EAW CB423M User manual

CINEMA SERIES
One Main Street, Whitinsville, MA 01588 • [phone] • FAX [phone] • Email [email protected] • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# CB423M-888165 (A)/3/1/00 • Printed In USA
Technical Specifications CB423M
APPLICATION
• Approved for use in THX®-certified theaters
• For small to medium-sized theaters
• Triamplified 3-way screen channel loudspeaker
PRODUCT INFORMATION
The CB423M triamplified three-way full-range screen channel loud-
speaker system has been approved for use in THX-certified theaters.
Three-way design dramatically advances cinema audio quality by
improving the naturalness and intelligibility of dialog, eliminating
distortion from excessive driver excursion and extending pattern
control into the lower octaves.
The two component system includes a BV423 15-in low frequency
enclosure and an HK523M mid/high section.
The low frequency enclosure uses optimally tuned enclosure venting
to increase LF response while limiting driver excursion. This method
produces less distortion and minimizes driver strain while extending
LF response to the lowest octaves. The enclosure’s shallow dimen-
sion allows convenient placement behind the screen.
The HK523M MF/HF section features a horn-loaded 10-in cone and
a high power 1.4-in exit compression driver loaded with a 90°x
45°coverage pattern constant directivity horn.
The adjustable steel bracket attaching the MF/HF section to the LF
enclosure can be positioned at one of three mounting points for
optimum front/rear placement. The bracket allows the MF/HF
section to be aimed independently of the LF section in both the
horizontal and vertical planes and can be locked once it is posi-
tioned.
Input connectors for the LF and MF sections are two-terminal barrier
strips that accommodate bare wire, tinned leads or spade lugs. Bind
posts for the high frequency section are located directly on compres-
sion driver. The input panels are located on the side and top of the
enclosures for convenient access in cramped installation areas.
All external components feature a non-reflective, textured black
finish to eliminate the reflection of light through perforated cinema
screens.
THX is a registered trademark of Lucasfilm, Ltd.
997112 (0)
exp 3/1/00 js
CB423M
24.83
TOP
INPUT
INPUT
15.88
RIGHT SIDE
14.88 (POS 1)
22.20 (POS 3)
18.69 (POS 2)
25°
5.21
24.43
3.66
21.75
FRONT
51.66
HK523M
BV423
LEFT SIDE
BRACKET
EAW 606098
ACCESS
PANEL
BACK

CINEMA SERIES
One Main Street, Whitinsville, MA 01588 • [phone] • FAX [phone] • Email [email protected] • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# CB423M-888165 (A)/3/1/00 • Printed In USA
Technical Specifications CB423M
COMPONENTS & CONSTRUCTION
The CB423M is a THX-approved, triamplified three-way, high-
output, full range loudspeaker system intended for use in behind-
screen cinema applications. The two component system includes a
BV423 15-in low frequency enclosure and an HK523M mid/high
system.
The system requires the use of external active electronic crossovers
to integrate all sections.
The BV423 low frequency component features a 15-in woofer
mounted in a vented enclosure for excellent bass extension and high
output level capability.
The HK523M mid/high component features a horn-loaded 10-in
midrange driver and a 1.4-in exit compression driver mounted to a
medium format 90°x 45°constant directivity horn.
Two-terminal barrier strip input connectors that accommodate bare
wire, tinned leads or spade lugs are included for the low- and mid
frequency sections. Bind posts for the high frequency section are
located directly on compression driver.
The LF cabinet is constructed of 3/4-in Medium Density Fiberboard
(MDF). The HK523M mid/high section is constructed of 3/4-in MDF
with the exception of the mid frequency flare which is void-free, 18-
ply-to-the-inch, Baltic birch plywood backed with high density
polyurethane foam. Both enclosures are coated with a non-reflec-
tive, textured black finish and the HF horn is constructed of flat
black structural foam plastic.
DESCRIPTIVE DATA
LF Subsystem & Loading 1x 15-in, vented
MF Subsystem & Loading 1x 10-in, horn loaded
HF Subsystem & Loading 1x 1.4-in exit compression driver
on CD horn
Number of Audio Bands 3-way
Powering Mode Triamp
Recommended Crossover EAW CX300-CB423M or
THX® Specified Unit
Cabinet Type (shape) Rectangular
Enclosure Materials LF-3/4-in MDF; 15mm
Birch plywood baffle — MF/HF-MDF
Finish Textured Black
Connectors 2x 2-Termimal Barrier Strips (LF and MF)
plus 2x Bind Posts (HF)
NOMINAL DATA
Frequency Response (1 Watt @ 1m)
±3 dB 42 Hz - 19 kHz
Axial Sensitivity (dB SPL, 1 Watt @1m)
LF 98
MF 108
HF 112
Impedance (Ohms)
LF 8
MF 8
HF 12
Power Handling (Watts)
LF 500
MF 325
HF 200
Calculated Maximum Output (dB SPL @ 1m)
LF Peak 131.0
MF Peak 139.1
HF Peak 137.0
LF Long Term 125.0
MF Long Term 133.1
HF Long Term 131.0
Nominal Coverage Angle/-6 dB points (degrees)
Horizontal 90
Vertical 45
Dimensions & Weights Inches Centimeters
Height 51.66 1312
Width 24.83 631
Depth 22.20 564
Weights Pounds Kilograms
Net Weight (approx) 150 68.1
Shipping Weight (approx) 165 74.1
