Dymo LabelManager 120P User manual

2
Contents
About Your New Label Maker.............................................................. 5
Product Registration..........................................................................................5
Getting Started................................................................................. 5
Connecting the Power........................................................................................5
Inserting the Tape Cassette................................................................................6
Using the Label Maker for the First Time............................................. 6
Getting to Know the Label Maker....................................................... 7
Power ................................................................................................................7
LCD Display.........................................................................................................8
Settings .............................................................................................................8
CAPS Mode.........................................................................................................8
Backspace ..........................................................................................................8
Num Lock...........................................................................................................9
Navigation Keys .................................................................................................9
Cancel ................................................................................................................9
Formatting Your Label....................................................................... 9
Changing the Font Size ......................................................................................9
Adding Font Styles...........................................................................................10
Adding a Border or an Underline......................................................................10
Using Symbols and Special Characters ............................................... 11
Adding Symbols...............................................................................................11
Adding International Characters......................................................................12
Printing Options...............................................................................12
Previewing Your Label .....................................................................................12
Adjusting the Print Contrast ............................................................................13
Caring for Your Label Maker ..............................................................13
LM120P manual UK_WEU.indd 2 01-08-2007 10:13:21

3
Troubleshooting...............................................................................14
DYMO D1 Tape Cassettes....................................................................15
Documentation Feedback.................................................................16
Environmental Information..............................................................17
LM120P manual UK_WEU.indd 3 01-08-2007 10:13:21

4
KO
lecnaC
1Tape cutter button 8Border 15 On/Off
2Print 9Space bar 16 Symbols
3OK 10 Vertical 17 Navigation
4Size 11 CAPS 18 Underline
5Num lock 12 Bold 19 LCD display
6Backspace 13 Cancel 20 Preview
7Accented character 14 Settings 21 Tape exit
1
2
3
4
5
6
7
8
910
11
12
13
14
15
16 18 2019
Figure 1 LabelManager 120P Electronic Label Maker
17 21
LM120P manual UK_WEU.indd 4 01-08-2007 10:13:22

5
About Your New Label Maker
With the DYMO LabelManager 120P electronic label maker, you can create a wide
variety of high-quality, self-adhesive labels. You can choose to print your labels
in several different font sizes and styles. The label maker uses DYMO D1 tape
cassettes in widths of 9 mm or 12 mm. These tape cassettes are available in a
wide range of colors.
Visit www.dymo.com for information on obtaining labels and accessories for
your label maker.
Product Registration
Visit www.dymo.com/registration to register your label maker online.
Getting Started
Follow the instructions in this section to print your first label.
Connecting the Power
The label maker is powered by six high-
capacity AA alkaline batteries. To save
power, the label maker will automatically
turn off after two minutes of inactivity.
To insert the batteries
Slide the battery compartment cover1.
away from the label maker. See Figure 2.
Insert the batteries following the polarity markings (+ and –).2.
Replace the cover.3.
xRemove the batteries if the label maker will not be used for a long
period of time.
Figure 2
LM120P manual UK_WEU.indd 5 01-08-2007 10:13:22

6
Inserting the Tape Cassette
Your label maker comes with one tape cassette.
You can purchase additional tape cassettes from
your local office supply retailer.
To insert the tape cassette
Lift the tape cassette cover to open the1.
tape compartment. See Figure 3.
xBefore using the label maker for
the first time, remove the protective
cardboard insert from the tape exit
slot. See Figure 4.
Insert the cassette with the label2.
facing up and the tape positioned
between the guideposts.
Press firmly until cassette clicks3.
into place. See Figure 5.
Close the tape cassette cover.4.
Using the Label Maker for the First Time
The first time you turn on the power, you are
asked to select the language and units of
measure. These selections will remain set until
you change them, or until the label maker is
reset. You can change these selections using
the Settings key.
Click !!
Figure 5
Click!
Click!
Figure 4
Remove
cardboard insert
Figure 3
Guideposts
LM120P manual UK_WEU.indd 6 01-08-2007 10:13:22

7
To set up the label maker
Press1. {to turn on the power.
Select the language and press2. }.
By default, the language is set to English. The language option you choose
determines the character set that is available.
Select inches or mm and press3. }.
Select the width of the tape cassette currently inserted in the label maker.4.
You are now ready to print your first label.
To print a label
Enter text to create a simple label.1.
Press2. G.
Press the cutter button to cut the label.3.
Congratulations! You printed your first label. Continue reading to learn more
about the options available for creating labels.
Getting to Know the Label Maker
Become familiar with the location of the feature and function keys on your label
maker. Refer to Figure 1. The following sections describe each feature in detail.
Power
The { button turns the power on and off. After two minutes of no activity,
the power is switched off automatically. The last label created is remembered
and displayed when the power is turned back on. The previously selected style
settings are also restored.
LM120P manual UK_WEU.indd 7 01-08-2007 10:13:23

8
LCD Display
You can enter up to 99 characters and spaces. The display shows about thirteen
characters at a time. The number of characters displayed will vary due to
proportional spacing.
With DYMO’s exclusive graphical display, most of the formatting you add is
visible instantly. For example, the border added to the text below is clearly
displayed.
Feature indicators along the top of the LCD display appear black to let you know
when a feature is selected.
Settings
The key displays the Label Width, Language, Units, and Contrast
submenus. These features are described later in this User Guide.
CAPS Mode
The key toggles capitalization on or off. When CAPS mode is turned on, the
CAPS mode indicator is shown on the display and all letters that you enter will
be capitalized. The default setting is CAPS mode on. When CAPS mode is off, all
letters appear in lower case.
Backspace
The 0key removes the character to the left of the cursor.
LM120P manual UK_WEU.indd 8 01-08-2007 10:13:23

9
Num Lock
The key provides access to the numbers located on some of the alphabetic
keys. When Num Lock mode is turned on, the Num Lock indicator is shown on the
display and the numbers 0 through 9 appear when you press the corresponding
letter keys. Num Lock is turned off by default.
Navigation Keys
You can review and edit your label using the left and right arrow keys. You can
also navigate through menu selections using the up and down arrow keys, and
then press }to make a selection.
Cancel
The
lecnaC
key allows you to exit from a menu without making a selection or to cancel
an action .
Formatting Your Label
You can choose from a number of formatting options to enhance the appearance of
your labels.
Changing the Font Size
Two font sizes are available for your labels: Normal and Large. The font size
you select applies to all characters on a label.
To set the font size
Press .
The font size key toggles from one size to the other. The font size indicator
displays the new size as you change.
LM120P manual UK_WEU.indd 9 01-08-2007 10:13:23

10
Adding Font Styles
You can choose from three different font styles:
AaBbCc Normal
AaBbCc Bold
aVertical
The style you select applies to all characters. Styles can be used with
alphanumeric characters and some symbols.
The font style keys toggle the style on and off.
To add bold text
Press for bold text.
To print a vertical label
Press for vertical text.
Adding a Border or an Underline
You can highlight your text by using a border or underline.
›Border
≥Underline
A label can be underlined or enclosed in a border, but not both together. The
border or underline keys toggle on and off. Border or underline styles apply to
an entire label.
To add a border
Press .
To add an underline
Press .
LM120P manual UK_WEU.indd 10 01-08-2007 10:13:24

11
Using Symbols and Special Characters
Symbols, punctuation, and other special characters can be added to your labels.
Adding Symbols
The label maker supports the extended symbol set shown below.
Position in row
To insert a symbol
Press1. .
Use the left and right arrow keys to move to your desired symbol.2.
The left and right arrows move horizontally along a row of symbols. The up
and down arrow keys scroll vertically through the rows of symbol types.
When you locate the symbol, press3. }to add the symbol to your label.
LM120P manual UK_WEU.indd 11 01-08-2007 10:13:24

12
Adding International Characters
The label maker supports the extended Latin character set using RACE
technology.
After pressing the key, repeatedly pressing a letter scrolls through the
available variations of that letter.
For example, if French is selected as the language and you press the letter a,
you will see a à â æ and so on through all the variations available. The character
variations and the order in which the variations appear depend on the language
you use.
To add accented characters
Press1. .
The accented character indicator is shown on the display.
Press an alpha character.2.
The accent variations are displayed.
When the desired accented character appears, wait a few seconds for the3.
cursor to move beyond the character to continue entering text.
Printing Options
You can preview your label and adjust the printing contrast.
Previewing Your Label
You can preview your label prior to printing.
To preview your label
• Press5.
The label length is displayed, then the text of the label scrolls across the display.
LM120P manual UK_WEU.indd 12 01-08-2007 10:13:24

13
Adjusting the Print Contrast
You can adjust the print contrast to fine tune the print quality of your label.
To set the contrast
Press1. .
Select2. Contrast and press }.
Use the arrow keys to select a contrast setting between3. 1(less contrast)
and 5(more contrast), and press }.
Caring for Your Label Maker
Your label maker is designed to give you long and trouble-free service, while
requiring very little maintenance. Clean your label maker from time to time to
keep it working properly. Clean the cutter blade each time you replace the tape
cassette.
To clean the cutter blade
Remove the tape cassette.1.
Press and hold down the cutter lever to2.
expose the cutter blade. See Figure 6.
Use a cotton ball and alcohol to clean both3.
sides of the blade.
èThe cutter blade is extremely sharp. Use
caution when cleaning.
To clean the print head
Remove the tape cassette.1.
Remove the cleaning tool from inside the tape compartment cover.2.
Gently wipe the padded side of the tool across the print head. See Figure 6.3.
Print head Cutter button
Figure 6
LM120P manual UK_WEU.indd 13 01-08-2007 10:13:25

14
Troubleshooting
Review the following possible solutions if you encounter a problem while using
your label maker.
Problem/Error Message Solution
No display Ensure the label maker is turned on.•
Replace discharged batteries.•
Poor Print Quality Replace batteries.•
Set Contrast to higher level.•
See Adjusting the Print Contrast.
Ensure tape cassette is installed properly.•
Clean the print head.•
Replace the tape cassette.•
Poor Cutter Performance Clean the cutter blade.
See Caring for Your Label Maker.
Printing . . . No action required. Message disappears when
printing is finished.
Too many characters
Exceeded maximum number of characters
Delete some or all of the text.
Batteries almost discharged
Replace batteries.
Tape Jam
Motor is stalled due to label jam
Remove jammed label; replace tape cassette.•
Clean cutter blade.•
If you still need assistance, contact DYMO Customer Support. See Contacting
Customer Support at the back of this User Guide to locate the contact number
for your country.
LM120P manual UK_WEU.indd 14 01-08-2007 10:13:25

15
DYMO D1 Tape Cassettes
Width:
Length:
9 mm
7 m
12 mm
7 m
Black/Clear
S0720670
40910 S0720500 45010
Blue/Clear ___ S0720510
45011
Red/Clear ___ S0720520
45012
Black/White
S0720680
40913 S0720530 45013
Blue/White
S0720690
40914 S0720540 45014
Red/White
S0720700
40915 S0720550 45015
Black/Blue
S0720710
40916 S0720560 45016
Black/Red
S0720720
40917 S0720570 45017
Black/Yellow
S0720730
40918 S0720580 45018
Black/Green
S0720740
40919 S0720590 45019
White/Clear ___ S0720600
45020
White/Black ___ S0720610
45021
Width:
Length:
9 mm
3,5 m
12 mm
3,5 m
Flexible labels for curved surfaces ___ S0718040
16957
Width:
Length:
9 mm
5,5 m
12 mm
5,5 m
Permanent labels ___ S0718060
16959
LM120P manual UK_WEU.indd 15 01-08-2007 10:13:25

16
Documentation Feedback
We are constantly working to produce the highest quality documentation for our
products. We welcome your feedback.
Send us your comments or suggestions about our user guides. Please include the
following information with your feedback:
Product name, version number, and page number•
Brief description of content (instructions that are inaccurate or unclear, areas•
where more detail is needed, and so on)
We also welcome your suggestions about additional topics you would like to see
covered in the documentation.
Send email messages to: [e-mail].
Please keep in mind that this email address is only for documentation feedback.
If you have a technical question, please contact Customer Support.
LM120P manual UK_WEU.indd 16 01-08-2007 10:13:25

17
Environmental Information
The equipment that you have bought requires the extraction and use of natural
resources for its production. It may contain substances that are hazardous to
health and the environment.
In order to avoid the dissemination of those substances in our environment,
and to diminish the pressure on natural resources, we encourage you to use the
appropriate take-back systems. These systems will reuse or recycle most of the
materials of your end-of-life equipment in an environmentally sound way.
The crossed-bin symbol marked on your device indicates you should use these
systems.
If you need more information on the collection, reuse, and recycling of this
product, please contact your local or regional waste administration.
You can also contact us for more information on the environmental performance
of our products.
This product is CE marked in accordance with the EMC directive and the low voltage directive and is designed to
conform with the following international standards:
US FCC Class B Compatibility
Safety - UL, CUL, TUV, CE, T-Mark, SAA, BABT, C-Tick
EMC - EMI Compatibility
EN 55022; EN 61000 (+ addendums)
RoHS 2002/95/EC
LM120P manual UK_WEU.indd 17 01-08-2007 10:13:25

LM120P manual UK_WEU.indd 18 01-08-2007 10:13:25

Contacting customer support
Country Telephone Support Fax Support
UNITED KINGDOM 020 73 41 55 29 + 31 20 581 93 80
IRELAND 014 118 934 + 31 20 581 93 80
FRANCE 01 69 32 49 32 + 31 20 581 93 80
NEDERLAND 020 581 93 86 020 581 93 80
BELGIË  BELGIQUE 02 713 38 08 + 31 20 581 93 80
DEUTSCHLAND 069 66 56 85 29 + 31 20 581 93 80
ÖSTERREICH 01 599 14 20 12 + 31 20 581 93 80
SCHWEIZ  SUISSE 044 342 04 66 + 31 20 581 93 80
SVERIGE 08 632 00 57 + 31 20 581 93 80
NORGE 22 97 17 10 + 31 20 581 93 80
DANMARK 35 25 65 08 + 31 20 581 93 80
SUOMI 09 229 07 04 + 31 20 581 93 80
ITALIA 02 45 28 13 08 + 31 20 581 93 80
ESPAÑA 91 662 31 49 + 31 20 581 93 80
PORTUGAL 21 120 61 64 + 31 20 581 93 80
POLSKA 022 349 15 02 + 31 20 581 93 80
MAGYAR 01 777 49 31 + 31 20 581 93 80
ČESKÁ REPUBLIKA 239 000 448 + 31 20 581 93 80
SLOVENSKÁ REPUBLIKA + 420 603 216 958 + 31 20 581 93 80
AUSTRALIA 1800 633 868 1800 727 537
NEW ZEALAND 0800 848 111 09 257 1080
HONG KONG 852 2690 4003 852 2690 4005
INTERNATIONAL + 31 20 50 40 566 + 31 20 581 93 80
LM120P manual UK_WEU.indd 19 01-08-2007 10:13:25

20
©2007 DYMO
A Newell Rubbermaid company
DYMO bvba
Industriepark-Noord 30
9100 Sint-Niklaas
Belgium
www.dymo.com
931482
LM120P manual UK_WEU.indd 20 01-08-2007 10:13:25
