E-Lins M100 User manual
M100 Cellular Modem Quick Start
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
E-Lins Cellular Modem QuickStart
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
PHONE: +86-755-83700465
WEB: www.szelins.com
E-mail: [email protected]
M100 Cellular Modem Quick Start
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
CONTENTS
PROLOGUE···············································································································································2
VERSION············································································································································3
NOTICE·············································································································································· 3
GETTING STARTED ·······························································································································4
CONNECT TO PRODUCTS·····················································································································4
INSERT SIM CARD ·····························································································································4
NOTE:HYPER TERMINAL ··················································································································· 5
TESTAT COMMAND ··························································································································· 9
SMS······························································································································································9
CSD····························································································································································12
ABOUT CSD···································································································································· 12
GETTING STARTED ··························································································································· 12
MUTUALITY COMMAND ··················································································································· 12
Generally command································································································· 12
Set the auto answer in ringing··················································································12
TEST 13
DIAL-UP···················································································································································14
SET-UP MODEM································································································································14
CONFIGURE 19200 MODEM·············································································································· 17
CREATE A DIAL-UP NETWORK··········································································································· 21
LOGIN ON NETWORK ························································································································ 28
SETTINGAPN OR VPDN························································································································2
SETTING APN····································································································································2
SETTING VPDN································································································································· 4
Chapter1
Prologue
This document is suitable for the following products, it will show how to setup an E-Lins
Cellular Modem and helps you to use it.
M100 Cellular Modem Quick Start
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
Products type Description
M100gs GSM Modem
M100g - 201 GPRS Modem
M100g - 209 GPRS Modem
M100c-305 CDMA1x Modem
M100c-309 CDMA1x Modem
Version
V
ersion Date Description Author
2.50 2011-10-10 Changed once Jason. Z
Notice
E-Lins is a registered trademark of E-Lins Technology Co.,Limited.
The copyright of the document belongs to E-Lins Technology Co.,Limited. Copying of this
document and modifying it and the use or communication of the contents thereof, is
forbidden without express. Authority and Offenders are liable to the legal sanction
M100 Cellular Modem Quick Start
Chapter2
Getting Started
Connect to products
1. Please connect antenna and cable with our products, make sure
the port COM1 or COM2?
Insert SIM Card
2. Open the back cover. insert into SIM card as below
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
M100 Cellular Modem Quick Start
Note: Hyper Terminal
3. Open the HyperTerminal and input ***( any) as follows
4. Choose a right port
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
M100 Cellular Modem Quick Start
5. The right configuration as following
6. When your start-up Hyper Terminal, if it is not connected successfully, you can
see the red mark of follow picture without any number.
7. Please follow the following steps to make it work.
8. First, disconnect existing connection.
9. Second, click the “Properties button” or “attribute button”.
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
M100 Cellular Modem Quick Start
Second, click
“attribute” tab
First, disconnect
existing connection
No baud rate
10. click the “configure”, and make sure again of you modify configure
11. make sure your modify configure again, click “OK”
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
M100 Cellular Modem Quick Start
12. Then you can see it appeared baud rate on white label, then click the black label
to make call
If the button of the window show “9600
8-N-1”, click this button to make call for
connection
First, check if show
detected Baud rate
13. Power on the modem, then you had successfully configured the Hyper Terminal
14.
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
M100 Cellular Modem Quick Start
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
15. Do not care about the ERROR code, just care if you see “+++++++++++” on the
screen. If yes, the connection is successful.
Test AT command
Notes:
1. All <CF> means “enter”
2. The character and words in Green and Red is very important. Please study
carefully. Thanks!
AT<CF> //Test “at” command
I/OK //Response ok parameter if successfully connected, you can
make sure the module have no malfunction
AT+CSQ<CF> // to check the Signal quality
+CSQ: **, ## // ** Should be the number between 10 and 31, the signal
quality becomes better as the number grows.
## should be is 99, Or you should checking the equipment of
antenna or SIM card.
If you succeed in testing command, at now, you can begin to SMS
Chapter3
SMS
Refer to the related SMS manual.
Please contact E-Lins to get SMS manual or download from website.
The follow SMS Info is just for CDMA modem with ZTE module.
3.1 Select message server
AT+CSMS=1 //Select Message Service,the parameter is 0 or 1, default is 0
AT+CSMS? //Select currently Message Service
+CSMS: 0,1,1,1 // chosen service is 0,and returns the type of messages
supported by<mt>,< mo>,< bm>,
M100 Cellular Modem Quick Start
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
0 : Type not supported 1: type supported
Ok
3.2 Send SMS message
3.2.1 Send English message
at+zmsgl=1,2 //one-step,Set SMS Message format by ASCII coding
mode
OK
at+cmgs="13632608834"<CR> //second-step, input aim telephone number,end as”
Enter” replace of <CR>
>helloyuhui // third-step, input content of message
+CMGS: 1 //Successful with send one message
OK //response
+CDS: 2, 1,"13632608834", 129,"07/01/15, 16:36:56 //response parameter about
content of message
Note: you have to set SMS Message format before sending message, English SMS Message format only
support ASCII code, and Chinese message format only support Unicode code, sending SMS Message
end as”ctrl-z”. Cancel it “ESC”
3.2.2 Send Chinese message
AT+ZMSGL=6, 4 //one-step, set SMS message format by Unicode code
Ok
41 54 2B 43 4D 47 53 3D 22 31 33 36 33 32 36 30 38 38 33 3422 //second-step, send
aim telephone and length of parameter by Unicode
>0D 501A592979D16280001A // content of message by Unicode code is “E-Lins
Technology”, end as (ctrl+z/Esc)
+CMGS: 1
OK
+CDS:2,1,"13798257916",129,"07/01/15,17 :37 :08","07/01/15,17 :37 :13",32768
3.3 Receive SMS message
AT+CPMS="MT" //Preferred Message Storage; “Mt “is receive SMS Message
+CPMS: 3, 15,0,15
OK
3.3.1 New SMS message indication
AT+CNMI=2,1,0,0,0 //value of format is<mode>,<mt>,<bm>,<ds>,<bfr>
M100 Cellular Modem Quick Start
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
+CNMI : “MT”3 //when <MT> equal 1,SMS message format
AT+CNMI=2,2,0,0,0 //<MT>=2 ,receive a new message,
OK
+CMT:"13798257916","07/01/15, 18:40:54", 129, 0, 2, 0," 13798257916", 2
Helloworld //when <MT>equal 2, SMS Message format
AT+CNMI=2,0,0,1,0 //when fourthly value is <ds>=1
Ok //response “ok”
3.3.2 Read SMS message
AT+CMGR=1 //read first SMS message
+CMGR:"REC UNREAD","13798257916","07/01/15, 17:47:39", 0, 2, 0," 13798257916"
Helloword //response connect of message
OK
3.3.3 Select SMS message
AT+CMGL=”all” //Select all SMS message form preferred store.
+CMGR: 0"REC READ","13798257916", 6, 4 //”READ” is received read
messages
Helloworld //response contents
+CMGR: 1"REC READ","13798257916", 6, 4
Yuhuilove
3.3.4 Delete SMS message
AT+CMGD=1 //Delete first SMS message
M100 Cellular Modem Quick Start
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
Chapter 4
CSD
About CSD
CSD(Circuit Switched Data) is 9.6kbps speed circuit Switched Data from GSM network,
GSM+2 operations could attainability 14.4kb/s speed, and encrypt the data at the same
time, so the GSM system has the encryption function. It can connect with the line Modem,
Getting started
zConnect two E-Lins M100 modem with each two computers’ cable and open up
Hyper Terminal
zSetting E-Lins M100 Modems baud rate 115200bps
zRegister the CSD function. If you used this function, the SIM card requires CSD
function registration from network provider. Dredge CSD Function usually have
two number. one is “pn” for voice message. and other is” un” for date message
Mutuality command
Generally command
ATD136****** //making a call
ATA //answer a call
+++ //Switch from date mode or PPP online mode to command
mode
ATO //Switch from command mode to data mode or PPP online
mode
ATH //Disconnect existing Connection
Set the auto answer in ringing
ATS0=n //Set number of ring before automatically answering the call
M100 Cellular Modem Quick Start
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
Test
Initialization commands”
AT&F0 // renew default parameter
AT+IPR=9600 // setting fixed baud rate
AT&W // save parameter
Initialization command of callee
ATS0=1
Initialization command of caller
ATD[dn] //note: not ending as” ; “is data call, end as”;” is voice call
make call [dn ] is data number 。
Callee answer command
ATA // answer call
communicate account command
+++ // abort communicate, return command mode
ATO // Switch from command mode to data mode or PPP online
mode
Disconnect existing Connection
ATH // Disconnect existing Connection,in command mode
When Callee receive a ring , it answer automatically. Both them will show connect
9600and enter data state .then you can used CSD.
There is a simple test course, it is suitable for E-Lins GSM /GPRS products, and fit for
E-Lins GSM/GPRS wireless modem connect with line modem
The Connecting mode of the CSD is same with line modem, even replace, but it is
expensive, and not always online, only point to point, not one point to many points (center
need to use modem, if come true point to point)
M100 Cellular Modem Quick Start
Chapter5
Dial-up
Notice: the Dial-up function is not support the E-Lins101 GSM Modem,it Suit for the following products
Products type Description
M100g - 201 GPRS Modem
M100g - 209 GPRS Modem
M100c-305 CDMA1x Modem
M100c-309 CDMA1x Modem
Dial-up to connect network in windows XP operating System for example as follows.
Set-up Modem
Please connect Modem with your computer Rs232 interface cable .then Start from
“Control Panel”, click “Phone and Modem Options”, and select “Modem”:
click “New location” to add a new modem:
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
M100 Cellular Modem Quick Start
Tap “Don’t detect my modem; I will select it from a list “,and then click “Next” to continue
When appear “install New Modem” dialog box, choose “standard Modem Type”in the left
manufacturer, and choose “Standard 19200 bps Modem”in the right Models
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
M100 Cellular Modem Quick Start
Select COM port and choose the right port( it depends your computer, may be not
“COM1”.), and click “next” then you will finish installation.
When appear Following Frame, Click “Finish” to succeed your modem installation.
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
M100 Cellular Modem Quick Start
Configure 19200 Modem
Click “Phone and Modem Options” from “Control Panel”, Click “Modems” tab; select the
modem that choose the” Standard 19200 bps modem”, and then click “Properties” button.
At “Modem” tab, set the “Maximum Port Speed” to “115200”.
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
M100 Cellular Modem Quick Start
Choose “Diagnostics” tab, click the “Query Modem, if Baud rate setting and so on is right,
there are automatic indication that it is have pass
Next, click “Advanced” tab, Here, you can add or change settings by filling in Extra
initialization commands at “Advanced” tab
M100gs Extra initialization commands: AT+CGDCONT=1,IP,CMNET
M100g Extra initialization commands: AT+CGDCONT=1,\”IP\”,\”CMNET\”
M100c-309/M100c-305 Extra initialization commands: AT&D2
Notes: CMNET is theAPN from network provider. Please get the correct APN from your
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
M100 Cellular Modem Quick Start
network provider before configing the initialization commands.
（this picture is the example to M100g-201 GPRS modem）
（example to M100g-209 GPRS modem）
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
M100 Cellular Modem Quick Start
（example to M100c-309/305 CDMA modem）
NOTICE: “CMNET” is China Mobile APN setting; you should change it in accordance with the information
provided by your local service provider.
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
Table of contents
Other E-Lins Modem manuals
