Earlens Photon™ 2 Processor
User Manual

1
Earlens Photon™2 Processor
User Manual

2
Welcome
Thank you for choosing the Earlens Light-Driven Hearing Aid. This user manual
is designed to show you how to use and care for your new Earlens Hearing Aid.
We encourage you to carefully read this entire booklet including the Warnings
and Precautions sections to achieve the maximum benet from your new
hearing technology.
If you have further questions that are not answered in this manual, please contact
your hearing professional or call the Earlens Concierge at 1
-844-234-LENS. You
should always access the most up-to-date version of the Earlens Light-Driven Hearing
Aid Patient Instructions for Use (IFU) at www.earlens.com/IFU. The IFU contains
detailed warnings, precautions, results from Earlens Hearing Aid clinical studies and
information regarding safe and eective EMC use.

3
Getting to Know Your Earlens Hearing Aid .........4
The Lens ...................................................................6
The Photon™2 Processor and Light Tip...............7
The Charger .............................................................8
Mineral Oil .............................................................10
Using your Earlens Hearing Aid .......................... 11
Turning the Processor On/O.............................11
Identifying Left or Right Device ...........................13
Putting on the Processor and Light Tip.............14
Removing the Processor and Light Tip..............16
Changing Volume and Program ........................17
Processor Alerts.....................................................22
Telephone and Cellphone Use ............................24
Charging and Battery Life ...................................26
Cleaning and Maintenance .................................. 27
Daily Care...............................................................27
Oiling Instructions.................................................29
Avoiding Moisture & Heat....................................32
Warranty................................................................33
Troubleshooting...................................................... 34
Warnings................................................................... 36
Precautions .............................................................. 38
Technical Information............................................ 42
Device Labeling Symbols ...................................... 44
Contents

4
Getting to Know Your Earlens Hearing Aid
The Earlens Hearing Aid uses a small Lens placed in your ear by a physician to
activate your natural hearing system.The behind-the-ear Photon™2 Processor
collects sound and transfers it to the Light Tip, which converts the sound signal
to non-visible light. The Lens collects this light and gently activates your natural
hearing system.
There are important components to your Earlens Hearing Aid that will be described
in this section: the Lens, the Processor, the Light Tip, the Charger and mineral oil.
The components that you will interact with include the Processor,
Light Tip, Charger and mineral oil.

5
1Sound enters the microphone on the Processor,
which transforms the sound and sends the
audio signal to the Light Tip.
2The Light Tip converts the audio signal into light
and then projects the light wave to the Lens, which
makes direct contact with the eardrum.
3When the Lens is activated by the light wave,
it vibrates the eardrum gently at dierent
frequencies—resulting in rich, natural sound.
1
2
3

6
The Lens
The Lens is driven by light waves that contain sound information. When the Lens
detects light waves, it gently activates your natural hearing system allowing you to hear
sound. To keep your Lens functioning properly, you must apply Earlens mineral oil
twice a week and avoid placing foreign objects in your ear (such as Q-tips, bobby
pins, and your ngernails).

7
The Photon™2 Processor and Light Tip
The Processor sits comfortably behind your ear. It collects and sends sound signals
to the Light Tip, which then converts the sound signals into non-visible light that is
projected by the emitter. The light from the emitter is collected by the Lens.
Light Tip
Processor
Microphones
Light Cable
Emitter
Vent
User Controls

8
The Charger
The Charger can hold one or two devices. It features a USB-based AC wall power
adaptor as its power source. The Charger includes an LED indicator display to let
you know the charging status of your Processor(s).
Micro-USB
Power Supply
Plug-in
Back View of Charger
Lid
Charging
Status
Indicators
Lid Release
Button
Front View of Charger
Slot Slot

9
Charging Status Indicators
Charging Status Indicators What It Means
One ashing light Charger connecting to Processor
One solid light Battery charging and below 33% charged
Two solid lights Battery charging and above 33% charged
Three solid lights Battery charging and above 66% charged
Four solid lights Battery fully charged
Four ashing lights
Processor not charging; remove from
Charger, re-insert into charging slot and
immediately press top user control
No lights Check that Charger is plugged in and
Processors are correctly in slots

10
Mineral Oil
Mineral oil plays an important role in keeping the Lens in position
and properly working. Apply two pumps of mineral oil to each ear
twice a week, or follow the instructions of your physician if you are
asked to use mineral oil more frequently. If you forget to apply the
mineral oil to your ear as advised, your Lens may stop working or fall
out. In the event that you forget to oil as scheduled, apply oil as soon
as possible and then resume as advised.
Detailed mineral oil use instructions are available in the Care and
Maintenance section of this manual.

11
Using your Earlens Hearing Aid
Turning the Processor O
When you remove your Processor from a plugged-in Charger, it will be ON.
To turn the Processor OFF,
push and hold the bottom
user control for 3 seconds.
Bottom User Control
3 Seconds

12
Turning the Processor On
To turn the Processor ON, push and hold the top user control for 3 seconds.
Top User Control
3 Seconds

13
Identifying Left or Right Device
To identify a left or right device, look at the color of the indicator in the Light Tip.
Left
Blue indicates a
Left device
Right
Red indicates a
Right device

14
Putting on the Processor and Light Tip
It is important that the Light Tip
is placed properly in your ear to
optimally aim the light towards
the Lens.
1
Place the Processor behind your ear,
where it should rest comfortably.

15
2 3
Hold the Light Tip between your thumb
and index nger with the colored dot
pointing up and the Positioning Lip
pointing toward the back of the head.
Slowly insert the Light Tip into your ear
canal. Gently pulling your outer ear up
and back may help with insertion.

16
Removing the Processor and Light Tip
1
Grasp the Light Cable between your
thumb and index nger near the Light Tip
and gently pull it out of the ear canal.
4
Gently push the Light Tip into your
ear canal, pushing it as far as it
will comfortably go, to ensure it is
seated in the correct position.

17
Changing Volume and Program
Your hearing professional can customize your user
controls based on your preferences and needs. User
controls can be set up to change volume, change programs
or have multi-functionality to change both the volume and
programs. Please discuss with your hearing professional
how your user control settings have been customized and
consult the tables on the next few pages for instructions.

18
User Control
Options Action/Press
Volume &
Program
Volume
Increase = Short Press Up
Cycle
to Next
Program
Volume
Increase
Power
O
Volume
Decrease
Volume
Decrease =Short
Press Down
Cycle to Next
Program =Long Press Up (3 seconds)
Power O =Long Press Down
(3 seconds)
