KT TESTER
Handle Test Kit for Trip
Unit(PXR4.1,PXR6.1)
Instruction Manual

KT TESTER
1 / 8
Table of Contents
Section 1: Production profiles ................................................................... 2
Section 2: Production composition
.............................................................. 2
Section 3: Operating parameters ........................................................... 3
3.1 Parameters of Adapter ................................................................................ 3
3.2 Parameters of Tester ................................................................................... 3
Section 4: Operating instructions ............................................................. 3
4.1 Panel layout ................................................................................................. 4
4.2 Tester connection ...................................................................................... 4
4.2.1 Test connection with the individual trip unit ...................................................4
4.2.2 Test connection with the circuit breaker ....................................................... 5
4.3 Operating steps ......................................................................................... 5
Section 5: Precautions for use ................................................................ 9

KT TESTER
2 / 8
Section 1: Product profiles
 KT TESTER tester is applied to the current type protection test of the trip unit;
 KT TESTER can be used for the characteristic test of the trip unit and the circuit breaker;
 KT TESTER has its own lithium battery, which can be directly powered by the battery
during the test;
 KT TESTER generates the AC voltage signal that simulates the output of CT(current
transformer), and loads it to the test port of the trip unit. Through the setting of the AC
voltage signal amplitude, it can test different current protections.
Section 2: Product composition
Figure 1 Product composition
① Power adapter for charging the battery inside the tester
② Tester
③ Test cable for connection between KT TESTER and the trip unit

KT TESTER
3 / 8
Section 3: Operating parameters
3.1 Parameters of Adapter
Input voltage: AC100V~240V
Frequency: 50/60Hz
Output voltage: DC25.2V
Working temperature: -5~40℃
Storage temperature: -20~50℃
3.2 Parameters of Tester
Size of KT TESTER: L：205mm,W：137mm,H：70mm
When using the tester, the parameter values in Table 1 must be within the normal
operating range。
Table 1 Working parameters of tester
NO. Name Signal
Range Unit Note
Min. Max.
1
Voltage of
Power
supply
Vcc 21 28 V
2
Current of Power
supply
Icc - 1 A
3
Power output
voltage
（
DC24V
）
Pout 22 26 V
4 Voltage of output signal V0 20 5000 mV
5 Frequency of output
signal f 49.95
50.05 Hz
6 Duration of battery
power supply tr 5 6 h
7 Charging time of
battery power supply
tc 1 - - h
8 Battery capacity Cb 2 - -
Ah@DC24
V
9 Charging operating
temperature TC 0 45 ℃
10 Discharge operating
temperature Tw -10 50 ℃
11 Storage temperature TS -20 50 ℃
Section 4: Operating instructions

KT TESTER
4 / 8
4.1 Panel layout
Figure 2 Panel layout
4.2 Tester connection
4.2.1 Test connection with the individual
trip
unit
When testing the action characteristics of the trip unit separately, connect the test
terminal of KT TESTER(Figure 4) to the programming test port of the trip unit(Figure 3), and
pay attention to the direction of the test terminal . Connect the "4 , 5" cables of KT TESTER
(Figure 5) with the "4 , 5" out cables from the trip unit for detecting the tripping time (It can
not be connected without measuring the tripping time).
1.
Test cable connection port(
DB25
)
；
2. Charging adapter input interface
；
3. Power switch
；
4. LCD
；
5. “WORK”light:it is on if the tester works
normally
；
6. “TEST”light:it flickers during the test
；
7. Keys
：
-“SET”key for entering the setting
interface
；
-“START”key for starting the test
；
-“STOP”key for stopping the test
；
-“
↑
”
、
“
↓
”
、
“EXIT”
、
“ENTER”4 keys for
menu operation and parameter setting
；

KT TESTER
5 / 8
4.2.2 Test connection with the circuit breaker
When testing the circuit breaker, connect the test terminal of KT TESTER to the
programming test port of the trip unit, and pay attention to the direction of the test terminal.
Connect the "4 and 5" cables of KT TESTER to the "4 and 5" of the secondary terminal of the
circuit breaker for detecting the tripping time (It can be disconnected without measuring the
tripping time).
4.3 Operating steps
NO.
Steps
D
iagram
s
1
Turn on the power and enter the default interface.
Note: 1) When there is no operation for a long time,
KT TESTER will automatically turn off the power
supply of the trip unit to avoid battery power loss.
and then press any key, KT TESTER will automatically
turn on.
2) KT TESTER will not turn off the power supply of
the trip unit during the test.
Figure4 Test port
Connect the socket boss
upward
Figure3
test terminal
Figure5
“
4
，
5
”
cables

KT TESTER
6 / 8
2
Press the "SET" key to enter the main test menu.
Other keys are invalid.
3
Press the "ENTER" key to enter the parameter
setting and test interface, and the steps are as
shown in 4-7.
4
1
、
SET RATIO OF CT
：
1) Move to this column through "
↑
" and "
↓
";
2)Press the "ENTER" key to enter the parameter
setting state. At this time, the "=" on the left side
of the column will change to "
→
", and then adjust
the parameter to the corresponding value
through "
↑
" and "
↓
" (See Table 2);
3)Press "ENTER" to confirm the setting and exit,
or press "EXIT" to cancel the setting and exit;
5
2
、
SELECT TEST PHASE
：
1) Move to this column through "
↑
" and "
↓
";
2) Press the "ENTER" key to enter the parameter
setting state. At this time, the "=" on the left side
of the column will change to "
→
", and the
n adjust
the parameter to the corresponding value
through "
↑
" and "
↓
" (Cycle display A, B, C, N );
3)Press "ENTER" to confirm the setting and exit,
or press "EXIT" to cancel the setting and exit;
This
symbol
represe
nts the
current
selectio

KT TESTER
7 / 8
6
3
、
SET TEST CURRENT
：
1) Move to this column through "
↑
" and "
↓
";
2) Press the "ENTER" key to enter the parameter
setting state. At this time, the "=" on the left side
of the column will change to "
→
", and then adjust
the parameter to the corresponding value
through "
↑
" and "
↓
" (See Table 3);
3)Press "ENTER" to confirm the setting and exit,
or press "EXIT" to cancel the setting and exit;
7
4
、
TEST
：
1) Press the "START" key to test. At this time, the
test status will change to "Testing", the test time
will automatically start to count, and the "TEST"
light will enter the flashing state;
2) If the "4 ,5" cables are connected, KT TESTER
will monitor whether the trip unit trips during the
test, automatically stop after capturing the trip
signal, and display the time; If the "4 ,5" cables
are not connected, the tester will always be in
the test status, and the time will continue to
count until the "STOP" key is pressed to stop.
3)During the test, press the "STOP" key to
manually stop, the test status changes to "Stop",
and the time stops counting.
Note: The trip time in the test is only for
reference, because it includes the status-
switch feedback, mechanical action time
and software judgment time(longer than
real time).
8
1) After this test, you can repeat steps 4
-
7 and
test again;
2)When the tests are completed, turn off the
power switch.
Table 2 Ratio of CT
Type Rated Current Ratio of CT

KT TESTER
8 / 8
IZM6
400~2000A 1000A:0.1V
2500~4000A 1000A:0.067V
IZM6 4000~6300A 1000A:0.05V
Table 3 Input current value for test
Protection Input current value Action result Display
accuracy
Long time
Test
1.5 x Ir (Current setting of Long
time)
Trip after delaying
the setting time(tr) ±5%
Short time
Test
1.1 x Isd (Current setting of Short
time)
Trip after delaying
the setting
time(tsd)
±10%
Instantaneo
us Test
1.2 x Ii (Current setting of
Instantaneous) Trip ±20%
Earth-fault
Test
1.1 x Ig (Current setting of Earth-
fault)
Trip after delaying
the setting time(tg) ±10%
Note: 1) Because the setting value of the grounding protection is small and the delay time is
short, the grounding setting needs to be turned off when testing Long time, Short time,
instantaneous. Otherwise, the grounding protection may have priority action.
2) During the grounding test, the analog signal can be tested at any of the three
phases A, B and C.
Example：In=2500A，Ir=2500A， Isd=7500A，Ii=15000A ,Ig=OFF. The steps for testing
instantaneous protection are as follows：

KT TESTER
9 / 8
Section 5: Precautions for use
 After the tests, please turn off the power supply of the tester in order to avoid battery
power loss.
 There are lithium batteries inside. Please use them under specified conditions to avoid
safety problems such as overheating, explosion, fire, etc;
 When scrapping, please pay attention to the recycling of batteries to avoid polluting the
environment;
