EarthWise LM71313 User manual

OWNER’S MANUAL
13A Electric Leaf Mulcher
Copyright All Rights Reserved.
Model LM71313
WARNING: To reduce the risk of injury, the user must read and understand the owner’s
manual before using this product.
Thank you for your purchase.
DO NOT RETURN THIS PRODUCT TO THE STORE. OPERATING,
ASSEMBLY, PARTS, SERVICE QUESTIONS? GO TO
WWW.AMERICANLAWNMOWER.COM OR CALL 1-800-633-1501
BETWEEN 8:00 AM—5:00 PM EST FOR ASSISTANCE.
SAVE THIS MANUAL FOR FUTURE REFERENCE
This leaf mulcher has been engineered and manufactured to our high standard for dependability, ease
of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free
performance.

TABLE OF CONTENTS
Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety Precautions / General Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Operating Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . 8
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Parts and Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2
Model LM71313

SPECIFICATIONS
Model…………………………………………. LM71313
Rated voltage………………………………… 120V AC 60Hz 13A
No load speed……………………………….. 8,000/RPM
Max cutting diameter………………………... 13 in.
Trimmer Line Dimension…………………... 0.09 in.
Net Weight…………………………………… 21.8 lb (9.9 kg)
3
Model LM71313
Intended use
This leaf mulcher is designed to shred leaves, grass clippings, pine needles, etc. It can not be used to
shred branches, sticks or brush. The machine is only for house-hold use.

Precautions that involve your safety.
SWITCH OFF! Remove plug from outlet immediately if the cord is damaged or cut.
SWITCH OFF! Remove plug from outlet before cleaning or maintenance.
Do not use in wet weather conditions.
Read the owner’s manual.
Wear eye protection, dust mask protection, and ear protection.
Wear glove protection.
Wear foot protection.
DANGER! Rotating blades. Keep hands and feet out of openings while leaf
mulcher is running.
DANGER! Of being hit by thrown objects.
Keep bystanders at a safe distance.
Double Insulation
SYMBOLS
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling
advice.
4
Model LM71313

SAFETY PRECAUTIONS
TO REDUCE RISK OF INJURY : Before any
use, be sure everyone using this product
reads and understands all safety instructions
and other information contained in this
manual.
CAUTION: Wear appropriate personal
hearing protection during use. Under some
conditions and duration of use, noise from
this product may contribute to hearing loss.
WARNING: When using electric gardening
appliances, basic safety precautions should
always be followed to reduce risk of fire, electric
shock, and/or personal injury.
Save these instructions and review frequently
prior to use and in instructing others.
READ ALL INSTRUCTIONS
GENERAL SAFETY
REPLACEMENT PARTS–When servicing use
only identical replacement parts.
AVOID DANGEROUS ENVIRONMENTS-
Don’t use this product in rainy, stormy, damp
or wet locations. Do not operate in gaseous or
explosive atmospheres. Motors in these
products normally spark, and the sparks might
ignite fumes. Do not use in rain.
DRESS PROPERLY- Don’t wear loose
clothing or jewelry and wear protective hair
covering to contain long hair. They can be
caught in moving parts. Use of rubber gloves
and substantial footwear is recommended
when working outdoors.
USE SAFETY GLASSES- Wear safety
glasses with side shields or goggles that
are marked to comply with ANSI Z87.1
standard when operating this product.
USE DUST MASK - Wear face or dust mask
when operating this product.
USE HEARING PROTECTION - Wear ear
plugs or muffs when operating this product.
GROUND FAULT CIRCUIT INTERRUPTER-
(GFCI) protection should be provided on the
circuit (s) or outlet (s) to be used for this
product if you are using an extension cord.
Receptacles are available having built-in GFCI
protection and may be used.
DOUBLE INSULATION – This product has
double insulation. This means that all external
metal parts are insulated from the electrical
supply. This is achieved by introducing an
insulation layer between electrical and
mechanical parts. The double insulation
guarantees you the greatest possible safety.
EXTENSION CORD– Make sure your extension
cord is in good condition. When using an
extension cord be sure it is heavy enough to
carry the current your product will draw. An
undersized extension cord will cause a drop in
line voltage resulting in loss of power and
overheating. The following table shows the
correct size to use depending on cord length and
nameplate ampere rating. If in doubt, use the
next heavier gage. The smaller the gage number,
the heavier the cord.
To reduce the risk of disconnection
from the extension cord during use
you can make a knot as shown. It is
also possible to tie more than one
extension cord in a knot as shown to
prevent them from becoming
disconnected during use.
POLARIZED PLUGS-To reduce the risk of
electric shock, this appliance has a polarized
plug (one blade is wider than the other) and will
require the use of a polarized extension cord.
The appliance plug will fit into a polarized
extension cord only one way. If the plug does not
fit fully into the extension cord, reverse the plug.
If the plug still does not fit, obtain a correct
polarized extension cord. A polarized extension
cord will require the use of a polarized wall outlet.
This plug will fit into the polarized wall outlet only
one way. If the plug does not fit fully into the wall
outlet, reverse the plug. If the plug still does not
fit, contact a qualified electrician to install the
proper wall outlet. Do not change the equipment
plug, extension cord receptacle, or extension
cord plug in any way.
5
Model LM71313
Minimum Gage for Cord Sets
Volts Total Length of cord in Feet
120V 0-25 26-50 51-100 101-150
Ampere Rating
More Not More American wire Gage
Than Than
0 - 6 18 16 16 14
6 - 10 18 16 14 12
10 - 12 16 16 14 12
12 - 16 14 12 Not Recommended

WARNING: To reduce the risk of electric
shock, use only with an extension cord
intended for outdoor use, such as an exten-
sion cord of cord type SW-A, SOW-A, STW-A,
STOW-A, SJW-A, SJOW-A, SJTW-A. or
SJTOW-A.
DISCONNECT UNIT from the power supply
when not in use or when servicing or cleaning.
Do not leave unattended.
DON’T ABUSE CORD-Never carry or pull
this product by the cord or yank the cord to
disconnect from the receptacle. Keep cord
from heat, oil, and sharp edges.
STAY ALERT-Watch what you are doing. Use
common sense. Do not operate the leaf
mulcher when you are tired or under the
influence of drugs or medication.
STORE IDLE UNIT INDOORS-When not in
use, the leaf mulcher should be stored indoors
in a dry and high or locked-up place, out of
children’s reach.
MAINTAIN UNIT WITH CARE-Keep clean for
best performance and to reduce the risk of
injury. Inspect extension cord periodically and
replace if damaged. Keep handles dry, clean
and free from oil and grease.
CHECK FOR DAMAGED PARTS - Before
further use of the product, any part that is
damaged should be carefully checked to
determine that it will operate properly and
perform its intended function. Check for
alignment of moving parts, binding of moving
parts, breakage of parts, mounting and any
other condition that may affect its operation.
Any part that is damaged should be properly
repaired or replaced. Call our customer
service help line at 1-800-633-1501 for
assistance.
Don’t Force Appliance – It will do the job
better and with less risk of injury at the rate for
which it was designed.
LIGHTING-Only operate your leaf mulcher in
daylight or good artificial light.
DON’T OVERREACH - Keep proper footing and
balance at all times. Wear oil resistant,
rubber soled footwear.
Never leave a running tool unattended. Turn the
leaf mulcher off and wait until it comes to a
complete stop before leaving the work area.
Avoid Unintentional Starting – Don’t carry
plugged-in appliance with finger on switch. Be
sure switch is off when plugging in.
USE RIGHT APPLIANCE– Do not use this
product for any job except that for which it is
intended.
KEEP CHILDREN AWAY- All visitors, children
and pets should stay at a safe distance from the
work area.
WARNING: Some dust and debris created by
the use of this tool could contain chemicals
known to the State of California to cause cancer
and birth defects or other reproductive harm.
Some examples of these chemicals are:
- chemicals in fertilizers
- compounds in insecticides, herbicides and
pesticides
- arsenic and chromium from chemically
treated lumber
Your risk from exposure to these chemicals
varies depending on how often you do this
type of work. To reduce your exposure, work
in a well-ventilated area and with approved
safety equipment, such as dust masks that are
specifically designed to filter out microscopic
particles.
WARNING: California Proposition 65:
This product contains chemicals known to the
State of California to cause cancer, birth
defects or other reproductive harm.
WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov.
GENERAL SAFETY
6
Model LM71313

OPERATING TIPS
• Never allow children or people unfamiliar
with the instructions use the product.
• Keep children, bystanders and pets away
while operating the leaf mulcher. Stop
using the machine while people, especially
children, or pets are nearby;
• Consider the environment in which you are
working. Keep the working area free from
wires, sticks, stones and debris
• Keep in mind that the operator or user is
responsible for accidents or hazards
occurring to other people or their property.
• Work only in daylight or good artificial light
• Avoid accidental starting. Ensure the
switch is in the OFF position before
plugging in. Carrying power tools with your
finger on the switch or plugging in power
tools that have the switch on invites
accidents.
• Never operate the machine with damaged
guards or without the guards in place.
• Before use, examine the power cord and
extension cable for damage or aging. If
there are signs of damage, it must be
replaced by a qualified service technician.
If the cord becomes damaged during use,
disconnect the cord from the power supply
immediately. DO NOT TOUCH THE
POWER CORD BEFORE
DISCONNECTING THE SUPPLY.
• Before using the machine and after any
impact, check for signs of wear or damage
and repair as necessary.
• Keep the power and extension cords away
from the cutting elements.
• Do not expose the machine to rain or wet
conditions.
• Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil,
sharp edges or moving parts. Damaged or
entangled cords increase the risk of
electric shock.
• When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
• Never operate the product when you are
tired, ill or under the influence of alcohol,
drugs or medicine.
• Use safety equipment. Always wear eye
protection. Safety equipment such as dust
mask, non-skid safety shoes, hard hat,
suitable gloves, or hearing protection used
for appropriate conditions will reduce
personal injuries.
• Do not overreach. Keep proper footing and
balance at all times. This enables better
control the power tool in unexpected
situations.
• Dress properly. Do not wear loose clothing
or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose
clothes, jewellery or long hair can be
caught in moving parts.
• Keep hands and feet away from the cutting
means at all times and especially when
switching on the motor
• Take care against injury from the blade
fitted for trimming the nylon line length.
After extending new cutter line always
return the machine to its normal operating
position before switching on.
7
Model LM71313

FEATURES
8
Model LM71313
1. Funnel handle 8. Wheel x 2
2. Funnel 9. Mulch adjustment control dial
3. Clamp 10. On/Off switch
4. Power cord 11. Rubber band
5. Air vent 12. Threaded cap
6. Upper bracket 13. Cutting line
7. Balance bracket 14. Spinning head
PRODUCT SPECIFICATIONS
Model LM71313
Input………………………120V, AC only, 60Hz, 13 A
Funnel Opening…………………………………..9 in.
Cutting Dimension………………………………. 13 in.
Trimmer Line Dimension……………………….0.09 in.

ASSEMBLING
1. Remove all parts from package.
Check all the parts against the list in the manual. If any parts are damaged or missing do not use
the leaf mulcher until the part is repaired or replaced. Call our customer service help line at
1-800-633-1501 for assistance.
2. Take out the lower bracket and axle in the package，find the holes on the left and right
sides, and insert the axle in the direction as shown in Fig.1.
3. On each left and right sides, fix one nut and two nut gaskets respectively. Put a gasket on the wheel
shaft, then install the wheel on the wheel shaft, and finally fix the wheel through a gasket and a nut
(Fig.2).
4. Press the wheel covers into the wheels to cover the ends of the axle. You may use a hammer to
seat them securely over the axles. There may be some clearance between the wheel and the wheel
cover. It is not necessary to press it to the bottom (Fig. 3).
9
Model LM71313
Fig. 3
Fig. 2
Fig. 1
PACKING LIST
- Leaf mulcher - Funnel handle -Upper and lower brackets
- Owner’s manual - Wheel axle - Hardware & Attachment bag
This product requires some assembly.

ASSEMBLING
5. Thread through the holes on both sides of lower brackets and upper brackets and secure with a
bolt （M8x45） and nut（M8） for each side ( Fig 4).
Please note: always follow the directions shown in below.
Fig 5
6. Fit the funnel onto the assembled upper and lower brackets in the direction as shown in Fig 5. Insert
two ends of upper bracket into the slots located on the funnel and fasten the funnel to the
brackets by using screws. Make sure the funnel is placed correctly and securely (Fig. 5).
7. Align the funnel handle with the gaps on lower funnel as shown in Fig.6. When fully seated
into the gaps, secure with buckles.
Fig. 6
Fig. 4
10
Model LM71313

2. Loading Your Machine (See Fig 8)
• With the unit running，feed double handfuls of dry leaves or single
handful of wet leaves into the funnel (Fig. 8).
• Allow the machine sufficient time to shred the load completely and
regain speed before inserting the next handful.
NOTE:Do not overload the machine by letting it labor at low speed; this
may cause the motor to stop.
WARNING: Wear protective gloves while loading the machine. Keep your
hands away from the spinning head and the cutting lines when loading the
machine.
WARNING: Filling the mulcher with unshredded material at a rate faster than
the machine can handle may result in permanent damage to the motor. Always
wear protective glasses and adust mask.
3. Adjusting the Control Dial (See Fig 9)
The control dial regulates the particle size and speed at which material
passes through the unit. When the control dial is set in the COARSE
position, material will process through the unit faster, but will yield a larger
particle size than if the dial were set to the FINE position. The FINE position
setting will discharge the material slower, but will yield the smallest particle
reduction ratio (up to 16 : 1). MEDIUM position can be available to serve
your purpose as needed. For best results, material should be shredded
when dry.
OPERATION INSTRUCTIONS
1. Starting and stopping
Starting: (See Fig. 7a)
Make sure the switch is in the off position. Plug the leaf mulcher into a suitable outlet using an
approved extension cord if necessary. To turn on, insert one finger into the slot and pull the switch
outwards.
Stopping: (See Fig. 7b)
To turn off, use your thumb to push the switch inwards.
WARNING: The motor will continue running for a while after the unit is turned off.
Fig. 7a
11
Model LM71313
Fig. 7b
MEDIUM
GRIND
FINE
GRIND
COARSE
GRIND
Fig. 8
Fig. 9

WARNING! Always turn off the leaf mulcher and unplug the power cord from the outlet before
maintaining the unit.
WARNING! Always wear gloves when cleaning.
Cleaning
1. Use only a warm damp cloth and a soft brush to clean the funnel handle and the funnel.
2. Never spray water on the unit's motor bracket or wash it with water. Do not use detergents or
solvents as these could cause irreparable damage to your leaf mulcher.
3. Make sure the ventilation slots are always kept clean and are free of debris.
4. Remove the funnel handle to clean the inside of the unit. Open the four clamps that secure the
funnel handle and remove the funnel handle (Fig. 10).
5Clean the spinning head and the discharge area. Remove wood sticks or objects that may clog
the cutting lines. Check the lines for damage.
6After cleaning the inside of the leaf mulcher, replace the funnel handle and lock the clamps.
Cutting Lines Replacement
IMPORTANT: Only use original replacement parts specified for this leaf mulcher.
1. Replace the cutting line when a noticeable decrease in mulching efficiency is observed. To
remove the worn cutting lines, cut the old lines and pull the remaining line out of the spinner
head.
2. When installing new cutting lines, feed each end of the new line through the two holes in the post
on top of the spinner head (Fig. 11).
3. Check that the two ends of the line are even in length on both sides (Fig. 12).
MAINTENANCE
12
Model LM71313
Fig. 11 Fig. 12
Fig. 10
Funnel
Handle Clamp

4. Thread the lines through each corresponding ferrule. Ensure that both ends of the line are
straight and are even in length (Figs. 13 – 14).
5. Refer to the above steps to replace another cutting line (Fig. 15)
NOTE: There is a built-in line cutter that will cut and trim the lines slightly longer than desired.
WARNING! For optimal performance, use only replacement cutting lines designed specifically for this
electric leaf mulcher. Monofilament lines having a maximum diameter of 0.09 in. (2.3 mm) and a
maximum length of 13.8 in. (351 mm) long may be temporarily substituted, but this is NOT
recommended. Use of thicker lines, lines made of substitute material, or lines greater than 13.8 in.
(351 mm) long may result in permanent damage to the motor and will void the manufacturer’s
warranty. Immediately replace any worn parts of the spinner head.
When storing the electric leaf mulcher at the end of the season, disassemble the unit and stack the
parts in the following order:
1. Place the funnel into the box.
2. Fit the funnel handle into the funnel.
3. Place the legs in the box beside the funnel.
MAINTENANCE
13
Model LM71313
Fig. 14
Fig. 13
Fig. 15
STORAGE

Problem Possible cause Possible correction
The motor does not run Power failure / unit not
plugged into a working
receptacle.
Check to make sure unit is plugged into a
working outlet. Make sure extension cord is
not damaged.
The material to be shredded
is not pulled in.
The material is jammed in
the feed inlet.
The cutting line is tangled.
Disconnect the power supply and unplug
the funnel handle. Pull the material from the
feed inlet. Replace the funnel handle.
Disconnect the power supply. Expose the
spinning head. Unwrap the tangled lines.
Cutting line becomes worn. Disconnecting the unit from the power
supply. Replace with new line.
TROUBLE SHOOTING
14
Model LM71313
Call us first with questions about operating or maintaining your product at 1-800-633-1501
between 8:00 a.m. – 5:00 p.m. Eastern Standard Time, or get assistance on www.americanlawnmower.com.
CALL US FIRST !!

Call us first with questions about operating or maintaining your product at 1-800-633-1501
between 8:00 a.m. – 5:00 p.m. Eastern Standard Time, or get assistance on www.americanlawnmower.com.
SERVICE
For parts or service, please call 1-800-633-1501 or visit us online at www.americanlawnmower.com. Be
sure to provide all relevant information when you call or visit.
REPAIR PARTS
The model number of this tool is found on a plate or label attached to the housing. Please record the
serial number in the space provided below.
• NAME OF ITEM Leaf Mulcher
• MODEL NUMBER LM71313
• SERIAL NUMBER
CALL US FIRST !!
15
Model LM71313
Always mention the model number when ordering kits/items for this tool.
No. Kit/Item Number Description
1LM-HK-1Hardware Kit
2LM-AF-1Air Filter Kit
3RS91313 Spool Kit
4LM-EB-1Elastic Band
5RS81313 Cutting Line
PARTS AND SERVICE

American Lawn Mower Company
The Great States Corporation
7444 Shadeland Station Way，
Indianapolis, IN 46256
Phone [phone]
www.americanlawnmower.com
In a continued commitment to improve quality, the Manufacturer reserves the right to
make component changes or design changes when necessary.
OWNER’S MANUAL
LM71313 13A Electric Leaf Mulcher
Copyright All Rights Reserved.
Rev. 11/13/2019
WARRANTY POLICY
Two (2) year limited warranty on Earthwise outdoor power equipment.
Earthwise warrants to the original owner that each new product and service part is free from defects in materials
and workmanship and agrees to repair or replace any defective product or part for the warranty period as stated
above from the original date of purchase except for the conditions and circumstances listed below:
This warranty applies only to the original purchaser at
retail and may not be transferred.
Warranty applies if the product is used for personal,
household or family use. Warranty is void if product is
used for commercial, industrial or rental purposes.
Warranty does not include repairs necessary due to
operator’s abuse or negligence (including overloading
the product beyond capacity or immersion in water), or
the failure to assemble, operate, maintain or store the
product according to the instructions in the owner’s
manual.
This warranty is not transferable and
only applies to product sold directly
from an authorized retailer. This warranty
does not apply to any product, new or used, purchased
through unauthorized third-party channels.
ANY INCIDENTAL, INDIRECT OR CONSEQUENTIAL
LOSS, DAMAGE, OR EXPENSE THAT MAY RESULT
FROM ANY DEFECT, FAILURE OR MALFUNCTION
OF THE PRODUCT IS NOT COVERED BY THE
WARRANTY. Some states do not allow the exclusion or
limitation on how long an implied warranty lasts, so the
above limitation may not apply to you.
Products sold damaged or incomplete, sold “as is”, or
sold as reconditioned are not covered under the warranty.
Damage or liability caused by shipping, improper
handling, improper assembly, incorrect voltage, improper
wiring, improper maintenance, improper modification or
the use of accessories and/or attachments not specifically
recommended is not covered by this warranty.
Expendable items that become worn during normal use
are not covered by the warranty.
Warranty does not cover damage caused by cold, heat,
rain, excessive humidity, corrosive environments and
materials, or other contaminants.
Warranty does not include installation, assembly or
normal adjustments explained in the owner’s manual.
The expense of delivering the product to the vendor and
the expense of returning the product or replacement parts
to the owner is not covered by the warranty.
The warranty does not cover normal deterioration of the
exterior finish, including but not limited to scratches,
dents, paint chips or any corrosion or discoloration
caused by heat, abrasive and chemical cleaners.
Proof of purchase, original dated sales receipt, must accompany all
warranty claims.

MANUAL DEL OPERARIO
Trituradora de hojas eléctrica 13A
Copyright Todos los derechos reservados.
Modelo LM71313
ADVERTENCIA: Para reducir el riesgo de sufrir alguna lesión, el usuario debe leer y comprender
el manual del operario antes de usar este producto.
Muchas gracias por su compra.
NO DEVUELVA ESTE PRODUCTO A LA TIENDA. ¿TIENE PREGUNTAS
SOBRE EL FUNCIONAMIENTO, EL MONTAJE, LAS PIEZAS Y EL
MANTENIMIENTO? IR A WWW.AMERICANLAWNMOWER.COM
OLLAME AL 1-800-633-1501 ENTRE LAS 8:00 AM YLAS 5:00 PM,
HORA DEL ESTE DE LOS ESTADOS UNIDOS.
GUARDE ESTE MANUAL PARA CONSULTAS FUTURAS
Esta trituradora de hojas ha sido diseñada y fabricada de acuerdo con nuestros altos estándares de
confiabilidad, facilidad de operación y seguridad para el operario. Si se trata con cuidado, esta
herramienta le otorgará años de óptimo rendimiento y resistencia.

ÍNDICE
Especificaciones del producto . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Símbolos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Precauciones de seguridad / Normas generales de seguridad . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Consejos útiles sobre el funcionamiento . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Caracteristicas 8
Instrucciones de montaje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10
Instrucciones de operación . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Mantenimiento . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13
Lista de piezas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Solución de problemas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Piezas y servicio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Garantía . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2
Modelo LM71313

ESPECIFICACIONES
Modelo………………………………………. LM71313
Tensión nominal …………………………… 120V C.A. 60 Hz 13 A
Sin velocidad de carga …………………….. 8000/RPM
Diámetro máximo de corte ………………... 330 mm (13 pulg.)
Dimensión de línea de recorte…………. 2.3mm(0.09 pulg)
Peso neto …………………………………… 9.9 kg (21.8 libras)
3
Modelo LM71313
Uso indicado
Este triturador de hojas está diseñado para triturar hojas, recortes de césped, agujas de
pino, etc. No se puede usar para triturar ramas, palos o cepillos. La máquina es solo
para uso doméstico.

Precauciones para su seguridad.
¡DESCONECTAR! Retire el enchufe del tomacorriente de inmediato si el cable
está dañado o cortado.
¡DESCONECTAR! Retire el enchufe del tomacorriente antes de realizar una
limpieza o un mantenimiento.
No trabaje en condiciones de humedad.
Lee el manual del propietario.
Use protección para ojos y oídos, y una mascarilla antipolvo.
Utilice guantes de protección.
Utilice calzado de protección.
¡PELIGRO! Cuchillas giratorias. Mantenga manos y pies lejos de las aberturas
mientras la trituradora está en funcionamiento.
¡PELIGRO! Puede ser golpeado por objetos que salen despedidos.
Mantenga a las personas que se encuentran en el lugar a una distancia segura.
Aislamiento doble.
SÍMBOLOS
Los productos eléctricos no se deben desechar junto con los residuos domésticos.
Recicle donde haya centros para tal fin. Consulte a la autoridad local o al distribuidor
minorista para obtener asesoramiento sobre reciclado.
4
Modelo LM71313
