DynaLock 3000 Series User manual

PLEASE READ BEFORE ATTEMPTING INSTALLATIONS
3000/ 3000LC/ 2000 SERIES CIRCUIT BOARD DESCRIPTION
Refer to Page 2 & 3 for wiring and voltage instructions
Power Input
and
Control
Fig "A, B & E"
Door
Status
Fig "D"
Dynastat
Fig "C"
L2 OPTION - FUNCTION
Requires Dynastat option to work.
Red = secure / Green = unsecure
Reversing plug direction changes
light indication.
ATS OPTION - WIRING
Indicator device, by others,
illuminates / sounds
when access cover is removed.
Contact Rating: SPDT @ 0.5A
DYNASTAT
CONNECTOR
TIME DELAY ADJ.
CW to increase.
Range 1-80 seconds
see fig. "E"
3000/2000 series mag lock accepts 12/24 VAC/DC
Circuit board shown fully loaded, with every option
ATS
SWITCH
LED
3 Pin Plug
LOCK HOUSING
Wht
Wht
2 Pin Plug
not polarized
COIL CONNECTOR PLUG
The Coil Connector is not polarized
and may go on in either direction.
Blk
Blk
Wht
Wht
4 Pin Plug
COIL PLUG RECEPTACLE
VOLTAGE SELECTION
JUMPERS - See page 2
SECURE
TAMPER
POWER INPUT
FOR ATS
OPTION GRN
WHT
RED
COM.
NO
NC
1
DynaLock Corp. z705 Emmett Street zP.O. Box 2728 zBristol, CT 06011-2728 z1-877-DYNALOCK zwww.dynalock.com
Electromagnetic Locking Systems

HOW TO SET VOLTAGE
Voltage is set by proper placement of the
blue jumper caps on 4 exposed pins
Set for 12 Volts
2 jumpers
Removable Jumpers
Voltage Selection Set for 24 Volts
1 jumper
FACTORY SET FOR 24 VOLTS
WIRING INSTRUCTIONS
3000/2000
12/24 VDC INPUT 3000/2000
12/24 VAC INPUT
(+)
12 / 24
VDC
INPUT
(-)
FIG. A FIG. B
INPUT FROM
INDICATOR POWER
SOURCE
DOOR CLOSED
DOOR OPEN
NOTES: 1. DSM CONTACTS RATED
0.25A MAXIMUM
2. INDICATORS NOT INCLUDED
12 / 24
VAC
INPUT
NORMALLY CLOSED STATION
CONTROL(S), I.E. PUSHBUTTONS,
KEYSWITCHES, ETC.
WIRE MULTIPLE CONTROLS IN
SERIES AS SHOWN.
NORMALLY CLOSED STATION
CONTROL(S), I.E. PUSHBUTTONS,
KEYSWITCHES, ETC.
WIRE MULTIPLE CONTROLS IN
SERIES AS SHOWN.
FIG. D
3000/2000 DYNASTAT
OPTION 3000/2000 DSM
OPTION
DOOR SECURE
DOOR UNSECURE
NOTES: 1. DYNASTAT CONTACTS RATED
1A MAXIMUM
2. INDICATORS NOT INCLUDED
INPUT FROM
INDICATOR POWER
SOURCE
FIG. C
LOCK POWER INPUT
USE FIGURES A OR B
}}LOCK POWER INPUT
USE FIGURES AOR B
2
C
NO
NC
NO
NC
C
12 3 4 5 6 7 8 9 10
12 3 4 5 6 7 8 9 10
12 3 4 5 6 7 8 9 10
12 3 4 5 6 7 8 9 10

1
2
3
4
COIL RESISTANCE CHECK
REMOVE THE
MAGNET COIL
CONNECTOR
FROM THE
CIRCUIT BOARD TO
PERFORM THE COIL TEST
PROPER COIL RESISTANCE SHOULD BE
FROM POINTS 1 TO 3, ~ 53 OHMS
FROM POINTS 2 TO 4, ~ 53 OHMS
ELECTRICAL SPECIFICATIONS
OPERATING VOLTAGES
12 OR 24 VAC / VDC
CURRENT CONSUMPTION, ALL MODELS
12 VAC / VDC - 0.44 A
24 VAC / VDC - 0.22 A
Notes:
1. Thislockmayacceptanyoneof4differentinputvoltagesandbefurnished
with a combination of options. Refer to page 1 for option location and
pages 2 and 3, figure A thru E, for wiring instructions that apply to
your specific installation.
2. For additional system wiring information, refer to the installation
documentation furnished with the external hardware and / or
peripheral devices (I.E. power supply, station controls, keypad, card
readers, etc.) supplied by DynaLock and / or others.
3000 / 2000 TD OPTION
(TIME DELAY) 12 / 24
VAC / VDC
INPUT
NORMALLY CLOSED STATION CONTROL(S),
I.E. PUSHBUTTONS, KEYSWITCHES, ETC.
WIRE MULTIPLE CONTROLS IN SERIES AS
SHOWN.
FIG. E
TIME DELAY OPERATION
1. PUT A JUMPER ACROSS TERMINALS 3 & 4.
2. MOMENTARILY OPENING THE CONTACT(S) AND
INTERRUPTING THE POWER ON 1 & 2 UNLOCKS THE DOOR.
THE DOOR WILL RELOCK AFTER THE DURATION OF THE TD.
3. SEE PAGE ONE FOR THE LOCATION OF THE TIMER
ADJUSTMENT CONTROL.
4. TIME ADJUSTMENT RANGE IS ONE (1) TO EIGHTY (80) SECONDS.
3
ADD
JUMPER
12 3 4 5 6 7 8 9 10

TROUBLESHOOTING TIPS
SYMPTOM POSSIBLE CHECK FOR
CAUSE
DOOR WILL NOT LOCK NO INPUT POWER CHECK ALL CONNECTIONS.
OR NO MAGNETIC CHECK FOR VOLTAGE AT POWER SOURCE
HOLDING FORCE AND LOCK TERMINAL STRIP.
REVERSED POLARITY IF A LOCK IS OPERATING ON DC VOLTAGE
CHECK FOR REVERSED POLARITY.
REFER TO FIG "A" PAGE 2.
AN OPEN CIRCUIT PERFORM THE COIL RESISTANCE CHECK.
IN THE COIL REFER TO BOTTOM OF THE PAGE 3.
LOW HOLDING FORCE WRONG INPUT VOLTAGE VERIFY INPUT VOLTAGE MATCHES JUMPER
SETTING. SEE TOP OF PAGE 2.
VOLTAGE SELECT JUMPERS VERIFY THAT JUMPERS MATCH INPUT
SET WRONG VOLTAGE. SEE TOP OF PAGE 2.
ARMATURE MOUNTING CHECK ARMATURE MOUNTING FOR FREE
TOO RIGID PIVOTING AND FULL CONTACT BETWEEN
THE MATING SURFACE OF THE LOCK
AND ARMATURE.
MAGNET OVERHEATS LOCK SET FOR 12V WITH VERIFY THAT JUMPERS MATCH
AND / OR DRAWS EXCESS 24V APPLIED INPUT VOLTAGE. SEE TOP OF PAGE 2.
CURRENT
POSSIBLE SHORTED COIL PERFORM THE COIL RESISTANCE CHECK.
REFER TO BOTTOM OF PAGE 3.
DYNASTAT BOND SENSOR INSUFFICIENT SUPPLY VOLTAGE CHECK SUPPLY FOR PROPER INPUT
NOT INDICATING DOOR VOLTAGE, SHOULD BE WITHIN 10%
SECURE WHEN CLOSED
AND LOCKED MAGNET AND / OR ARMATURE CLEAN BOTH SURFACES WITH SCOTCH
(WHEN APPLICABLE) FACE DIRTY OR BURRED BRITE TYPE CLOTH AND APPLY WD-40.
CHECK FOR BURRS.
POOR LOCK / ARMATURE CORRECT AS NECESSARY
ALIGNMENT
DSM (DOOR STATUS DSM MAGNETS NOT INSTALLED REPLACE / INSTALL AS NECESSARY
MONITOR) NOT IN ARMATURE HOUSING
INDICATING DOOR
CLOSED / OPEN STATUS
(WHEN APPLICABLE) POOR LOCK / ARMATURE CORRECT AS NECESSARY
ALIGNMENT
42000-3000 Wiring Manual 02-07

3000/3000LC/2000 SERIES
LP - LOW POWER OPTION
SUPPLEMENTAL INSTRUCTIONS
DynaLock
705 Emmett Street Bristol, CT 06011-2728
Phone:[phone] Fax:[phone]
DynaLock 3000 and 2000 Series electromagnetic locks equipped with the LP - Low Power Option are configured
to operate exclusively on 12V AC/DC input voltage. Current draw is 0.16 Amps for single models and 0.32 Amps
for double models.
Damage may occur if input voltage exceeds 16V AC/DC. Do not attempt operation at higher voltages.
GENERAL INFORMATION
BASIC INPUT POWER WIRING
3000/2000 x LP BASIC
12 VDC INPUT(+)
12VDC
INPUT
(-)
FIG. A
NORMALLY CLOSED STATION
CONTROL(S), I.E. PUSHBUTTONS,
KEYSWITCHS, ETC.
WIRE MULTIPLE CONTROLS IN
SERIES AS SHOWN.
12 3 4 5 6 7 8 9 10
3000/2000 x LP BASIC
12 VAC INPUT
12VAC
INPUT
FIG. B
NORMALLY CLOSED STATION
CONTROL(S), I.E. PUSHBUTTONS,
KEYSWITCHS, ETC.
WIRE MULTIPLE CONTROLS IN
SERIES AS SHOWN.
12 3 4 5 6 7 8 9 10

FOR UNITS USING THE CIRCUIT BOARD
DISCARD THE MOVAND THIS PAGE.
BLACK
WHITE
BLACK
WHITE
1
2
3
4
12 VOLT DC OPERATION
MOV
+
-
BLACK
WHITE
BLACK
WHITE
1
2
3
4
MOV
+
-
24 VOLT DC OPERATION
NOTE: TO PROTECT OTHER ELECTRONIC DEVICES IN SYSTEM CONNECT THE SUPPLIED MOV
ACROSS THE LEADS AS SHOWN ABOVE.
NOTE: TO PROTECT OTHER ELECTRONIC DEVICES IN SYSTEM CONNECT THE SUPPLIED MOV
ACROSS THE LEADS AS SHOWN ABOVE.
JUMPER
WIRING INSTRUCTIONS
DynaLock
705 Emmett Street Bristol, CT 06011-2728
Phone:[phone] Fax:[phone]
SERIES 2000/3000 x LCB
ELECTROMAGNETIC LOCK
