Eaton 93PM UPS (208–480V) Seismic (OSHPD) Door Retention Kit Insta Instructions P-164000883—Rev 01 1
EEaattoonn 9933PPMM UUPPSS ((220088––448800VV)) SSeeiissmmiicc ((OOSSHHPPDD)) DDoooorr RReetteennttiioonn KKiitt IInnssttaa IInnssttrruuccttiioonnss
Use these instructions to install the seismic door retention kit brackets to secure the uninterruptible power
supply (UPS) door. One kit is required per UPS door.
These instructions are applicable to all UPS frame sizes for the following models
• Eaton 93PM-L UPS (208V)
• Eaton 93PM UPS (480V)
NOTE 1 This kit is used to support seismic installations where applicable.
NOTE 2 Refer to the installation and operation manual supplied with the UPS for dimensions and
required clearances.
Seismic Door Retention Kit Contents Quantity
Bracket, 93PM Cabinet, OSHPD 1
Bracket, 93PM Door, OSHPD 1
Flange Hea Bolt, Black M5 X 12 2
NOTE See Figure 1 for door retention kit detai s.
!
IMPORTANT
For seismic installations, the UPS cabinet floor mounting surface must be level.
To install the brackets
1. Unload and mechanically install the UPS according to the instructions in the applicable installation and
operation manual.
2. Open the UPS door. Locate the horizontal slot on the top rear of the door. See Figure 2 for the bracket
horizontal slot location.
3. Remove the two M4 screws directly beneath the opening. See Figure 2 for the screw location.
4. Install the door bracket and secure with two M4 screws previously removed. Hand tighten the screws.
5. Install the cabinet bracket using the two M5 thread forming screws included in the kit. Hand tighten the
screws. See Figure 3 for cabinet bracket mounting location and Figure 4 bracket installation details.
6. Both brackets have slots for adjusting bracket position. Adjust brackets so the spring-loaded fastener on
the cabinet bracket aligns with the threaded insert of the door bracket.
7. Once the brackets are properly aligned, secure the brackets by tightening the screws to the following
torque specifications.
Door bracket M4 screws 2.0–3.3 Nm, or 18–29 in- bs.
Cabinet bracket M5 screws 4.1–6.6 Nm, or 36–58 in- bs.
8. Close and secure the UPS door.

2 Eaton 93PM UPS (208–480V) Seismic (OSHPD) Door Retention Kit Insta Instructions P-164000883—Rev 01
RReeffeerreennccee IImmaaggeess
Figure 1. Seismic Door Retention Kit Bracket Details
NOTE Slots in door bracket allow for horizontal adjustment.
NOTE Slots in cabinet bracket allow for adjustment in the depth direction.
Door Bracket
Cabinet Bracket
NOTE 1 The Seismic Door Retention kit is designed for use with all Eaton 93PM UPS (480V) and
Eaton 93PM-L UPS (208V) models.
NOTE 2 One kit is required per UPS door.

Eaton 93PM UPS (208–480V) Seismic (OSHPD) Door Retention Kit Insta Instructions P-164000883—Rev 01 3
Figure 2. Seismic Door Bracket Install Location and Details
Remove these
screws to install
the door bracket.
Top Inside View of Door
Install the door bracket
and secure with screws
previously removed.
NOTE The interior of the UPS door is identical for the Eaton 93PM-L UPS (208V) and Eaton 93PM UPS (480V) models.
Door bracket
horizontal slot
location

4 Eaton 93PM UPS (208–480V) Seismic (OSHPD) Door Retention Kit Insta Instructions P-164000883—Rev 01
Figure 3. Seismic Cabinet Bracket Install Location
Holes used to mount
the cabinet bracket.
Holes used to mount
the cabinet bracket.
Eaton 93PM-L (208V) UPS
Eaton 93PM (480V) UPS
NOTE For clarity, the UPS door is not shown.
NOTE For clarity, the UPS door is not shown.

Eaton 93PM UPS (208–480V) Seismic (OSHPD) Door Retention Kit Insta Instructions P-164000883—Rev 01 5
Figure 4. Seismic Cabinet Bracket Install Details
Eaton 93PM-L (208V) UPS
Eaton 93PM (480V) UPS
Cabinet bracket installed
(bolts provided in kit).
Cabinet bracket installed
(bolts provided in kit).
NOTE For clarity, the UPS door is not shown.
NOTE For clarity, the UPS door is not shown.

6 Eaton 93PM UPS (208–480V) Seismic (OSHPD) Door Retention Kit Insta Instructions P-164000883—Rev 01
FFoorr MMoorree IInnffoorrmmaattiioonn
Refer to the following manuals for the information listed below
•Eaton 93PM–L UPS (20–60 kW, 208V) Installation and Ope ation Manual
•Eaton 93PM–L UPS (20–120 kW, 208V) Installation and Ope ation Manual
•Eaton 93PM–L UPS (20–160 kW, 208V) Installation and Ope ation Manual
•Eaton 93PM–L UPS (20–200 kW, 208V) Installation and Ope ation Manual
•Eaton 93PM UPS 480V Th ee-Wi e – 50 kW F ame Installation and Ope ation Manual
•Eaton 93PM UPS 400V/480V Fou -Wi e – 50 kW F ame Installation and Ope ation Manual
•Eaton 93PM UPS 480V Th ee-Wi e – 100 kW F ame Installation and Ope ation Manual
•Eaton 93PM UPS 400V/480V Fou -Wi e –100 kW F ame Installation and Ope ation Manual
•Eaton 93PM UPS 480V Th ee-Wi e 150 kW F ame Installation and Ope ation Manual
•Eaton 93PM UPS 400V/480V Fou -Wi e – 150 kW F ame Installation and Ope ation Manual
•Eaton 93PM UPS 480V Th ee-Wi e – 200 kW F ame Installation and Ope ation Manual
•Eaton 93PM UPS 400V/480V Fou -Wi e – 200 kW F ame Installation and Ope ation Manual
•Eaton 93PM UPS 480V Th ee-Wi e – 400 kW F ame Installation and Ope ation Manual
1. UPS, optional components, and accessory installation instructions, including site preparation, planning for
installation, and wiring and safety information. Detailed illustrations of cabinets and optional accessories
with dimensional and connection point drawings are provided.
2. UPS operation, including UPS controls, functions of the UPS, standard features and optional accessories,
procedures for starting and stopping the UPS, and information about maintenance and responding to
system events.
3. Communication capabilities of the UPS system.
Visit www.eaton.com/powerquality or contact an Eaton service representative for information on how to obtain
copies of these manuals.
