Eaton MC6-EN User manual

MC6-EN
Installation Manual

2 INSTALLATION MANUAL (25-13288-B) June 2020 www.eaton.com
Installers
Thank you for purchasing the Eaton
MC6-EN ceiling speaker. This product
was tested before shipment and
therefore should arrive in working
condition. If you have any issues with
this speaker, please contact your
supplier in the first instance.
Safety Information
CAUTION
WARNING: Inappropriate use of this
speaker can result in property dam-
age, injury or death.
• Please be sure to read the whole
installation manual
• Please follow all recommendations of
this installation manual
• We recommend you keep this manual
for future reference
If you have any concerns or questions
regarding the points raised in this
manual, please contact your supplier in
the first instance.
Please note:
• The speaker is not waterproof and
is only designed for use inside a
building. Exposure to raise or other
water sources will result in damage to
the unit.
• This unit is design to operate at 100v
AC. Please isolate the speaker cabling
from the source before conducting
any works within the unit
• Ensure the speaker is correctly
installed into a firm recess. Failure to
do so may result in the speaker failing
and causing an injury or death
• Ensure all terminations are fully
tightened to avoid short circuits
forming due to disconnected cables
• Do not install speakers into
humid, dusty, smoky or steamy
environments; the speaker may be
damaged and not operate correctly
• Do not use the fire dome as
junction box for other cables. Only
70V/100V loudspeaker lines should be
connected to this speaker
Installation
Step 1
Pull down the speaker grill from the red
fire dome. Disconnect the grill from the
fire dome by compressing the 2 spring
connections
Step 2
Remove as many knock-outs as required
and fit 20mm fire-rated glands. Install
the cable into the fire dome leaving
8”-10” of cable within the fire dome.

3 INSTALLATION MANUAL (25-13288-B) June 2020 www.eaton.com
Step 3
Loosen the thumb screws inside the fire
dome and slide the retaining brackets
up. Tighten the thumb screws to hold
the brackets in place in place at the top
of their travel.
Step 4
Insert the fire dome into the hole cut
in the ceiling (dimensions shown in the
specification section of the manual).
Step 5
Loosen the thumb screws and slide the
brackets down until they are holding the
fire dome firmly to the ceiling. Tighten
the thumb screws.
Step 6
Terminate the cable into the contacts
and select the required tapping. Reinstall
the speaker grill into the fire dome.
Specifications
Model MC6-EN
Power Taps@100 6W, 3W, 1.5W, 0.75W, 0.38
Power Taps@70V 3W, 1.5W, 0.75W, 0.38W,
0.19W
Impedance COM/ 1.7K Ω/ 3.3K Ω/
6.7K Ω/ 13K/ 26K Ω
SPL (1W/1M) 92dB
Frequency
Response (-10dB) 120-18KHz
Cutout Size 207mm
Dimensions 230x126mm
Weight 1550 grams
Dimensions
