E-Lins H685 Series User manual

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
Industrial Grade 2G 3G 4G Cellular Router
User Manual
H685 Series
E-Lins Technology Co., Limited
PHONE: [phone]
Email: [email protected]
WEB: http://www.e-lins.com
ADDRESS: Rm.33, Unit B, Floor 12, U chuanggu, Xinniu Rd,
Minzhi, Longhua, Shenzhen, 518000, China

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
Content
1 Preparation job before configuration·······························································································································4
1.1 Learn your router version and feature·················································································································4
1.2 Prepare SIM Card and working condition···········································································································6
1.3 Highly recommendation for the configuration·····································································································6
2 Hardware Installation·························································································································································6
2.1 Overall Dimension··················································································································································7
2.2 The Ports··································································································································································7
2.3 Installment································································································································································9
2.4 SIM/UIM card installed···········································································································································9
2.5 The installation of terminal blocks························································································································9
2.6 Grounding······························································································································································11
2.7 Power Supply························································································································································11
2.7.1 PoE Function (Option Feature)·······················································································································11
2.8 LED and Check Network Status·························································································································12
3 Software configuration ····················································································································································13
3.1 Overview································································································································································14
3.2 How to log into the Router···································································································································14
3.3 Router status·························································································································································17
3.3.1 Status overview·················································································································································17
3.3.2 Network status···················································································································································18
3.3.3 Firewall status····················································································································································21
3.3.4 Routes·································································································································································21
3.3.5 System log··························································································································································22
3.3.6 Kernel log····························································································································································23
3.3.7 Realtime graphs·················································································································································23
3.4 System Configuration···········································································································································25
3.4.1 Setup wizard ······················································································································································25
3.4.2 System································································································································································27
3.4.3 Password····························································································································································29
3.4.4 NTP······································································································································································30
3.4.5 Backup/Restore·················································································································································33
3.4.6 Upgrade······························································································································································34
3.4.7 Reset···································································································································································35
3.4.8 Reboot·································································································································································36
3.5 Services configuration··········································································································································36
3.5.1 ICMP check························································································································································36
3.5.2 VRRP ··································································································································································38
3.5.3 Failover (link backup)········································································································································39
3.5.4 DTU·····································································································································································40
3.5.5 SNMP··································································································································································42
3.5.6 GPS·····································································································································································44
3.5.7 SMS·····································································································································································45

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
3.5.8 VPN········································································································································错误!未定义书签。
3.5.8.1 IPSEC······························································································································································65
3.5.8.2 PPTP································································································································································68
3.5.8.3 L2TP·································································································································································71
3.5.8.4 OpenVPN························································································································································74
3.5.8.5 GRE tunnel······················································································································································75
3.5.9 DDNS··································································································································································52
3.5.10 Connect Radio Module···································································································································57
3.5.11 Modbus ·····························································································································································57
3.6 Network Configuration ·········································································································································76
3.6.1 Operation Mode·················································································································································77
3.6.1.1 Gets two LAN Ethernet Port for H685·········································································································77
3.6.2 Mobile configuration··········································································································································78
3.6.3 Cell mobile data limitation································································································································81
3.6.4 LAN settings·······················································································································································82
3.6.5 wired-WAN··························································································································································85
3.6.6 WiFi Settings······················································································································································86
3.6.6.1 Wifi General configuration ····························································································································87
3.6.6.2 WiFi Advanced Configuration·······················································································································87
3.6.6.3 WiFi Interface Configuration·························································································································88
3.6.6.4 WiFi AP client··················································································································································90
3.6.7 Interfaces Overview··········································································································································93
3.6.8 Firewall································································································································································94
3.6.8.1 General Settings·············································································································································94
3.6.8.2 Port Forwards·················································································································································94
3.6.8.3 traffic rules·······················································································································································95
3.6.8.4 DMZ··································································································································································99
3.6.8.5 Security··························································································································································100
3.6.9 Static Routes····················································································································································101
3.6.10 Switch······························································································································································102
3.6.11 DHCP and DNS·············································································································································103
3.6.12 Diagnostics·····················································································································································105
3.6.13 Loopback Interface ·······································································································································106
3.6.14 Dynamic Routing···········································································································································107
3.6.15 QoS·································································································································································108
3.6.16 Guest LAN(Guest WiFi) ·······························································································································110

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
Chapter 1
1 Preparation job before configuration
1.1 Learn your router version and feature
1) H685 series contains different version and option feature. Please learn it before using it.
H685 series defines the model as follows,
Notes: please be informed the following features are option. Please indicate with your

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
orders.
1) WiFi Feature
2) GPS feature
3) Serial to cellular feature, RS232 or RS485 can choose one
4) Voice/SMS control
5) DC5V~60V
6) BGP, OSPF, RIP, etc.
7) DIO (digital input and output feature)
8) RMS (Remote Management System)
2) Find the modem type info at the back cover of the router. This will be used while do
configuration.
For example: the following label indicates the version, type and inside module modem.
The module modem name is “ME909s-120”, remember this and will select this module name while
do configuration.

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
1.2 Prepare SIM Card and working condition
1. H685 router has different version. Study your router version before installation.
2. For GSM/GPRS/EDGE/HSDPA/HSUPA/HSPA/HSPA+/4G LTE version, please get a SIM
card with data business.
3. For CDMA2000 EVDO/CDMA1x version, please get a UIM card with data business or
inform us before order if the network uses non-ruim (nam-flashing).
4. Make sure the sim card or uim card is with enough data business and balance.
5. Make sure the signal is good enough where you test or install the router. Weak signal will
make the router no work. If you find your signal strength is not good, please contact us for
high gain antenna.
6. Different countries and carriers use different network band and frequency. E-Lins packs
units with free world-wide-use antenna. It can work, but the data speed or signal may not be
good at your sites. Please buy dedicated high gain antenna from your local suppliers or
contact E-Lins to OEM/ODM the antenna.
1.3 Highly recommendation for the configuration
The wireless cellular is unstable sometimes with some uncertain issue. In order to keep the
router working in the best condition, it is highly recommended that the Cell ICMP Check
feature is activated. Please refer to chapter 3.5.1 to configure.
Chapter 2
2 Hardware Installation
This chapter mainly describes the appearance, model and function of H685 series and how to
install and set the configurations.
1. Overall Dimension
2. Accessories Description
3. Installment

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
2.1 Overall Dimension
2.2 The Ports
Pictures:

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
LAN: LAN RJ45 Ethernet ports.
WAN: WAN RJ45 Ethernet ports.
RST: sys reset button
PWR: DC power socket. DC5~40V, DC5~50V option depends on the router version.
VCC: DC wire positive pole. DC5~40V, DC5~50V option depends on the router version
GND: DC wire ground
GND: Serial ground
RX: serial receiving
TX: serial transmission
RST: reset router
DIO0: digit I/O port 0
IDO1: digit I/O port 1
IDO2: digit I/O port 2
IDO3: digit I/O port 3
Antenna Connection Table
Antenna Connector
Marks
Cell1
for main cell antenna

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
Aux / Cell2
for auxiliary cell antenna
C3/W1
cellular antenna 3 or Wi-Fi antenna.
C4/G/W2
cellular antenna 4, or GPS antenna, or
Wi-Fi 2 antenna
WiFi / W1/W2
for WiFi antenna
2.3 Installment
H685 series should be installed and configured properly before putting in service. The
installation and configuration should be done or supervise by qualified engineer.
Attention:
Do not install H685 series or connect/disconnect its cable when it is power on.
2.4 SIM/UIM card installed
If your router has SIM/UIM card protector, please remove it, insert the sim card correctly,
and fix the protector.
If your router has no SIM/UIM card protector, please insert the sim card correctly.
Attention: SIM/UIM card does not reach the designated position, the equipment can not
find a card, can't work normally, therefore inserted a try to check again for a SIM
card is stuck fast.
2.5 The installation of terminal blocks
This chapter is for version with terminal blocks only. Default, the H685 is with DB9
connector. Please use DB9 cable to connect H685 and the equipment directly.
The following is for version with terminal blocks only:
H685 uses pluggable terminals to connect the user’s data and the power supply. Spacing:
3.81mm，10 Pin; User data and power supply suggestion: 14~24AWG. Please refer to the
table 2-4 for the interface definition of the power cable and connection sequence. Specific
interface definition of the power cable and connection sequence you can read on the
labels of H685 products. Using 14~24AWG cable and referring to H685 products labels
or the bellowed interface definition and connection sequence, you need to use the oblate
screw driver to fix the cable to the connecting jacks of the pluggable terminal. After
successfully connection, you need to insert the terminal into the corresponding position in

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
the bottom of the H685 products.
Notes: Connection sequence should be accurate。Cable’s insulating striping length is
about 7mm. (For safety, insulating striping length should be too long). Please refer
to the picture.
Attention:
1.The power cable should be connected correctly. We “suggestion double check before
switch it on .Wrong connections may destroy the equipment.
2.Power terminals: Pin 1 and Pin 2;
3.Here ： Pin 2 is “GND”, PIN 1 is power input “Vin”(DC5~40V, or DV5~50V).
PIN
Signal
Description
Note
1
VCC
+5-40V DC Input,
+5~50V option
Current: 12V/1A
2
GND
Ground
3
TX
Transmit Data
4
RX
Receive Data
5
PGND
Ground
6
RST
Reset
Reset Pin has the same
function with reset
button. In the usage, it
needs to be short
connected to the GND.
After giving the device a
1 sec low level, it will
reboot.3 seconds, the
device will restore
factory settings
7
DIO0
General Purpose
I/O

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
I/O Terminal on router
Serial port (RS485 or RS232)
Port 3 (GND)
Pin 5
Port 4 (RX)
Pin 2
Port 5 (TX)
Pin 3
Notes: If not through, can switch Port4 and port5.
2.6 Grounding
To ensure a safe, stable and reliable H685 series operation, Router cabinet should be
grounded properly.
2.7 Power Supply
H685 series can be applied to complicated external environment and usually the power
range is very large. So in order to fit the complicated application environment and improve
the stability of the system, H685 series is designed with advanced power management
technology. The DC power supply electronic to the device via the pluggable terminal PIN
2(GND) and PIN 1(Vin). Please refer to the above table for the detail definition of the
terminal.
Normally, H685 series input powers supply is +5～+40V (if your H685 support 50V, the
option is +5~+50V). In most cases, the standard configuration is 12V/1A.
Attention:
The H685 supports POE (Power over Ethernet) (This is option feature. Please confirm with
your order). It supports 5-40VDC default, it the POE voltage is 48V, please order 5-60VDC
version, otherwise it will defeat the hardware of H685.
2.7.1 PoE Function (Option Feature)
Both the LAN port and the WAN port support PoE, and the PoE switch uses an network
8
DIO1
General Purpose
I/O
9
NC
Not connect
Reserved for DIO2
10
NC
Not connect
Reserved for DIO3

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
cable to connect to the router to supply power and transmit data.
The PoE is an optional function and is only used on models that support the PoE function.
2.8 LED and Check Network Status
Please connect the antenna after you successfully connect to the cable. And then insert the
valid SIM/UIM card and provide the power to the H685 series via the cable. After provide the
power to H685, if the SYS LED starts to blink in a few seconds, that means the system start-up
is normal; if the CELL LED works, that means the network is online; if the VPN light works, that
means VPN tunnel has been set up. Please refer to the below table for the situation of the
indication lights.
LED
Indication Light
Description
SYS
On for 25 seconds
On for 25 seconds after power supply
blink
System set-up normally

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
Off or still on after 25
seconds
System set-up failure
LAN
blink
Data transmission in Ethernet
Off
Ethernet connection abnormal
On
Ethernet is connected
VPN
On
IPSec VPN tunnel set-up
Off
IPsec VPN tunnel set-up failure or inactivated
CELL
On
Access to the Internet/Private Network
WiFi
On
Enable
Off
Disable
WAN
blink
Data transmission in Ethernet
Off
Ethernet connection abnormal
On
Ethernet is connected
Signal
Off
No signal, or signal checking is not ready
blink ( 2 seconds for
on, and 2 seconds
for off)
Signal bar is 1
blink ( 1 seconds for
on, and 1 seconds
for off)
Signal bar is 2
blink ( 0.5 seconds
for on, and 0.5
seconds for off)
Signal bar is 3
Chapter 3
3 Software configuration
1.Overview
2.How to log into the Router
3.How to config web

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
3.1 Overview
H685 series routers with built-in WEB interface configuration, management and debugging
tools, user should configuration the parameters first; and it could be altered the parameters
flexibility and software upgrades and simple testing. User can set up and manage the
parameters of the router on its interface, detail step are bellow:
3.2 How to log into the Router
3.2.1 Network Configuration of the Computer.
The router default parameters as follow
Default IP: 192.168.1.1, sub mask: 255.255.255.0.
There are two ways to set the PC’s IP address.
Way 1) Manual setting
Set the PC IP as 192.168.1.xxx (xxx = 2~254), subnet mask: 255.255.255.0, default
gateway: 192.168.1.1, primary DNS: 192.168.1.1.
Way 2) DHCP
Choose “Obtain an IP address automatically” and “Obtain DNS server address
automatically”.

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
After IP setting, check it by ping. Click Windows start menu, run, execute “cmd” command.
Input “ping 192.168.1.1” in the DOS window.

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
This information means the connection is work.
This information means the connection is failure. If so, please check the network cable
connection and IP address setting, and can refer to Chapter 4.9.
3.2.2 Log into Router
⚫Open the Web Browser, and type http://192.168.1.1 into the address field and press
Enter bottom in your computer keyboard.
⚫Type User Name “admin” and Password “admin” in the Login page, and then press the
“Login” button.
⚫If you type into the correct User Name and Password, you will get the access into the
Router’s status overview page.

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
3.3 Router status
3.3.1 Status overview
Click “Status” in the navigation bar, and then click “Overview”.

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
3.3.2 Network status
Network status pages show detail information of cell mobile interface, WAN and LAN.
Cell mobile interface page:

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
WAN status page:

H685 User Manual
E-Lins Technology Co. Limited
Tel: [phone] E-mail: [e-mail] www.e-lins.com
LAN status page:
