Dynacord SUB 2.18 User manual

Features:
• Power Handling Rated 1000 W / 4 Ohms
Peak 4000 W
• Dual 18‘‘ EVS-18S LF Transducer
• 102 dB Sensitivity, 138 dB Maximum SPL
• Four Integrated Handles for Easy Portability
• Mounting Points to attach optional WK-C18
Wheel Kit
Technische Informationen
Engineering Data Sheet
Sub 2.18
2 x 18“
Subwoofer
Wir weisen ausdrücklich darauf hin, dass bei
gehängten Lautsprecherboxen die einschlägigen
Sicherheitsbestimmungen zu beachten sind. Es
muss unbedingt qualifizierte Fachberatung in
Anspruch genommen werden!
We expressly point out that the relevant safety
regulations must be observed for “flying”
loudspeaker systems. It is imperative that quali-
fied expert advice is sought.
Sub 2.18
Order No. F01U165096
Cabinet Subwoofer
Configuration Vented-Direct Radiator
Nominal impedance 4 Ohms
Minimum Impedance 3.3 Ohms
Rated Power RMS 1000 W
Peak Power 4000 W
Sound pressure level
SPL 1 W / 1 m 102 dB
Max. SPL 1 m (calculated
with peak power)
138 dB
Frequency Range (-10 dB) 35 Hz to 250 Hz
Nominal Coverage Angle
(Horizontal x Vertical)
Omnidirectional
LF Transducer 2x EVS-18S, 18 ‘‘ (457 mm) Driver
Connectors 2x Neutrik Speakon NL4
Sub 1+ / 1-
Wired through 2+ / 2-
Dimensions (W x H x D) 513 mm x 1200 mm x 710 mm
(20.2“ x 47.2“ x 28.0“)
Net Weight 66.3 kg (146.2 lbs)
Shipping Weight 71.7 kg (158.1 lbs)
Enclosure material MDF with D-PUR PLUS
Grille Steel, Black Finish with Acoustic Gauze
Warranty 5 years
Optional Accessories
WK-C18 F01U169672
Spare Parts
LF Transducer F01U105741

Beschreibung Description
Der Sub 2.18 ist ein Doppel-18" Hochleistungs-Subwoofer für sehr hohe Schalldrücke:
Sensitivity 102 dB 1 W/1 m, SPLmax 138 dB. Seine Belastbarkeit beträgt 1000 W Con-
tinuous und 4000 W Peak. Der Sub 2.18 kann universell für Aktiv 2-Weg oder 3-Weg Sys-
teme eingesetzt werden.
Er ist vor allem aber auch die ideale Ergänzung der C 25.2 zum Aufbau eines Aktiv-2-Weg
Systems wird zusammen mit den Controllern DSP 260 oder DSP 600 und Endstufen der
Serien SL oder LX. Geeignete Presets stehen für beide Controller zur Verfügung, bei Ver-
wendung des DSP 600 auch ein FIR-TUNE Preset.Der Sub 2.18 ist vorbereitet für das
optional erhältliche Wheelkit WK-C18.
The Sub 2.18 is a double 18", high-powered subwoofer for very high sound pressure
levels: sensitivity 102 dB 1W / 1m, SPLmax 138 dB. Boasting power handling of 1000 W
continuous and 4000 W peak, the Sub 2.18 can be used universally for active two-way or
three-way systems.
It is above all, however, the ideal companion to the C 25.2 for the creation of an active
two-way system together with the DSP 260 and DSP 600 controllers and power amp-
lifiers from the SL or LX series. Suitable presets are available for both controllers as well
as a FIR-TUNE preset for the DSP 600. The Sub 2.18 is prepared for the optionally
available WK-C18 wheel kit.
Illustration 1: Dimensions

Illustration 2: Frequency Response
Illustration 3: Block diagram
20 100 1k 10k 20k
60
65
70
75
80
85
90
95
100
105
110
f / Hz
SPL / dB
Frequency Response, 1/6 Oct.
20 100 1k 10k 20k
1
2
5
10
20
50
100
200
f / Hz
|Z| / Ω
Impedance, 1/6 Oct.

12000 Portland Avenue South, Burnsville, MN 55337, USA Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:
Phone: [phone], Fax: [phone] [phone] Fax: [phone]
Asia & Pacific only. For customer orders, contact Customer Service at:
www.dynacord.com [phone] Fax: [phone]
For technical assistance, contact Technical Support at: [phone]
© Bosch Communications Systems 09/2010
Part Number F01U167457 Vs 01 Specifications subject to change without notice.
Illustration 4: Optional Wheel Kit WK-C18
