Dyna-Glo DGA550SSN User manual

Serial Number Purchase Date
ATTACH YOUR RECEIPT HERE
Español p. 59
Français p. 30
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-877-447-4768, 8:30 a.m. – 4:30 p.m., CST, Monday – Friday,
or e-mail us at [email protected].
1
5-BURNER NATURAL
GAS BARBECUE
Model #DGA550SSN/
DGA550SSN-D
70-10-055 Rev 02/2014
ANS Z21.58b-2012
CSA 1.6b-2012
Outdoor Cooking
Gas Appliance

2
TABLE OF CONTENTS
Package Contents............................................................................................................... 3
Hardware Contents.............................................................................................................. 5
Safety Information ............................................................................................................... 5
Preparation.......................................................................................................................... 7
Assembly Instructions.......................................................................................................... 8
Operating Instructions ....................................................................................................... 19
Care and Maintenance...................................................................................................... 23
Troubleshooting................................................................................................................. 26
Warranty............................................................................................................................ 28
Replacement Parts List ..................................................................................................... 29
Assembler/Installer: This instruction manual contains important information necessary for the proper
assembly and safe use of this appliance. Read and follow all warnings and instructions before
assembling and using this appliance. Leave these instructions with the consumer.
Consumer/User: Follow all warnings and instructions when using this appliance.
Keep these instructions for future reference.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
 2.Extinguishopename.
3. Open lid.
4. If odor continues, keep away from
the appliance and immediately
callyourgassupplieroryourre
department.
5. Failure to follow these instructions
couldresultinre,explosion,or
burn hazard which could cause
property damage, personal injury
or death.
WARNING:
1. DO NOT store or use gasoline or other ammable
liquids or vapors in the vicinity of this or any other
appliance.
2. An LP (liquid propane) cylinder not connected for
use shall not be stored in the vicinity of this or any
other appliance.
3. This grill is for outdoor use only and shall not be
used in a building, garage, under overhangs or any
other enclosed area.
4. DO NOT leave a lit grill unattended. Keep children
and pets away from the grill at all times.

33
P
VU
O
G
M
N
F
E
D
T
S
W
Q
A1
Z
R
J
K
HI
B
X
L
Y
A
C
PACKAGE CONTENTS

4
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Bottom Shelf 1
BLocking Caster 2
C Caster 2
D Cart Left Side Panel 1
E Cart Right Side Panel 1
F Cart Rear Panel 1
G Upper Front Door Brace 1
HLeft Door Assembly 1
IRight Door Assembly 1
J Door Handle 2
KDoor Handle Sleeve 4
L AA Battery 1
M Main Burner Control Knob
(Lg) 5
N Side/Rear Burner Control
Knob (Sm) 2
PART DESCRIPTION QUANTITY
O Grill Body 1
P Left Shelf 1
Q Side Burner Cooking
Grate 1
R Right Shelf 1
S Grease Pan 1
T Grease Cup 1
U Lid Handle 1
V Lid Handle Bezel 2
WWarming Rack 1
XHeat Tent 5
YCooking Grate 3
ZNatural Gas Hose Holder 2
A1 Quick Disconnect Coupling 1

5
M6x12 Screw
Qty. 29 M4x10 Screw
Qty. 14
NOTE: Four screws
preassembled with
bottom shelf.
M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE: Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE: Preassembled
with lid handle.
AA DD EE
GG HH
BB CC
M6x16 Screw
Qty. 10
FF
Please read and understand this entire manual before attempting to assemble, operate or install the
product. If you have any questions regarding the product, please call customer service at:
1-877-447-4768, 8:30 a.m. – 4:30 p.m., CST, Monday – Friday.
SAFETY INFORMATION
HARDWARE CONTENTS (shown actual size)
DO NOT use in an explosive atmosphere. Keep grill area clear and free from combustible materials,
gasoline and other ammable vapors and liquids.
DANGER
CALIFORNIA PROPOSITION 65
• Fuels used in gas, oil red, wood burning, and charcoal burning appliances and the products of
combustion of such fuels contain chemicals known to the state of California to cause cancer, birth
defects or other reproductive harm. This product contains chemicals, including lead and lead
compounds, known to the state of California to cause cancer, birth defects or other reproductive harm.
Wash hands after handling.

6
SAFETY INFORMATION
CAUTION
• NEVER use charcoal or lighter uid with the grill.
• DO NOT use gasoline, kerosene or alcohol for lighting.
• This grill is not intended to be used in or installed on recreational vehicles and/or boats.
• ALWAYS open grill lid slowly and carefully as heat and steam trapped within the grill can burn you
severely.
• NEVER attempt to operate this grill using propane.
• ALWAYS employ a qualied service agency to install all necessary natural gas supply plumbing,
manual shutoff valve, and quick-connect ttings.
• DO NOT store or use gasoline or other ammable liquids or vapors in the vicinity of this or any other
appliance.
• An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.
• This grill is for use with natural gas only.
• NEVER attempt to attach this grill to the self-contained propane system of a boat, camper trailer,
motor home or house.
• DO NOT attempt to move the grill while it is lit or when it is hot. The casters should be locked when
not moving the grill.
• DO NOT use the grill unless it is completely assembled and all parts are securely fastened and
tightened.
• Keep all combustible items and surfaces at least 36 inches (91.44 cm) away from the grill at all
times.
DO NOT place the grill under overhead
combustible construction or awnings.
Minimum clearance from sides and back
of unit to combustible construction is 36
inches (914.4mm).
NOTE: The installation must conform
with local codes or, in the absence of
local codes, with either the National
Fuel Gas Code, ANSI Z223.1/NFPA54,
Natural Gas and Propane Installation
Code, CSA B149.1, or Propane Storage
and Handling Code, B149.2.
WARNING
36 inches
(91.4 cm)
36 inches
(91.4 cm)

7
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to
assemble the product.
Estimated Assembly Time: 50 minutes with two people
Tools Required for Assembly and leak testing (not included): Phillips screwdriver, spray bottle.
SAFETY INFORMATION
• DO NOT touch metal parts of grill until it has completely cooled (about 45 minutes) to avoid burns,
unless you are wearing protective gear (pot holders, gloves, BBQ mittens, etc…).
• DO NOT alter this grill in any manner.
• Clean and inspect the hose before each use. If there is evidence of abrasion, wear, cuts, or leaks,
the hose must be replaced prior to operating the appliance. The replacement hose assembly will be
that which is specied by the manufacturer, listed in the repair parts list in this manual.
• Move gas hoses as far away as possible from hot surfaces and dripping hot grease.
• Keep the grill’s valve compartment, burners and circulating air passages clean. Inspect the grill
before each use. Do not obstruct the ow of gas or ventilation air.
• The use of alcohol, prescription or non-prescription drugs may impair the operator’s ability to properly
assemble or safely operate the grill.
• DO NOT leave a lit grill unattended. Keep children and pets away from the grill at all times.
• DO NOT place this grill on any type of tabletop surface. The grill should be placed on a at and level
surface.
• DO NOT use the grill in high winds.

8
ASSEMBLY INSTRUCTIONS
3. Flip the bottom shelf (A) over. Partially insert four
M6x12 screws (AA) into the bottom shelf (A).
1. Attach two locking casters (B) to the rear of
the bottom shelf (A) and secure using four plain
washers (BB), four spring washers (CC), and
four M6x12 screws (AA) for each locking
caster (B).
2. Attach two casters (C) to the front of the
bottom shelf (A) and secure using four plain
washers (BB), four spring washers (CC), and
four M6x12 screws (AA) for each caster (C).
AA
A
3
1
1
2
CC
C
AA
BB
A
2
1
1
2
CC
B
AA
BB
A
1
Hardware Used
Hardware Used
M6x12 Screw
M6x12 Screw
Plain washer
Plain washer
Spring washer
Spring washer
x 8
x 8
x 8
x 8
x 8
x 8
AA
AA
BB
BB
CC
CC
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD
Hardware Used
M6x12 Screw x 4
AA
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD

9
ASSEMBLY INSTRUCTIONS
6. Attach the cart rear panel (F) by sliding the keyholes
in the cart rear panel (F) over the inserted screws
(AA). Slide the cart rear panel (F) down to meet
bottom shelf (A). Secure the cart rear panel (F) to
the bottom shelf (A) with three M6x12 screws (AA).
Tighten all screws, including the two screws in cart
side panels (D & E).
5. Partially insert two M6x12 screws (AA) into the
cart left and right side panels (D & E).
4. Attach the cart left and right side panels (D & E)
by placing the panel keyholes over the screw
heads (AA) on the bottom shelf (A). Slide the
cart side panels (D & E) so that the screw head
is over the smaller part of the keyhole. Thread
the screws (AA) down snug but DO NOT tighten
as some slack will be necessary in following
assembly steps.
222
1
1
3
F
AA
A
D
E
6
1
1
2
AA
D
E
5
11
11
2
D
E
AA
4
A
Hardware Used
M6x12 Screw x 2
AA
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD
Hardware Used
M6x12 Screw x 3
AA
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD

10
ASSEMBLY INSTRUCTIONS
Hardware Used
M6x12 Screw x 4
AA
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD
1
1
2
DD
H
D
9
1
1
2
H
J
K
GG
8
2
2
11
3
AA
G
E
D
7
7. Partially insert two M6x12 screws (AA) into the
cart left and right side panels (D & E). Attach
upper front door brace (G) to the four M6x12
screws (AA). Tighten the screws.
8. Remove preassembled M4x10 screws (GG) from
the door handles (J). Insert two door handle
sleeves (K) into the holes located on the back
of the left door assembly (H). Insert two M4x10
screws (GG) into the door handle sleeves (K)
and into the threaded holes in the door handle
(J). Tighten the screws. Repeat with right door
assembly (I).
9. Attach the left door assembly (H) to the cart
body by aligning the holes in the hinge of the left
door assembly (H) with the holes in the cart left
side panel (D). Secure using four M4x10 screws
(DD). Tighten all screws. Repeat with right door
assembly (I).
Hardware Used
Hardware Used
M4x10 Screw
M4x10 Screw
x 4
x 8
GG
DD
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD

11
ASSEMBLY INSTRUCTIONS
O
D
E
F
12
O
M
N
11
11
2
U
V
HH O
10
10. Remove preassembled M6x25 screws (HH)
from the lid handle (U). Attach the lid handle (U)
by inserting two M6x25 screws (HH) from inside
the lid of the grill body (O), through the lid handle
bezels (V), into the lid handle (U) and tightening
securely.
11. Slip main burner control knobs (M) and side/
rear burner control knobs (N) onto the valve
stems located on the front control panel of the
grill body (O).
12. Lock the back two locking casters (B) to ensure
the cart does not move. Using two people,
carefully place the grill body (O) over the
mounting tabs on the cart side panels (D & E)
and onto the cart. Adjust the grill body (O) so that
the holes in the grill body (O) are aligned with the
holes in the tabs of the cart side panels (D & E).
NOTE: Make sure the natural gas hose is inside
the cart and exits through the opening hole in the
cart rear panel (F).
Hardware Used
M6x25 Screw x 2
HH
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD

12
ASSEMBLY INSTRUCTIONS
Hardware Used
M6x20 Screw x 4
EE
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD
1
1
2
FF
O
15
1
1
2
DD
Z
14
1
1
1
1
2
EE
O
13
14. Install the natural gas hose holders (Z) by
removing four M4x10 screws (DD) from the
predrilled holes in the bottom shelf (A), aligning
the natural gas hose holders (Z) with the
predrilled holes and over the natural gas hose,
then securing with the screws (DD).
15. Partially insert two M6x16 screws (FF) into the
left side of grill body (O). DO NOT fully tighten
screws (leave approximately 5 mm).
13. Secure the grill body (O) using two M6x20
screws (EE) on each side.
Hardware Used
Hardware Used
M4x10 Screw
M6x16 Screw
x 4
x 2
DD
FF
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD

13
ASSEMBLY INSTRUCTIONS
18
2
2
1
3
DD
17
1
1
2
P
FF
O
16
16. Align the key holes in the left shelf (P) with the
two M6x16 screws (FF) just installed in the
grill body (O) and tighten screws. Insert three
M6x16 screws (FF) in the remaining holes in the
supports and tighten.
17. Align the side burner tubing with the side burner
orice and insert into the side burner orice.
Use two M4x10 screws (DD) to secure the side
burner orice and side burner orice support to
the side burner support.
18.Attach the ignition wiring to the electrode.
Hardware Used
M6x16 Screw x 3
FF
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD
Hardware Used
M4x10 Screw x 2
DD
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD

14
ASSEMBLY INSTRUCTIONS
1
2
FF
O
R
21
11
2
FF
O
20
Q
19
19. Align the key holes on the burner tray with the
side burner cooking grate (Q) and set in place.
20. Partially insert two M6x16 screws (FF) into the
right side of grill body (O). DO NOT fully tighten
screws (leave approximately 5 mm).
21. Align the key holes in the right shelf (R) with the
two screws (FF) just installed in the grill body (O)
and tighten screws. Insert three M6x16 screws
(FF) in the remaining holes in the supports and
tighten.
Hardware Used
Hardware Used
M6x16 Screw
M6x16 Screw
x 2
x 3
FF
FF
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD
M6x12 Screw
Qty. 40 M4x10 Screw
Qty. 12 M6x20 Screw
Qty. 4
M4x10 Screw
Qty. 4
NOTE:
Preassembled
with door handle.
Plain Washer
Qty. 16 Spring Washer
Qty. 16
M6x25 Screw
Qty. 2
NOTE:
Preassembled
with lid handle.
AA BB CC
FF
EE
GG HH
M6x16 Screw
Qty. 10
DD

15
ASSEMBLY INSTRUCTIONS
1
2
X
22
Y
23
Burner
Valve
Orifice
WARNING
22. Open the lid of the grill body (O) and place
the ve heat tents (X) on the brackets directly
above the burners.
23. Place three cooking grates (Y) on the grill body
braces and grill rear panel.
WARNING: IT IS VERY IMPORTANT TO
CHECK AND ENSURE THAT EACH AND
EVERY BURNER IS FULLY ENGAGED
WITH THEADJACENT VALVE ORIFICE
BEFORE COMPLETING STEP 22.
FAILURE TO DO SO MAY RESULT
IN FIRE OR EXPLOSION, POSSIBLY
CAUSING SERIOUS INJURY OR DEATH.
REFER TO MAINTENANCE SECTION
INSTRUCTIONS TO PROPERLY CHECK
THE ENGAGEMENT.

16
ASSEMBLY INSTRUCTIONS
3
2
4
1
L
26
1
2
1
ST
O
25
W
24
24. Insert the warming rack (W) into the two holes
located on the back edge of the grill body (O).
25. Insert the grease pan (S) into position by sliding it
in the grill body (O) from the rear along the rails.
Insert the grease cup (T) into position by sliding
it onto the rails located on the bottom side of the
grease pan (S).
26. Remove the igniter cap by turning it counter-
clockwise. Insert theAA battery (L) into the igniter
body with positive (+) end facing out. Replace the
igniter cap.

17
OPERATING INSTRUCTIONS
Connecting the Grill to the Natural Gas Supply
• The quick disconnect coupling (A1) and supply gas line must be installed by a qualied service
agency. The supply connection must be made in accordance with local codes or, in the absence
of local codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, in the USA, or the
Natural Gas and Propane Installation Code, CSA B149.1, in Canada.
• A properly sized manual shutoff valve must be installed between the grill and the gas supply piping.
• The grill and its individual shutoff valve must be disconnected from the gas supply piping system
during any pressure testing of that system at test pressures in excess of 0.5 PSI (3.5 kPa).
• The grill must be isolated from the gas supply piping system by closing its individual manual shutoff
valve during any pressure testing of the gas supply piping system at test pressures equal to or less
than 0.5 PSI (3.5 kPa).
• Always connect the exible gas supply hose to the gas supply before opening the manual shutoff
valve.
To Connect:
1. Ensure that the manual gas shutoff valve is closed.
2. Remove the protective rubber caps from the plug and
sleeve ends of the quick disconnect ttings. Check that
the ttings are clean.
3. Retract the sleeve on the coupling as illustrated.
4. Insert the plug and release the sleeve as illustrated.
5. Push the plug into the sleeve until the sleeve snaps
forward to lock the plug in the coupling.
6. Open the manual gas shutoff valve.
To Disconnect:
1. Close the manual shutoff valve.
2. Push the sleeve back and gently pull out the plug.
3. Replace the protective rubber caps on the plug and sleeve ends of the quick disconnect couplings.
In the connection process, make sure:
• The gas supply hose does not come in contact or remain in contact with the rebox.
WARNING
A1

18
OPERATING INSTRUCTIONS
Checking for Leaks
After all connections are made, check all connections and ttings on the NG hose and quick
connector for leaks with a water and soap solution.
To prevent re or explosion while testing for a leak:
• ALWAYS perform leak test prior to lighting the grill.
• DO NOT smoke while testing for a leak.
• ALWAYS perform leak tests outdoors in a well-ventilated area.
• DO NOT use any source of ame while testing for leaks.
• DO NOT use the grill until any and all leaks are corrected.
• If you are unable to correct a leak, close the manual shutoff valve and call a gas appliance service
dealer.
Perform Leak Test
• Prepare leak test solution by combining 1 part liquid dish soap with 3 parts water. Total solution
required is approximately 2 - 3 ounces (70 - 90 ml). Put leak test solution in a spray bottle.
• Ensure all control knobs are in the OOFF position.
• Connect the gas hose to the gas supply.
• Open the manual shutoff valve.
• Spray leak test solution on all gas carrying connections and ttings. Presence of bubbles at areas of
applied test solution indicates a gas leak. If leaks are detected or you smell or hear gas, shut off the
gas supply valve immediately and repair or replace the defective part. Do not use the grill until all
leaks are corrected.
Use only the hose assembly provided. If a replacement is necessary, please call our customer service
center. DO NOT use replacement parts that are not intended for this grill.
CAUTION
ALL INSTRUCTIONS AND SAFEGUARDS ON THIS PAGE MUST BE FOLLOWED TO PREVENT FIRE,
DAMAGE AND/OR INJURY.
WARNING

19
OPERATING INSTRUCTIONS
Lighting Instructions (for all burners, including side burner and rotisserie burner)
Before First Use:
Remove all hangings or plastic straps, if present. Before you cook on your new gas grill, it is important
to clean your grill with heat. To do this, operate the grill for approximately 15 minutes with the lid
closed and the control knob in the highest position. This will clean the internal parts by burning off any
residue and odor from the manufacturing process.
Important: If your grill is equipped with a rotisserie burner, only that burner should be used for
cooking when the rotisserie is mounted and in operation. The main burners on the grill must be
turned OOFF when the rotisserie burner is in use.
Important: DO NOT use the rotisserie burner and the main burner at the same time while using the
rotisserie. DO NOT use side burners and the rotisserie simultaneously.
Read instructions before lighting.
1. Check that the control knobs are in the OOFF position.
2. Open lid during lighting.
3. Open manual shutoff valve fully.
4. Push igniter down 3 to 4 seconds while turning the desired control knob to the high position. The
burner should ignite.
NOTE: When lighting the rotisserie burner, the control knob must be pushed in and turned to the
high position. Push igniter down 3 to 4 seconds while continuing to depress the rotisserie burner
control knob in the high position. Once the rotisserie burner has ignited, continue to depress the
control knob for an additional 30 seconds. The rotisserie burner should then stay lit.
If ignition of any burner does not take place within 5 seconds, immediately turn the control knob to
the OOFF position. Wait 5 minutes and repeat step 4 above or refer to match lighting instructions in
manual.
5. Repeat Step 4 above to ignite all other burners.
DO NOT lean over grill when lighting. Read instructions before lighting.
WARNING
Iftheameextinguishesaccidentallyduringignitionoroperation,immediatelyTURNOFFthe
manual shutoff valve and then TURN OFF the control knobs.
CAUTION

20
OPERATING INSTRUCTIONS
Lighting the Grill with a Match
1. Open the lid.
2. Insert a match in the end of the match holder that is
installed on the inside of the cabinet door.
3. Light the match.
4. Immediately place the lit match through the 20 mm
(0.75 in.) hole on the side of the grill body, nearest
the left burner. Make sure the lit match is close to the
burner ports.
5. Press in the control knob that operates the burner and
rotate counter-clockwise to High position and
burner should light immediately.
6. The other main control can now be turned on the High
position by sequence and will light via crossover port.
7. Adjust burners to desired cooking settings.
NOTE: When lighting the rotisserie burner, the control
knob must be pushed in and turned to the high position,
continuing to depress the rotisserie burner control knob in
the high position. Once the rotisserie burner has ignited,
continue to depress the control knob for an additional 30
seconds. The rotisserie burner should then stay lit.
Shutdown Instructions
1. Turn control knobs clockwise to the O"OFF"
position.
2. Close manual shutoff valve.
3. Close lid.
Turn off manual shutoff valve when appliance is not
in use.
LIGHTING SIDE BURNER
LIGHTING ROTISSERIE BURNER
LIGHTING MAIN BURNER
Make sure all burner controls are off, except for the
burner being lit and the burners that have been lit.
WARNING
