Eaton DeviceNet E50DNA User manual

111032 Rev --Cutler-Hammer
InstallationInstructionsfor
DeviceNet™ E50 Limit Switches
MODELS COVERED BYTHIS MANUAL
Catalog Number Description
E50DNA Solid State Switch Body
with 2-meter cable
E50DNAC Solid State Switch Body
with 5-pin DeviceNet
micro-connector
DESCRIPTION
General Information
• Network Media - DeviceNet
• Protocol - DeviceNet Rel 2.0
• Type - Group 2 Only Slave Device using Predefined
Master Slave Connection Set
• Bandwidth - 125, 250, 500 Kbaud
All E50 Limit Switches consist of two modular, interchange-
able plug-in components: operating head and a solid state
switch body. Operating heads (side rotary, top and side
push, and wobble stick) are mounted on top of the switch
body in any of four positions. All assembled limit switches are
rated NEMA 3, 3S, 4, 4X, 6, 6P and 13. Obtain renewal parts by
ordering the catalog number labeled on each of the two limit
switch components.
NEMA ICS 2-225 describes preferred installation recommenda-
tions which ensure greatest reliability and longest life expect-
ancy for Industrial Limit Switches.
INSTALLATION
WARNING
DO NOT INSTALL OR PERFORM MAINTENANCE ON THIS
DEVICE WHILE THE CONTROLLER IS ENERGIZED. DEATH OR
SEVERE PERSONAL INJURY CAN RESULT FROM CONTACT
WITH ENERGIZED EQUIPMENT. VERIFY THAT NO VOLTAGE IS
PRESENT BEFORE PROCEEDING WITH INSTALLATION OR
MAINTENANCE. Only qualified persons, as defined in the
National Electric Code, who are familiar with the installation,
maintenance and operation of this device and the equipment
onto which is to be installed, as well as applicable local, state
and national regulations and industry standards and
accepted practices regarding safety of personnel and the
equipment safety should be permitted to install, maintain or
operate this device. These instructions are provided only as
a general guide to such qualified persons and are not all-
inclusive. They do not cover every application or circum-
stances which may arise in the installation, maintenance or
operation of this equipment. Users are advised to comply
with all local, state and national regulations and industry
standards and accepted practices regarding safety of
personnel and the equipment safety.

111032 Rev --Page2
Effective 9/97
OPERATING HEAD POSITIONING
Heads can be mounted on the switch body in any of four
directions, 90° apart. Torque screws according to require-
ments on page 1.
OPERATING HEADS — SIDE ROTARY
The operating mode (CW, CCW or CW and CCW) of these
spring return operating heads is easily changed without
tools as shown in the illustration. Remove the head from
switch body. Pull out the plunger and turn until its position
matches that shown on the diagram for the desired opera-
tion mode. Levers are adjustable to any angle (360°). The
operating shaft screwdriver slot can be used to maintain
shaft position during lever installation.
Side Rotary Operational Head
Bottom View of Side Operated
Rotary Head (Note Mode Change
Instructions in Head)
Set Operating Head Mode
Before Assembly
Push Operational Head
OPERATING HEADS — WOBBLE STICK
These spring return, top operated heads use different rod-
type operators to detect motion in any direction perpendicu-
lar to the operator. The operator screws onto the threaded
head stub.
TORQUE REQUIREMENTS FOR LIMIT SWITCH ASSEMBLY
Tighten the operating head screws to a torque value within the
following ranges to ensure and maintain the Enclosure Type
Ratings for the assembled limit switch.
Operating Head Screws — Tighten to ensure contact of head
to switch body: 14 - 18 lb. in.
OPERATING HEADS — PUSH OPERATED
These spring return top push or side push operating heads
are available in pushbutton and roller styles.
The push roller style can be converted from vertical to
horizontal operation or vice versa. Pull roller out of the head
until it can be rotated 90° to the desired orientation. When
released, it will snap into the set position.
The Maintained Contact head has the reset pushbutton
located opposite of the actuator pushbutton.

111032 Rev -- Page3
Effective 9/97
REPEAT ACCURACY
The type of operating head used on an assembled limit
switch determines repeat accuracy for the switch assembly.
Assembled limit switches, without rollers used on operating
heads or levers, have a repeat accuracy as listed in Table 1
only.
Assembled limit switches with rollers used on operating
heads or levers have a repeat accuracy determined as
follows: add the repeat accuracy tolerance of Table 1 for the
type of operating head used to the concentricity tolerance of
Table 2 for the type of roller used on the lever or operator.
The combination of these two tolerances is the limit switch
repeat accuracy.
Operating Data —Nominal Operating
Travel To Travel To Force To Minimum Temp. Catalog
Operate Reset Total Operate Return Range No.
Contacts Contacts Travel Contacts Force (See Table)
5° 2° 90° 3 in.-lbs. 4.5 in.-oz. A E50DR1
5° 2° 90° 3 in.-lbs. 4.5 in.-oz. D E50DR19
15° 6° 90° 1.5 in.-lbs. 2.5 in.-oz. A E50DL1
50° 50° 90° 3 in.-lbs. — B E50DM1
0.065 in. 0.030 in. 0.290 in. 4 lbs. 8 oz. B E50DS1
0.065 in. 0.030 in. 0.290 in. 4 lbs. 8 oz. B E50DS2
0.065 in. 0.030 in. 0.290 in. 4 lbs. 8 oz. B E50DS3
0.200 in. 0.130 in. 0.320 in. 5 lbs. 5 lbs. B E50DH1
0.040 in. 0.020 in. 0.280 in. 4 lbs. 8 oz. C E50DT1
0.040 in. 0.020 in. 0.280 in. 4 lbs. 8 oz. C E50DT2
0.040 in. 0.020 in. 0.280 in. 4 lbs. 8 oz. C E50DT3
10° 6° 15° 2 in.-lbs. 2.4 in.-oz. C E50DW1
10° 6° 15° 2 in.-lbs. 2.4 in.-oz. C E50DW2
Standard
Spring Return
Low Temperature
Spring Return
Low Force
Spring Return
Maintained
Two position
Pushbutton
Spring Return
Pushbutton Adjustable
Spring Return
Push Roller
Spring Return
Pushbutton
Maintained
Pushbutton
Spring Return
Pushbutton Adjustable
Spring Return
Push Roller
Spring Return
Standard
Spring Duty
Return Heavy
Duty
Description
Operating Heads
Side Rotary
Side Push
Top Push
Wobble Head
OPERATING HEAD DATA
TABLE 1 Operating Head Repeat Accuracy 1
Side Operated Standard Construction within 0.0012”
Low Operating Force within 0.0024”
Two-Step within 0.006”
Neutral Position within 0.006”
Side Push within 0.003”
Top Operated Top Push within 0.002”
1Measured along arc for 1-1/2” lever or measured along push operator axis.
TABLE 2
Type Diameter Width Concentricity Tolerance
Lever Roller Type Nylon 3/4” 5/16” +/-0.002”
Metal 3/4” 5/16” +/-0.001”
Nylon 3/4” 1” +/-0.005”
BallBrg. 11/16” 1/4” +/-0.002”
Nylon 1-1/2” 9/32 +/-0.005”
Push Roller Type Metal 7/16” 5/32” +/-0.002”
Metal 3/4” 5/32” +/-0.005”

111032 Rev --Page4
Effective 9/97
DEVICE CONFIGURATION
Before using the E50 limit switch, you must configure the
device’s baud rate and network address. The baud rate
defaults to 125 kbaud, and the address defaults to 63.
Additional parameters you may wish to configure include the
on, off, and one-shot delay, and the operate mode. After
connecting the device to the network, use NetView or
another configuration tool to configure device.
Network Address
After connecting the E50 to the network, use the Netview
configuration software (or other configuration software) to
configure the device. Unless pre-configured, a new device
will have a default address of 63 at a baud rate of 125 Kbaud
when connected to the network.
CAUTION
Since all new DeviceNet devices are factory set to address
63, it is usually not a good idea to leave an address set at
63. Two nodes at the same address will cause a network
fault!
Built into the Cutler-Hammer Netview configuration software
is a function to locate nodes by continually flashing the
Module/Network Status LED between green and red. Once the
Netview configuration software is communicating to the E50,
the address and all other user configurable parameters can then
be programmed. (See the Netview manual for specific informa-
tion on how to change attributes.) A list of configurable
attributes can be found on page 5 of this manual.
Off-line Configuration
An E50 switch may be configured off-line by connecting it
directly to the configuration tool (PC with software or a
hand-held type tool) and following the instructions for on-
line configuration. 24 VDC must still be supplied to the
switch in order to configure it off-line.
WIRING CONSIDERATIONS
ATTENTION
THE DEVICENET CABLE IS NEC (UL)TYPE CL2
RATED. THE CABLE IS NOT SUITABLE FOR USE IN
ENVIRONMENTS REQUIRING RESISTANCE TO
CERTAIN OILS AND CUTTING FLUIDS. PLEASE
CONSULT FACTORY FOR CABLING OPTIONS FOR
THESE APPLICATIONS.
Red
Blue
Bare
ConnectorVersion-FaceView Male
CableVersion
DeviceNet
Sensor Black
V+
4
2
31
5
V– Drain
CAN_H
CAN_L
V+
V–
Drain
CAN_H
CAN_L
White

111032 Rev -- Page5
Effective 9/97
SPECIFICATIONS
Material of Construction
Zinc Die-Cast Alloy
Enclosure Ratings
IP67
NEMA 3, 3S, 4, 4X, 6, 6P, and 13
Operating Temperature Range
-25° to 70° C (-13° to 158° F)
Storage Temperature Range
-40° to 150° C (-40° to 302° F)
Operating Humidity
<95% RH, non-condensing
LED DEFINITIONS AND DIAGNOSTICS
The E50 includes three LED status indicators: Switch state
indication, MAC ID, and network/module status indication. LED Status
MODULE/NETWORKSTATUSLED
OFF Deviceis neither on-linenor faulted
- Device has not yet completed the Dup_MAC_ID test
- Device may not be powered
Solid Deviceisoperatingproperly and properly allocatedbya
Green master.
Flashing Deviceis operating properly and on-linebut not allocated
Green byamaster.
Flashing Devicehasdetectedarecoverablefaultoraconnection
Red isin thetimed-outstate.
Solid Devicehas detectedanunrecoverablefaultorisinthe
Red communicationsfaultedstate.
Flashing Device is faulted and visibly identifying itself.
Green/Red
Alternately
MAC ID LED
Flashing The number of blinks is the ten’s digit of the
Red deviceMACID.
Flashing The number of blinks is the one’s digit of the
Green deviceMACID.
SWITCH STATE LED
Solid Red Switchmechanismis actuated
OFF Switchmechanismis not actuated
Operating Voltage
11 to 24 Vdc
Minimum Operational Current
33 mA @ 25 Vdc
Maximum Operational Current
120 mA @ 11 Vdc
Maximum Inrush Current
305 mA @ 25 Vdc
Electromagnetic Compatibility Compliance
Immunity
ESD per IEC 1000-4-2: +/- 8 KV
RFI per IEC 1000-4-3: 50 V/m
EFT per IEC 1000-4-4: 2 kV
Module/Network Status LED
MAC ID LED
Switch State LED

111032 Rev --Page6
Effective 9/97
APPROXIMATE DIMENSIONS Shown in mm (inches)
Top Push Operators
Top Push Roller
Limit Switch with Side Rotary Operator
Top Pushbutton
Side Push Operators
Top Pushbutton Adjustable
Side Pushbutton Maintained
Top Pushbutton Adjustable
Side Pushbutton
Side Push Roller
(1)
(1)
(1)Can accommodate both
U.S. 29.4 (1.16) x 59.5
(2.34) and DIN, 30
(1.18) x 60 (2.36)
mounting operations
CABLE ENTRANCE
[10-32] TAP, 9.65 [0.38] DEEP
2 HOLES FOR REAR MOUNTING

111032 Rev -- Page7
Effective 9/97
APPENDIX: ELECTRONIC DATA SHEETS
(Programming Information)
Connection Object - Class 5 (05HEX), Instances 1, 2 and 3
This device supports Explicit Messaging (Instance 1), I/O Poll
(Instance 2), and I/O Bit Strobe (Instance 3).
DeviceNetObject - Class3(03HEX),Instance 1
Attribute Attribute ID Access
MAC ID (0..63) 1 Get/Set
Baud Rate 2 Get/Set
(0=125K, 1=250K, 2=500K)
Bus-Off Interrupt 3 Get/Set
Bus-Off Counter 4 Get/Set
Allocation Information 5 Get
Bus-Off Separation 100 Get/Set
If Bus-Off Interrupt is true, the device automatically attempts to
recoverfrom abus-off conditionif itis on-lineand hasn’tbeen bus-off
sincepower-up,orifithassentandreceivedatleast Bus-OffSeparation
messagessincethelastbus-offcondition.
Presence Sensing Object - Class 14 (0EHEX), Instance 1
Attribute Attribute ID Access
Output (0..1) 1 Get
Diagnostic (0=OK, 1=fault) 4 Get
On Delay (0..65535 mS) 5 Get/Set
Off Delay (0..65535 mS) 6 Get/Set
One Shot Delay (0..65535 mS) 7 Get/Set
Operate Mode 8 Get/Set
(0=normally open, 1=normally closed)
Switch State (0=nonactuated, 1=actuated) 100 Get
Head Actuation Count 101 Get/Set
Maximum Head Actuation Count 102 Get/Set
Service Service ID
Diagnose Nonactuated Switch 50
Output takes into account the On Delay , Off Delay , One Shot Delay ,
and
Operate Mode . Switch state represents the physical location of
the limit switch.
Head Actuation Count increments each time the head is actuated.
When
Head Actuation Count reaches 80% or 100% of the Max Head
Actuation Count
, a fault is added to the diagnostic object. Maximum
head actuation count is based on Mean Time Between Failure (MTBF)
data and therefore statistically some units could potentially fail earlier
than that, as well as operate well past that number.
The
Diagnose Nonactuated Switch service causes the device to
perform a self diagnostic on its sensing circuitry. The test is only
valid if the limit switch is in the nonactuated position. Running this
test is the only way to clear the
Diagnostic bit.
Assembly Object Data - Class 4 (04HEX), Instance 1
Attribute Attribute ID Access
Data 3 Get
Use Assembly Object Data to read diagnostic and output status. Data
bit 0 is output status, which is obtained from Attribute 1 of the
Presence Sensing Object. Data bit 1 is diagnostic status, which is
obtained from Attribute 4 of the Presence Sensing Object. The
remaining bits (2..7) are 0.
The I/O Poll and I/O Bit Strobe connections consume 0 bytes and
product 1 byte. The one produced byte is
Data .
Identity Object - Class 1 (01HEX), Instance 1
Attribute Attribute ID Access
Vendor (68) 1 Get
Device Type (4) 2 Get
Product Code (50) 3 Get
Revision 4 Get
Status 5 Get
Serial Number 6 Get
Product Name (“E50”) 7 Get
State 8 Get
Message Router Object - Class 2 (02HEX), Instance 1
Attribute Attribute ID Access
Object List 1 Get

Effective 9/97
Printed in U.S.A.
111032 Rev --
Cutler-Hammer
720 80th Street SW
Everett, WA 98203-6299
www.cutlerhammer.eaton.com
Page8
APPENDIX: ELECTRONIC DATA SHEETS (Continued)
Diagnostic Object - Class 198 (C6HEX), Instance 1
Attribute Attribute ID Access
Number of Faults 1 Get
Fault List 2 Get
Overwrite (0 = preserve oldest faults) 3 Get/Set
(1 = preserve newest faults)
Timestamp (0..65535) 4 Get/Set
Resolution (0..65535 mS) 5 Get/Set
Maximum Number of Faults (8) 6 Get
The Fault List is accessible via the Get Member service. Each
member has the following structure:
Parameter Data Type
Class UINT
Instance UINT
Error Code USINT
Additional Error Code USINT
Status UINT
Timestamp UINT
Test Object - Class 199 (C7HEX), Instance 1
Attribute Attribute ID Access
Power OK 5 Get
LED Disable 6 Get/Set
SOFTWARE TIMING
The E50 is not capable of responding to all DeviceNet messages at all
baud rates if multiple messages are sent in rapid succession. For
best results, a master should wait for a response to a previous
request before sensing a subsequent request.
HARDWARESPECIFICATIONS
DeviceNet Wiring Connections
V+ Power Operating range: 11..27 V
Protected range: -30..30 V referenced against V-
V- Common
CH CAN high Protected range: -30..30 V referenced against V-
CL CAN low Protected range: -30..30 V referenced against V-
DDrain
Still Need Help?
Contact Cutler-Hammer Advanced Product Support
Phone: [phone]
Select 2 for Sensor and Application Assistance
Select 6 for DeviceNet Communication and Configuration Assistance
