EAW Cinema CB2592 User manual

CINEMA SERIES
One Main Street, Whitinsville, MA 01588 • [phone] • FAX [phone] • Email [email protected] • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# CB2592/11/17/98 • Printed In USA
Technical Specifications CB2592
APPLICATION
• For very large theaters
• Biamplified 2-way screen channel loudspeaker
PRODUCT INFORMATION
The CB2592 large format 2-way screen channel loudspeaker system
fills the largest theaters with all the high-impact, full-range sound
encoded on today’s digital soundtracks while reproducing voices
clearly and naturally.
The three component system includes two BV253C vented dual 15-
in low frequency units and EAW’s HK2591 high frequency system –
a large format 90°x 40°horn loading a large diaphragm 2-in exit
compression driver.
TheHK2591'slargeformatHFcinemahornensuresevendistribution
of HF information over the entire audience area.
The BV253C’s optimally vented enclosures use enclosure resonance
toincrease LFresponse whilelimiting driverexcursion. Thismethod
produceslessdistortionandminimizesdriverstrainwhileextending
LF response to the lowest octaves. Their shallow enclosure dimen-
sions allow convenient placement behind the screen.
Each LF enclosure has 3 mounting points to allow optimum front/
rear positioning of the HF component. The adjustable mounting
bracketattachingtheHFhorntotheLFenclosureallowstheHFhorn
to be aimed independently of the LF section in both the horizontal
and vertical planes and can be locked once it is positioned.
TheLFsectionincludesatwo-terminalbarrierstripthataccomodates
bare wire, tinned leads or spade lugs. The HF component uses heavy
duty spring-loaded push button type connectors. Input connectors
for the LF section are located on the side of the enclosure for
convenient access in cramped installation areas. HF input connec-
tors are directly on the compression driver.
All components feature a “dead” flat black finish to eliminate the
reflection of light through perforated cinema screens.
999440 (0)
exp 11/16/98
CB2592
28.91
FRONT
24.50
7.25
RIGHT SIDE
17.75
20°7.5°
1.50
13.13
2.25
5.25
16.36
111.25
INDICATES 3/8-16 THREADED MOUNTING HOLE
INDICATES 5/16-18 THREADED MOUNTING HOLE
INDICATES CENTER OF BALANCE

CINEMA SERIES
One Main Street, Whitinsville, MA 01588 • [phone] • FAX [phone] • Email [email protected] • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# CB2592/11/17/98 • Printed In USA
Technical Specifications CB2592
COMPONENTS & CONSTRUCTION
The CB2592 is a biamplified, high output, two-way, full range
loudspeaker system intended for use in cinema applications. It
features 4x 15-in low frequency transducers mounted in two com-
pact, vented enclosures and a 2-in exit titanium diaphragm com-
pression driver mounted to a large format 90°x 40°constant
directivity horn.
The CB2592 requires an external active electronic crossover. The
recommended crossover point is 500 Hz.
The low frequency enclosure is constructed of 3/4-in thick Medium
Density Fiberboard (MDF) with the exception of the baffle which is
15mmvoid-free,cross-grain-laminatedBalticbirchplywood.Exten-
sive internal bracing is employed to minimize panel resonances
resulting from the large acoustical energies generated within the
enclosures.
The high frequency horn is constructed from a specially dampened
fiberglass which is non-resonant, lightweight and non-reflective.
TheLFsectionincludesatwo-terminalbarrierstripthataccomodates
bare wire, tinned leads or spade lugs. The HF component uses heavy
duty spring-loaded push button type connectors. Input connectors
for the LF sections are located on the side of the enclosure for
convenient access in cramped installation areas. HF input connec-
tors are directly on the compression driver.
The adjustable mounting bracket attaching the HF horn to the LF
enclosure can be positioned at one of three mounting points for
optimum HF horn placement. It allows the HF horn to be aimed
independently of the LF section in both the horizontal and vertical
planes and can be locked once it is positioned.
DESCRIPTIVE DATA
Part Number 999440
LF Subsystem & Loading 4x 15-in, vented
HF Subsystem & Loading 1x 2-in exit compression driver on large
format CD horn
Number of Audio Bands 2-way
Type of Audio Bands Full Range
Powering Mode Biamplified
System Crossover Active (500 Hz at 24 dB/oct minimum)
Recommended High-Pass
Frequency (24 dB/Octave) 30 Hz
Cabinet Type (shape) Rectangular LF cabinet (x2) with
externally mounted HF horn/driver
Enclosure Materials 3/4-in MDF with 15mm Baltic birch
plywood baffle
Finish Flat Black
Connectors LF- 2 terminal barrier strip (x2); HF -
spring-loaded pushbutton (accepts bare
wire)
NOMINAL DATA
Frequency Response (1 Watt @ 1m)
±3 dB 42 Hz -18 kHz
Axial Sensitivity (dB SPL, 1 Watt @ 1m)
LF 103
HF 111
Impedance (Ohms) LF 2x 4 Ohms
HF 12
Power Handling, AES Standard (Watts)
LF 2000
HF 100
Calculated Maximum Output (dB SPL @ 1m)
LF Peak 142.0
HF Peak 137.0
LF Long Term 136.0
HF Long Term 131.0
Nominal Coverage Angle/-6 dB points (degrees)
Horizontal 90
Vertical 40
Recommended Complementary Systems
Sub SB184C, SB185C, SB284C
Dimensions Inches Centimeters
Height 112.44 285.6
Width 29.00 73.7
Depth 34.19 86.8
Weights Pounds Kilograms
Net Weight 343.5 156.3
Shipping Weight 391.5 178.1
