Dyaco XTERRA 16804534000US User manual

OWNER’S MANUAL
MODEL NO.
16804534000US
Assembly
Operation
Trouble –Shooting
Parts
Warranty
CAUTION:
You must read and
understand this owner’s
manual before operating
unit.
Keep this manual for
future reference.
Serial number
_____________________
Write the serial number
in the space above for
reference. Serial number
can be found at the front
bottom section of the
rower.
Rower

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
1
Manufacture’s Limited Warranty
Dyaco Canada Inc. warrants all its home use rower parts for a period of time listed below, from the
date of retail sale, as determined by a sales receipt or in the absence of a sales receipt. Dyaco
Canada Inc.’s responsibilities include providing new or remanufactured parts, at Dyaco Canada Inc.’s
option, and technical support to our independent dealers and servicing organizations. In the absence
of a dealer or service organization, these warranties will be administered by Dyaco Canada Inc.
directly to a consumer. The warranty period applies to the following components:
Home Use Limited WARRANTY
Frame 1 Year
All Other Components 1 Year
Labour 1 Year
This warranty is not transferable and is extended only to the original owner.
The warranty shall not apply to exercise units which are (1) used for commercial or other income
producing purposes, or (2) subject to misuse, neglect, accident or unauthorized repair and alterations.
This warranty provided herein is lieu of all other express warranties, any implied warranties, including
any implied warranties of merchantability of fitness for particular purpose, are limited in duration to
the first 12 months from date of purchase. All other obligations or liabilities, including liability for
consequential damages are hereby excluded.
REPAIR PARTS AND SERVICE
All of the parts for the rower shown in figure can be ordered from Dyaco Canada Inc. 6050 DON
MURIE STREET, NIAGARA FALLS, ONTARIO L2G 0B3. When ordering parts, the parts will be sent
and billed at the current prices. Prices may be subject to change without notice. Check or money
order must accompany all orders. Standard hardware items are available at your local hardware
store.
To ensure prompt and correct handling of any errors, or to answer any questions, please call our Toll
Free number: 1-888-707-1880, or local number 1-905-353-8955 or fax [phone] or email
[e-mail]. You can visit us at www.dyaco.ca Office hours are from 8:30 AM to
5:00 PM Monday to Friday Eastern Standard Time.
Always include the following information when ordering parts
Model number
Name of each part
Part number of each part
TABLE OF CONTENTS
Manufacture’s Limited Warranty 1
SAFETY PRECAUTIONS 2
Important Safety Instructions 3
Product Registration 5
Assembly Instructions 8
Operation of Your Console 13
User’s Directions 15
General Maintenance and Troubleshooting 22
Exploded View Diagram 23
Parts List 24
Training Guidelines 27

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
2
SAFETY PRECAUTIONS
Thank you for purchasing our product. Even though we go to great efforts to ensure the quality of
each product we produce, occasional errors and /or omissions do occur. In any event should you find
this product to have either a defective or a missing part please contact us for a replacement.
This product has been designed for home use only. Product liability and guarantee conditions will not
be applicable to products being subjected to professional use or products being used in a gym center.
This exercise equipment was designed and built for optimum safety. However, certain precautions
apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual
before assembly and operation of this machine. Also, please note the following safety precautions:
1. Read the OWNER’S OPERATING MANUAL and all warnings posted on the unit and follow it
carefully before using your rower.
2. If dizziness, nausea, chest pains, or any other abnormal symptoms are experienced while using
this equipment, STOP the workout at once. CONSULT A PHYSICIAN IMMEDIATELY.
3. Review all warnings labels that affixed to the unit. Inspect your exercise equipment prior to
exercising to ensure that all nuts and bolts are fully tightened before each use. Functional and
visual inspection of the equipment shall be made after assembling your rower.
4. The rower must be regularly checked for signs of wear and damage. Any part found defective must
be replaced with a new part from the manufacturer.
5. Set up and operate the exercise unit on a solid level surface. It is recommended to use an
equipment mat to prevent the unit from moving while it is being used, which could possibly scratch
or damage the surface of your floor.
6. No changes must be made which might compromise the safety of the equipment.
7. It is recommended to have a minimum of 2’ safe clearance around the exercise equipment while in
use.
8. The pulse sensor is not a medical devise. Various factors, including the user’s movement may
affect the accuracy of the heart rate readings. The pulse sensor is intended only as an exercise aid
in determining heart rate trends in general.
9. Keep children and pets away from this equipment at all times while exercising.
10. Warm up 5 to 10 minutes before each workout and cool down 5 to 10 minutes afterward. This
allows your heart rate to gradually increase and decrease and will help prevent you from straining
muscles.
11. Never hold your breath while exercising. Breathing should remain at a normal rate in
conjunction with the level of exercise being performed.
12. Always wear suitable clothing and footwear while exercising. Do not wear loose fitting clothing
that could become entangled with the moving parts of your rower.
13. Care must be taken when lifting or moving the equipment, so as not to injure your back. Always
use proper lifting techniques.
14. User weight should not exceed 250lbs.
15. Tie all long hair back.
16. Remove all personal jewelry before exercising.
17. After eating, allow 1-2 hours before exercising as this will help to prevent muscle strain.
18. Injuries may result from incorrect or excessive training and using the equipment otherwise than
as directed or recommended by your doctor.

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
3
Important Safety Instructions
When using an electrical unit, basic precautions should always be followed, including the following: Read all
instructions before using this unit.
WARNING - To reduce the risk of burns, fire, electric shock, or injury to persons:
1.Always unplug this unit from the electrical outlet immediately after using and before cleaning.
WARNING - To reduce the risk of burns, fire electric shock, or injury to persons:
1. An unit should never be left unattended when plugged in. Unplug from outlet when not in use,
and before putting on or taking off parts.
2. Do not operate under blanket or pillow. Excessive heating can occur and cause fire, electric
shock, or injury to persons.
3. Close supervision is necessary when this unit is used by, on, or near children, invalids, or
disabled persons.
4. Use this unit only for its intended use as described in this manual. Do not use
attachments not recommended by the manufacturer.
5. Never operate this unit if it has a damaged cord or plug, if it is not working properly, if it has
been dropped or damaged, or dropped into water. Return the unit to a service center for
examination and repair.
6. Do not carry this unit by the supply cord or use the cord as a handle.
7. Keep the cord away from heated surfaces.
8. Never operate the unit with the air openings blocked. Keep the air openings free of lint, hair, and
the like.
9. Never drop or insert any object into any opening.
10. Do not use outdoors.
11. Do not operate where aerosol (spray) products are being use or where oxygen is being
administered.
12. Connect this unit to a properly grounded outlet only.
13. The unit is intended for household use.
14. The decal shown below has been placed on the rower. If the decal is missing or illegible,
please call our Customer Service Department toll-free at 1-888-707-1880 to order a
replacement decal. Apply the decal in the location shown.

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
4
WARNING: Before beginning any exercise program consult your physician. This is especially
important for individuals over the age of 35 or persons with pre-existing health problems. Read all
instructions before using any fitness equipment. We assume no responsibility from personal injury or
property damage sustained by or through the use of this product.
Fitness Equipment Safety Instructions
• To disconnect, turn all controls to the off position, then remove the plug from the outlet.
• Do not operate equipment on deeply padded, plush or shag carpet. Damage to
both carpet and equipment may result.
• Before beginning this or any exercise program, consult a physician. This is
especially important for persons over the age of 35 or persons with pre-existing
health conditions.
• Keep hands away from all moving parts.
• The pulse sensors are not medical devices. Various factors, including the user’s movement,
may affect the accuracy of heart rate readings. The pulse sensors are intended only as
exercise aids in determining heart rate trends in general.
• Do not attempt to use your equipment for any purpose other than for the purpose it is intended.
• Wear proper shoes. High heels, dress shoes, sandals or bare feet are not
suitable for use on your equipment. Quality athletic shoes are recommended
to avoid leg fatigue.
Failure to follow all guidelines may compromise the effectiveness of the exercise experience,
expose yourself (and possibly others) to injury, and reduce the longevity of the equipment.
SAVE THESE INSTRUCTIONS - THINK SAFETY!
CAUTION!! Please be careful when unpacking the carton.

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
5
PRODUCT REGISTRATION
Purchase Location
Purchase Date
Record Your Serial Number
Please record the Serial Number of this fitness product in the
space provided below.
Serial Number
Register Your Purchase
The self-addressed product registration card must be completed in full and returned to Dyaco
Canada Inc. You can also go to www.dyaco.ca to register online.
POWER
This product uses an external power supply. The power supply
must be plugged into
the power jack, located on the front of the unit near the
stabilizer tube. Next, plug the power supply into the appropriate
wall outlet. When not in use, it is recommended to unplug the
power supply from the wall outlet.
IMPORTANT: If the product has been exposed to cold
temperatures, allow the product sit in room temperature to
warm up before plugging in the power supply. Failure to do so
may result in damage to the display or electronic components.
IMPORTANT: Do not operate the product if the power supply,
its plug, or its cord has been damaged.

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
6
HOW ROWER WORKS

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
7
Assembly Pack Checklist
Hardware Step 1
Assembly Tools
#93. 3/8”x 2-1/2
Carriage Bolt
(2 pcs)
#94. 3/8” x 23 x 1.5T
Curved Washer
(2 pcs)
#95. 3/8” x 12.5T
Cap Nut
(2 pcs)
#97. Combination M5 Allen Wrench
& Phillips Head Screw Driver
#96. Wrench

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
8
1
ASSEMBLY INSTRUCTIONS
This manual is designed to help you easily assemble, adjust and use this machine. Please read this
manual carefully. For the sake of familiarizing yourself with the parts identified in
the instruction, first study the overview drawing.
Set all parts in a clear area on the floor and remove the packing material. Refer to the parts list for help
to identify the parts.
Note: If a part is not in the hardware kit, check to see if it has been preassembled. To avoid
damaging parts, do not use power tools for assembly.
FRONT STABILIZER & WHEEL COVERS
1. Mount the Front Stabilizer (6) onto the Main Frame (1) by using two Carriage Bolts
(93) going through Front Stabilizer (6) and Main Frame (1), two Curved Washers (94)
and Cap Nuts (95). Tighten up with 12/14mm open end wrench (96).
2. Install right and left Wheel Covers (54, 55) on twin tube ends of the Main Frame, be
aware to not mix up between left and right, and use Combination M5 Allen Wrench &
Phillips Head Screw Driver (97) to tighten with two Phillips Head Screws (45)

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
9
2REAR STABILIZER
1. Pull up the Main frame (1) as shown in figure 2 and install the Rear
Stabilizer (3) on the end of the Aluminum Track (2). Use Combination M5
Allen Wrench & Phillips Head Screw Driver (97) to tighten with four Button
Head Socket Bolts (92) and four Flat Washers (69).

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
10
3STABILIZER TUBES & WHEEL COVERS
1. Pull out the Locking Pin (60) from of the Aluminum Track (2)
and make sure the unit is
level then reinsert the Locking Pin (60) and lock well. Pull down the unit as shown in
the figure in circled box when reinserting the Locking Pin (60).
NOTE: It is very important to insert the locking pin (60) back as shown in the figure in circled
box when the unit is unfolded to prevent injury. The stabilizer plug(105) can be used for
leveling the machine.
105

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
11
4SEAT & PEDALS
1. Slide the Seat (30) onto the Aluminum Track (2). Be sure of the correct orientation of
the Seat (30).
2. Implement one of Axle Bushings (91) on the Pedal Stopper Shaft (58) going through
the Main frame (1) and cover with Lever Sleeve (59).
3. Pierce the Pedal Axle (8) through the Main frame (1) and put on two Axle Bushings
(73) and Pedals (72) on both ends (make sure pedals are correct for each side) and
use Combination M5 Allen Wrench & Phillips Head Screw Driver (97) to tighten the
shaft with two Flat Washers (69) and two Button Head Socket Bolts (92).

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
12
5COVERS
1. Cover the aluminum track with Plastic End Cover (29) by using Combination M5 Allen
Wrench & Phillips Head Screw Driver (97) to tighten with two Phillips Head Screws
(45).
2. Secure two Rubber Stoppers (82) at one end of the aluminum track with two Phillips
Head Screws (83).
3. Secure Protective Cap (84) at of the aluminum track with two Phillips Head Screws
(45).

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
13
Operation of Your Console
Console
Power Up
Power the rower on by plugging it into an appropriate wall outlet. When turned on, the display with
emit 1 beep sound as all LCD displays.
Note: When there is no signal or data input for 4 minutes, the machine will enter sleep mode. Using
the rower or key selection will wake-up the computer.
NEVER operate this rower without reading and completely understanding the results of any
operational change you request from the computer. Understand that changes in resistance do not
occur immediately. Set your desired level on the computer console and release the adjustment key.
The computer will obey the command gradually.

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
14
KEY FUNCTIONS
START
1. Pressing this key located under the ENTER or DOWN buttons , starts P0 exercise mode.
STOP/RESET
1. Pressing this key under operational mode, the console enters pause mode.
2. Pressing this key and holding at any time resets all function, the display clears and enters idle mode
automatically.
ENTER KEY
1. Press this key for data setting. If “Enter” key is not pressed during adjustment, the data will be also
accepted.
2. Press this key to confirm the setting or the data value.
UP/DOWN
1. Use this key to choose the program.
2. Use this key to increase or decrease for data setting
3. During workout, use this key for level adjustment, with increment of 1 for each press. When press
and hold for 2 seconds or more, it enters fast key mode.
PROGRAM DESCRIPTION
1. P0 Pressing START key in ready mode starts the unit. Adjust the resistance by using UP/DOWN
key and use STOP/RESET to pause. Press and hold START returns to ready mode.
2. P1~P6 In ready mode, use UP / DOWN key to choose the pre-set program and press ENTER key
for TIME/DIST/CAL/COUNT editing. Pressing START key finishes editing and starts the program.
During the workout, use UP/DOWN key to control the resistance, STOP to pause and press and
hold STOP to return to the ready mode.
P1: ROLLING P2: VALLEY P3: FAT BURN
P4: RAMP P5: MOUNTAIN P6: MOUNTAIN
In ready mode, use UP/DOWN key to choose USER PROGRAM, press ENTER key to edit TIME/
DIST/CAL/COUNT and 10 segments of resistance setting with setting levels 1~16. Press START key
when finish and the program starts. During the workout, use UP/DOWN key to control the resistance,
STOP to pause and press and hold STOP to return to the ready mode.

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
15
User’s Direction
Important Reminder
Make sure that there is minimum of 2 feet of clearance all around the rower.
1.While operating, especially when the machine has been extended, make sure the safety locking pin is
in position.
2. Stand behind the seat, slide the seat backwards and make sure the seat is in proper position.

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
16
3. Undo the Velcro strap on the pedal for adjustment. Place your foot on the pedal and make sure the
ankle is on the rear of the pedal then tighten the strap. (Choose the proper tightness depending on the
user)
4. Gently adjust the console for proper viewing angle.
(This depends on the height of the user)

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
17
5. When properly seated on the rower. Grasp the handle to start.

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
18
Releasing
Make sure that there is minimum of 2 feet of clearance all around the rower.
1.Pull out Locking Pin of the Aluminum Track and put in level.
2. Return the Locking Pin and lock well. Pull up the unit as shown in the figure in circled box when returning the
Locking Pin.
STEP1
STEP2

CUSTOMER SERVICE 1-888-707-1880 Dyaco Canada Inc.©2015
19
Folding
1. To fold it up, slide the seat to the front end and be careful not to pinch your fingers.
2. Pull out the safety locking pin and fold the rail.
When pulling out, please pull up the mainframe (as shown by the arrowhead)
3. Return the safety locking pin in its position (Attention: keep the rail in balance to prevent from tipping.
STEP1
STEP2
