Dyson DC33 User manual

3
2
4
1
OPERATING MANUAL
REGISTER
YOUR FREE
5 YEAR
GUARANTEE
TODAY
WASH FILTERS
Wash filters with cold water
at least every 3 months.
ASSEMBLY
A
B
click
click
ON/OFF
A
B
For carpets
For hard floors

Note your serial number for future reference
After registering for your 5 year guarantee, your Dyson
vacuum cleaner will be covered for parts and labour for
5 years from the date of purchase, subject to the terms of
the guarantee.
If you have a query about your Dyson vacuum cleaner,
call the Dyson Customer Care Helpline with your serial
number and details of where/when you bought the
vacuum cleaner. Your serial number can be found on
your rating plate which is behind the clear bin.
Most queries can be solved over the phone by one of our
trained Dyson Customer Care Helpline staff.
Alternatively visit www.dyson.co.uk/support for online
help, general tips and useful information about Dyson.
IMPORTANT SAFETY PRECAUTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
When using an electrical appliance, basic precautions should always be followed, including the following:
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY:
1. Do not leave the Dyson vacuum cleaner when plugged in. Unplug from socket when not in use and before
servicing.
2. Do not use outdoors or on wet surfaces. Suitable for dry locations only. Do not use to pick up water.
3. Do not allow to be used as a toy. Close attention is necessary when used by or near children. Children should be
supervised to ensure that they do not play with the Dyson vacuum cleaner.
4. This Dyson vacuum cleaner is not intended for use by young children or infirm persons with reduced physical,
sensory or reasoning capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction by a responsible person concerning use of the Dyson vacuum cleaner to ensure that they can use the
Dyson vacuum cleaner safely.
5. Use only as described in this manual. Use only Dyson recommended accessories and replacement parts. Do not
carry out any maintenance other than that shown in this manual, or advised by the Dyson Customer Care Helpline.
Contact the Dyson Customer Care Helpline when service or repair is required. Do not disassemble the Dyson
vacuum cleaner as incorrect reassembly may result in an electric shock or fire.
6. Do not use with a damaged cable or plug. If the Dyson vacuum cleaner is not working as it should, has been
dropped, damaged, left outdoors, or dropped into water, do not use and contact the Dyson Customer Care
Helpline. If the supply cable is damaged it must be replaced by Dyson, its service agent or similarly qualified person
in order to avoid a hazard.
7. Do not pull or carry by cable, use cable as a handle, close a door on cable, or pull cable around sharp edges or
corners. Do not run the Dyson vacuum cleaner over cable. Keep cable away from heated surfaces. To avoid a
tripping hazard wind the cable when not in use.
8. Do not unplug by pulling on the cable. To unplug, grasp the plug, not the cable.
9. Do not handle the plug or Dyson vacuum cleaner with wet hands.
10. Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything
that may reduce airflow.
11. Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts, such as the brush
bar. Do not point the hose, wand or tools at your eyes or ears or put them in your mouth.
12. Turn off all controls before unplugging.
13. Use extra care when cleaning on stairs. Do not work with the Dyson vacuum cleaner above you on the stairs.
14. Do not use to pick up flammable or combustible liquids, such as petrol, or use in areas where they or their vapours
may be present.
15. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
16. Do not use without the clear bin and filters in place.
17. The use of an extension cable is not recommended.
READ AND SAVE THESE INSTRUCTIONS
THIS DYSON VACUUM CLEANER IS INTENDED FOR HOUSEHOLD USE ONLY
REGISTER
BY MAIL
Complete and return
the form to Dyson in the
envelope supplied.
REGISTER
BY PHONE
Call our dedicated Helpline.
Open 7am–10pm.
7 days a week.
REGISTER
ONLINE
Visit our website to register
your full parts and labour
guarantee online.
www.dyson.com/register
UK 0800 298 0298
ROI 01 475 7109
3 EASY WAYS TO REGISTER FOR YOUR FREE 5 YEAR GUARANTEE
Do not pull on
the cable.
Do not store near
heat sources.
Do not use near
naked flame.
Do not run over
the cable.
Do not pick up
water or liquids.
Do not pick up
burning objects.
Do not use above
you on the stairs.
Do not put hands
near the brush bar
when the vacuum
cleaner is in use.
23
This illustration is for example purposes only.

click
click
3
2
1
4
click
click
ON/OFF
2 31
click
1
2
For carpets
For hard floors
45
Using your Dyson vacuum cleaner Looking for blockages
High-reach cleaning
Hard floors/carpets Turbine maintenance*
*Selected models only.
Emptying the clear bin
Clearing brush bar obstructions
Carrying your Dyson
vacuum cleaner

IMPORTANT!
WASH FILTERS
Wash filters with cold water at least every 3 months.
Filter
Filter
click
Rinse and shake filters under tap. Turn over and tap very
firmly to remove motor emissions. Repeat 10x until water
runs clear.
67

89
ASSEMBLY
• Stand the vacuum cleaner up straight and slide the hose into guides at the back
of the vacuum cleaner and click into place.
• Ensure the hose is straight and slide the wand straight down into the hose until it
clicks into place.
• Click the wand handle into the top of the vacuum cleaner. Press the red button
on the rear of the wand handle and slide the tube down. Close the wand cap.
• Attach the tools to the vacuum cleaner and wind the cable anti-clockwise around
cable hooks and secure with clip.
USING YOUR DYSON VACUUM CLEANER
Unwind the cable and insert the plug into a suitable socket. Hold the cleaner
head down with your foot and pull the handle downwards. To switch ‘ON’ or
‘OFF’ press the power button in front of the handle.
CAUTION:
• Do not allow the vacuum cleaner to be used by anyone who may not be able to
operate it safely.
• The use of an extension cable is not recommended.
• Always switch ‘OFF’ and unplug before performing maintenance on your
vacuum cleaner.
• When returning to the upright position, ensure that the wand and clear bin
assembly are fully upright before releasing the vacuum cleaner.
• Ensure the cyclone is secured to the vacuum cleaner. Do not press the cyclone
release button or shake the vacuum cleaner while carrying or it could fall and
cause injury.
• Store the vacuum cleaner indoors. Put the vacuum cleaner away after use with
the cable coiled safely, to prevent tripping hazards.
• Do not use outdoors or on wet surfaces or to vacuum water or other liquids –
electric shock could occur.
• Do not lubricate any parts, or carry out any maintenance or repair work
other than that shown in this manual, or advised by the Dyson Custome Care
Helpline.
PLEASE NOTE:
• This vacuum cleaner is intended for domestic use only. Fine dust such as plaster
dust or flour should only be vacuumed in very small amounts.
• Do not use the vacuum cleaner to pick up sharp hard objects, small toys, pins,
paper clips, etc. They may damage the vacuum cleaner.
• If used in a garage, care should be taken to wipe the soleplate and wheels with
a dry cloth after vacuuming to clean off any sand, dirt, or pebbles that could
damage delicate floors.
• Consult your flooring manufacturer’s recommended instructions before
vacuuming and caring for your flooring, rugs, and carpet. Some carpets will fuzz
if a rotating brush bar is used when vacuuming. If this happens, we recommend
vacuuming in hard floors mode and consulting with your flooring manufacturer.
• When vacuuming, certain carpets may generate small static charges in the clear
bin. These are entirely harmless and are not associated with the mains supply.
To minimise any effect from this, do not put your hand or insert any object into
the clear bin unless you have first emptied it and rinsed it out with cold water.
(See ‘Cleaning the clear bin’ section.)
• Do not use or store this vacuum cleaner below 0°C (32°F). Ensure that the
vacuum cleaner is at room temperature before operating.
HARD FLOORS/CARPETS
Ensure the machine is in an upright position before adjusting the setting. The
brush bar will automatically stop if it becomes obstructed. If the brush bar stops
during use, please refer to the ‘Clearing brush bar obstructions’ section.
HIGH-REACH CLEANING
CAUTION:
• Switch ‘OFF’ the vacuum cleaner before changing tools.
• Powerful suction can cause the hose to ‘pull back’ - please take care.
• Take extra care when vacuuming on stairs; do not work with the vacuum cleaner
above you on the stairs. Do not put the vacuum cleaner on chairs, tables etc.
• Ensure vacuum cleaner is in upright position before using tools.
PLEASE NOTE:
• To release the wand, open the wand cap and pull the red tube from inside
the handle until it clicks. Press button to release the wand and hose from the
machine. Tools can be attached to either the hose or wand.
• The brush bar will not rotate when the vacuum cleaner is in an upright position.
• Ensure wand cap is closed when not in use.
EMPTYING THE CLEAR BIN
CAUTION:
• Switch ‘OFF’ the vacuum cleaner and unplug before emptying the clear bin.
• Empty as soon as the dirt reaches the level of the MAX mark – do not overfill.
• To remove the clear bin from the vacuum cleaner, press the button at the rear
of cyclone carrying handle. To release the dirt, press the red bin release button.
Emptying into a bag is recommended for allergy sufferers.
• Do not use the vacuum cleaner without the clear bin in place.
• To minimise dust/allergen contact when emptying, encase the clear bin tightly
in a plastic bag and empty. Remove the clear bin carefully and seal bag tightly,
dispose as normal. For a free fact sheet visit
www.dyson.co.uk/technology/allergy
CLEANING THE CLEAR BIN
CAUTION:
To remove the cyclone unit from the clear bin press the red bin release button.
This exposes a small silver button behind the red opening mechanism. Press the
silver button and separate the cyclone unit from the clear bin.
• Clean the clear bin with cold water only.
• Ensure the clear bin is completely dry before replacing.
PLEASE NOTE:
• Do not use detergents, polishes or air fresheners to clean the clear bin.
• Do not put clear bin in a dishwasher.
• Clean the shroud with a cloth or dry brush to remove lint and dust.
WASHING YOUR FILTERS
DO THIS EVERY 3 MONTHS
CAUTION:
• Switch ‘OFF’ and unplug the vacuum cleaner before removing the filters.
• Ensure filters are completely dry before refitting to the vacuum cleaner.
PLEASE NOTE:
This machine has two filters, located as shown. It is important to check your
filters regularly and wash at least every 3 months according to instructions, to
maintain performance. FilterB should be rinsed and tapped out until the water
runs clean, then tapped out again to ensure all excess water is removed. This
will normally require up to 10 rinse cycles.
• After washing please leave for 24 hours to dry completely.
• The filters may require more frequent washing if vacuuming fine dust.
• Do not use detergents to clean the filters.
• Do not put the filters in a dishwasher, washing machine, tumble dryer, oven,
microwave or near a naked flame.
LOOKING FOR BLOCKAGES
CAUTION:
• Switch ‘OFF’ and unplug the vacuum cleaner before checking for blockages.
Failure to do so could result in personal injury.
• Please ensure the vacuum cleaner is upright and switched off before removing
hose or airway inspection parts.
• Beware of sharp objects when clearing blockages.
• Refit all parts of the vacuum cleaner securely before using.
PLEASE NOTE:
• Clearing blockages is not covered by your vacuum cleaner’s limited guarantee.
• This vacuum cleaner is fitted with an automatically resetting thermal cut-out.
If any part of the vacuum cleaner becomes blocked, it may overheat and
automatically cut-out. Switch ‘OFF’ and unplug the vacuum cleaner and leave to
cool down for 1-2 hours before checking filters or for blockages.
CLEARING BRUSH BAR OBSTRUCTIONS
CAUTION:
• Switch ‘OFF’ and unplug the vacuum cleaner before clearing brush bar
obstructions. Failure to do so could result in personal injury.
• Beware of sharp objects when clearing obstructions.
• Refit all parts of the vacuum cleaner securely before using.
PLEASE NOTE:
• Clearing brush bar obstructions is not covered by your vacuum cleaner’s limited
guarantee.
BRUSH BAR TROUBLESHOOTING
If the brush bar has stopped spinning, follow the steps below. Alternatively
contact a Dyson expert on UK 0800 298 0298 or ROI 01 475 7109 or visit
www.dyson.co.uk/support
CAUTION:
• Ensure machine is in reclined position.
• Ensure clutch is turned on (See page 3).
• Check the cleaner head for blockages (i.e. tangled hair, large debris).
• If the brush bar still isn’t spinning, contact a Dyson expert on
UK 0800 298 0298 or ROI 01 475 7109.
DISPOSAL INFORMATION
Dyson products are made from high grade recyclable materials. Please dispose
of this product responsibly and recycle where possible.
DYSON CUSTOMER CARE
THANK YOU FOR CHOOSING TO BUY A DYSON VACUUM CLEANER
If you have a query about your Dyson vacuum cleaner, most times these can be
solved over the phone by one of our Dyson Customer Care Helpline staff, or by
visiting www.dyson.co.uk/support.
Have your serial number and details of where and when you bought the vacuum
cleaner to hand. The serial number can be found on the main body of the
vacuum cleaner behind the clear bin.
If your vacuum cleaner needs a service, call the Dyson Customer Care Helpline
so we can discuss the available options. If your vacuum cleaner is under
guarantee, and the repair is covered, it will be repaired at no cost.
PLEASE REGISTER AS A DYSON VACUUM OWNER
To help us ensure you receive prompt and efficient service, please register as a
Dyson vacuum cleaner owner. There are three ways to do this:
• Online at www.dyson.com/register
• By calling the Dyson Customer Care Helpline on UK 0800 298 0298 or
ROI 01 475 7109.
• By completing and returning the enclosed form to us by mail.
This will confirm ownership of your Dyson vacuum cleaner in the event of an
insurance loss, and enable us to contact you if necessary.
LIMITED 5 YEAR GUARANTEE
TERMS AND CONDITIONS OF THE DYSON 5 YEAR LIMITED
GUARANTEE.
WHAT IS COVERED
• The repair or replacement of your vacuum cleaner (at Dyson’s discretion) if your
vacuum cleaner is found to be defective due to faulty materials, workmanship or
function within 5 years of purchase or delivery (if any part is no longer available
or out of manufacture Dyson will replace it with a functional replacement part).
• Use of the vacuum cleaner in the UK and Republic of Ireland.
WHAT IS NOT COVERED
Dyson does not guarantee the repair or replacement of a product as a result of:
• Normal wear and tear (e.g. fuse, belt, brush bar, batteries etc).
• Accidental damage, faults caused by negligent use or care, misuse, neglect,
careless operation or handling of the vacuum cleaner which is not in accordance
with the Dyson Operating Manual.
• Blockages – please refer to the Dyson Operating Manual for details of how to
unblock your vacuum cleaner.
• Use of the vacuum cleaner for anything other than normal domestic household
purposes.
• Use of parts not assembled or installed in accordance with the instructions of
Dyson.
• Use of parts and accessories which are not Dyson Genuine Components.
• Faulty installation (except where installed by Dyson).
• Repairs or alterations carried out by parties other than Dyson or its authorised
agents.
If you are in any doubt as to what is covered by your guarantee, please call the
Dyson Customer Care Helpline on UK 0800 298 0298 or ROI 01 475 7109 or
visit www.dyson.co.uk/support
SUMMARY OF COVER
• The guarantee becomes effective at the date of purchase (or the date of delivery
if this is later).
• You must provide proof of delivery/purchase before any work can be carried
out on your vacuum cleaner. Without this proof, any work carried out will be
chargeable. Please keep your receipt or delivery note.
• All work will be carried out by Dyson or its authorised agents.
• Any parts which are replaced will become the property of Dyson.
• The repair or replacement of your vacuum cleaner under guarantee will not
extend the period of guarantee.
• The guarantee provides benefits which are additional to and do not affect your
statutory rights as a consumer.
ABOUT YOUR PRIVACY
If your personal details change, if you change your mind about any of your
marketing preferences or if you have any queries about how we use your
information, please let us know by contacting Dyson Limited, Tetbury Hill,
Malmesbury, Wiltshire, SN16 0RP England, or by calling the Dyson Customer
Care Helpline on UK 0800 298 0298 or ROI 01 475 7109. Or you can email us
at [e-mail]
For more information on how we protect your privacy, please see our privacy
policy on www.dyson.co.uk
PRODUCT INFORMATION
Net weight: 7.80kg.
Please note: Small details may vary from those shown.

www.dyson.com
Dyson Customer Care
If you have a query about your Dyson vacuum cleaner, call the
Dyson Customer Care Helpline with your serial number and
details of where and when you bought the vacuum cleaner, or visit
www.dyson.co.uk/support. The serial number can be found on the
main body of the vacuum cleaner behind the clear bin.
JN.34000 PN.20146-03-01 11.05.10
UK Dyson Customer Care
[e-mail]
0800 298 0298
Dyson Ltd, Tetbury Hill, Malmesbury, Wiltshire SN16 0RP.
ROI Dyson Customer Care
[e-mail]
01 475 7109
Dyson Ireland Limited, Unit G10, Grants Lane,
Greenogue Business Park, Rathcoole, Dublin 24.
IMPORTANT!
WASH FILTERS
Wash filters with cold water at least every 3 months.

REGISTER
BY MAIL
Complete and return
the form to Dyson in the
envelope supplied.
REGISTER
BY PHONE
Call our dedicated Helpline.
Open 7am–10pm.
7 days a week.
REGISTER
ONLINE
Visit our website to register
your full parts and labour
guarantee online.
www.dyson.com/register
UK 0800 298 0298
ROI 01 475 7109
3 EASY WAYS TO REGISTER FOR YOUR FREE 5 YEAR GUARANTEE
GUARANTEE FORM
Title Surname
First name
Telephone Mobile
email
Postcode
Address
By mail Yes No
By phone Yes No
By email Yes No
By text message Yes No
As a Dyson vacuum cleaner owner, you can hear
about Dyson inventions, services and products before
anyone else. If it’s okay to contact you, please let us
know how we may do this.
We sometimes ask other companies (such as market researchers) to
contact owners on our behalf. We do this to get feedback on ideas or
ask you to try new products and services. Would this be okay?
Yes ■ No ■
Date of purchase / / Country of purchase UK ROI
Serial number
