Earlex WS125US User manual

PLEASE EAD THESE INST UCTIONS CA EFULLY BEFO E USE
Thank you for purchasing an Earlex Steam Wallpaper Stripper. This is a highly versatile
machine for use all around the home. In order to obtain the best results please read the
instructions before commencing any work.
Please also make a special note of the safety rules and
ETAIN FO FUTU E EFE ENCE
Earlex Inc. will accept no responsibility for the use of this product if used for any purposes other than those
detailed herein.
GO TO WWW.EA LEX.COM TO EGISTE YOU P ODUCT
VEUILLEZ LI E ATTENTIVEMENT CE MODE D'EMPLOI AVANT UTILISATION
Nous vous remercions d'avoir acheté la décolleuse de papier peint à vapeur Earlex. Cet appareil très polyvalent peut être
utilisé dans toute la maison. Afin d'obtenir les meilleurs résultats, veuillez lire le mode d'emploi avant de commencer tout
travail. Veuillez également porter une attention particulière aux règles de sécurité et
CONSE VE POU ÉFÉ ENCE ULTÉ IEU E
Earlex Inc. ne saurait être responsable pour une utilisation de cet appareil dans des buts autres que ceux qui
sont décrits ci-après.
ALLEZ SU WWW.EA LEX.COM POU EN EGIST E VOT E P ODUIT
DISPOSITIVO A VAPO PA A DESEMPAPELA
INST UCCIONES DE FUNCIONAMIENTO
LEA ATENTAMENTE ESTAS INST UCCIONES ANTES DE USA EL DISPOSITIVO
Gracias por adquirir el Dispositivo a Vapor para Desempapelar de Earlex. Se trata de una máquina altamente versátil para el
uso en toda la casa. Con tal de obtener los mejores resultados, lea las instrucciones antes de empezar a trabajar.
Tenga también en especial consideración las normas de seguridad y
CONSE VE ESTAS INST UCCIONES PA A FUTU A EFE ENCIA
Earlex Inc. no aceptará ninguna responsabilidad por el uso de este producto si se utiliza para un fin diferente a los
indicados en este documento.
VISITE WWW.EA LEX.COM PA A EGIST A SU P ODUCTO
US
FR
U
ES
STEAM WALLPAPE ST IPPE
WS125US

G OUNDINGINST UCTIONS
This product should be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing
an escape wire for the electric current. This product is equipped with a cord having grounding wire with an appropriate grounding
plug. The plug must be plugged into an outlet that is properly installed and grounded in accordance with all local codes and
ordinances.
DANGE ! - Improper installation of the grounding plug can result in a risk of electric shock.
If repair or replacement of the cord or plug is necessary, have your nearest Earlex Authorized Service Center replace it.
Check with a qualified electrician or serviceman if the grounding instructions are not completely understood, or if in doubt as to
whether the product is properly grounded. Do not modify the plug provided; if it will not fit the outlet, have the proper outlet installed
by a qualified electrician.
EXTENSIONCO DS
Use only a 3-wire extension cord that has a 3-blade grounding plug, and a 3-slot receptacle that will accept the plug on the product.
Make sure your extension cord is in good condition. When using an extension cord, be sure to use one heavy enough to carry the
current your product will draw. For lengths less than 50', 16 AWG extension cords should be used, and over 50' use 14 AWG
extension cords. An undersized cord will cause a drop in line voltage resulting in loss of power and overheating.
P OTECT YOU HOME!
The heat generated by the boiler unit can mark carpets, soft furnishings, table tops, cabinets, etc.
To prevent this we recommend placing the unit on a wooden board, tray or other barrier - making sure it will not slip off one side or tilt
during use.
Dust sheets or newspapers are not suitable heat protectors for delicate surfaces.
CAUTION !
Check the state of your plaster before starting work.
Steam can loosen weak, porous or poorly bonded plaster - which also loosens readily if cracked, holed or if the steamplate is held in
one position for too long after the paper is soaked.
Weak plaster can normally be detected by tapping a few areas of wall. A hollow sound indicates that you should proceed only with
extreme care - stopping immediately if you hear a cracking sound or plaster starts to break loose.
The steam stripper is safe for drywall/plaster board surfaces but whatever the material, it is always wise to check a small area before
starting work.
• Stay clear of steam, hose, hose fittings and steam
plate surface. DO NOT place hand in front of steam
plate.
• Ensure boiler is placed on a flat level surface, and
should the boiler become tilted in use - level again
immediately. Failure to do so can result in severe
overheating, complete element failure and void your
guarantee.
• Water drops are hot and may burn skin. Use extreme
caution when using steamplate overhead, and
routinely empty water from steamplate. Wear eye
protection.
• Allow parts to cool before changing accessories
and/or opening filler cap.
• NEVE point steamplate at anyone.
• DO NOT over fill water container.•
• DO NOT strain or kink hose. eplace hose if it is
cracked, worn, or damaged. Never repair a damaged
hose.
• DO NOT allow water to boil dry. Boiling dry may
cause overheating and fire.
• Power cord must be connected to grounded
(3 prong) outlet.
• eplace a worn or damaged power cord. Never
repair a power cord.
•DO NOT pull water container by power cord.
• DO NOT allow water or steam to enter light switches
or sockets.
• DO NOT stand or sit on water container.
• DO NOT modify parts or components. Never repair
damaged or worn parts. Always replace with new,
identical parts.
• Water container must rest on a sturdy, level surface
and in an upright position.
• Keep steamer away from children.
• DO NOT leave steamer unattended.
• Never change tools when the unit is operating.
• Use only standard faucet water. Never add
detergents or chemicals.
SAFETY ULES
US
2

PEPA ATION
To achieve efficient paper removal always gently score the areas to be stripped.
With heavily embossed, vinyl coated or painted papers this is essential. Either use a proprietary perforator tool or
alternatively score the paper with the edge of a wall scraper in a ‘criss-cross’ pattern with 6 inch spacing.
As with all decorating work be sure to protect carpets and furniture with covers.
ST IPPING: Remember to check a small area first.
Operation is simple for both right and left-handed people.
Simply hold the steamplate flat against the wallpaper for approx. 10 seconds. Now move the steamplate to the spot immediately next
to the one just steamed - from which the paper should now easily come away with a little help from a wall
scraper. Working this way should enable continuous paper removal although it may be necessary to steam for
longer periods with some papers, or if not completely removed first time.
Operate steamer until water level is low, then unplug unit and allow to cool for at least 2 minutes
before removing filler cap and re-filling unit.
BEWA E OF STEAM!
When finished, allow to cool completely and empty unit. Always store unit empty.
SAFETY CUT-OUT
A safety cut-out is fitted to prevent overheating the element if the water boils low. If unit stops boiling during use this
may be the cause. Wait for 2 minutes before removing filler cap then re-fill with water. The cut-out will self-reset and
steam be produced again within 5-15 minutes.
The cut-out will not protect the element if a part-filled unit is tilted during use in a way which enables part of
the element to be out of the water for longer than 15-20 seconds. Failure to do so can result in severe
overheating, complete element failure and void your guarantee.
OTHE USES FO THE STEAMPLATE
Textured Wall Coatings
Normally textured wall coatings can be removed using the same method as for wallpaper although the steaming time will be longer.
CAUTION! Some textured finishes may contain asbestos which may be hazardous to health and which are subject to licensing
controls.
Vinyl Floor Tiles
inyl floor tiles can also be removed if the steamplate is left long enough for the heat to penetrate the
adhesive. Once the adhesive is hot it softens and the tile can be peeled from the floor.
Disinfecting Soil
To disinfect soil in seed trays or greenhouses rake the soil to obtain a fine surface. Leave the steamplate
on each section, for 2 to 2 1/2 minutes which should ensure that the steam has penetrated the surface.
Killing Weeds
Steam will kill weeds on paths and patios without the use of chemicals. You will need to steam the weeds
for 1 to 1 1/2 minutes in order to kill them.
OPE ATION
The unit is designed for safe, fast removal of wallpaper but please be aware that steam is produced at 212oF, so be careful, wear
protective clothing and protect your hands with heat-resistant gloves or mitts.
FILLING:
The capacity of 4 litres (9 pints) provides approx. 105 mins (1500W) or 150 mins (1200W) steaming time before the safety cut-out
operates.
For a shorter steaming time use less water. Do not overfill the unit or hot water will be forced up the steam hose
Screw hose onto threaded outlet of steamplate, hand-tight is sufficient. Do not over-tighten but do check for hand-tight fit from time
to time during use.
Connect mains lead from unit to power socket and switch on. lt can take up to 24 mins (approx.) before steam is produced -
depending on fill water quantity and temperature.
Do not leave unattended and keep children & pets out of the room.
Just before full steam production a small amount of bubbling and water will occur at the steamplate.
Beware of hot water discharge prior to steam emission.
US
SYMBOLS
CAUTION STEAM IS HOT! WA NING: Hot liquid or steam can burn. Danger of scalding. Steam may
also condense into boiling droplets. Steam should not be directed
towards electrical appliances. Danger of scalding appears on the cap
as either symbol.
3

TROUBLESHOOTING
Unit Fails to Boil
The unit has probably not been left for long enough to cool; refer to section on safety cut-out.
If using an extension lead check that it is fully unwound and of the correct rating (see page 3).
Unit Leaks Steam from ressure Relief Valve
The pressure relief valve is a special low pressure valve and cannot be replaced by any other valve. If steam is leaking from the
valve, the most likely cause is a blockage in the hose. Allow the hose to cool then remove the hose and check for any blockage.
Always check the inlet in the tool you are using.
UNDER NO CIRCUMSTANCES FORCE THE VALVE SHUT. THIS IS OPERATING FOR YOUR PROTECTION.
DESCALING
To maintain peak performance of the unit, particularly in areas of hard water, it may be necessary to descale the element in the unit.
Proprietary kettle descaling products can be used in your unit - always follow the manufacturer’s instructions.
Always wear a glove or mitt for added protection.
IF YOU REQUIRE FURTHER ASSISTANCE LEASE CONTACT OUR HEL LINE ON:
Tel: [phone] email: [email protected]
WARRANTY
This product is guaranteed for a period of 24 months against faulty materials and workmanship.
Whilst every possible care is taken by Earlex to ensure that our products leave the factory in good working order, Earlex cannot
under any circumstances accept liability for problems or damage caused by their subsequent use.
It is the responsibility of the user to ensure that surfaces to be treated, cleaned or stripped are suitable for steam.
This warranty does not affect your statutory rights. This warranty excludes the use for hire purposes.
In the event of a fault occuring please contact our helpline before returning the unit to our Service Department at the address
below together with a copy of your purchase receipt. All repairs will be dealt with speedily.
Wagner SprayTech Corporation
1770 Fernbrook Lane, Plymouth, N 55447
Tel: [phone] Website: www.earlex.com
© Earlex Inc. 2014
