Eahora PXiD P5 User manual
Content
1. Must read before assembling and riding ............................................................................................................. 1
2. Unboxing and checklist.......................................................................................................................................... 3
3. Installation instructions ......................................................................................................................................... 5
4. Operating instructions ........................................................................................................................................... 7
5. Moving and storage instructions ........................................................................................................................ 12
6. Ebike maintenance instructions ......................................................................................................................... 18
7. Frame code & motor code ................................................................................................................................... 22
8. Warranty service................................................................................................................................................... 23
9. Safety instructions ............................................................................................................................................... 25
10. Legal statements.................................................................................................................................................. 28
1
1. Must read before assembling and riding
1. Please read this manual throughout before assembling this e-bike or the rider’s first time riding it.
2. Before unboxing, please check the shipping damages on the box and take the photo(s) to record it.
3. You may need a friend’s assistance to avoid hurting yourself or damaging the bike when unboxing.
4. The serial number is on the right side of the head tube. Please take a photo of it and back it up. It’s required for ：
• warranty;
• insurance;
• lost & found;
• report a stolen bike.
5. Seriously check ：
• the brake system (both front and rear) works fine;
• the handlebar steers smoothly;
• the frame & other construction components are intact;
• all bolts and screws have been tightened properly before your first ride.
6. Know and obey the local traffic regulations.
7. Do necessary tests (brake, steer, shift, etc.) and wear a helmet before every ride.
8. DO NOT pursue high speed, haul overload, or carry a passenger.
9. The owner is responsible for using and maintaining it according to our instructions and suggestions.
10.The battery and bike can be dangerous with improper operation and maintenance. Please keep the “Safety instructions” in mind and take
care.
11.DO NOT modify the original components or use a third-party aftermarket replacement part before confirming with us.
2
E-bike specifications
You can choose the appropriate version according to your own needs, and in the future P5 will launch various optional upgrade accessories
and color style kits, please consult your dealer for details.
Model P5
Battery 48V 20Ah Removable battery
Charger 54.6V DC American charger
Motor 750W
Range 32 ~ 38 miles with throttle only,
38 ~ 44 miles with pedal assist ( load is about 198lb)
Top speed 28 Mph
Tire 24*4.0 Inch
Brakes Front and rear hydraulic disc brakes, 180mm rotors
Payload capacity 330Ib
IP rating IPX4
Enviroment of use -10~40°C( 14~104°F ) indoors and outdoors
Net weight 84.8Ib
Size 1850*700*1070mm
Age required / recommended height 16 years old / 5.4 ~ 6.2ft
3
2. Unboxing and checklist
1. Take the bike and all items on the Checklist out of the box.
2. Remove all wrapping materials and put them back into the box.
3. Recycle the box and wrapping materials after 15 days or when you decide to keep the bike.
4
Handlebar * 1
User manual * 1
User manual
Hexagon wrench * 3
13-15#
wrench * 2
Headlight * 1 Pedal * 2 Saddle * 1
P5 Bike frame * 1Front wheel * 1
Charger * 1
Accessories
If there are missing parts or shipping damages to be found, please contact us within 15 days from receipt of the bike.
4# 5# 6#
5
3. Installation instructions
1. Fix the front, unscrew the screws on the
slot first, and correspond the horizontal kit to
the slot.
2. Secure the horizontal kit, tighten it with
a hexagon screwdriver, and finish the
installation, as shown in the figure above.
3. Install the saddle, open the lock and insert
the saddle first.
4. After the saddle is inserted, make sure that
the seat does not turn back, do not shake,
and the lock is tightly fixed.
5. Place the gasket ①inside of the bracket,
pass through the screws, and install the
headlights.
6. Remove the front fork protector rod ①and
the front splinter protection plate ② as shown
in the figure above.
�
6
7. Place the wheel brake disc at the front clip
①, and point the wheel snap release lever at
the front fork dropout.
10.Turn the right foot clockwise and slowly
spin in, tighten it with a wrench, so as not to
cause slippery teeth.
8. Put the wheels right and check the gap
between the brake disc and the clamp, after
the installation, tighten the nuts on both sides.
11.T wist knob ①to lock/activate the shock
absorber; Air shock absorbers cannot be
adjusted by twisting the knob.
9. Install the pedal, to left and right sides of the
foot, and twist the left one counterclockwise.
12.As shown in the figure, the hydraulic brake
has a built-in screw , which can adjust the grip
distance.
�
R�
L
7
4. Operating instructions
Reflector
Keyboard
Shifter
Charge port
Display
Motor
Bell
Freewheel
Battery housing
Derailleur
Reflector
8
Brake lever
Shock absorber
Saddle
Headlight
Front fork
Rear tire
Front tire
Rear disc brake
Front brake rotor
Pedal
Kick stand
9
Display
Battery
Mode
Error code Headlight
Total milage
Trip mileage
Max speed
Average speed
Speed
km/h
MPH
Current speed
Walk
10
Head combination switch
Plus button
Minus button
Power button
Throttle
Info-switch button
Bell
Headlight button
Shifter
Power button Long press to start working and power the controller. In the boot state, long press the button to turn
off the power supply.
Plus button Short press key to switch the electric vehicle power gear to change the output power of the motor.
Press and hold for three seconds to turn on the high beam.
Minus button Long press to a power implementation state, the bike travels at a constant speed of 3km/h Also,
screen display works. Release the button immediately returns to the booster state.
Info-switch button Short press the key display information switches between the total mileage (km), single mileage (km),
maximum speed (km/h), and average speed (km/h).
Headlight button Press the button to turn on the near-light lamp and press it again to turn off the near-light lamp.
In the factory default setting, if the electric vehicle is not used for more than 10 minutes, the instrument will automatically shut down.
11
Error code meaning sheet
Error number Failure type Error number Failure type
E001 Controller error E004 Throttle error
E002 Communication error E005 Brake lever error
E003 Motor hall error E006 Motor error
12
Check before riding
Tire pressure examination
Riding in Wet Conditions
Riding at Night
5. Moving and storage instructions
To reduce the occurrence of accidental injuries, the following items should be checked before each ride:
1. Check bike status, tire and brake effect, etc. Ensure that no parts including the handlebars, risers, tires, brake lines, brake handles, fenders,
and screws show any signs of loosening or damage.
2. When the power is low, the electric bike/scooter does not have enough power to maintain normal cycling. Please make sure that the power
is sufficient to avoid danger.
3. Must wear a helmet and a full set of knee pads, wrist pads, elbow pads, wear sports shoes, and wear clothes suitable for sports. Long hair
or enough to affect the line of sight bangs, broken hair should be tied up, so as not to block the line of sight affect normal riding.
4. For your first ride, please do not choose the areas where children, pedestrians, pets, vehicles or other obstacles and potential hazards may
occur.
Inflate tires to a pressure within recommended range: 35P.S.I in summer, 40P.S.I in winter. Check the tire pressure of both wheels before riding
to ensure the tires are inflated to the recommended pressure.
This electric bicycle can withstand light rain and small splashes but is not designed to be subjected to inclement weather, heavy showers, or
submersion in water. Use caution when riding in wet conditions as it will take longer to use the brakes to slow down, and also when turning as
the tires may slip. The electrical components on the e-bike are not waterproof, and water damage is not covered under warranty.
Riding at night comes with more risks than riding during the day due to decreased visibility so riders are encouraged to exercise increased
caution. Before riding at night make sure that reflectors are installed on your e-bike. Riders should wear bright-colored clothing at night.
Note: If there are any abnormal signs, please stop using it immediately and contact the after-sales service for testing guidance.
13
Max weight
Important safety instructions
The e-bike can safely carry a total weight of 330 lbs. The recommended loading is 300lbs.Heavier loading than 330lbs will affect the e-bike
performance. Failure to adhere to these weight limits may result in damage to the e-bike, the rack, or cause serious injury to the rider. Note
range and top speed will be affected by the total weight being carried by the e-bike.
1. WARNING - When using this product, basic precautions should always be followed, including the following:
2. Read all the instructions before using the product.
3. To reduce the risk of injury, close supervision is necessary when the product is used near children.
4. Do not put fingers or hands into the product.
5. Do not use this product if the flexible power cord or output cable is frayed, has broken insulation, or any other signs of damage.
6. For all equipment, the instructions shall indicate “This equipment is not intended to be used at ambient temperatures less than ( bike ) 0 °C (
32 °F) or above ambient temperatures of 40 °C ( 104 °F).”
7. For all equipment, the instructions shall indicate “The battery is intended to be charged when the ambient temperature is between ( battery )
0 °C ( 32 °F) and 45 °C ( 113 °F). Never charge the battery when ambient temperatures are outside this range.”
14
1. Preparation:There is a risk of falling and injury, so wear a helmet and
protective gear all the time.
2. Operating: Press on/off to unlock and power on; and
check battery status, if the charge is too low, please charge it
immediately.
3. Start: Adjust the sitting position, slowly
press the accelerator at speed gear; pedal it
after balancing.
4. Speed up: Push shifter can perform from 1
to 7 gears.
5. Slow down and brake: Release the throttle
and slow down. Emergency brake requires a
quick press on the brake lever.
Warning: Quick braking may fall due to insufficient.
15
6. Turning: When turning, lean your center of
gravity slightly and slowly turn your handle.
1. As shown in the picture, ①insert the key
into the battery box lock and turn it to the left.
Move the battery cover in the direction shown
in ②.
2. As shown in the picture, open the entire lid. 3. Hold the button marked with the PUSH,
hold the battery box handle and propose the
battery outward.
7. Get off: After cycling, please park the bike on the flat road and long press
on to turn off the power; drop the foot support to avoid slipping or falling.
Important safety instructions
1
2
16
Duetobatteryself consumptionduringtransportationandstorage,itisnormalforthebatterytobelowornobatterywhenusedforthefirstti
me.Pleasechargeaccordingtothefollowingchargingsteps.Youcanchoosetwowaysforcharging:outsidechargingandwholescooterchar
ging.Donotallowminorstousethechargingequipment.
Wholevehicle charging
Find the charging port above the rear shock absorber, open the rubber plug of the charging port, connect the output end of the charger, then
connect the power supply, and fasten the rubber plug after charging.
