Eagle Group A218901 User manual

EG9988 Revised 08/05
PART #A218901
ASSEMBLY INSTRUCTIONS
Dolly Truck
Eagle Foodservice Equipment, Eagle MHC, SpecFAB, and Retail Display are divisions of Eagle Group. ©2005 by the Eagle Group
• 100 Industrial Boulevard, Clayton, Delaware 19938-8903 U.S.A. • www.eaglegrp.com
• Phone: [phone] • (Foodservice) 800/441-8440 • (MHC/Retail) 800/637-5100
• Fax: [phone] or 302/653-3036
CAUTION
INSPECT CONTENTS IMMEDIATELY AND FILE CLAIM WITH DELIVERING CARRIER FOR ANY DAMAGE.
SAVE YOUR BOX AND ALL PACKING MATERIALS. YOU ARE RESPONSIBLE FOR DAMAGE TO
YOUR UNIT IF RETURNED IMPROPERLY PACKED.
(continued on back page)
Before assembly:
Unscrew the leveling foot
from each post.
leveling foot
post
post
frame
leveling foot
Step 1 - Attach posts to frame
using leveling feet.

ASSEMBLY INSTRUCTIONS
Dolly Truck
Eagle Foodservice Equipment, Eagle MHC, SpecFAB, and Retail Display are divisions of Eagle Group. ©2005 by the Eagle Group
• 100 Industrial Boulevard, Clayton, Delaware 19938-8903 U.S.A. • www.eaglegrp.com
• Phone: [phone] • (Foodservice) 800/441-8440 • (MHC/Retail) 800/637-5100
• Fax: [phone] or 302/653-3036
Step 2 - Attach shelves.
Repeat Step 2, attaching each shelf at desired height, until all shelves are attached.
Snap split sleeve onto each post at
the same height (the wider part of
the taper goes toward the bottom).
split
sleeves
split
sleeve
dolly truck fully assembled.
shelf
collar
post
Lower shelf onto split sleeves.
(End)
