Dyson DC32 User manual

OPERATING MANUAL
5
1
4
3
2
REGISTER
FOR YOUR
FREE 5 YEAR
GUARANTEE
TODAY
WASH FILTER
Wash filter with cold water
at least every 3 months.
ASSEMBLY
ON OFF
click
click
click

Note your serial number for future reference
IMPORTANT SAFETY PRECAUTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER
When using an electrical appliance, basic precautions should always be followed, including the following:
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY:
1. This vacuum cleaner is for domestic use only. Do not use outdoors or on wet surfaces.
2. Do not handle plug or vacuum cleaner with wet hands.
3. Do not allow to be used as a toy. Close attention is necessary when used by or near children.
4. Do not use with damaged cable or plug. If the supply cable is damaged, it must be replaced by Dyson Ltd., our
service agents or similarly qualified persons in order to avoid a hazard.
5. If the vacuum cleaner is not functioning properly, has been dropped, damaged, left outdoors, or immersed in liquid,
do not use. Contact the Dyson Customer Care Helpline.
6. Do not use the vacuum cleaner if any parts appear to be faulty, missing or damaged.
7. Ensure all parts, including the clear bin, are securely attached before using or carrying the vacuum cleaner.
8. This vacuum cleaner is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the vacuum cleaner by a person responsible for their safety. Children should be supervised to ensure that
they do not play with the vacuum cleaner.
9. Do not leave vacuum cleaner when plugged in. Unplug from outlet when not in use, and before performing user
maintenance, connecting or disconnecting the hose or changing accessories.
10. Store the vacuum cleaner indoors. Do not use or store this vacuum cleaner below 0°C(32°F). Ensure that the
vacuum cleaner is at room temperature before operating. Put the vacuum cleaner away after use with the cable
stored safely to prevent tripping hazards.
11. This vacuum cleaner is fitted with a thermal protection device. If any part of your vacuum cleaner becomes blocked
it may cause the device to operate and automatically stop the vacuum cleaner. If this happens, the vacuum cleaner
must be switched off, unplugged and allowed to cool down before attempting to check filters or for blockages.
Ensure any blockage is cleared before re-starting the vacuum cleaner.
12. Turn off all controls before unplugging.
13. Do not unplug by pulling on cable. To unplug, grasp the plug, not the cable.
14. Do not pull or carry by the cable, use the cable as a handle, close a door on the cable, or pull the cable around
sharp edges or corners. Do not run the vacuum cleaner over the cable. Keep the cable away from heated surfaces.
15. The use of an extension cable is not recommended.
16. Keep hair, loose clothing, fingers, and all parts of your body away from openings and moving parts, such as the
brush bar.
17. Do not put any object into openings on the vacuum cleaner. Do not use with any opening blocked: keep free of dust,
lint, hair, and anything that may reduce air flow.
18. Take extra care when vacuuming on stairs. Always work with the vacuum cleaner at the bottom of the stairs.
19. Keep the vacuum cleaner on the floor. Do not put the vacuum cleaner on chairs, tables etc.
20. Do not shake the vacuum cleaner or press the cyclone release button while carrying the vacuum cleaner, or it could
fall and cause injury.
21. Do not use to pick up flammable or combustible liquids, such as petrol, or use in areas where they may be present.
22. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
23. Check to ensure your electricity supply matches that shown on the rating plate. The vacuum cleaner must only be
used as rated.
24. Use only as described in this Dyson Operating Manual. Use only Dyson recommended attachments.
25. Do not use without the clear bin and filters in place.
26. Do not lubricate any parts, or carry out any maintenance or repair work other than that shown in this Dyson
Operating Manual, or as advised by the Dyson Customer Care Helpline.
SAVE THESE INSTRUCTIONS
THIS VACUUM CLEANER IS INTENDED FOR HOUSEHOLD USE ONLY
REGISTER
BY MAIL
Complete and return
the form to Dyson in the
envelope supplied.
REGISTER
BY PHONE
Call our dedicated Helpline
Open 7am–10pm.
7 days a week.
REGISTER
ONLINE
Visit our website to register
your full parts and labour
guarantee online.
www.dyson.com/register
UK 0800 298 0298
IRL 01 475 7109
3 EASY WAYS TO REGISTER FOR YOUR FREE 5 YEAR GUARANTEE
23
Do not pull on
the cable.
Do not store near
heat sources.
Do not use near
naked flame.
Do not run over
the cable.
Do not pick up
water or liquids.
Do not pick up
burning objects.
Do not use above you
on the stairs.
Do not put hands
near the brush bar
when the vacuum
cleaner is in use.
After registering for your 5 year guarantee, your Dyson
vacuum cleaner will be covered for parts and labour for
5 years from the date of purchase, subject to the terms of
the guarantee.
If you have any query about your Dyson vacuum cleaner,
call the Dyson Customer Care Helpline with your serial
number and details of where/when you bought the
vacuum cleaner. Your serial number can be found on
your rating plate which is behind the clear bin.
Most queries can be solved over the phone by one of our
trained Dyson Customer Care Helpline staff.
Alternatively visit www.dyson.co.uk/support for online
help, general tips and useful information about Dyson.

5
4
3
1
2
ON OFF
1
2
3
1
2
3
4
45
Power and cable
Tool attachments
Looking for blockages
Emptying the clear bin
Cleaning the clear bin
Turbine head
Suction release
click
click
click
click
click
Mini turbine head maintenance
Clearing brush bar obstructions
click
click

IMPORTANT!
WASH FILTER
Wash filter with cold water at least every 3 months.
3
months
67

89
USING YOUR DYSON VACUUM CLEANER
PLEASE NOTE:
• Always extend the cable fully to the red tape before use.
• Fine dust such as plaster dust or flour should only be vacuumed in very small
amounts.
• Do not use the vacuum cleaner to pick up sharp hard objects, small toys, pins,
paper clips etc.
• Consult your flooring manufacturer’s recommended instructions before
vacuuming and caring for your floorings, rugs and carpets. Some carpets will
fuzz if a rotating brush bar is used when vacuuming. If this happens,
we recommend vacuuming in hard floors mode and consulting with your
flooring manufacturer.
• If used in a garage when car cleaning, care should be taken to wipe the
soleplate and wheels with a dry cloth af ter vacuuming to clean off any sand, dirt
or pebbles which could damage delicate floors.
• When vacuuming, certain carpets may generate small static charges in the clear
bin. These are entirely harmless and not associated with the main supply. To
minimise any effect from this, do not put your hand or insert any object into the
clear bin unless you have first emptied it and rinsed it out with cold water.
• Only use parts recommended by Dyson; failure to do so could invalidate your
guarantee.
EMPTYING THE CLEAR BIN
CAUTION:
• Switch OFF and unplug the vacuum cleaner before emptying the clear bin.
• Empty as soon as the dirt reaches the level of the M AX mark – do not overfill.
To remove the clear bin from the machine press the button at the rear of the
carrying handle. To release the dirt, press the red button to open the bin.
The British Allergy Foundation has approved this product. It is a UK national
charity with the aim of improving awareness, prevention and treatment of
allergies. The British Allergy Foundation Seal of Approval is a UK registered
trademark of The British Allergy Foundation.
PLEASE NOTE:
• Do not use the vacuum cleaner without the clear bin in place.
• To minimise dust and allergen contact when emptying, encase the clear bin
tightly in a plastic bag and empty. Remove the clear bin carefully and seal bag
tightly, dispose as normal.
CLEANING THE CLEAR BIN
CAUTION:
• Do not immerse the whole cyclone in water or pour water into the cyclones.
• Ensure the clear bin is completely dr y before replacing.
• Clean the shroud with a cloth or dry brush to remove lint and dirt.
PLEASE NOTE:
• Do not use detergents, polishes or air fresheners to clean the clear bin.
• Do not put the clear bin in a dishwasher.
WASHING YOUR FILTER
CAUTION:
• Switch OFF and unplug the vacuum cleaner before removing the filter.
• Ensure filter is completely dry before refitting into the vacuum cleaner.
PLEASE NOTE:
• It is important to check your filter regularly and wash at least every 3 months
according to instructions, to maintain performance.
• Please leave to dry completely for 24 hours.
• The filter may require more frequent washing if vacuuming fine dust.
• Do not use detergents to clean the filter.
• Do not put the filter in a dishwasher, washing machine, tumble dryer, oven,
microwave or near a naked flame.
LOOKING FOR BLOCKAGES
CAUTION:
• Switch OFF and unplug the vacuum cleaner before checking for blockages.
• Beware of sharp objects when clearing blockages.
• Refit all par ts of the machine securely before using.
PLEASE NOTE:
• Clearing blockages is not covered by your machine’s limited guarantee.
If any part of your machine becomes blocked, it may overheat and then
automatically shut off. Unplug the vacuum cleaner and leave to cool down.
Clear any blockage before restar ting.
• Large items may block the tools or wand inlet, if this happens switch the vacuum
cleaner off and unplug the vacuum cleaner before removing the blockage.
Do not operate the wand release catch.
This product should not be treated as household waste. Instead it should be
handed over to the applicable collection point for the recycling of electrical
and electronic equipment – this may be your local civic amenity site or a
facility provided by the retailer selling the product or a replacement product.
By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and for human health, which could
otherwise be caused by inappropriate waste handling of this product. For more
detailed information about recycling of this product, please contact the Dyson
Customer Care Helpline, your local authority civic amenity site or the retailer
selling the product or a replacement product.
GUARANTEE - TERMS AND CONDITIONS
DYSON CUSTOMER CARE
If you have a question about your Dyson vacuum cleaner, call the Dyson
Customer Care Helpline with your serial number and details of where and when
you bought the vacuum cleaner, or contact us via the website. The serial number
can be found on the main body of the vacuum cleaner behind the clear bin.
Most questions can be solved over the phone by one of our Dyson Customer
Care Helpline staff.
If your vacuum cleaner needs service, call the Dyson Customer Care Helpline so
we can discuss the available options. If your vacuum cleaner is under guarantee,
and the repair is covered, it will be repaired at no cost.
PLEASE REGISTER AS A DYSON VACUUM OWNER
THANK YOU FOR CHOOSING TO BUY A DYSON VACUUM CLEANER
To help us ensure you receive prompt and efficient service, please register
as a Dyson vacuum owner. There are three ways to do this:
• Online at ww w.dyson.com/register
• By calling the Dyson Customer Care Helpline: UK: 0800 298 0298
or IRL: 01 475 7109.
• By completing and returning the enclosed form to us by mail. This will confirm
ownership of your Dyson vacuum cleaner in the event of an insurance loss,
and enable us to contact you if necessary.
LIMITED 5 YEAR GUARANTEE
TER MS AND CONDITIONS OF THE DYSON 5 YEAR LIMITED GUARANTEE.
WHAT IS COVERED
• The repair or replacement of your vacuum cleaner (at Dyson’s discretion) if your
vacuum cleaner is found to be defective due to faulty materials, workmanship or
function within 5 years of purchase or delivery (if any part is no longer available
or out of manufacture Dyson will replace it with a functional replacement part).
• Use of the vacuum cleaner in the UK and Republic of Ireland.
WHAT IS NOT COVERED
Dyson does not guarantee the repair or replacement of a product as a result of:
• Normal wear and tear (e.g. fuse, belt, brush bar, batteries etc).
• Accidental damage, faults caused by negligent use or care, misuse, neglect,
careless operation or handling of the vacuum cleaner which is not in accordance
with the Dyson Operating Manual.
• Blockages – please refer to the Dyson Operating Manual for details of how
to unblock your vacuum cleaner.
• Use of the vacuum cleaner for anything other than normal domestic
household purposes.
• Use of parts not assembled or installed in accordance with the instructions
of Dyson.
• Use of parts and accessories which are not Dyson Genuine Components.
• Fault y installation (except where installed by Dyson).
• Repairs or alterations carried out by parties other than Dyson
or its authorised agents.
• If you are in any doubt as to what is covered by your guarantee, please call the
Dyson Customer Care Helpline on UK: 0800 298 0298 or IRL: 01 475 7109.
SUMMARY OF COVER
• The guarantee becomes effective at the date of purchase (or the date of delivery
if this is later).
• You must provide proof of delivery/purchase before any work can be carried
out on your vacuum cleaner. Without this proof, any work carried out will be
chargeable. Please keep your receipt or deliver y note.
• All work will be carried out by Dyson or its authorised agents.
• Any parts which are replaced will become the property of Dyson.
• The repair or replacement of your vacuum cleaner under guarantee will not
extend the period of guarantee.
• The guarantee provides benefits which are additional to and do not affect your
statutor y rights as a consumer.
ABOUT YOUR PRIVACY
Your information will be held by Dyson Ltd. and its agents for promotional,
marketing and servicing purposes.
If your personal details change, if you change your mind about any of your
marketing preferences or if you have any queries about how we use your
information, please let us know by contacting
Dyson Ltd., Tetbury Hill, Malmesbury, Wiltshire, SN16 0RP England,
or by calling the Dyson Customer Care Helpline on
UK 0800 298 0298 or IRL 01 475 7109.
Or you can email us at [e-mail]
For more information on how we project your privacy, please see our privacy
policy on www.dyson.co.uk
PRODUCT INFORMATION
Maximum product weight 8.88kg.
Please note: small details may vary from those shown.
This product is protected by the following intellectual property rights:
PATENT/PATENT APPLICATION NUMBERS
EP1361812; EP1370172; EP1361814; EP1268076; EP1361815; EP0636338;
EP1748848; EP1474242; EP1551270; EP1883336; EP1898768; EP1380247;
EP1365676; EP1542576; EP1542574.
DESIGNS/DESIGN APPLICATIONS
EM000941398-0001; EM000941406-0001; EM000941414-0001.
Equivalent patents, registered designs and applications exist in other countries.
1
2
3

www.dyson.com
Dyson Customer Care
If you have a question about your Dyson vacuum cleaner, call
the Dyson Cus tomer Care Helpline with your serial number and
details of where and when you bought the cleaner, or contact us
via the Dyson website. The serial number can be found on the
main body of the vacuum cleaner behind the clear bin.
JN.32670 PN.18001-07-01 05.11.09
UK Dyson Customer Care
[e-mail]
0800 298 0298
Dyson Ltd, Tetbury Hill, Malmesbur y, Wiltshire SN16 0RP.
IRL Dyson Customer Care
[e-mail]
01 475 7109
Dyson Ireland Ltd, Unit 10 Greenogue Business Park,
Rothcoole, Dublin 24
IMPORTANT!
WASH FILTER
Wash filter with cold water at least every 3 months.
3
months

REGISTER
BY MAIL
Complete and return
the form to Dyson in the
envelope supplied.
REGISTER
BY PHONE
Call our dedicated Helpline
Open 7am–10pm.
7 days a week.
REGISTER
ONLINE
Visit our website to register
your full parts and labour
guarantee online.
www.dyson.com/register
UK 0800 298 0298
IRL 01 475 7109
3 EASY WAYS TO REGISTER FOR YOUR FREE 5 YEAR GUARANTEE
GUARANTEE FORM
Title Surname
First name
Telephone Mobile
e-mail
Postcode
Address
By mail Yes No
By phone Yes No
By email Yes No
By text message Yes No
As a Dyson vacuum owner, you can hear about Dyson
inventions, services and products before anyone else.
If it’s okay to contact you, please let us know how we
may do this.
We sometimes ask other companies (such as market researchers) to
contact owners on our behalf. We do this to get feedback on ideas or
ask you to try new products and services. Would this be okay?
Yes ■ No ■
Date of purchase / / Country of purchase UK IRL
Serial number
