Eaton Wright-Line TechOrganizer Corner User manual

1
The Corner TechOrganizer can be installed on Linx
Worksurfaces or appropriate industrial work benches.
LINX Worksurfaces with full depth uprights are
recommended to provide a Workstation/Organizer
with greatest stability.
Important Safety Instructions
* The Organizer must be properly secured to the Work-
surface prior to installing of components.
* Frame load capacity is 300 lbs. (Linx worksurfaces)
400 lbs. (Workbenches).
* Do not install shelves that are greater than 18” deep.
* Do not install shelves more than 35” above the Work-
surface.
1. Assemble Left hand and Right hand Organizer frames
to the Corner post with the 1/4”-20 x 1-5/8” Button
head cap screws provided. See Figure 1.
Corner TechOrganizer
Figure 1
R.H. Organizer
frame
L.H. Organizer
frame
Corner post
1/4”-20 x 1-5/8” Button
head cap screws
Tools Required
-#33 (.113 dia.) Drill (Jobbers length)
-Electric drill
-5/32” Allen wrench (provided)
-Phillips head screwdriver
-Plastic mallet
85081 Rev A 11/20/07
C o r n e r
T e c h O r g a n i z e r

2
2. With two people, position the TechOrganizer in the
desired location on the back of the Worksurface. On a
Linx Worksurface, locate the back of the frame .20”
from the back edge of the Worksurface. See Figure 2.
3. Using the holes in the frame bottom crossbar and the
holes in the feet as a template, locate and drill the
appropriate quantity of .113 dia. holes .50” deep in
the Worksurface. See Figure 2.
NOTE: If the feet are not 90° to the frame, tap the
ends with a plastic mallet to correct.
4. Attach the frame bottom crossbar to the worksurface
using the #10AB x 2.25” Phillips head flat head screws
(provided). See Figure 2.
5. Attach the feet to the Worksurface using the four
#10AB x .75 Phillips pan head screws (provided).
See Figure 2.
.20
Linx worksurface
(with full depth uprights)
Corner TechOrganizer
frame
Foot
#10AB x .75” Phillips
pan head screws
#10AB x 2.25” Phillips
flat head screws
Bottom crossbar
Figure 2
85081
C o r n e r
T e c h O r g a n i z e r

3
Figure 1
T e c h O r g a n i z e r
I n s t a l l a t i o n o n
P h e n o l i c C o r n e r
T e c h B e n c h
Corner TechOrganizer
TOOLS REQUIRED
(1) #19 drill bit (not supplied)
(1) 7/32” drill bit (not supplied)
(1) Electric drill (not supplied)
(1) Phillips head screwdriver
(1) Plastic mallet
(1) 3/8” wrench
Important Safety Instructions
* The Organizer must be properly secured to the Work-
surface prior to installing of components.
* Frame load capacity is 400 lbs. (TechBench).
* Do not install shelves that are greater than 18” deep.
* Do not install shelves more than 35” above the Work-
surface.
1. Position the Corner TechOrganizer in the desired
location on the back of the Phenolic worksurface.
See figure 1.
2. Using the holes in the frame bottom crossbars as a
template, locate and drill the appropriate quantity
of .164 dia. holes .650” deep in the worksurface. See
figure 1.
NOTE: If the feet are not 90° to the frame, tap the
ends with a plastic mallet to correct.
3. Attach the frame bottom crossbars to the worksurface
using the #10 x 2.00” phillips flat head screws
provided. See figure 1.
#10 x 2.00” phillips
flat head screws
Bottom crossbars
TechOrganizer
Corner TechBench with Phenolic top
85081

4
T e c h O r g a n i z e r
I n s t a l l a t i o n o n
P h e n o l i c C o r n e r
T e c h B e n c h
4. Using the holes in the feet as a template, locate and
drill four .218 dia. holes thru the worksurface. Attach
the feet to the worksurface using the four #10 x 1.25”
phillips pan head machine screws, #10 washers, #10-
32 lock nuts and #10-32 acorn nuts provided. See
figure 2.
Figure 2
TechOrganizer
#10 x 1.25” phillips
pan head machine screws
#10-32 lock nuts
#10-32 acorn nuts
#10 washers
Foot
85081
