dynarex 5613 User manual

Infrared Forehead
Thermometer
User Manual
Reorder No. 5613

Introduction
•Thank you for purchasing this non-contact Infrared
Forehead Thermometer. Please read this User
Manual carefully to ensure safe and proper use of
the thermometer.
•Please read and fully understand the Safety
Precautions before use.
•Keep this User Manual with the thermometer
for easy reference.

Contents
Safety Precautions ................................................................................. 4
Warning .................................................................................................. 5
Symbols.................................................................................................. 6
Body Temperature Basics....................................................................... 7
Product Description ................................................................................ 8
Features ................................................................................................. 9
Structure............................................................................................... 10
Display and Operating Instructions .......................................................11
Measurement Process ......................................................................... 16
Replacing Batteries .............................................................................. 18
Cleaning and Disinfection..................................................................... 19
Maintenance......................................................................................... 19
Troubleshooting.................................................................................... 20
Specifications ....................................................................................... 21
Security Category................................................................................. 22
Storage and Transportation.................................................................. 22
List of Accessories................................................................................ 23
3

4
Safety Precautions
Read the following precautions carefully before using the thermometer.
Attention
• Take care of the temperature probe lens, which is fragile.
• Dispose of used batteries with care. To safeguard the environment,
you are recommended to send the used batteries to a designated
collection point.
• Remove the batteries if the thermometer will not be used for more
than two months.
• Do not immerse the thermometer in water or expose it to direct sunlight.
• Do not subject the thermometer to vibration or impact.
• Normal body temperature varies from person to person. Tracking an
individual’s temperature on a consistent basis will help determine
whether a fever is present.
• Do not take body temperature readings within 20 minutes after you do
physical exercises.
• Clean the thermometer after each use.
Follow these safety precautions carefully when using the
thermometer:
• Do not use the thermometer for continuous temperature monitoring
purposes.
• Do not put the thermometer, which is not waterproof, into water or other
liquid. Clean and disinfect the thermometer as described in “Cleaning
and Disinfection”.
• Do not touch the tip of the temperature probe, on which a precise
temperature sensor resides.
• The ambient temperature must not be extremely high or low. To ensure
accurate readings, keep the thermometer at room temperature for
more than 30 minutes before use.
• Do not use the thermometer at an ambient temperature higher than
40°C (104°F) or lower than 10°C (50°F), which is beyond the operating
temperature range of the thermometer.

5
Warning
Warning
• The thermometer is not intended to diagnose or treat any health
problem or disease. The measurement results are for reference only.
• It is dangerous to make a self-diagnosis or self-treatment based on
the obtained measurement results. For such purposes, please
consult a physician or other medical professionals.
Do not charge an alkaline dry-cell battery or throw it in fire. Otherwise,
the battery may explode.
Do not disassemble the thermometer or attempt to repair it.
Otherwise, the thermometer may be damaged permanently.
During measurement, do not use a mobile phone or any other device
that may cause electromagnetic interference.
Do not use the thermometer in an environment where flammable
anaesthetic mixture with air or with oxygen or nitrous oxide
is available.

6
Symbols
Symbol Description
Type BF applied part.
Attention must be paid.
The action is prohibited.
Information about a manufacturer, such as name
and address.
Waste electrical materials should be sent to a
dedicated collection point for recycling.
Warning A personal injury or thermometer damage may
occur if the thermometer is not correctly used.
Attention Inaccurate reading or thermometer damage may
occur if the thermometer is not correctly used.

Body Temperature Basics
Take the body temperature on the forehead. The temperature measured at
different parts of the body may differ slightly.
Body Part Normal Temperature Range*
Forehead 35.8°C–37.8°C/96.4°F–100°F
*The normal body temperature range slightly varies with age and gender.
Generally, newborns or children have higher body temperatures than
adults, and adults have higher body temperatures than the elderly.
Women’s body temperatures are approximately 0.3°C higher than men’s.
Consult your physician regarding body temperatures and acceptable
ranges.
7

8
Product Description
1) Overview
Non-contact Infrared Forehead Thermometer
measures human body or object temperature based on
the infrared energy emitted from the forehead or object
(such as milk and water). You can quickly get
measurement results after pointing the temperature
probe to the target.
2) Structure
The thermometer consists of a shell, an LCD, buttons,
a beeper, an infrared temperature sensor, and a
microprocessor.
3) Operating principle
The infrared temperature sensor collects infrared
energy emitted from the forehead. After being focused
by a lens, the energy is converted into a temperature
reading by the thermopiles and measurement circuit.
4) Application scope
The thermometer takes human body temperature for
clinical or household use. It applies to all age groups
and those who are suffering from a fever.
5) Prohibited use
None

9
Features
01 Good safety
● Passive infrared receiving technology, without radiation
● Non-contact measurement, preventing cross-infection
02 Easy operation
● Handheld design, facilitating ergonomic operation
● One-click automatic temperature measurement
03 Quick response
1-second measurement.
04 High accuracy
● Advanced infrared temperature sensor, with high sensitivity
● Enhanced accuracy with automatic temperature calibration
05 Diverse functions
● 20 temperature readings stored in memory
● Forehead/Object temperature measurement
● Automatic recording of the highest temperature during a scan
● Fever alert, with the alert threshold configurable
● Switching between ºC and ºF
● Tunable temperature compensation
● Switching between the mute/un-mute mode
(measure sound notification)
● Automatic power-off saves power
06 Extensive application scope
Applicable to all groups of people

10
Structure
Infrared temperature probe
Measure button
Battery cover
LCD
Mute/Un-mute button
Mode button
˚C/˚F button

11
Screen Display Operating Instructions
/Displayed State
Description
Display and Operating Instructions
In power-off mode, press the
Measure button to power on
the thermometer. The
temperature reading is
displayed. For effective
measurement, the distance
between the thermometer and
the target must be 1-5 cm. If
you hold the Measure button,
continuous measurements are
taken and the highest
temperature is recorded.
In object mode, temperature
reading > 100ºC (212.0ºF)
The thermometer
sounds two short
beeps.
Forehead mode:
a. The default fever
alert threshold is
37.6ºC.
b. T indicates a
temperature reading.
1. If 34.9ºC ≤ T <
37.6ºC, the
thermometer sounds a
long beep, and the
white background light
is on for 3 seconds.
2. If 37.6ºC ≤ T ≤
42.2ºC, the
thermometer sounds
three quick short
beeps, white
background light is on
for 3 seconds, and the
screen flashes.
Object mode:
If 0.0ºC ≤ T < 100.0ºC,
the thermometer
sounds a long beep,
and the white
background light is on
for 3 seconds.

12
Screen Display Operating Instructions
/Displayed State
Description
Display and Operating Instructions (continued)
In forehead mode, temperature
reading > 42.2ºC (109.9ºF)
The thermometer
sounds two short beeps.
In object mode, temperature
reading < 0ºC (32.0ºF)
In forehead mode, temperature
reading < 34.9ºC (94.8ºF)
The thermometer
sounds two short beeps.
The thermometer
sounds two short beeps.
When the ambient temperature
is higher than 40.0ºC (104.0ºF)
or lower than 10.0ºC (50.0ºF),
“Er1” is displayed.
The low-battery symbol
(no flashing) displayed if the
power voltage is lower than
2.5 V± 0.1V.
When is displayed in the
lower right corner of the
screen, the battery level is low,
but the thermometer can still be
used.
The thermometer
sounds two short beeps.

13
Screen Display Operating Instructions
/Displayed State
Description
Display and Operating Instructions (continued)
Hold the ºC/ºF button for a
short while to switch between
ºC and ºF.
Switching between ºC and ºF
Switching between forehead and object
Hold the Mode button for a
short while to switch between
forehead ( ) and object
( ).

14
Screen Display Operating Instructions
/Displayed State
Description
Display and Operating Instructions (continued)
Switching between mute and un-mute
Querying 20 readings
Hold the Mode button for more
than 2 seconds. “F-1” is
displayed.
Press the Measure
button to return to the
measurement
interface.
The symbol is
displayed in mute
mode and disappears
in un-mute mode.
Hold the Mute/Un-mute
button for a short while to
switch between mute and
un-mute.
Press the ºC/ºF or button.
The first reading is displayed.
The sequential number of the
stored reading increments
every time the ºC/ºF button is
pressed, and decrements every
time the Mute/Un-mute
button is pressed. The reading
is displayed 1 second later.
A maximum of 20 temperature
readings can be recalled.

15
Screen Display Operating Instructions
/Displayed State
Description
Display and Operating Instructions (continued)
Querying 20 readings (continued)
Temperature compensation settings
Fever alert threshold settings
If no temperature reading has
been taken, “- - - M” is
displayed.
When “F-1” is displayed, press
the Mode button. Then “F-2” is
displayed.
When “F-2” is displayed, press
the Mode button. Then “F-3” is
displayed.
Press the Measure
button to return to the
measurement
interface.
Press the Measure or
Mode button to return
to the measurement
interface.
Press the ºC/ºF or button.
The compensation value is
displayed. The value increases
by 0.1ºC/ºF every time the
ºC/ºF button is pressed, and
decreases by 0.1ºC/ºF every
time the button is pressed.
The tunable range is ±2ºC/ºF.

01. Precautions
1) The thermometer is suitable for an indoor environment without
strong air convection (for example, winds from a fan, an
air-conditioner, or a heater) between the thermometer and
the target.
2) Do not hold the thermometer for a long time, because it is
sensitive to the ambient temperature.
02. Select the measurement mode.
1) Press the Measure button to power on the thermometer. Select
the measurement mode using the Mode button.
2) The symbol indicates the forehead mode. The symbol
indicates the object mode.
03. Press the Measure button to start a measurement.
1) When taking forehead temperature, point the temperature probe
to the forehead with a distance of 1-5 cm in between, and press
the Measure button. After the beeper sounds once, a reading
is displayed.
16
Screen Display Operating Instructions
/Displayed State
Description
Display and Operating Instructions (continued)
Fever alert threshold settings (continued)
The default fever alert
threshold is 37.6ºC.
Press the ºC/ºF or button.
The fever alert threshold is
displayed. The threshold value
increments by 0.1ºC/ºF every
time the ºC/ºF button is
pressed, and decrements by
0.1ºC/ºF every time the
button is pressed. The tunable
range is 35.0ºC–42.0ºC
(95.0ºF–107.6ºF).
Measurement Process

2) When taking object temperature, point temperature probe to the
object with a distance of 1-5 cm in between, and press the
Measure button.
04. Continuous measurement
1) Hold the Measure button. Move the temperature probe while
keeping the distance between the thermometer and the target
unchanged. The thermometer beeps several times. In this way, the
temperature of different positions of the target can be measured.
2) Release the Measure button. The highest reading during this
measurement period is displayed.
05. After a measurement
1) Repeat the preceding steps to take a new measurement.
2) After each measurement, you can enter the recall mode and query
earlier temperature readings by holding the Mode button. For
details, see “Querying 20 readings” in the preceding table.
3) After each measurement, clean the thermometer with a dry soft
cloth, and put the thermometer in a dry and well-ventilated place.
4) The thermometer automatically powers off if it is not used within
30 seconds.
17

1) Slide the battery cover off along the marked direction. Put two
AAA batteries correctly into the compartment (batteries included).
2) If the low-battery symbol is displayed on the screen, replace
the batteries.
Ensure that the batteries are installed correctly. Otherwise,
the thermometer may be damaged.
Batteries of a same type should be used. Dispose used batteries
in accordance with local environmental policies.
The thermometer is shipped with batteries installed. Remove the
insulation sheet before use.
18
Replacing Batteries

Cleaning
1) Clean the temperature probe with a soft cloth. Clean the lens of
the temperature probe with a cotton swab.
2) Wipe the thermometer body with a slightly damp soft cloth, and
gently dry the body with a piece of tissue paper.
Keep water off the lens during the cleaning process. Otherwise,
the lens may be damaged.
The lens may be scratched if it is cleaned with a piece of tissue
paper, resulting in inaccurate readings.
Do not clean the thermometer with corrosive cleansers. During the
cleaning process, do not touch the lens using hard objects,
immerse any part of the thermometer into liquid, or allow liquid to
enter the thermometer.
Disinfection
1) Disinfect the thermometer body and the area around the
temperature probe with a cloth slightly moistened with 75%
medical alcohol.
Do not use hot steam or ultraviolet radiation for disinfection.
Otherwise, the thermometer may be damaged or quickly aged.
Maintenance
1) After each use, clean the temperature probe as described in
“Cleaning and Disinfection”.
2) Store the thermometer in a dry, dust-free, and well-ventilated
place. Ensure that the thermometer is not exposed to sunlight.
Ensure that the storage and transportation environments meet
the requirements
3) Check whether safety risks exist on a regular basis.
4) Remove the batteries if the thermometer will not be used for
more than two months.
19
Cleaning and Disinfection

The battery level is
extremely low.
Use new batteries of
the same model or
specifications.
Polarities of the batteries
are reversed.
The thermometer is faulty.
Ensure that the batteries
are correctly installed
according to the polarity
symbols in the battery
compartment.
If the warranty period
does not expire,
contact Dynarex or a
local distributor.
The thermometer
fails to power on.
The battery level is low. Use new batteries of
the same model or
specifications.
Only the battery symbol
is displayed after the
thermometer powers on.
The ambient temperature is
lower than 10°C (50.0°F) or
higher than 40°C (104°F).
Take a measurement
under an ambient
temperature between
10°C (50.0°F) and
40°C (104°F).
"Er1" is displayed.
An error occurs when data
is being read from or written
into the memory, or the
temperature correction is
not complete.
Contact Dynarex."Er4" is displayed.
The lens of the temperature
probe is dirty.
Clean the lens using a
cotton swab.
The distance between the
temperature probe and the
target is too long.
Move the thermometer
closer to the target.
The thermometer is not
used within 30 minutes after
being taken from a cold
environment.
Wait for more than 30
minutes after the
thermometer is moved
into the measurement
environment.
The temperature reading
is lower than the typical
body temperature range.
20
Troubleshooting
Symptom Possible Cause Solution
