Eaton MEM Memera User manual

MEM姞Memera
Consumer unit
Important notes
1. This product should be installed, commissioned and maintained by or under the supervision of a competent electrician
in accordance with current electrical engineering Codes of Practice, Regulations for the Electrical equipment of
Buildings (BS7671), HSG224 – Construction (Design and Management) Regulations 1994, HSG150 – Health and
Safety in Construction, Statutory requirements and any Specific instruction issued by the Company.
2. After completing the installation and testing of this product it is essential that this leaflet is drawn to the attention of
the person responsible for its future operation and maintenance, and is at all times available for ready reference.
3. These notes assume throughout that the product is disconnected from the supply.
It is essential that this is done before any work is carried out.
1. This Consumer Unit must be installed by a competent person in accordance with BS7671 IEE Regulations for
electrical Installations with the requirements of all relevant legislation, and Accepted practices in the industry.
2. The total current supplied by the Consumer Unit must not exceed the rating of the incoming
main switch, RCD or any additional limitations (as shown on the Way Labels).
3. This board is suitable for indoor use only and is rated at IP40.
4. Ambient Temperature Conditions:
The MCB’s are calibrated to meet 35°C according to requirements laid down in IEC/EN60898. For other
temperatures the following rating factor should be used: 60°C - 0.85, 20°C - 1.0, 0°C - 1.1
5. All components used in the EATON MEMERA CONSUMER UNIT must be supplied by or approved by EATON. The use of any
other components within the EATON MEMERA CONSUMER UNIT will negate any warranty issued by EATON ELECTRIC LTD.
6. The consumer unit and appropriate devices have been type tested to the following specifications:
MCB’s IEC/EN 60898
RCCD’s IEC/EN 61008-1
RCBO’s IEC/EN 61009-1
Main Switch IEC/EN 60947-3
Consumer Unit IEC/EN 60493-3

Eaton Electric Limited
Reddings Lane
Birmingham B11 3EZ
United Kingdom
Customer Support Centre
UK tel: [phone]
UK fax: [phone]
email: [email protected]
www.eaton.com
© 2009 Eaton Corporation
All Rights Reserved
Printed in UK
Form No. IL01900001U
March 2009
PowerChain Management is a registered
trademark of Eaton Corporation.
All other trademarks are property of their
respective owners.
Remove the main outer cover from the
EATON MEMERA CONSUMER UNIT
1. Remove the Busbar from the transit holder.
2. Fix the back plate to the wall using the keyhole Fixings
CAUTION: DO NOT BEND & RE-STRAIGHTEN THE BUSBAR
When fitting the Busbar into the isolator ensure that the flexible
live connector is fitted beneath the busbar in the box clamp.
Fit the busbar Shield into the base and
over the unprotected Busbar.
Fit the busbar Shield into the base and
over the unprotected Busbar.
Remove the appropriate “Knockouts” for cable entry.
Cut the Busbar to the desired length (number of ways
plus one tongue) the raised “Dog leg portion of the
busbar must be fitted to the Main Switch. Ensure the full
portion between tongues is removed and discarded.
CABLE CAPACITY AND TORQUE SETTINGS
CABLE CAPACITY
ISOLATOR 2.5Nm 50mm2
RCD/RCBO 2.5Nm 25mm2
OTHERS 2.0Nm 25mm2
Fit the Busbar/s: Ensure all terminals are fully open before installing
the busbar, tighten all connections to the specified torques.
Apply the Instruction Label & RCD resetting instructions
(where applicable) to the inside of the door.
Affix the required main circuit identification labels
& Sub circuit identification for RCD protected
circuits, for split loads cut as required.
Warning – Intellectual Property Rights
Eaton wishes to make it clear that it owns intellectual property rights in the product
which it manufactures (whether or not listed in this leaflet) and that it will take legal
action against any party found to be manufacturing, using, or selling any article which
infringes the company’s intellectual property. All marks in this document identified
with an R symbol or a TM symbol adjacent to the mark are trademarks of Eaton.
The use to which this product is put and its place of installation is outside our control.
Particular care should therefore be taken to follow the instructions given here and
to ensure their continued availability in conjunction with the use of the product.
No responsibility can be accepted by us if these instructions are disregarded. Further
copies of these instructions and information concerning the installation and proper use
of this product can be obtained by contacting the: Technical Services Department
