E-matic EHB150C User manual

Ematic_EHB150C_Instructions_Rev01
INSTALLATION INSTRUCTION
EHB150C
Please read these instructions before installation and retain for the user/maintenance engineer for future reference
•perating Temperature -40～+40℃
•IP65
Model Input Voltage Powe
Facto Watt Total Watt Incl D ive CRI Colou Tempe atu e
Input
Cu ent
Dimensions
(mm)
Lumen
Output
Net
(Kg)
EHB150C 100-277v AC ≥0.9 150W 138-157W >80 4000K 1.8A Φ 276*180.5 19,000 3.2
IMPORTANT
Installation must be carried out by a skilled electrician who is familiar with the appropriate standards and
technical requirements of the appliance also taking in to consideration the latest building regulations.
The person carrying out the installation is to check and verify that the total load on the circuit, including
the rating of the cable, fuse and/or circuit breaker is not exceeded
Ensure there is adequate ventilation around the luminaire
Ensure the AC supply is isolated before installing or servicing
This product must be earthed
DO NOT look or stare at the LED fitting directly when in close proximity once illuminated
Never modify the unit, there are no user serviceable parts inside

Ematic_EHB150C_Instructions_Rev01
FIG . 1
FIG . 2
FIG . 3
YOKE ASSEMBLY :
• Locate the yoke and the accessories bag inside the box, (see Fig 1)
• Attach the yoke to the luminaire as per Fig. 2.
• Ensure the luminaire is securely fixed to a surface/ceiling free from vibration, see Fig. 3.
• Ensure the cable is slack enough to ensure the angle of the fitting can be altered unhindered
• Wiring connection:
Connect wires into wiring terminal; Blue/White wire to “Neutral” terminal, Brown/Black to “Live” terminal,
Yellow/Green wire to terminal. See Fig.7.
Suspension Ring Mount
• Locate the suspension ring in the accessories bag inside the box (see Fig. 4)
• Install the ring to the luminaire. (see Fig. 5) a nd feed the cable though
• Hang the luminaire to a suitable mounting, ensure the suspension and ceiling fixing can exceed the
weight of the luminaire (see Fig. 6).
• Wiring connection:
Connect wires into wiring terminal; Blue/White wire to “Neutral” terminal, Brown/Black to “Live” terminal,
Yellow/Green wire to
terminal. See Fig.7.
Yoke
M8*16Bolt
M4*8Screws
Adapter

Ematic_EHB150C_Instructions_Rev01
Figure 4 Figure 5 FIG . 6
Wiring Diagrams:
Fig 7: Without the external sensor
Live(Brown /Black)
Neutral
(
Blue
/White)
DIM
-
(Grey)
DIM+(Purple)
Earth
(Yellow/Green )
Ring Hook
OR Ensureseal
(0
-
10V/PWM/VR)
FIG . 7

Ematic_EHB150C_Instructions_Rev01
Maintenance
Repairs should only be carried out by suitably qualified person.
Regular cleaning of luminaires should be carried out at regular intervals not only to ensure good optical performance
but also ensure that dirt does not accumulate to such an extent as to impair the electrical or thermal safety of the
fitting, this should be done with the luminaire switched off and isolated, and with a soft damp cloth, do not use any
chemicals or abrasives.
Servicing should only be carried out after the fitting has been made electrically safe, isolated and if any emergency
pack are fitted are also disconnected.
Light Sou ce Maintenance: the light source of this luminaire is not replaceable; in case the light source need to be
replaced (e.g. at the end of its life), the whole luminaire shall be replaced.
Wa anty:
This product is covered by an extended warranty for 5 years from date of purchase.
The extended warranty is available for installations in the UK or Ireland by a competent person in accordance with
the current building and IEE wiring regulations.
If the defective product is no longer available then Challenger may provide alternatives of similar specification and
quality.
The ambient temperatures and environment and voltage range according to manufacturer specifications are not
exceeded
The product is not exposed to any adverse mechanical stresses or impact
For full terms and conditions in regards to our extended warranty please refer to the website.
Due to our policy of continuous improvement we reserve the right to change specification without prior notice. Errors and omissions
excepted. These instructions have been carefully checked prior to publication. However, no responsibility can be accepted by Challenger
for any misinterpretation of these instructions.
E-Matic Ene gy Management Solutions
Dist ibuted by Challenge
10 Sandersons Way,
Blackpool, FY4 4NB
Email: [e-mail]
Web: www.e-matic.co.uk
