DYNACO st416 Quick start guide

COMPONENT VALUES PART#
All resistors are 1/4 watt, 5% R229 750 ohms PART# R422 10,000 ohms 119103
unless otherwise indicated. 5% 2 watt 110751 R423 470,000 ohms 119474
PART# R230 300 ohms R424 24,000 ohms 119243
R101 470 ohms 119471 5% 1 watt 116301 R425 820 ohms, 1/2 watt 113821
R102 1,000 ohms 119102 R231 300 ohms R426 5,600 ohms 119562
R103 120,000 ohms 119124 5% 1 watt 116301 R427 7,500 ohms 119752
R104 10,000 ohms 119103 R232 750 ohms R428 47,000 ohms 119473
R105 470 ohms 119471 5% 2 watt 110751 R429 10,000 ohms 119103
R106 470 ohms 119471 R233 1,000 ohms R430 470,000 ohms 119474
R107 18,000 ohms 119183 5% 2 watt 110102 R431 20,000 ohms 119203
R108 3,900 ohms 119392 R235 47 ohms R432 820 ohms, 1/2 watt 113821
R109 15,000 ohms 119153 5% 1/2 watt AB 103470 R433 47,000 ohms 119473
R110 10,000 ohms 119103 R236 47 ohms R434 10,000 ohms 119103
R111 100 000 ohms 119104 5% 1/2 watt AB 103470 R435 470,000 ohms 119474
R112 680 ohms 119681 R237 47 ohms R436 20,000 ohms 119203
R113 100,000 ohms 119104 5% 1/2watt AB 103470 R437 820 ohms, 1/2 watt 113821
R114 100,000 ohms 119104 R238 47 ohms R438 7,500 ohms 119752
R115 10,000 ohms 119103 5% 1/2 watt AB 103470 R439 5,600 ohms 119562
R116 10,000 ohms 119103 R239 1,000 ohms 119102 R440 20,000 ohms 119203
R117 5,100 ohms 119512 R240 1,000 ohms 119102 R441 15,000 ohms 119153
R118 10,000 ohms 119103 R244 200,000 ohms 119204 R442 470,000 ohms 119474
R119 100 ohms 119101 R245 39 ohms 119390 R443 20,000 ohms 119203
R120 100 ohms 119101 R246 39 ohms 119390 R444 820 ohms, 1/2 watt 113821
R121 2,200 ohms 119222 R247 330,000 ohms 119334 R445 20,000 ohms 119203
R122 8,200 ohms 119822 R301 10 ohms R446 15,000 ohms 119153
R126 620 ohms 119621 5% 10 watt 110100 R447 470,000 ohms 119474
R127 100 ohms 119101 R302 10 ohms R448 20,000 ohms 119203
R128 150,000 ohms 119154 5% 10 watt 110100 R449 820 ohms, 1/2 watt 113821
R129 150,000 ohms 119154 R303 10 ohms R450 15,000 ohms 119153
R130 1,000 ohms 119102 5% 10 watt 110100 R451 5,600 ohms 119562
R131 7,500 ohms 119752 R304 10 ohms R452 10,000 ohms 119103
R132 390,000 ohms 119394 5% 10 watt 110100 R453 15,000 ohms 119153
R133 390,000 ohms 119394 R305 1000 ohms R454 470,000 ohms 119474
R134 1,000 ohms 119102 10% 10 watt 120102 R455 20,000 ohms 119203
R135 7,500 ohms 119752 R306 10 ohms R456 820 ohms, 1/2 watt 113821
R136 3,300 ohms 119332 10% 10 watt 120100 R457 10,000 ohms 119103
R137 3,300 ohms 119332 R307 850 ohms R458 15,000 ohms 119153
R138 47,000 ohms 119473 10% 10 watt 120851 R459 470,000 ohms 119474
R139 5,600 ohms 119562 R308 850 ohms R460 20,000 ohms 119203
R140 5,600 ohms 119562 10% 10 watt 120851 R461 820 ohms, 1/2 watt 113821
R141 10,000 ohms 119103 R309 0.18 ohm R462 15,000 ohms 119153
R142 360 ohms 3% 10 watt 120180 R463 3,000 ohms 119302
5% 2 watt 110361 R310 0.18 ohm R464 10,000 ohms 119103
R143 200,000 ohms 119204 3% 10 watt 120180 R465 15,000 ohms 119153
R144 100,000 ohms 119104 R311 0.18 ohm R466 1,000,000 ohms 119105
R145 390,000 ohms 119394 3% 10 watt 120180 R467 20,000 ohms 119203
R146 2,200 ohms 119222 R312 0.18 ohm R468 820 ohms, 1/2 watt 113821
R147 2,700 ohms 119272 3% 10 watt 120180 R469 10,000 ohms 119103
R201 1,000 ohms 119102 R313 82 ohms 119820 R470 15,000 ohms 119153
R202 22,000 ohms 119223 R314 220 ohms 119221 R471 1,000,000 ohms 119105
R203 33,000 ohms 119333 R315 300 ohms 119301 R472 20,000 ohms 119203
R204 33,000 ohms 119333 R317 100,000 ohms R473 820 ohms 118821
R205 4,700 ohms 119472 1/2 watt 102104 R474 15,000 ohms 119153
R206 2,200 ohms 119222 R318 3.3 ohm 1/2 watt 103030 R475 1,500 ohms 119152
R207 2,200 ohms 119222 R319 10,000 ohms 119103 R476 10,000 ohms 119103
R208 100,000 ohms 119104 R320 10,000 ohms 119103 R477 15,000 ohms 119153
R209 100 ohms 119101 R321 18,000 ohms 119183 R478 1,000,000 ohms 119105
R210 22,000 ohms 119223 R322 600 ohms R479 4,700 ohms 119472
R211 6,200 ohms 5% 10 watt 120601 R480 820 ohms, 1/2 watt 113821
5% 1/2 watt film 133622 R323 2,200 ohms R481 10,000 ohms 119103
R212 220 ohms 119221 10% 10 watt 120222 R482 15,000 ohms 119153
R213 130 ohms 119131 R401 150 ohms, 5% 1 watt 116151 R483 1,000,000 ohms 119105
R214 150 ohms 119151 R402 20,000 ohms 119203 R484 4,700 ohms 119472
R215 100 ohms 119101 R404 150,000 ohms 119154 R485 820 ohms,1/2 watt 113821
R216 22 ohms 119220 R406 100,000 ohms 119104 R486 15,000 ohms 119153
R217 1,000 ohms 119102 R407 20 ohms 119200 R487 680 ohms 119681
R218 2,200 ohms 119222 R408 20,000 ohms 119203 R488 10,000 ohms 119103
R219 1,000 ohms 119102 R410 150,000 ohms 119154 R489 15,000 ohms 119153
R220 39 ohms 119390 R412 100,000 ohms 119104 R490 1,000,000 ohms 119105
R221 39 ohms 119390 R413 20 ohms 119200 R491 1,500 ohms 119152
R222 2,400 ohms 119242 R414 2,400 ohms 119242 R492 820 ohms, 1/2 watt 113821
R223 2,400 ohms 119242 R415 15,000 ohms 119153 R493 10,000 ohms 119103
R224 10 ohms AB 109100 R416 47,000 ohms 119473 R494 15,000 ohms 119153
R225 100 ohms 119101 R417 10,000 ohms 119103 R495 1,000,000 ohms 119105
R226 100 ohms 119101 R418 470,000 ohms 119474 R496 1,500 ohms 119152
R227 10 ohms AB 109100 R419 24,000 ohms 119243 R497 820 ohms, 1/2 watt 113821
R228 1,000 ohms R420 820 ohms, 1/2 watt 113821 R498 15,000 ohms 119153
5% 2 watt 110102 R421 47,000 ohms 119473 R499 240 ohms 119241

PART # PART # PART #
R500 10,000 ohms 119103 C213 200 mfd 15v 283207 D302 silicon diode
R501 15,000 ohms 119153 C214 200 mfd 15v 283207 1A 200 prv 1N4003 544012
R502 10,000,000 ohms 119106 C215 .001 mfd 100v 10% D304 zener diode
R503 1,500 ohms 119152 disc 240102 13v 1w 5% 540113
R504 820 ohms, 1/2 watt 113821 C217 .001 mfd 100v 10% D305 zener diode
R505 10,000 ohms 119103 disc 240102 13v 1w 5% 540113
R506 15,000 ohms 119153 C218 1000 mmfd 100v 5% 255102 D401 silicon diode
R507 10,000,000 ohms 119106 C219 .022 mfd 100v 10% 264223 1A 200 prv 1N4003 544012
R508 1,500 ohms 119152 C220 .022 mfd 100v 10% 264223 D402 silicon diode
R509 820 ohms, 1/2 watt 113821 C221 1000 mmfd 100v 5% 255102 1A 200 prv 1N4003 544012
BR301 AC line breaker 15A 342702 C222 1000 mmfd 100v 5% 255102 D403 zener diode
BR302 thermal sensor C223 1000 mmfd 100v 5% 255102 12v 1w 5% 540012
85°C 15A 342001 C301 .1 mfd 100v 20% D404 zener diode
BR303 thermal sensor disc 224104 15v 1w 5% 540115
BR304 85oC 15A 1 342001 C302 500 mfd l5v 283507 D405 zener diode
BR304 AC line breaker 7A 342703 C303 500 mfd 15v 283507 15v 1w 5% 540115
BR305 thermostat C304 10,000 mfd 80v 284109 D406 light emitting
55oC 15A 342007 C305 .1 mfd 100v 20% thru diode, red 546220
C101 4.7 mfd 15v 20% disc 224104 D421
tantalum 282505 DB301 silicon diode bridge
C102 .01mfd l00v20% C306 10,000 mfd 80v 284109 25A
disc 234103 C307 .1 mfd 100v 20% F301 fuse 5A 3AG 342025
C103 .01 mfd 100v 20% disc 224104 F302 fuse 10A 8AG 342012
disc 234103 C308 .l mfd l00v 20% F303 fuse 10A 8AG 342012
C104 12 mmfd disc 244120 disc IC101 IC NE5558 587458
C105 10 mfd l5v 281106 C309 .01 mfd 500v disc 228103 IC102 IC LM301AH 537709
C106 .0082 mfd 100v 5% C401 500 mfd 25v 280507 IC103 IC LM301AH 587709
mylar 264822 C402 20 mfd 15v 281205 IC401
C107 .0082 mfd 100v 5% C404 .15 mfd 100v 5% 265154 thru IC LM339 580339
mylar 264822 C406 .15 mfd 100v 5% 265154 IC404
C108 .47 mfd 100v 10% D101 silicon diode L301 choke assembly 453001
mylar 260474 1N4148 543148 P101 470 ohms trimpot 140471
C109 .47 mfd 100v 10% D102 silicon diode P201 1,000 ohms trimpot 190103
mylar 260474 1N4148 543148 P202 1,000 ohms trimpot 190103
C110 35 mfd 30v D103 dual silicon diode P301 100,000 ohms
non-polarized 283366 BZ102 546361 1/2 watt linear 142104
C111 5 mfd 15v 283505 D104 silicon diode PL301 neon lamp 521021
C112 5 mfd 15v 283505 1N4148 543148 PL302 neon lamp 521021
C113 500 mfd 3v 281507 D105 silicon diode PL303 #53 lamp 526053
C114 50 mfd 10v 281506 1N4148 543148 Q101 transistor EN3962 562962
C115 50 mfd 10v 281506 D106 silicon diode Q102 transistor SE4010 572010
C116 .01 mfd 100v 20% 1N4148 543148 Q104 thyristor 2N5061 574061
disc 234103 D107 silicon diode Q105 transistor FT4356 562356
C117 .01 mfd 100v 20% 1N4148 543148 Q106 transistor 2N4889 562889
disc 234103 D108 silicon diode Q201 transistor 2N4889 562889
C118 .47 mfd l00v5% 260474 1N4148 543148 Q202 transistor 2N4889 562889
C119 .47 mfd 100v 5% 260474 D109 silicon diode Q203 transistor 2N4889 562889
C120 .47 mfd 100v 5% 260474 1N4148 543148 Q204 transistor 2N3440 572440
C121 .01 mfd 100v 20% DUO silicon diode Q205 transistor 2N3440 572440
Disc 234103 1N4148 543148 Q206 transistor 2N3440 572440
C122 .01 mfd 100v 20% D111 silicon diode Q207 transistor 2N5415 562415
Disc 234103 1N4148 543148 Q208 transistor BC308B 567070
C123 .01 mfd 100v 20% D112 silicon diode Q209 transistor SE6020A 577021
disc 234103 1A 200 prv 1N4003 544012 Q210 transistor SE6020A 577021
C124 .01 mfd 100v 20% D113 silicon diode Q211 transistor BC308B 567070
disc 234103 1N4148 543148 Q212 transistor TIP41C 577041
C125 200 mfd 3v 281207 D114 silicon diode Q213 transistor TIP41C 577041
C126 470 mfd 12v 283507 1N4148 543148 Q214 transistor TIP42C 567042
C201 11 mfd 15v Kemet D201 silicon diode Q215 transistor TIP42C 567042
Tantalum 281115 1N4148 543148 Q301
C202 .l mfd l00v 20% D202 silicon diode thru transistor 2N5630 571104
disc 224104 1N4148 543148 Q304
C203 .1 mfd 100v 20% D203 silicon diode Q305
disc 224104 1N4148 543148 thru transistor 2N6030 561356
C204 .1 mfd 100v 20% D204 silicon diode Q308
disc 224104 1N4148 543148 Q401
C205 180 mmfd 100v 10% 224181 D205 zener diode thru transistor 577020
C206 .47 mfd 100v 5% 260474 14v .4w 5% 540014 Q420 MPS A-20
C207 1000 mfd 10v 281112 D206 silicon diode RY301 relay DPST
C208 47 mmfd 500v 10% 224470 1N4148 543148 15A 48v coil 539248
C209 .1 mfd 100v 20% D207 silicon diode S101 switch 8PDT dual 338000
disc 224104 1N4148 543148 S301 switch DPTT
C210 .001 mfd 100v 10% D208 silicon diode rotary 15A 333241
disc 240102 1N4148 543148 S302 switch DP5T rotary 333025
C211 82 mmfd 100v 10% D209 silicon diode S303 switch 2P4T rotary 333020
disc 224820 1N4148 543148 S304 switch 4PDT single 331105
C212 .001 mfd 100v 10% D301 silicon diode T301 power transformer 464026
disc 240102 1A 200 prv 1N4003 544012 T302 power transformer,
international model 464030
