easybike G3 User manual

com.int-easybike.www
0page
Electric Scooter
model G3
User manual
Pleas ready carefully before use.
easybike israel -ultra light mobility
Golan 62, Nirit,44805 , IS AEL
03-9382567,054-6648155

com.int-easybike.www
1page

com.int-easybike.www
2page
1. THE IDING ULE
othe G3 design for use any age begin 9 years old.
oNo need driver license , insurance not must.
omust use hamlet
oThe riding allo ed on pavement and special sign line for bicycle
oNot allo to ride on high ay or fast road
oThe max speed possible is 28 km/h but limit by country regulation.
oavoid ride on slip road , oil , sandy road , grass area
o make sure the air pressures is 40PSI (+- 5 PSI)
o al ays hold the handlebar ith t o hand
odo not use this scooter for jumping, racing etc
oFor one rider only .
oin dark light use the front light and rear light
oFollo carefully your country / city rule
ouse front brake very carefully , slo and soft tuch.
befor your ride check your scooter stability , every thing must be very tightening ,
no shake. If you find any part not tightening correct please use our service. e
like you to be very safe using our product.
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________

com.int-easybike.www
3page
How to fold the scooter
push up by hand the top neck closer.
move the closer to the top inside the hole .
pull back ard . please atch our video
search YouTube for "G3 EASYBIKE" .
OPE ATE THE G3 SCOOTE
The G3 controlled by Remote key for turn on/OFF and alarm
turn on : double click on the electric sign.
Turn Off : One click on the the lock open key.
Alarm on : click on the Lock close key.
Locate your scooter : click on the red bell.
When the dispay is on the scooter ready to go.
each scooter come ith t o remote key.

com.int-easybike.www
4page
Display function
the green led use for battery level indicator
the blue led use to controll the riding option .
Mode a: the max speed is 6 km/h . you must push the scooter first to enable the
throttel to ork.
Mode b: the max speed is 12 km/h . you must push the scooter first to enable the
throttel to ork.
Mode c: the max speed is 28 km/h (no need to push) - lo acceleration .
Mode d : the max speed is 28 km/h (no need to push) - high acceleration.
Mode c and d can be preset for the folo ing speed : 12 , 20 , 28. (km/h)
the default speed for c and d is 12 km/h.
ho to change the speed for c or d .
the max speed preset according the the country regulation.
click the mode til the c led is on.
pull the brake lever + push the throotle for 5 sec.
the speed ill set from 12 to 20.
do it again and the speed ill set to 28 km/h.
same idea for d . do it again the speed ill be 12 etc.
Battery level indicator.
Cut off votage
the scooter cut off voltage to protect the battery . for the controller it is 33v .
for the battery the cut off is 29v
the scooter ill lo er the speed to 12 km/h hen the voltage come to 33v.
at the end , the battery led ill all flash this is sign to the battery ended.
you ill have 100-200 meter to end it.
led voltage
4 39-42
3 36-39
2 32-36
1 <=32

com.int-easybike.www
5page
Handlebar
the throotle located on the right side
change the handlebar high
change the handlebar height
each steering stem can be move up and do n .
you have t o quick clamp to set . open the clamps to change .
close the clamp to set.
please make sure the clamp tightening strongly.
do not up the stem too high .
the correct high is according the the rider comfort .

com.int-easybike.www
6page
Using Brake
the G3 come ith double disk brake front and rear.
Using the front brake must be very careful because it is very strong brake.
use it soft touch and slo . make sure the front heel never block.
Never use the front only to brake. more safe is to use only the rear brake and add
the front only if you need very fast stop.
al ays keep good distance in front to other vehicle to enable safe stop.
since the rider center of gravity is high it is good practice to lay do n hen use
the front brake for fast stop . other ise you can loose the control , the rear heel
can go up quickly if use the front brake too strong.
Adjast and clean the brake
the brake pads need to be clean . dust and sand can come inside and make
noise and damage the brake operation.
clean the brake ith degreaser . the degreaser remove the oil out ,then you can
use ater ith press machine or air compressor.
Adast the brake must be done only by technical professional people.
Never ride the scooter if the brake not operate correct 100% .
good adjust is critical . the brake pads have limit life . replace the pads if need.
don't ait till the pad too thin .
the brake lever must come back hen not in use. if the lever not come back
totally the motor ill not run.
each brake lever connect ith ire to the controller . hen you pull the lever the
motor stop.
if the brake lever damaged please replace ith ne one.

com.int-easybike.www
7page
BATTE Y AND CHA GING
To charge the battery use the original changer from easybike. this charger is set
specially to the battery . use SANS model SSLC084V42 for 36v battery.
charge time : 4.5 hours hen the battery is
ne
during the time the battery capacity get
lo er . the charging time reduce according
to the battry capacity.
NO NEED AND BETTER NOT TO DISCHARGE fULLY.
hen ever you can you can charge.
the led on the charge become red hen charging. once it is become green the
battery is full.
using diffrent charger then the one you got ith your scooter ill avoide your
arranty for the battery, also this can be dangerous for the battery.
keep the rule to save your life and your battery.
please read the charger manual carfully.
Storage : the best voltage for long stroage is 70% of the capacity.
if the battery fully charge the life ill be shorter.
please reae more about ho to keep the battry best in our ebsite.
befor first ride please charge the battery fully. (2-4 hours)

com.int-easybike.www
8page
Battery safe instruction :
• This appliance includes Li-Ion batteries;
do not incinerate batteries or expose to high temperatures, as they may explode.
• Shorting the battery terminals may cause burns or fire.
• Do not place battery pack on et or metallic surfaces.
• When you dispose of the appliance remove the battery and dispose of the
battery safely in accordance ith local regulations.
• You must al ays use the battery in accordance ith the instructions on the
battery label.
• Liquid ejected from the battery may cause irritation or burns.
• Leaks from the battery cells can occur under extreme conditions. Do not touch
any liquid that leaks from the battery. If the liquid gets on the skin ash
immediately ith soap and ater. If the liquid gets into the eyes, flush them
immediately ith clean ater for a minimum of 10 minutes and seek medical
attention. Wear gloves to handle the battery and dispose of immediately in
accordance ith local regulations.
ship BATTE Y by air :
The batteries are considered to be dangerous by the
INTERNATIONAL MARITIME DANGEROURS GOODS regulation ( IMDG ) .Batteries
shall be shipped as class 9 hazardous materials.
Ho ever, if those lithium ion battery or cells are pack ith or contained in an
equipment, then it is the responsibility of the shipper to ensure that the
consignment are packed for that consignment to be declared as
“NOT RESTRICTED” (non-hazardous / non-dangerous) or “DANGEROUS GOODS”.
CHA GING :
use only the charger you got ith
the product .
the charger led light red hen
charge and green mean no charge
the charger automatic stop the
charging once the battery fully
charge.
wheels and tire
keep the air pressure 40psi

com.int-easybike.www
9page
if the air pressure less then 40psi the battery ill ork much harder , the range ill
be shorter and the life of the battery ill be much shorter.
replace the tire if need.
7. USE MAINTENANCE *
Many parts on your E-SCOOTER are subject to a higher degree of ear due to
their function and depending on their use.
Have your E-SCOOTER checked regularly at a professional e-bike shop and have
any orn parts replaced.
After an accident or crash you must take your E-SCOOTER to a bike repair
specialist to make sure that it is safe to ride. Be a are that damage may not be
visible. Failure to do this may result in serious injury.
Any form of crack, scratches or change of colouring in highly stressed areas
indicate
that the life expectancy of the part has been reached and it should be
replaced immediately. Ensure the battery is removed from the bike before
carrying out any maintenance. Make sure that all scre s and bolts are tightened
securely and to the prescribed tightening torques before riding. You must al ays
use genuine replacement
parts hen performing maintenance on your E-SCOOTER.
Regularly check the tyre pressures minimum 35psi, maximum 45psi and regularly
check the tread depth of tyres.
Personal Safety:
• This e-scooter is intended for use as a commuter and leisure e-scooter.
Using the e-scooter for any
other purpose may result in serious injury.
• Before you ride this e-scooter in a busy area or on
public roads, practice riding in a safe area free
from hazards. Take time to learn the e-scooter’s
controls and po er.
• It is your responsibility to identify and follo all
local la s and regulations, including fitting your
e-scooter ith any additional equipment necessary
to comply ith local la s.
• Observe the applicable traffic regulations.
• At night your e-scooter MUST have hite front and

com.int-easybike.www
10page
red rear lights lit. It MUST also be fitted ith a
red rear reflector and amber pedal reflectors
hich are both supplied.
• Never ride ith no hands.
• Adopt a speed that reflects the terrain as ell
as your riding ability.
• Use designated cycle paths hen not using
public roads.
• When riding your e-scooter, ear close-fitting
trousers, or use a e-scooter clip. Loose clothing
can get bet een moving parts and cause injury.
• Wear bright and/or reflective clothing hen
cycling.
• When riding your e-scooter, you should ear a
e-scooter helmet that conforms to
current regulations.
• Your e-scooter saddle should be as close as
possible to horizontal. Do not tilt the saddle
back ards, as this can lead to back pain and
physical injury.
• Take care hen loading your e-scooter into a car or
hen mounting it on a e-scooter carrier.
• We DO NOT recommend that you use a e-scooter
trailer ith your Easybike e-scooter.
• You can fit a standard fitment luggage carrier to
your e-scooter. Please check ith the manufacturer
to make sure that a child seat can be safely
attached to the luggage carrier.
e-scooter Safety:
• You must be over 16 to ride an e-scooter.
• The drive assist system is limited to a maximum
continuous po er rating of 0,25kW (250W) and
a maximum speed of 25Km/h, (15.5 mph).
• Your e-scooter is designed for a maximum
permitted overall eight (rider + luggage +
e-scooter) of 110kg. The maximum permitted
eight of the rider (90kg) plus luggage (20kg)
is 110kg.
• Do not submerge your e-scooter in ater.
• Be a are that the speed at hich you are
travelling may be faster than you are used to,
especially hen accelerating.
Electrical Safety:
• Only use batteries and chargers supplied by
Easybike.

com.int-easybike.www
11page
• Never modify the charger in any ay.
• The charger has been designed for a specific
voltage, al ays check that the mains voltage is
the same as that stated on the rating label.
A charger that is suitable for one type of battery
pack may create a risk of fire hen used ith
another battery pack; never use the charger
ith another appliance or attempt to charge
this product ith another charger.
• Before use, check the charger cord for signs
of damage or ageing. A damaged or entangled
charger cord increases the risk of fire and
electric shock.

com.int-easybike.www
12page
G3 e-scooter specfication
Performace
item Description spec comment
Weight according
to battery
selected
from 12kg to
16kg
according to battery
Speed 4 option for
max speed
preset
6 , 12 , 25 , 28
km/h
Can be set by the
customer or preset
according to country
regulation
Range According
to battery
36v 8.8Ah 25km Flat road , no stop , 75kg ,
no ind .
36v 17Ah 50km
48v 8.8A 30km
48v 17Ah 60KM
Battery cycle life
see battery
spec and
arranty
terms
document
500 cycle If folo the instruction
Motor po er nominal 250
Electric
item Description spec comment
BLDC gear Motor Rear Cast hub
motor
Nominal 250 According to
country regulation
Max 18A

com.int-easybike.www
13page
36v / 48V
Battery Samsung sdi
18650 22p
Li-on battery
ncm chines
brand
36v , 8.8A Standard
Li-on battery 36v , 17A Option 1
Li-on battery 48v , 8.8A Option 2
Li-on battery 48v , 17A Option 3
Controller DHMC Intelligent 15A 36v / 48v ire for Alarm
Alarm cut off the
motor
po er s itch logical s itch
charger socket
display king-meter led
ith multy
function *
charger sans 2A
charer
110-240v , 50-
60-Hz
chare time 4.5H for
8.8A battery
cherger all plug
per customer
country
need to specify
light front led light
+ horn

com.int-easybike.www
14page
body and forks
Item Description
spec comment
Alloy 6005 / 6061
/ 6063 T6
made ith
extrusion +
CNC ALL
ASSY by
scre
Can ship ithout assembly
Water proof 95%
Scre High
quality
stainless
steel scre
M6 , M5 ith
lock
All stainless
steel
Finish treatment T4,T6 Anodize sand
black/silver
head set
sealed bell
bearing
(tai an
made)
Size and wheels
item Description
spec comment
fold size Yes Fold size
130x30x50cm
Open size 130x30x160cm
pack size carton size 42x30x106 cm
Wheels Fron and
rear cast
alluminium
12"

com.int-easybike.www
15page
Tire Standard
Option
Kenda 12 1/2
x 2.125
Tire option INNOVA 12
1/2 X 3"
Need to order in advance
length Distance
bet een
heel
center
960 mm
Brake
Item Description
spec comment
brake lever Wuxing
Rear braek Disk Tektro novella
disk 160mm
standard
Front brake ready for
Disk
Tektro novela
disk 160mm
Optional
Board option
Item Description
spec comment
no Board scooter
body
idth 160mm standard
Bamboo,Mayple
5 layer
carbonize
ood
Wide
board
8mm
thickness ,
idth 260mm
Option
Bamboo,Mayple
5 layer
carbonize ood
nerro
board
8mm
thickness ,
idth 200mm
Option

com.int-easybike.www
16page
