EasyN H Series User manual

We never stop trying!
1
CONTENTS
1.General introduction ....................................................................................................................... 3
1.1.Brief introduction ...........................................................................................................................3
1.2. Applications ..................................................................................................................................3
1.3. Product appearance and interface introduction .............................................................................4
1.3.1. Product appearance ..............................................................................................................4
1.3.2. .Interface introduction ..........................................................................................................4
2. Function introduction....................................................................................................................6
2.1. Basic function introduction ...........................................................................................................6
2.2. Advance function introduction...................................................................................................... 6
3. System requirements .....................................................................................................................8
4. Installation ......................................................................................................................................8
4.1. Connection of network cable and power adpter ............................................................................9
4.2. Connect IP camera to router/switch/hub with network cable ........................................................ 9
5. Access to IP camera ..................................................................................................................... 11
5.1. Access to IP camera though web page ........................................................................................ 11
5.2. Use Finder ................................................................................................................................... 11
5.3. System login................................................................................................................................ 13
5.4. List of Operation Keys ................................................................................................................14
5.4.1. Stream and operator ...........................................................................................................15
5.5. IP Camera settings.......................................................................................................................15
5.5.1 Device information .............................................................................................................15
5.5.2. Time settings ......................................................................................................................16
5.5.3. System Maintenance ..........................................................................................................16
5.5.4. Network settings ................................................................................................................17
5.5.5. Wireless settings.................................................................................................................17
5.5.6. Remote access settings.......................................................................................................18
5.5.7. User management settings..................................................................................................18
5.5.8. Capture time settings..........................................................................................................19
5.5.9. Email settings.....................................................................................................................19
5.5.10. FTP server settings........................................................................................................... 20
5.5.11. Alarm server settings........................................................................................................ 20
5.5.12. PTZ settings ..................................................................................................................... 21
5.5.13. External alarm settings.....................................................................................................21
5.5.14. Motion detection settings ................................................................................................. 21
5.5.15. Linkage alarm settings .....................................................................................................22
5.5.16. Alarm time settings ..........................................................................................................22
5.5.17. Image parameters settings ................................................................................................ 23
5.5.18. Video parameters settings ................................................................................................23
5.5.19. Audio parameters settings ................................................................................................ 24
6. Brief introduction to Super Client..............................................................................................26
6.1. Installation and Registration........................................................................................................26

We never stop trying!
2
6.2. Add equipment ............................................................................................................................ 26
6.2.1Basic information................................................................................................................. 27
6.2.2. Alarm .................................................................................................................................27
6.2.3Recording.............................................................................................................................28
6.2.4Additional information......................................................................................................... 30
7. Platform introduction..................................................................................................................31
8. Mobile Access ............................................................................................................................... 32
8.1. Smart phone Access .................................................................................................................... 32
9. Others............................................................................................................................................ 35
9.1 Port Forwarding Settings in router ...............................................................................................35
9.2. Spcifications for part of H3 series Products ................................................................................36
10. Frequently Asked Questions......................................................................................................37
11. Product Warranty ......................................................................................................................38
11.1. Warranty Instructions ................................................................................................................38
11.2. Warranty Card........................................................................................................................... 39

We never stop trying!
3
1.General introduction
1.1.Brief introduction
This series product is designed for network video surveillance system,including wired box IP
camera,wireless box IP camera, IR dome IP camera,IR waterproof IP camera etc. . I t adpots high
performance chip to ensure high quality media processor which can process audio and video
collection, compression and transmission at the same time .Standard H.264 compression format
makes video transmission more clearer and smoother. It enables users to realize the real-time
monitor and remote control via browsers like IE, Super-Client sofeware and Application
Platform. It has good stability andcompatibility.It is easy to intall and operate.Users only
need take a few minutes to conncet the ip camera to the network.
1.2.Applications
The series products usually can be appied to public places,such as big
department,school ,factory,workshop etc. High-end cameras are more suitable for the envirement
where powful image processing ability and high definition are needed ,such as bank ,crossroads.
Before intall the IP camera,please check whether the product accessories are all in
your package ,if not ,please contact the distributor as soon as possible.
List of articles：
IP camera…………………………………………………………………………………….1
Bracket(to be equipped by the model) ………………………………………………………1
WIFI Antenna（for wireless model）……………………………………………………….1
Power adapter ………………………………………………………………………………..1
Qualification certificate…………………………………………………………………........1
CD ……………………………………………………………………………………………1

We never stop trying!
4
1.3.Product appearance and interface introduction.
1.3.1. Product appearance
Diagram for dome IP camera：
：：
：Diagram for box IP camera:
1.3.2.Interface introduction.
Extended line interface diagram：
：：
：
Power ：direct current 12V
GPIO alarm interface：accept external connection linkage alarm equipment(for
example: door sensor ,infared sensor)

We never stop trying!
5
Reset line：short circuit two lines with power off,then power on for 10 seconds to
return back default setting.
RJ-45 ethernet interface：connect ip camera to LAN
Backup：follow-up product extend interface.
About GPIO alarm interface (S terminal)definition:
1# +DC12V
2# RS485（A）
3# 地（GND）
4# IO2 （OUT PUT）
5# RS485 （B）
6# IO1 （IN PUT）
GND: Signal ground, Alarm ground, RS485
ground
RS485: RS485 control interface ， The left one is
connected to negative pole of RS485 and the right
one is connected to the positive pole of RS485. It
can be connected to Pan/Tilt or encoder and can support multiple protocols
Warning ：
：：
：Please use the attached power adapter to avoid damaging
the IP camera.

We never stop trying!
6
2.Function introduction
2.1.Basic function introduction
IP camera is mainly used for remote video transmission on the network.It adopt H.264
hardware compression technique, which can realize high-quality and real-time video transmission
at 30fts speed on LAN/WAN.
IP camera run on the entirely open standard TCP/IP protocol,.Built-in web server made
users easy to realize monitoring via IE ,configuring remotely, updating firmware, managing
and maintaining the equipments via network.
It allows you monitor ,control and zoom the image though the internet at anytime anywhere.
2.2.Advance function introduction
* High-density and programmable media processor Hi3512, support H.264 Main Profile video
coding
* Support up to 30 fts
* Adpot H.264 video compression format,which can realize high-quality image transmmison
through limited network bandwidth.
* Support up to 10 users viewing simultaneously
* Built-in web server allows the use of standard IE browser for real-time monitor and
management
* Some models support WiFi 802.11b/g wireless network
* Support system upgrade remotely
* Support dynamic IP address, LAN, and Internet (Router access etc.) )
* Some models support one or two way audio talk back
* Support motion detection function ,four detection areas and sensitivity can be set)
*Built-in guard dog, auto recovery if exception occurs and auto-connection if the internet is
disconnected.
* Support dynamic alarm function to set alarm time periods
* Support email sending ,FTP uploading,external ouputing
* Support mobile view

We never stop trying!
7
Spcifications
System
Features
System security Supports there-level account, password, multi-user authority management
Self-prepared
DDNS(Free)
Free DDNS bounded i.e., http://demo.easyn.hk( body code is demo)
IE multi-screen
client（free）
No need to install software, IE multi-screen monitoring and management,
message alarm setting, save alarm picture
Super Client（free)
1,4,9,16,25,36, 64-channel Super Client software, no user limited,
centralized monitor, remote record and playback , Skype message alarm,
skype telephone alarm
Moile view
Support IPhone、Windows Mobile、Symbian、Android view directly,support mobile
phone with Java MIDP 2.0
CPU
Operation system Embedded Linux system
Microcomputer
processor
High-density and programmable media processor Hi3512
Video
Compression
format
H.264
Signal system PAL or NTSC
Frame rate PAL: 25fps,NTSC:30fps
Resolution
CCD model：D1(720*576), CIF(352*288), QCIF(176*144)
CMOS model：VGA(640*480), QVGA(320*240)
1.0 mega model：720P(1280x720), QVGA(320x240)
Image adjustment Brightness, contrast, chroma, saturation.
Audio Processor
Two way audio（support external connecting MIC and sound box）
Audio gain AGC
P/T control
P/T
Accept external connection RS485
P/T protocol PELCO-D protocol Baud rate: 9600 address: 1
Network
Network interface RJ-45 10/100Mb self-adaptable Ethernet slot
Delay time < 500 MSEL(0.50 second) in LAN
Online visitor
Support up to 10 users viewing simultaneously
IP mold Dynamic IP address, static IP address, PPPOE
Alarm
Input/output 1/1
Alarm dectection Motion detection
Motion detection Support 4 motion detection regions
Alarm action Support Email photo, FTP photo, FTP video etc
System System requirments Microsoft Win98 SE/ME/2000/XP、Vista, Internet Explorer 5.0, NET4.5 or above
Certificate Certification ISO FCC CE

We never stop trying!
8
3.System requirements
Minimum Hardware Configuration
CPU : Pentium 1.6Ghz
Memory : 256MB
Sound Card : Necessary for audio monitoring and two-way talking
Hard Drive: To record video, minimum 40G Operation
System : 32 or 64 bit Windows2000、WindowsXP、Windows2003、Windows Vista etc.
Software environment
IE 6.0 or above
DirectX8.0 or above version
TCP／IP network protocol
2.1. 4. Installation
Accroding to most of usage mode,we summary 3 kinds of networking ways to control ip
camera.
Before you install the ip camera,please do related hardware intallation and software settings
following the below steps.
The following is the overall chart of two connections:：
：：
：
1. Connect an IP Camera to a router
Tips：
：：
：If your ip camera is conneted to network,you can visit the ip camera
directly by free DDNS Service

We never stop trying!
9
2.Connect the IP Camera to the computer Directly
4.1.Connection of network cable and power adpter
Step 1:Connect the crystal head of network cable to RJ45 interface of IP camera
Step 2:Connect the power adpter to ip camera and power on
4.2.Connect IP camera to router/switch/hub with network cable
Connect the other side of the network cable to Ethernet switch ,router or IP sharing device.
Warning :Make sure use the attached power adapter,
unauthorized ones may damage the IP camera.
Check whether the mains voltage(110V or 220v) and
frequency(50x or 60x) of your location is matched
with the description of the label on the power
adapter ,if not ,don’t use it !

We never stop trying!
10
If connecting the LAN successfully ,the green LED light on the RJ45 interface will be
on .If there are datas transmissons on the LAN,orange LED light will flash.
After about one minute,under nomal conditions ,the yellow is normally on ,and green light
flashes ,here physical connection of the IP camera is complete.(For smooth connection,it is
recommended to set up the IP camera to a fixed IP in the same network segment as PC within the
LAN.Please refer to Article 10”Frequently Asked Questions for setting).
Now you can login the main web page and visit the IP camera.

We never stop trying!
11
5.Access to IP camera
There are three ways to access to IP camera as below:
1. Through web page
2. Through super-client software
3. APP platform
5.1.Access to IP camera though web page
After IP camera is connected to PC LAN through router,you could process operations to IP
camera via PC,first please put right CD to CD-ROM and run the related software,as below:
5.2.Use Finder
Open the disk ,CD will run automatically,then appear the following interface:
Choose the second options(IP Camera Finder)to open the Finder,and the following interface
will appear:

We never stop trying!
12
Wizard mode is remmended for primary users,open the IP camera and set device parmeters
according to indication..
Advanced users choose Advance Mode,then the following interface will appea( if the users
connect the camera for the first time ,please click update to set ):
If network cable and power supply are correctly connected, device type, name and IP
address will be shown in the device list (Otherwise, please confirm whether power supply and
network cable work normally).

We never stop trying!
13
In the interface above, the configuration information of the current computer is listed on
the left side; and the network configuration information of the selected device is listed on the
right side. Default IP address of the IP camera is 192.168.1.126, and HTTP port is 81.
Inner Access refers to the LAN access address; Outer Access refers the WAN access
address. 。
5.3.System login
1. Open the Web page. You can open it directly by first clicking the Inner Access or Outer
Access on Finder and then clicking Open; and you can also directly input the corresponding
address of the inner and outer access into the address bar of the web page, as the address
shown in the picture above http://192.168.1.126:81 (LAN); and http://aodn.ipcam.hk (WAN)
2. If the IP camera has been connected with the outer network when you are browsing it, the log-in
interface as below will appear when you open the web page through LAN or outer work.：
Tips:Port forwarding setting is necessary for outer access,please refer to
‘router port forwarding ’in 7.1 section.
Note：
：：
：
1. Device information indicates the IP camera information. 2. When the
current computer has a fixed IP, (namely non-DHCP IP), and the IP
camera is used for the first time, please click automatic setup, so that IP
address of the IP camera, gateway and DNS can be synchronous with the
PC.
3. If it is necessary to manually modify the contents including camera
name, HTTP port, IP address, sub mask, gateway, primary DNS
server, secondary DNS server and so on, please click apply after
modification, and then click OK after entering username and password of
the IP camera in the pop-up dialog box for access validation.

We never stop trying!
14
After selecting the language required, enter the corresponding log-in information, click ok to
log in. Under the address bar, an ActiveX installation pop-up will appear . You can use it
after installation. If the ActiveX intallatioin is held by the Anti-virus software, please release
it.
Note: the default User Name of the camera is “admin”, password is admin.
5.4. List of Operation Keys
After logged on the device, monitor picture is displayed on the left side of the screen, and
the right side is the panel where you can implement the basic operations for the device.

We never stop trying!
15
5.4.1. Stream and operator
1.The default stream is second stream
2.Users can be divided into three kinds: Guest ,user ,admin.Admin own highest
authority, authority is varied as different kinds of users. Plese refer to 5.5.7 section
for more details.
5.5.IP Camera settings
Click ，enter the interface of parameters setting,includings
system settings,network settings,advanced settings,alarm settings,video&audio settings.
5.5.1 Device information
System settings include device info,time settings,system maintenance
Device info is shown as below, including Device Name, Software Version, MAC Address, IP
Address etc.

We never stop trying!
16
5.5.2.Time settings
You can set the time manually, or synchronize time with the PC or NTP server.
5.5.3. System Maintenance
Here you can upgrade the system,restart the ip camera, restore factory default values, please
operate it cautiously.

We never stop trying!
17
5.5.4.Network settings
Here you can set the ip manually or obtain the ip automatically. Make sure do the port
forwarding before visiting though internet. If you choose to set the ip manually,please fill the
right IP Address , LAN Netmask Address, LAN Gateway Address,DNS, Http port.
5.5.5.Wireless settings
There are five kinds security type:none, WEP64,WEP128,WPA-PSK and WPA2-PSK
1.Only the camera SSID is the same as the wireless router or AP SSID ,you can use the camra.As
for other options ,you can choose according to your requirements.
2.The default camera SSID is SSID.

We never stop trying!
18
5.5.6.Remote access settings
When remote access is needed, the dynamic DNS must be enabled, and fill the server
address,server port ,username and password(the default server is user.ipcam.hk,the default server
port is 808 . You can use the other dynamic DNS, such as peanut shell.
UPNP ‘s full name is Universal Plug and Play. If the router support UPnP function and is
enabled on the router, Port forwarding is not necessary when users visit the ip camera via outside
web.
。
5.5.7.User management settings

We never stop trying!
19
Admin is administrator account ,user is operator account ,guest is vistor account.
Note：
：：
：At least one administrator account is needed for the device
5.5.8.Capture time settings
Users can set capture time interval ,and choose if need to send e-mail or save the image to the
SD card according to their requirements..
5.5.9.Email settings
Above setting is equally similar to Mail Server Settings , when alarming is on it will send
pictures，please fill in STMP server ,port,username,password,receiver email address,sender email
address,theme ,information etc.
