Dyon SMART 42 AD User manual

EN
DYON SMART 42 AD
V1.2.0
Content
1Important Safety Instructions ................................................................3
2Support Information..............................................................................8
3Appropriate use....................................................................................9
4Notes on energy efficiency..................................................................10
5Conformity..........................................................................................12
6Montage.............................................................................................13
6.1 Stand mounting.........................................................................................13
6.2 Wall mounting...........................................................................................14
7Controls and connections ...................................................................15
7.1 The Device................................................................................................15
7.2 Connections..............................................................................................16
7.3 CI/CI+ Slot ................................................................................................ 17
7.4 Remote Key Function............................................................................... 19
7.5 Antenna Connection.................................................................................21
8Initial setup.........................................................................................24
8.1 Basic Settings...........................................................................................24
8.2 Add remote control ...................................................................................25
8.3 Setup via Android Smartphone ................................................................25
8.4 Internet Setup ...........................................................................................26
8.5 Country Setup...........................................................................................28
8.6 Select TV mode ........................................................................................29
8.7 Chromecast...............................................................................................29
8.8 Tuner mode ..............................................................................................29
8.9 Satellite Search.........................................................................................30
8.10 Antenna settings.......................................................................................31
8.11 Cable TV setup.........................................................................................32
9Menu-Settings....................................................................................37
9.1 Menu favorites ..........................................................................................37
9.2 Menu Source ............................................................................................38
9.3 Menu Picture.............................................................................................38
9.4 Menu Display Mode..................................................................................40
9.5 Menu Speaker ..........................................................................................41
9.6 Menu Power..............................................................................................41
9.7 Menu CI-Card ...........................................................................................42
9.8 Menu Advanced Options ..........................................................................43
9.9 Menu Settings...........................................................................................43
10 Menu Sound.......................................................................................44
11 EPG (Electronic Program Guide)........................................................46
12 Troubleshooting..................................................................................47
12.1 No sound /No Picture................................................................................47
12.2 Error Notes................................................................................................48
13 CI+ Information...................................................................................50
14 TELETEXT.........................................................................................52
15 Selecting the Source...........................................................................53

EN
DYON SMART 42 AD
2
16 Connecting USB Devices....................................................................54
17 Specifications.....................................................................................55
18 Glossar...............................................................................................58
19 Warranty Condition.............................................................................59

EN
DYON SMART 42 AD
3
1 Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings, install in accordance
with the instructions.
8) Do not install near any heat sources such as radiations,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized plug. If
the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10) Protected the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Unplug this apparatus during lighting storms or when
unused for long periods of time.

EN
DYON SMART 42 AD
4
13) Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
14) Mains plug is used as the disconnect device, the
disconnect device shall remain readily operable.
15) The ventilation should not be impeded by covering the
ventilation openings with items, such as newspapers, table-
cloth, curtains, etc.
16) No naked flame sources, such as lighted candles, should
be placed on the apparatus.
17) Attention should be drawn to the environmental aspects of
battery disposal.
18) The use of apparatus in moderate climate.
WARNING
To reduce the risk of fire or electric shock, do not expose
this apparatus to rain or moisture.
The batteries shall not be exposed to excessive heat
such as sunshine, fire or the like.

EN
DYON SMART 42 AD
5
The symbol indicates that dangerous voltages
constituting a risk of electric shock are present within
this unit.
The symbol indicates that there are important
operating and maintenance instructions in the literature
accompanying this unit.
Warning
High voltages are used in the operation of this
television receiver. Do not remove the cabinet
back from your set. Refer servicing to qualified
service personnel.
To prevent fire or electrical shock hazard, do not
expose the television receiver to rain or moisture.
Do not drop or push objects into the television
cabinet slots or openings. Never spill any kind of
liquid on the television receiver.
Do not block the ventilation holes in the back
cover. Adequate ventilation is essential to prevent
failure of electrical components.

EN
DYON SMART 42 AD
6
Caution
Do not trap the power supply cord under the
television.
Never stand on, lean on, or suddenly push the
television or its stand. You should pay special
attention to children. Serious injury may result if it
should fall.
Do not place your television on an unstable cart,
stand, shelf or table. Serious injury to an individual
and damage to the television, may result if it
should fall.
When the television is not used for an extended
period of time, it is advisable to disconnect the AC
power cord from the AC outlet.
If the television is to be built into a compartment or
similar enclosure, the minimum distances must be
maintained. Heat build-up can reduce the service
life of your television, and can also be dangerous.

EN
DYON SMART 42 AD
7
Tips regarding environmental protection
At the end of its operating life, this product may not be
disposed of by way of your normal household waste.
Instead it must be delivered to a collection point for
recycling electrical and electronic equipment. The icon
on the product, in the operating instructions or on the
packaging, indicates this.
The materials used in manufacturing this product are
recyclable, depending on their identifying markings. By
recycling this equipment, by recycling its components,
or through other procedures of re-using outdated
equipment, you are making an important contribution to
protection our environment. Please ask you local
municipal administration for the location of the
corresponding recycling point.
Battery Recycling
In order to ensure the environmentally friendly disposal
of batteries, please do NOT dispose of used
batteries through normal household waste. Please take
the batteries to your local retail or community collection
point for recycling.
The following may be an indication of a discharged
battery: The device cannot be switched on. The
device switches off automatically and "Battery Empty"
is shown in the display. The device and or battery do
not function properly.

EN
DYON SMART 42 AD
8
2 Support Information
See our website for the latest information on this device,
on other products by our company and on our company itself.
If you have questions or problems, please read the FAQs on
our website or contact our customer support service.
Service Adress
Support-Hotline
AXDIA International GmbH
Service Center
Schmelzerstraße 27
47877 Willich
+49 (0)2154 / 8826-101
Web: www.dyonhilfe.de
E-Mail: [e-mail]

EN
DYON SMART 42 AD
9
3 Appropriate use
The device is designed for receiving and watching encrypted
and unencrypted DVB-T2, DVB-S2 and DVB-C TV channels
(free-to-air) for private use. It is exclusively meant for this
purpose and must only be used for the same. This also
includes paying attention to all information contained in this
operating manual, especially in the safety instructions. Any
other usage is considered to be improper and may lead to
material damages and even personal injuries. Moreover, it will
result in the immediate loss of guarantee. The manufacturer
does not bear any liability for damages caused due to improper
use.
Enjoy more high definition channels with DYON TV!

EN
DYON SMART 42 AD
10
4 Notes on energy efficiency
The device has facilities for reducing the energy requirement.
Make the appropriate settings as required.
Tune mode
During initial installation and via the menu:
Menu key –Settings - Device Preferences –Retail Mode
Home Mode
Adapted illuminance for home use.
Retail Mode
Adapted illuminance for bright
environments (e.g. salesrooms)
Important
Please note, the power consumption is
increased, by using the exhibition
mode.
Standby
Menu settings:
Device Preferences –Power –Switch Off Timer
Automatic standby
mode
After a predefined time, the device
switches to standby mode.
Automatic networked
standby mode
After a predefined time, the device
switches to networked standby
mode when the connection is active.

EN
DYON SMART 42 AD
11
Important!
The device switches to standby mode independently after
4 hours without operations. Please note, this is NOT a
defect. It is a legal requirement.
A note occurs shortly before the device turn in the off-
mode. Press any key to avoid the off-mode. Switch the
device off and on again via the power-button to reactivate
it.
This function can be deactivated in the system settings
by setting it to “off”.
(Device Preferences –Power –Switch Off Timer)
Attention
The deactivation of the automatic stand-by or extending
the preset switch off time, will lead to a higher power
consumption.
Note
The available modes are named as follows if available
Automatic Standby mode
Standby
Automatic networked
standby mode
Network Standby

EN
DYON SMART 42 AD
12
5 Conformity
We, Axdia International GmbH, hereby declare
that this device corresponds to the basic
requirements and relevant regulations outlined in
guidelines 2014/53/EU, 2014/30/EU, 2014/35/EU
and 2009/125/EC.
The CE declaration of conformity for this product may be found
on the following link:
https://www.dyonhilfe.de/konform

EN
DYON SMART 42 AD
13
6 Montage
6.1 Stand mounting
Fix the feet in the device as described in the picture and fix
them with the enclosed mounting screws

EN
DYON SMART 42 AD
14
6.2 Wall mounting
Fasten your wall bracket to the threads on the back and
observe the hole spacing.

EN
DYON SMART 42 AD
15
7 Controls and connections
7.1 The Device
Remote Sensor and Status indicator
In Standby Mode, the status indicator lights up red.
Turn the TV on or off

EN
DYON SMART 42 AD
16
7.2 Connections
Connections from left to right and bottom up:
1. ETHERNET (LAN)
2. Optical Audio Out
3. USB-Port (2.0)
4. HDMI 3
5. HDMI 2
6. AV-IN
7. LNB IN (Satellite)
8. RF (C/-T2) Antenna
connection
9. USB-Port (2.0)
10. HDMI 1 (ARC)
11. CI-Module
12. Headphone jack
6
7
8
9
10
11
12
9
10
11
1
2
3
4
5
6
7
8

EN
DYON SMART 42 AD
17
7.3 CI/CI+ Slot
Note according the CI Slot
Please take care to insert the CI-Module (CAM) in the
correct way. The Top side of the module must face
against the wall behind.
This device is equipped with a CI+ slot for use with CAM
modules and Smart cards which allow for the viewing of
encrypted Pay-TV channels. The corresponding modules may
be purchased from the Pay-TV provider or specialized dealer.
Installation
1. Disconnect the TV set from power.
2. Before inserting the module into the device, insure that the
Smart card has been properly installed into the module ().
Pay close attention to the direction when inserting.
The printing on the module and the chip of the Smart card
must be on top.
3. Insert the Module with inserted Smart card with the printing
of the module facing backwards (). Insert the module
carefully into the slot of the device until a little resistance is
felt. Using a little pressure, carefully press the module into
the slot until it sits firmly.
4. Reconnect the power source.
Remove the module
1. Disconnect the TV set from power.
2. Take the module out carefully.

EN
DYON SMART 42 AD
18
Please note
Module and Smart card are not including.
Install the CI+ module after the channel scan has been
accomplished and all other settings have been set.
The activation of the card may take several minutes for
the first time it is used. When necessary, the device will
check the module every time the device is switched on.
Pay close attention to the manual of the CI+ module and
Smart card. Depending on the provider, the Smart card
may be omitted.
Notice to CI+
Please note some function may be limited on some
channels. These limitations are determined by the
broadcaster. The manufacturer takes no responsibility.



EN
DYON SMART 42 AD
19
7.4 Remote Key Function
1. POWER: To switch the set device to on or standby.
2. INPUT: Select input source.
3. NETFLIX: Open Netflix App.
4. YOUTUBE: Open YouTube App.
5. SUBTITLES: Used to switch among different
subtitles that are broadcasted in TV mode.
6. MUTE: To disable or enable the sound output.
7. :Stop playback
8. :Fast rewind
9. :Fast forward
10. :Play / Pause
11. TEXT: To open teletext, if teletext is available in the
broadcasted stream.
12. ASPECT: To switch the aspect ratio.
13. EPG: To display information about the program
being viewed and what’s on next. (Not for ATV)
14. ARROWKEYS: Move within the menus.
15. OK: Used to confirm a selection within a menu.
16. BACK:
In menu: Used to return to the previous screen or
menu.
17. HOME: With this Button you will Return to the
Homescreen.
18. MENU: Open the menu of the current App.
19. Google Asisstant Button: activates Microphone on
Remote for you to use with Google Asisstant
20. VOL+/-: Adjust the volume level.
21. CH+/-: Channel selection.
22. NUMBER KEYS: used to select channel numbers or
input numbers in menus.
23. INFO: Shows Information for current Channel
24. RECALL: To show the last viewed channel
25. RED COLOR KEY: In Menu: Menu function as
displayed.
In TV Teletext Mode: To open further teletext
pages directly, as shown at the bottom. If the
page is not available, the color display on the
screen flashes briefly.
26. BLUE COLOR KEY: Refer to RED Color Key
27. GREEN COLOR KEY: Refer to RED Color Key
28. YELLOW COLOR KEY: Refer to RED Color Key
1
2
3
4
5
7
8
6
9
10
13
14
16
17
18
19
20
21
22
23
15
12
11
24
25
26
27
28

EN
DYON SMART 42 AD
20
Insert Batteries into the Remote Control
1. Take a coin to remove the battery cover. Insert
the coin into the latch and press down the coin
with a little pressure, until the battery cover
released from the latch. Remove the battery
cover. Inserting the two AAA 1.5V batteries,
make sure that the polarity (+ or -) of the
batteries matches with the polarity inside the
unit.
2. Replace the battery cover by first inserting the
battery cover at the upper end and then pressing it
at the bottom.
Replace the batteries when the TV set begins to
show the following symtomps:
•The signal is hesistant or irregular.
•The remote control does not work
Note
•Alkaline Batteries are recommended.
•Remove the batteries when they are
exhausted or if the remote control is not be
used for a long time.


