DynaLock 3101C-TJ101 User manual

MODEL 3101C-TJ101
DELAY EGRESS SYSTEM
WIRING INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com

Page 2
3101C-TJ101 MANUAL 06/14
MODEL 3101C-TJ101
DELAY EGRESS SYSTEM
WIRING INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
BASIC SET-UP
Remove the Electronics Cover to expose the circuit board assembly.
1.
2. - System Selector Switches
The selector switches (S3) which control major system
functions are factory set to the OFF position for basic lock
operation. Switch 1 will be used during sensor adjustment
(page 8). Switches 2 through 7 are only used for options
described on page 10.
L
C
C
(Factory Setting)

Page 3
3101C-TJ101 MANUAL 06/14
MODEL 3101C-TJ101
DELAY EGRESS SYSTEM
WIRING INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
BASIC WIRING
Terminals 1& 2 - Auto-Sensing Power Input. May be 12 or 24 Volts, AC
or DC, uninterrupted. Maximum current draw, by voltage, is as follows:
12V DC: 453mA
12V AC: 1.08A
24V DC: 254mA
24V AC: 750mA
DO NOT INTERRUPT INPUT POWER (TERMINALS 1 & 2) FOR
AUTHORIZED ACCESS/EGRESS. EXTERNAL ACCESS/EGRESS
CONTROLS (EX. KEYPAD, CARD READER, ETC.) SHOULD USE
DEDICATED BYPASS TERMINALS 7 & 8 or 9 & 10 (SEE PAGE 11).
Terminals 3 & 4 - Fire Panel Input. May be normally-open (N.O.) or
normally-closed (N.C.) dry contacts from re panel (check re alarm control
jumper “FA” - page 6). DO NOT APPLY POWER TO TERMINALS 3 & 4
OR CIRCUIT BOARD DAMAGE WILL OCCUR.
When the re panel trips, the 3101C-TJ101 will release, the audible will
sound a constant tone and the bi-color LED (LED1) will change to green.
When the re panel is reset, the 3101-TJ101 will reset and lock.
Basic hook-up is shown below. For other system features hook-up see “Option Wiring” (page 11).
PROPER OPERATION OF THE 3101C REQUIRES
ADJUSTMENT OF THE EGRESS SENSOR
PROCEED TO EGRESS SENSOR ADJUSTMENT
POWER
FAC
CONTINUOUS
1 2 3 4
POWER INPUT
12/24 VAC/VDC
FIRE PANEL INPUT
N.O. OR N.C.
CONTACTS

Page 4
3101C-TJ101 MANUAL 06/14
MODEL 3101C-TJ101
DELAY EGRESS SYSTEM
WIRING INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
EGRESS SENSOR ADJUSTMENT
WHEEL STOP INSTALLED
(LOCKS ADJUSTMENT)
SEE PAGE 5 FOR LOCATION OF ELECTRONIC PARTS MENTIONED IN THIS SECTION
The sensor and armature assembly are designed for use on a door with existing mechanical latching hardware. If used
on a door without a latch, false alarms are possible. In these cases, we suggest using an external trigger such as our
6451 Exit Sensor Bar - connect using terminals 11&12 and disable this internal sensor (see page 5).
With the door closed and latched apply input power to terminals 1 & 2. Slide
selector switch (DS1) #1 to the ON position to activate the Set-Up mode.
Rotate the on-board keyswitch counter-clockwise. The 3101C-TJ101 should
now be unlocked (LED1-OFF).
Open the door. Temporarily remove the Adjustment Wheel Stop from the
Armature Mounting Plate and close the door. Set aside for re-installation
later.
With the door closed observe the bi-color LED (LED1) on the circuit board. It
should be lit red. If it is not lit, rotate the adjustment wheel counter-clockwise
as necessary to ensure that it will contact and fully depress the ball plunger
on the lock. Rattle the door to ensure the LED remains lit.
With the door closed and LED1 lit red, unlatch and slowly open the door. The
LED will shut off as soon as the door opens far enough for the ball plunger
to fully project.
With adjustment completed, re-install the adjustment wheel stop to lock-in the
adjustment. Close the door, slide selector switch (DS1) #1 back to the OFF
position and return the on-board keyswitch to the center position to re-lock
the 3101C-TJ101.
Unlatch and push on the door until delay egress triggers (1-3 seconds). The
audible will sound and LED1 will ash red. After 15 seconds the lock will
release. Turn the on-board keyswitch clockwise to reset the lock. If delayed
egress triggers too soon, or fails to trigger, re-adjust the sensor adjustment
wheel for desired sensitivity.
WHEEL
STOP
MOUNTING
SCREW
WHEEL
STOP
EGRESS SENSOR
ADJUSTMENT WHEEL
ARMATURE
MOUNTING
PLATE
1.
2.
3.
4.
5.
6.
DOOR CLOSED AND LATCHED
DOOR UNLATCHED AND MOVED

Page 5
3101C-TJ101 MANUAL 06/14
MODEL 3101C-TJ101
DELAY EGRESS SYSTEM
WIRING INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
SEPERATE 7050 KEYSWITCH OPERATION
CENTER
CLOCKWISE (SPRING LOADED)
COUNTER-CLOCKWISE
NORMAL / LOCKED
RESET AFTER DELAY EGRESS ALARM
BYPASS / UNLOCKED WITHOUT ALARM
POSITION DESCRIPTION
INDICATOR & AUDIBLE DESCRIPTIONS
CONDITION AUDIBLE SIGNAL LOCK 7050 LED
DELAY EGRESS ALARM One second pulse rate during
delay cycle.
ON BLINK RED
DELAY EGRESS ALARM Steady tone after delay until
reset.
OFF GREEN
FIRE ALARM
RELEASE
Steady tone until re alarm
contacts are reset.
OFF GREEN
OPTIONAL REMOTE
AUTHORIZED BYPASS
(TERMINALS 7&8 / 9&10)
None, unless bypass audible
is enabled (dip switch 2). If
door is held open past relock
time, goes into delay egress
alarm & requires reset.
OFF BLINK GREEN
POOR MAGNETIC
BOND
Rapid pulse rate until problem
is corrected (only functional
with Dynastat Force Sensor
option).
N/A FAST BLINK RED

Page 6
3101C-TJ101 MANUAL 06/14
MODEL 3101C-TJ101
DELAY EGRESS SYSTEM
WIRING INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
OPTIONAL SET-UP
- System Selector Switches
Set the System Selector Switches (S3) to
address your specic system requirements.
The normal factory setting is all switches
off.
1. C
1 SYSTEM SET-UP NORMAL SET-UP MODE
2 BYPASS AUDIBLE DISABLED ENABLED
3 NUISANCE DELAY 1 SEC. 3 SEC.
4 EGRESS DELAY 15 SEC. 30 SEC.
5 MASTER AUDIBLE ENABLED DISABLED
6
7 EGRESS SENSOR ENABLED DISABLED
8 UNUSED SPARE
SWITCH FUNCTION OFF ON
MODE SETTINGS
*
*Only applies to terminals 9&10 (see next page)
FIRE ALARM
INPUT SETTING
NORMALLY
CLOSED
NORMALLY
OPEN
C

Page 7
3101C-TJ101 MANUAL 06/14
MODEL 3101C-TJ101
DELAY EGRESS SYSTEM
WIRING INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
The external 7050 is included with the 3101C-TJ101 to provide reset and bypass functions to the maglock using the
7050’s momentary / maintained key switch. The external 7050 also indicates lock status as well as door movement during
egress sensor adjustment through LED 1 located on the 7050 faceplate.
The 3101C-TJ101 circuit board is supplied with ying lead connections for LED 1 and the 7050 key switch. These leads
must be connected to match the same color ying leads coming from the 7050-LED. (See above illustration).
Remember to observe polarity for either the key switch or LED’s three wire harness. The key switch must be connected
with the blue wire facing the left (WHITE/BLACK/BLUE See above illustration). The LED 1 must be connected with the
green wire facing the left (GREEN/BLACK/RED See above illustration).
EXTERNAL MODEL 7050xLED KEY SWITCH CONNECTIONS

Page 8
3101C-TJ101 MANUAL 06/14
MODEL 3101C-TJ101
DELAY EGRESS SYSTEM
WIRING INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
OPTION WIRING
REMOTE BYPASS INPUT
Momentarily closing a normally-open dry contact
across terminals 7 & 8 will immediately release the
lock without alarm. The door will remain unlocked
until the contact is opened. Connect authorized
access/egress control(s) here (typical).
REMOTE RESET INPUT
Momentarily closing a normally-open dry contact
across terminals 5 & 6 will reset and re-lock the
3101C following delayed egress and re-closure of
door.
REMOTE TRIP INPUT
Momentarily closing a normally-open dry contact
across terminals 11 & 12 will initiate delayed egress.
This input may be used as a redundant or substitute
means of triggering delayed egress if built-in sensor
initiation is not desired (see page 10, note 3).
INPUT DESCRIPTIONS
! WARNING: Do not apply power to inputs marked “ ! ” or damage will occur.
A
C
B
D
REMOTE BYPASS INPUT TIME DELAY
Momentarily closing a normally-open dry contact across
terminals 9 & 10 will immediately release the lock without
alarm. The door will remain unlocked for a period of time
controlled by on-board adjustable timer S2. To increase the
delay rotate timer S2 clockwise. Range is 1 to 75 seconds
(~5 sec. per click). For NFPA101 applications, the remote
bypass device time delay must be set for 0 seconds.
12 3 4 56 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
NC NO C
NC NOC NC NOC NC NO
C
REMOTE
RESET
INPUT
REMOTE
BYPASS
INPUT
REMOTE
TRIP
INPUT
DELAY
EGRESS
OUTPUT
DYNST
OPTION
OUTPUT
DSM
OPTION
OUTPUT
ATS
OPTION
OUTPUT
STANDARD
INPUT/OUTPUT TERMINALS
(TYPICAL - ALL MODELS)
OPTIONAL
OUTPUT TERMINALS
(AS ORDERED)
A
BD
E
FGH
3101B CIRCUIT BOARD
C
SEE PAGE 7
FOR WIRING
INFORMATION
S2
REMOTE
BYPASS
INPUT
TIME
DELAY
3101C-TJ101 CIRCUIT BOARD

Page 9
3101C-TJ101 MANUAL 06/14
MODEL 3101C-TJ101
DELAY EGRESS SYSTEM
WIRING INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
OPTION WIRING
MONITORING OUTPUT DESCRIPTIONS
DELAY EGRESS OUTPUT
Delay egress alarm monitoring.
SPDT dry relay contacts rated 1Amp @ 24 Volts
Contacts change state upon initiation of delayed
egress, after the nuisance delay has elapsed.
They remain in that state until door is closed and
reset.
DYNST OPTION OUTPUT
Dynastat bond sensor monitoring.
SPDT dry relay contacts rated 1Amp @ 24 Volts
Contacts change state to signal lock status as
either secure or unsecure. Armature misalignment
can also create an unsecure condition.
DSM OPTION OUTPUT
Door position sensor monitoring.
SPDT dry relay contacts rated 0.5Amp @ 24 Volts
Contacts change state to signal physical door
position as either closed or open. DSM is an
independent circuit that does not require lock
power to operate.
ATS OPTION OUTPUT
Anti-Tamper Switch monitoring.
SPDT dry relay contacts rated 0.5Amp @ 24 Volts
Contacts change state to signal removal of the
lock electronics cover.
TYPICAL WIRING
NOTE: INDICATORS ARE NOT INCLUDED
NOTE: INDICATORS ARE NOT INCLUDED
NOTE: INDICATORS ARE NOT INCLUDED
NOTE: INDICATORS ARE NOT INCLUDED
13 14 15
ALARM
SECURE
NC C NO
TO INDICATOR
POWER SUPPLY
16 17 18
UNSECURE
SECURE
NC C NO
TO INDICATOR
POWER SUPPLY
19 20 21
OPEN
CLOSED
NC C NO
TO INDICATOR
POWER SUPPLY
22 23 24
TAMPER
NORMAL
NC C NO
TO INDICATOR
POWER SUPPLY
E
F
G
H

Page 10
3101C-TJ101 MANUAL 06/14
MODEL 3101C-TJ101
DELAY EGRESS SYSTEM
WIRING INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
FACTORY WIRING
DYNASTAT
HARNESS
(2 COND.)
DSM OPTION
HARNESS
(3 COND.)
3101C SENSOR COVER
ASSEMBLY
SENSOR
HARNESS
(4 COND.)
COIL
HARNESS
(4 COND.)
DSM
OPTION
SENSOR
LOCK COIL ASSEMBLY
3101C-TJ101 CIRCUIT BOARD
Harness connectors J3 and J6 are not polarity sensitive.
Harnesses J6 and J8 are only present if the 3101C-TJ101 is equipped with the DYN - Dynastat Force Sensor
and/or DSM - Door Status Switch Options.
Observe polarity when re-connecting the J5 and J8 harness connectors. Orient these connectors with
respect to harness wire colors as follows:
J5 WHT GRN RED BLK
J8 GRN WHT RED
1.
2.
3.
NOTES:

Page 11
3101C-TJ101 MANUAL 06/14
MODEL 3101C-TJ101
DELAY EGRESS SYSTEM
WIRING INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
INSTALLER NOTES

Page 12
3101C-TJ101 MANUAL 06/14
PLEASE DELIVER THIS MANUAL
AND THE KEYS TO THE END USER UPON
COMPLETION OF THE 3101C-TJ101
INSTALLATION
FOR PRODUCT SUPPORT AND PARTS
ORDERING INFORMATION CONTACT:
DynaLock Corp.
705 Emmett Street
Bristol, CT 06010
Bus: [phone] Toll-Free USA
[phone]
Fax: [phone]
DYNALOCK ON THE INTERNET:
E-mail: [email protected]
Website: www.dynalock.com
