Easy Track RS3003 User manual



corner shelves (3)
corner cleats (2)
Note: 48" corner requires 1 corner shelf kit. 72" corner requires 2 corner shelf kits.This instruction set assumes installing a 72" corner.

shelf pins (10)
offset shelf pins (2)
#8 x 50mm screws (14)
screw covers (14)
AS EASY AS IT GETS.
AS EASY AS IT GETS.
AS EASY AS IT GETS.
RS3003
Corner Shelves
11
2
2

Get the big picture.
Read these installation instructions. Check to see you have all the parts on the
hardware list. If you’re adding optional components, such as drawers, you’ll
find instructions for installing them in their cartons.
Check wall type.
The screws and toggle bolts in the carton should only be used on standard
drywall, wallboard, or sheetrock walls. To attach the system to other walls,
such as cement or block, use suitable wall anchors, available from your local
hardware store.
Remove existing shelves and rods.
Optional: repair any wall holes and repaint now.
Gather the tools you’ll need.
TAPE MEASURE
STUD FINDER
LEVEL
PENCIL
POWER DRILL, NO.2 PHILLIPS, 1/8" & 1/2" DRILL BITS
Accessorize your new closet
Outfit your new Easy Track closet with accessories that hold, sort, and adjust
when you change your mind or your wardrobe.
Apreciamos tus comentarios
Nous apprécions vos commentaires
corner shelves basket shoe shelves
sliding wardrobe rod belt or tie rack

Attach track. Measure desired height at the corner of both
walls. 75.5" above the floor is recommended.
The track height can be adjusted depending on the
individual needs. Using a level, draw a straight line on
each wall out from the corner.

Mounting track 75.5" from the floor will put the top of vertical
panels 84" above floor.
Locate studs. Tap the wall or use an electronic stud
finder to locate studs. Mark wall 1⁄2" below horizontal line.
Studs (2 x 4) are usually located on 16" centers
measured from the left or right side.
Lay out the closet design to determine approximately
where vertical panels will be located. Corner units are
30" wide. Mark locations on wall below horizontal line.
1
Vertical panel location
Mark wall
2
Mark vertical panel locations
30" Wide

Do not install track all the way into the corner in order to leave
room for the corner cleats.
Level line 75.5" from the floor,
then mark stud locations.

Install toggle channels.

Insert toggle into wall.
Slide plastic straps until they align with
each other.
Slide plastic ring along straps until
flange of ring is flush against wall.
Bend plastic straps back and forth until
they snap off, leaving plastic ring in
place.
For holes marked as studs, drill pilot holes with a 1⁄8" drill
bit at holes marked for studs. Attach the track to wall using
#8 x 50mm screws. If a toggle is needed, use a 1⁄2" drill
bit to drill the hole.
   
Use toggle bolts if vertical panels are not within 3" of a stud. Determine the
location of the toggle bolts by holding the track over the horizontal line. Mark
hole locations near the vertical panels. Keep track level. Any toggle bolts
must be installed prior to attaching track to wall. Do not leave end of track
unsupported. It must be attached to wall.
For wall types other than drywall: Use a suitable wall anchor available
from your local hardware store.
3 4
Do not use holes directly behind a vertical
panel. Mark holes around vertical for stud
or toggle bolt.
Vertical panel
location
Track
#6 x 1
/
2"
zinc screws
Toggle bolt
#8 x 50mm screw
Track
Hang vertical panel on track.
5
Vertical panel
Vertical panel
location
#8 x 50mm screw

Remove vertical panel. Install 2nd and 3rd cleat
to end of previously installed one with #8 x 50mm
screws. Two (2) cleats are supplied in one corner
shelf kit. Two corner shelf kits are required for a
72" section.
Position cleat in corner and level with vertical panel.
Screw cleat to wall using two (2) #8 x 50mm screws.

Second hole location is recommended. Top hole will be needed
for top shelf.
6 7
Corner shelves are supported by using either 48" or 72" vertical
panels. Position one of the vertical panels on the floor as shown
with front edge up. Attach bottom and middle corner shelf using
#8 x 50mm screws.

Corner shelves are supported by using either 48" or 72" vertical panels.
These panels can be found in RB1460, RB1448, RV1472, RV1447, or
RV72.
8
#8 x 50mm screw
Push cleats together
screw covers
screw covers
#8 x 50mm screw
#6 x 1
/
2"
zinc screws
Toggle bolt
#8 x 50mm screw
#6 x 1
/
2"
zinc screws
Toggle bolt
#8 x 50mm screw
#6 x 1
/
2"
zinc screws
Toggle bolt
#8 x 50mm screw

Rotate assembly as shown. Position the
second vertical panel on the floor with
the front edge up and next to the corner
shelves. Attach the vertical panel to the two
corner shelves using #8 x 50mm screws.
9
Lift assembled corner unit onto track. Two people
are recommended for this step. Install offset shelf
pins on the underside of fixed corner shelf in the
corner cleat (Figure A). Lift up back corner of shelf
and install offset shelf pin into cleat.
10 Install top shelf. Push shelf pins into vertical panels
and a shelf pin into the corner cleat (Figure B).
Add additional corner shelves if desired.
11
A

offset shelf pins clavijas para estantes
shelf pins
Adjustable shelves

Offset shelf pin
Shelf pins
#6 x 1
/
2"
zinc screws
Toggle bolt
#8 x 50mm screw
