFACE MOUNTING
HOLE LOCATIONS
13/32 [10.16]
Ø5/8 [15.88]
THRU HOLE FOR
CONDUIT CONNECTION
OUTSIDE DIAMETER
OF A-286 FLANGE
1-1/4 [31.75] (3) FLANGE MOUNTING
HOLE LOCATIONS
Ø5-17/32 [140.49]
BOLT CIRCLE
MOUNTING HOLE DIMENSION
FOR A-286 FLANGE
Ø5-1/8 [130.18]
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]
