DYNACO Stereo 400 User manual

Page 1 of 12
Updatemydynaco
Dynaco Stereo 400/410/416
Replacement RCA Jack Installation
(ST400RCAJ)
© 2021 AkitikA LLC
All rights reserved
Revision 1p02 March 9, 2021

Page 2 of 12
Table of Contents
Table of Contents ................................................................................................................ 2
Table of Figures .................................................................................................................. 2
Section 1: About This Manual ............................................................................................ 3
Who Should Attempt this Project? ................................................................................. 3
Tools you’ll need ............................................................................................................ 3
Project Overview ............................................................................................................ 3
Important Safety Notes ................................................................................................... 4
About Components ......................................................................................................... 4
Recommended Solder ..................................................................................................... 4
Warranty ......................................................................................................................... 4
Section 2: Kit Building Hints .............................................................................................. 5
Section 3: Building the New RCA Jack Assembly ............................................................. 5
Section 4: Removing the Old RCA Jack Assembly............................................................ 6
Section 5: Installing the New RCA Jack Assembly............................................................ 9
Section 6: Reassembling the ST400 ................................................................................. 12
Table of Figures
Figure 1-bending the RCA jack ground lugs ...................................................................... 5
Figure 2-Assembling RCA jacks to the mounting PCB's ................................................... 5
Figure 3-Building the new RCA jack assembly, front view ............................................... 6
Figure 4-Building the new RCA jack assembly, back view ............................................... 6
Figure 5-remove the two transformer shield screws ........................................................... 7
Figure 6-Remove two screws from the side, behind the fan ............................................... 8
Figure 7-Remove two side screws (non-fan side) ............................................................... 8
Figure 8-Remove 9 bottom screws ..................................................................................... 9
Figure 9-Back is rotated away from the chassis ............................................................... 10
Figure 10-solder wires to the new RCA jack assembly .................................................... 11
Figure 11-Position the jack assembly prior to installation................................................ 11
Figure 12-New RCA jack kit is installed .......................................................................... 12

Page 3 of 12
Section 1: About This Manual
This manual gives the information you need to build and install new, gold-plated RCA
input jacks into Dynaco’s Stereo 400/410/416 power amplifier. We’ll just say Stereo 400
to cover all three models. Please note however, that this manual was written based on the
Stereo 400, so there may be slight differences in the disassembly procedures for the
Stereo 410 and the Stereo 416.
The jacks in most Stereo 400’s may be more than 40 years old. The ground connections
tend to oxidize, which could result in a bad, high resistance, ground connection and
excess noise. Replacing these jacks with new gold-plated jacks will make for a much
lower resistance ground connection. These new jacks also project a bit more from the
back panel. This makes the Stereo 400 able to mate with a wider range of RCA jack
configurations.
Who Should Attempt this Project?
You can build this kit if you can:
1. Solder (using normal rosin core solder and a soldering iron).
2. Use simple hand tools like screwdrivers, wire cutters, and pliers.
3. Read and follow directions.
It helps if you:
1. know a bit about electronics, or
2. have a friend who knows a bit about electronics
3. can get to YouTube to watch a few helpful videos about the assembly process
(none are posted as of this version of the manual).
Please note that Stereo 400’s are heavy. You are in for a wrestling match of sorts with
this beast. Please also note that the amount of energy controlled by one of these
behemoths is impressive. That makes it distressingly easy to let the “magic smoke” out of
the amp. We urge you to use caution as you undertake replacement of the RCA input
jacks.
Tools you’ll need
You’ll need the following tools:
1. Phillips screwdriver (#1 and #2), regular screw-drivers.
2. Pliers or nut drivers suitable for #4 and #6 hardware
3. needle nose pliers (helpful, but not strictly necessary)
4. pencil type soldering iron of 25 to 50 Watts (no huge honking soldering guns or
blowtorches)
5. wire cutters and strippers
Project Overview
The project consists of the following steps:
1. Disassembling the amp to allow separating the heat-sink assembly from the body
of the amplifier.
2. Removing the old RCA Jacks.

Page 4 of 12
3. Installing the new RCA Jacks.
4. Reassembling the amp.
Important Safety Notes
By purchasing, using, or assembling this kit, you have agreed to hold Akitika LLC
harmless for any injuries you may receive in its assembly and/or use. To prevent injuries:
 Wear safety glasses when soldering or clipping wires to prevent eye injuries.
 Always unplug the power before working on the amplifier.
 Large capacitors hold lots of energy for a long time. Before you put your hands
into the amplifier:
o Pull the AC plug!
o Wait 2 full minutes for the capacitors to discharge!
 Remove jewelry and rings from your hands and wrists, or anything that might
dangle into the amplifier.
 If working on the equipment with the power on, keep one hand in your pocket,
especially if you’re near the power supply or power supply wires. This can
prevent serious shocks.
 Build with a buddy nearby. If you’ve ignored all the previous advice, they can
dial 911 or get you to the hospital.
 Read and understand the safety manuals of all the tools you use.
About Components
We reserve the right to make design/or component changes at any time without prior
notification.
Recommended Solder
The kit must be assembled with 63/37 Rosin Core solder. The recommended diameter is
0.031 inches.
Warranty
With the exception of fuses, Akitika LLC will replace for free any parts of a correctly
assembled product that fails within one year of the date of purchase when the equipment
has been used in home stereo applications. It is the responsibility of the kit builder to
install the replacement part(s). This warranty applies to the original purchaser only. It
does not apply to units that have been physically or electrically abused, modified without
prior factory authorization, or assembled with other than 63/37 Rosin Core solder.
Akitika LLC’s liability shall in no event exceed the cost paid to Akitika LLC for the kit.

Page 5 of 12
Section 2: Kit Building Hints
Yes, I know you want to ignore this section and jump right into building the kit.
However, please take a minute and read the advice. I’ve condensed it into bullets so that
even you guys who are in a hurry can benefit.
 Stop any time you’re feeling confused, tired, or anxious. Taking breaks at those
strategic times will keep the build enjoyable and greatly enhance your chances of
first-time success.
 A soup bowl is your friend. Before you build, carefully empty the parts for just
that board into a broad, flat, light colored soup bowl. That makes it easy to find
the parts, and keeps them from getting lost.
 Is something in this manual confusing? Does something look wrong? Send your
questions by email to [email protected] or [e-mail]. You’ll
help yourself and everyone who builds the kit.
Section 3: Building the New RCA Jack Assembly
We recommend you read through this section first before you start to build. After you’ve
read through it, go back and begin building the RCA jack assembly.
Remove and reserve the nuts that holds the ground lug to the RCA jack. Bend the RCA
jack ground lugs as shown here using needle-nose pliers:
Figure 1-bending the RCA jack ground lugs
Figure 2-Assembling RCA jacks to the mounting PCB's
Install the gold-plated RCA jacks in the ST400 BD1 printed circuit board as shown in
Figure 3 and Figure 4.

Page 6 of 12
Figure 3-Building the new RCA jack assembly, front view
Figure 4-Building the new RCA jack assembly, back view
Note the position of the ground lugs and the orientation of the contacts of the jacks as
shown in Figure 4. The ground lugs should ideally be at 12 o’clock, but anywhere from
11 o’clock to 1 o’clock is fine.
You’ll want to make sure that the nuts that hold the jacks in place are snug. Here’s the
process I use:
1. Assemble everything as shown, but just finger tight for now.
2. Position the lugs (back view) at 10 or 11 o’clock.
3. Use a pair of slip-joint pliers on the base (widest part) of the front side of the
RCA jack and an 11/32” nut-driver on the nut. Turn the nut to make a snug
mechanical connection. The lug will move clockwise a bit, stopping in the range
from 11 to 1 o’clock.
4. You may have to try the process a few times to get the feel of where to start the
tightening operation.
Make sure that the nuts and jacks are quite tight. You don’t want them to come loose
once they are installed.
Section 4: Removing the Old RCA Jack Assembly
Make sure that your amp is unplugged before beginning. Wait at least one minute to
allow the large capacitors to fully discharge.
The object of this procedure is to separate the big black heatsink assembly from the body
of the amp. This will give you access to the old RCA jack assembly.

Page 7 of 12
Label a cup, “perforated metal cover screws”. Remove the screws that hold the black,
perforated metal cover to the chassis, and place them in the labeled cup. There are:
1. Four screws along the top front edge of the perforated metal cover, just behind the
faceplate.
2. Two screws in a vertical line along the right-side front edge of the perforated
metal cover, just behind the faceplate.
3. Two screws in a vertical line along the left-side front edge of the perforated metal
cover, just behind the faceplate.
4. Two screws in a horizontal line on the right side where the perforated metal cover
slides into the chassis base.
5. Two screws in a horizontal line on the left side where the perforated metal cover
slides into the chassis base.
Remove the perforated metal cover. Even after the screws are gone, it may take
considerable force if it has been a long time since the front cover was taken off. In
addition, you may find that the cover is pinched between the transformer and the chassis.
I find I will often need to place the point of an awl into one of the side perforations, and
use it as a handle to pull up the transformer side of the cover. Be careful with the awl, as
it's sharp and pointy, and we’d prefer to not get blood over the amp.
Figure 5-remove the two transformer shield screws
Now, remove the two screws shown in Figure 5 that hold the transformer shield to the
heat sink. The bottom screw will probably require a mix of contortionist skills and a
small screwdriver. We recommend that you label the screws with their original location
to take the guess-work out of reassembly.
Remove 2 screws on the side, from behind the fan.

Page 8 of 12
Figure 6-Remove two screws from the side, behind the fan
Remove two side screws, on the non-fan side of the chassis.
Figure 7-Remove two side screws (non-fan side)
Turn the Stereo 400 on its side, with the transformer side on the table to get access to and
remove 9 screws on the bottom. Once again, labeling these screws and the lock-washers
can take some of the guess-work out of reassembly.

Page 9 of 12
Figure 8-Remove 9 bottom screws
Assuming that your Stereo 400 is like mine, you should now be able to wiggle the heat-
sink assembly loose from the chassis. Be careful and gentle, as there are a number of
wires that hold the heat-sink assembly to the chassis. Your Stereo 400 might even have a
screw that mine didn’t, as there may have been changes during production that I am not
aware of.
With a little persistence and a lot of care, you will be able to swing the bottom of the
heat-sink assembly away from the chassis. Remove the 2 screws, 2 nuts, and 2 lock
washers adjacent to the RCA jacks that hold them into the heatsink. Don’t let the
lockwashers fall into the chassis.
Gently pull the old RCA jack assembly into the clear space between the heatsink
assembly and the chassis, as shown in Figure 9.
Notice the two twisted pairs connected to the RCA jacks:
1. Green and Black (green is left channel signal and the associated black is left
channel ground).
2. Red and Black (red is right channel signal and the associated black is right
channel ground).
Section 5: Installing the New RCA Jack Assembly
Clip the wires as close to the old jacks as possible to leave the maximum possible length.
Maintain the pair relationships. Strip ¼” of insulation from the ends of each of the 4
wires. Bend the ends into L-shaped hooks, and insert them into the new RCA jack
assembly:
1. Red wire to center conductor of red RCA jack.
2. Black wire from the red-black pair to the ground lug of the red RCA jack.
3. Green wire to the center conductor of the white RCA jack.

Page 10 of 12
4. Black wire from the green-black pair to the ground lug of the white RCA jack.
If you’d like, you can now fold the wire ends over, converting the L-shape to a U-shape.
Either way, it’s time to solder the 4 connections to the jacks.
Figure 9-Back is rotated away from the chassis
Figure 9-Back is rotated away from the chassis

Page 11 of 12
Figure 10-solder wires to the new RCA jack assembly
Figure 11-Position the jack assembly prior to installation
Use the supplied 6-32x5/8” sems screw and 6-32 keps nuts to fasten the new RCA jack
assembly to the heatsink. There will be a little bit of play between the mounting holes,
screws, and RCA jack PCB. Your goal is to end up with the RCA jacks centered in their
holes in the heatsink.
In both original and improved forms, the RCA jack grounds should not contact the
heatsink. That isolation prevents the formation of ground loops which could cause hum.

Page 12 of 12
You’ll note that the tops of the new RCA jacks project further than the old ones by about
1/8”. This may allow the use of a wider range of RCA jack style for making input
connections.
Figure 12-New RCA jack kit is installed
Section 6: Reassembling the ST400
Reverse the procedure used to disassemble the ST400 to reassemble it. Briefly:
1. Carefully wiggle the heatsink assembly back into position in the chassis. Be
careful not to bend components as you work it back into place. Depending upon
your preferences:
a. You may find that it’s easier to set the amp on its feet so that gravity could
help guide the heat sinks assembly back into place. Then insert the 4 side
screws in place before turning the amp vertical again to re-install the 9
bottom screws.
b. Alternatively, you may find it easier to leave the amp vertical with its
transformer side down, and re-install the 9 bottom screws, then set the
amp horizontal to reinstall the four side screws.
2. Reinstall the screws that hold the transformer shield to the heatsink.
3. Reinstall the perforated black cover.
4. Return your ST400 to service in your system.
